150–300mm Hochpräzise Digital-Messschraube, 0,004mm, Touchscreen, ISO17025 Kalibrierzertifikat - Microtech Metrology
€949.00
Product information "150–300mm Hochpräzise Digital-Messschraube, 0,004mm, Touchscreen, ISO17025 Kalibrierzertifikat - Microtech Metrology"
Micrometer — Wide-range micrometer with interchangeable anvils by Microtech Metrology
The Micrometer is a wide-range, computerized micrometer designed for sub-micron precision measurement across workshop and production environments.
- Wide measuring range 150–300 mm
- 2.4" colour touchscreen display
- Wireless+USB data transfer options
- ISO 17025 calibration certificate included
- Interchangeable anvils and setting rods included
Precision and range that adapt to varied parts
This wide-range micrometer delivers a sub-micron capable workflow with a measuring span of 150–300 mm, making it suitable for medium to large components where a single instrument must cover multiple sizes. The instrument features an ultra-fine resolution of 0.0001 mm and a declared accuracy of 0.004 mm, which supports reproducible dimensional checks during both serial inspection and individual part setup. Interchangeable anvils and setting rods extend versatility by allowing quick adaptation to different geometries without sacrificing stability.
Seamless data handling for Industry 4.0 integration
Equipped with the MICS computerized operating environment and a colour 2.4" touchscreen, the device provides intuitive on-board operations such as graphical online display, Go/NoGo checks, Max/Min, formula functions and linear/temperature compensation. Data transfer supports WIRELESS to MDS app, WIRELESS HID, WIRELESS HID+MAC and USB HID, plus memory management for 2000 values with folders and statistics. Microtech’s wireless approach simplifies connectivity compared with the U-WAVE technology of Mitutoyo: a single dongle receives data to a PC and direct transfers to iPhone, iPad and Android devices are possible from the tool itself.
Robust construction and repeatable measurement control
The housing is CNC-machined from solid aluminium block for improved stiffness and handling, reducing the risk of deflection during longer measurements. A manually adjustable measurement force control ensures that the same measuring pressure is applied in every operation; the instrument records values only when the preset force is reached, which increases repeatability across operators and materials. The combination of solid mechanical design and electronic compensation supports reliable results in demanding shop-floor conditions.
Highly recommend the Microtech Metrology Micrometer for precision workshops and production lines; for technical advice or to confirm suitability for specific applications contact METAV Werkzeuge — eMail: info@metav-werkzeuge.com — Phone: +49 2822 7131930 — WhatsApp: +49 170 2837271
Technical information
- Designation: Micrometer
- Brand: Microtech Metrology
- SKU: 110183039
- Measuring range: 150–300 mm
- Resolution: 0.0001 mm
- Accuracy: 0.004 mm
- Display: 2.0 and 2.4" Hi-res touchscreen displays (colour)
- Data output: Wireless+USB (WIRELESS to MDS app, WIRELESS HID, WIRELESS HID+MAC, USB HID)
- Measuring hub: Wireless MICROTECH instrument connection; synchronization; 2D mode; 2D graph; probe mode; compensation
- Functions: Graphic online, Analog scale, Go/NoGo, Max/Min, Formula, Timer, Linear correction, Temperature correction, Peak, Limits, FW update, Manual temperature compensation, E-FORCE control
- Memory: 2000 values with folders, statistics; memory data transfer supported
- Housing: CNC machined solid aluminium block
- Accessories included: 5 setting rods and 5 anvils
- Calibration: Calibration certificate included (ISO 17025 (Ilac MRA))
- Manufacturer: MICROTECH Private Scientific Manufacturing Enterprise; 04080, Ukraine, Kyiv; Nizhneyurkovska str., 45a; tool@microtech.tools
FAQ
What measuring range does the Micrometer from Microtech Metrology cover?
The Micrometer by Microtech Metrology covers a wide measuring range of 150–300 mm, allowing one instrument to handle a variety of medium and larger components without swapping tools.
How does data transfer work with the Micrometer from Microtech Metrology?
The Microtech Metrology Micrometer offers multiple modes: wireless transfer to the MDS app (Windows, Android, iOS, MacOS), wireless HID, wireless HID+MAC and USB HID; PC reception can use a single dongle while direct wireless sending to smartphones is supported.
Is calibration provided with the Micrometer from Microtech Metrology?
Yes, the Micrometer from Microtech Metrology is supplied with a calibration certificate in accordance with ISO 17025 (Ilac MRA) to support traceability and quality assurance.
Can the measuring pressure be standardised on the Micrometer by Microtech Metrology?
The Micrometer from Microtech Metrology includes a manual measurement force control so the operator sets the preferred measuring pressure and the device captures values only once that preset force is reached, ensuring consistent results.
Need help choosing or verifying suitability?
If unsure whether the Micrometer by Microtech Metrology meets specific requirements or if additional technical data are needed, METAV Werkzeuge offers expert consultation — eMail: info@metav-werkzeuge.com, Phone: +49 2822 7131930, WhatsApp: +49 170 2837271
