High-precision clamping holders with internal coolant for extended tool life
Clamping holders with internal coolant are designed to secure indexable inserts accurately while delivering coolant directly to the cutting edge, reducing thermal load and improving chip evacuation in demanding metalworking operations. Used for turning and internal machining of tough materials, these holders channel the coolant through built-in boreholes to the insert and beneath the chip, which boosts tool life and enhances surface finish. As a reliable system solution, the combination of clamping holder, internal coolant and indexable insert ensures consistent performance at high cutting speeds and under heavy cut conditions.
100mm Clamping Holder SVJCL 1616 H11 For VCMT 1103 Indexable Inserts Innenkühlung Linksschneidend - Teknik Makina
Benefit from a compact, stiff clamping solution with a precise 93° cutting geometry and compatibility with VCMT 1103 inserts for reliable left-hand turning; order the component directly via Metav Werkzeuge or consult our specialists for application advice. Clamping Holder SVJC for VCMT Indexable Inserts — SVJCL 1616 by Teknik Cutting Tools The Clamping Holder SVJC is a left-hand toolholder designed for turning operations with VCMT 1103 indexable inserts, providing a compact 100 mm length for confined setups. Left-hand turning orientation Compatible with VCMT 1103 inserts 93° cutting geometry for radial cuts SVJCL 1616 profile, 100 mm overall length Increased process stability through geometry The holder's near-square 93° cutting geometry is engineered to deliver enhanced radial support and reduced deflection during facing and light turning operations. With a 25 mm cutting height and a reinforced cutting-head width of 20 mm, the unit increases stability at the insert interface, which translates into more consistent surface finishes and fewer rejects. The combination of compact form and measured stiffness is particularly suitable for short overhang applications in production or jobbing environments. Reduced setup time and predictable integration Featuring the standard SVJCL 1616 profile and a clear shank/bore designation (H11), the toolholder enables straightforward substitution into existing tool turrets and bar holders. The 100 mm overall length and modest mass (0.204 kg) support rapid tool changes and predictable vibration characteristics, helping to shorten machine downtime. Compatibility with VCMT 1103 inserts means established insert geometries and grades can be used immediately, avoiding lengthy requalification. Practical benefits for workshop workflows Supplied for left-hand cutting direction, the clamping unit simplifies tooling planning for specific turning strategies and complements a workshop stock focused on indexable inserts. The measured dimensions — 16 mm holder width, 16 mm holder height and 20 mm cutting-head width — combine to form a compact package that is easy to index and store while maintaining repeatable positioning. The toolholder is therefore well suited to small- to medium-scale manufacturers seeking consistent, low-complexity tooling solutions without sacrificing machining reliability. For reliable left-hand turning with VCMT inserts, contact Metav Werkzeuge for tailored supply and technical advice — call +49 2822 7131930 or email info@metav-werkzeuge.com Technical data Article number: D385TM SKU: D385TM ISO designation: SVJCL 1616 Facts Overall length: 100 mm Cutting height: 25 mm Cutting-head width: 20 mm Holder width: 16 mm Holder height: 16 mm Weight: 0.204 kg Cutting angle: 93° Cutting direction: left Compatibility & features Compatible inserts: VCMT 1103 Shank/bore designation: H11 Profile: SVJC for VCMT Brand: Teknik Cutting Tools FAQ Which inserts fit this toolholder? This clamping holder is designed for VCMT 1103 indexable inserts and accepts standard geometries for that insert family. Is the holder suitable for right-hand turning? The unit is specified for left-hand cutting direction; a right-hand version would be required for opposite feed directions. What is the ISO designation for ordering? Order using the ISO code SVJCL 1616 or the article number D385TM for exact matching. How does the 93° cutting angle affect machining? A 93° cutting geometry provides strong radial support for facing and light turning, improving stability and surface quality compared with more acute tool geometries. Manufacturer / Responsible: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
100mm Klemmhalter 72.5° SVVBN 1616 H16 for VBMT 1604 Wendeplatten Innenkühlung Rechtsschneidend - Teknik Makina
Benefit from precise turning geometry with a 16 x 16 mm shank and a 100 mm overall length, combined with a 72.5° cutting angle for reliable, repeatable cuts. Order the SVVBN 1616 clamp holder directly via Metav Werkzeuge or consult the specialists for application advice. SVVBN 1616 clamp holder for VBMT indexable inserts — Teknik Makina The SVVBN 1616 clamp holder is a compact turning tool holder engineered for VBMT 1604 indexable inserts, intended for stable, repeatable workshop turning tasks. SVVBN 1616 ISO tool holder Compatible with VBMT 1604 inserts 16 x 16 mm shank, designation H16 100 mm overall length, 0.184 kg weight Stable chip control through precise clamping geometry The SVVBN 1616 is designed to secure VBMT-style indexable inserts with consistent seating and clamping force. The combination of a rigid clamp design and a defined 72.5° cutting angle produces steady cutting engagement and reduced insert movement during operation. This geometry helps to preserve cutting-edge life by limiting micro-vibration and unexpected insert shifts. The modest 8 mm cutting head width contributes to focused cutting forces, which is particularly advantageous when repeatability and predictable tool life are required in batch turning operations. Reduced setup time and predictable toolpath geometry A clear, standardised shank size of 16 x 16 mm (H16) and the ISO designation SVVBN 1616 enable straightforward integration into existing tool posts and holders. The 100 mm overall length and low mass of 0.184 kg make handling and balancing simpler on smaller lathes while maintaining rigidity for common workshop speeds. Standard dimensions and ISO conformity translate into fewer measurement checks during setup and consistent toolpath geometry across jobs, improving production throughput and lowering the risk of setup-related scrap. Workshop resilience and parts compatibility for reliable uptime Compatibility with the widely used VBMT 1604 insert family ensures broad applicability across finishing and general turning tasks where defined insert geometry is required. The steel shank and compact head layout provide durable seating for frequent insert changes while keeping inventory management efficient through standardised insert use. Supplied by Teknik Makina and available via Metav Werkzeuge, the holder forms part of a supply chain focused on accessibility of precision tools, backed by a stocked European hub that supports reliable delivery and consistent quality for professional workshops. For tailored advice on the Teknik Makina SVVBN 1616 clamp holder (SKU D132TM) and to arrange supply through Metav Werkzeuge GmbH in Emmerich, please contact info@metav-werkzeuge.com or call +49 2822 7131930 Technical data SKU: D132TM ISO designation: SVVBN 1616 Product type: Clamp holder for VBMT indexable inserts Manufacturer: Teknik Makina Facts Height: 16 mm Width: 16 mm Cutting head width: 8 mm Overall length: 100 mm Cutting angle: 72.5° Weight: 0.184 kg Special features For VBMT 1604 indexable inserts Shank designation: H16 EClass: 21181004 ISO-compatible turning holder FAQ Which insert type fits this holder? The SVVBN 1616 clamp holder accepts VBMT 1604 indexable inserts; the geometry is matched for that insert form. What are the shank and mounting dimensions? Shank dimensions are 16 x 16 mm with designation H16, ISO code SVVBN 1616, and an overall length of 100 mm. What is the cutting angle and how does it affect cutting? The holder presents a 72.5° cutting geometry, which promotes stable engagement and predictable cutting forces in common turning operations. Is this holder suitable for small lathes and light-duty turning? With a compact length of 100 mm and a weight of 0.184 kg, the holder is suited to situations where reduced overhang and manageable mass are beneficial. What is the SKU for ordering and reference? The product is listed under SKU D132TM and is available from Metav Werkzeuge as the Teknik Makina SVVBN 1616 clamp holder. Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
100mm Klemmhalter 93° SVJBL 1616 H11 For VBMT 1103 Indexable Inserts Innenkühlung Linksschneidend - Teknik Makina
Benefit from a left‑hand orientation, a 25 mm cutting height and secure seating for VBMT 1103 inserts — order the holder directly via Metav Werkzeuge or consult our specialists for application advice. Klemmhalter SVJB for VBMT Indexable Inserts (SVJBL 1616) — left‑hand, 100 mm Klemmhalter SVJB for VBMT Indexable Inserts is a left‑hand clamping holder designed for turning applications with VBMT 1103 indexable inserts, providing compact geometry for tight toolposts and reliable repeatability. Left‑hand orientation for precise turning Compatible with VBMT 1103 inserts Compact head, 20 mm width 25 mm cutting height for stable clamping Engineered for consistent turning performance The Klemmhalter SVJB for VBMT Indexable Inserts is built to maintain a stable cutting set‑up in routine production and workshop environments. Its ISO designation SVJBL 1616 and suitability for VBMT 1103 inserts ensure interoperability with common insert families, reducing changeover complexity. With an overall length of 100 mm, a head width of 20 mm and a cutting height of 25 mm, the toolholder aligns insert geometry consistently; the 93° cutting angle assists in predictable chip flow and tool engagement. The modest mass (0.192 kg) contributes to reduced centrifugal effects at higher speeds while the left‑hand orientation supports dedicated turning directions, improving process repeatability and minimising setup adjustments. Faster changeovers and secure seating to lower downtime Precision in the clamping interface delivers practical benefits: the holder’s geometry locates and secures indexable inserts with repeatable seating, which shortens maintenance intervals and helps preserve insert life. The bar designation H11 is commonly used in machined bar stocks for stable mounting, and the compact design is suitable for tighter toolpost environments where clearance is limited. By focusing on quick, error‑reducing insert replacement and steady clamping, the SVJB holder supports higher machine utilisation and a measurable reduction in production interruptions — a rational choice for operations prioritising efficiency and throughput. Integration into workshop workflows and application fit This clamping holder is targeted at machinists and maintenance engineers who require a robust, space‑efficient solution for left‑hand turning tasks. Compatibility with standard VBMT 1103 inserts and the SVJBL 1616 interface means the tool integrates easily into existing toolsets without extensive modifications. The combination of compact dimensions and a defined cutting height provides consistent rake and clearance for standard turning operations, making it a practical option for small‑batch runs as well as serial production. Its specification supports straightforward inventory management where ISO‑referenced holders streamline ordering and replacement. For dependable left‑hand turning performance choose Teknik Makina’s SVJB clamping holder — secure supply via Metav Werkzeuge with fast delivery from Emmerich; contact our technical advisors at info@metav-werkzeuge.com or +49 2822 7131930 Technical data SKU: D373TM Manufacturer: Teknik Makina Designation (EN): SVJB for VBMT Indexable Inserts ISO designation: SVJBL 1616 Suitable for inserts: VBMT 1103 Cutting direction: left Bar designation: H11 Weight: 0.192 kg Dimensions / core data Overall length: 100 mm Head width: 20 mm Holder width: 16 mm Height: 16 mm Cutting height: 25 mm Cutting angle: 93° Features / compatibility Left‑hand clamping holder Fits VBMT 1103 indexable inserts ISO interface SVJBL 1616 Bar designation H11 FAQ Which indexable inserts fit this holder? The Klemmhalter accepts VBMT 1103 inserts and is specified for VBMT geometry when used with the Teknik Makina SVJB clamping holder (SKU D373TM). Is the holder suitable only for left‑hand turning? Yes, the toolholder is configured for left‑hand cutting direction and is intended for left‑hand turning operations. What are the key dimensions to check for mounting? Key dimensions are an overall length of 100 mm, head width 20 mm, holder width 16 mm and a cutting height of 25 mm, which define fitment and clearance. What is the ISO designation and bar reference? The holder uses the SVJBL 1616 ISO interface and the bar designation provided is H11, aiding straightforward replacement and compatibility checks. Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
100mm Klemmhalter 93° SVJBR 1616 H11-F for VBMT 1103 Wendeplatten Innenkühlung Rechtsschneidend - Teknik Makina
Take advantage of a compact, robust clamping solution that combines precise insert seating with a short overall length for tight turning applications; the holder’s SVJBR 1616 profile and compatibility with VBMT 1103 inserts ensure consistent chip control and repeatable results — order via Metav Werkzeuge or consult our specialists for application advice Clamping holder SVJB for VBMT Indexable Inserts — right‑hand toolholder with SVJBR 1616 profile The Clamping holder SVJB for VBMT Indexable Inserts is a right‑hand turning holder engineered for secure clamping of VBMT 1103 inserts in restricted‑space operations. SVJBR 1616 profile for stable seating Compatible with VBMT 1103 inserts Compact 100 mm overall length 16 mm shank and head dimensions Reliable clamping for precision turning The holder is designed as a toolholder for turning operations where stability and repeatability matter. Its SVJBR 1616 ISO profile gives a defined pocket geometry that secures the insert and reduces micro‑movement under load, which translates into consistent surface finish and extended insert life. The right‑hand cut orientation and a 93° approach angle reduce chatter in interrupted cuts; this makes the holder suitable for short overhangs and subcontracting environments where predictable results are essential. The technical design focuses on functional rigidity rather than decorative detail, so shops can expect dependable performance during routine production. Space‑saving design that supports productivity With a 100 mm overall length and matched 16 mm shank and head widths, this holder is made for tight set‑ups and compact toolposts. The reduced projection lowers leverage on the toolpost and allows faster spindle acceleration during cycle changes, improving throughput in small‑batch turning. The 25 mm cutting height positions the insert accurately at centre height for many standard lathes, meaning less adjustment time at setup and more time cutting. For operations that require quick changeovers, the short, lightweight construction — 0.204 kg — eases handling and minimises fixture stress without compromising clamping force. Clear compatibility and simple specification Compatibility with VBMT 1103 indexable inserts is a core feature; the pocket geometry and clamp alignment are produced to match that insert style so insert fitment and seat are repeatable. The holder’s ISO designation SVJBR 1616 identifies its shank profile and size, aiding rapid selection from tooling lists or CAD libraries. The H11‑F bar reference indicates the suitable bore or bar connection where required. For engineers unfamiliar with insert codes: VBMT 1103 denotes a triangular‑shaped, negative‑geometry insert with a specific corner radius and chipbreaker style, chosen here for general turning and facing tasks. Robust choice for production environments Manufactured for industrial use, the holder prioritises mechanical simplicity and manufacturing tolerances that matter on the shopfloor. The pronounced 93° cutting angle supports better chip evacuation and allows a stable cutting edge engagement for facing and light profiling. Where repeatability contributes directly to cost‑efficiency, this clamping solution supports predictable tool life and reduces scrap rates. It is particularly well suited to contract workshops and job shops that need a reliable, easy‑specified holder for common negative inserts. For selection guidance or to confirm suitability for a specific turning task, contact Metav Werkzeuge for expert advice on the Teknik Cutting Tools SVJB clamping holder (SKU D130TM) and benefit from rapid supply from Emmerich — eMail info@metav-werkzeuge.com or call +49 2822 7131930 Technical data Article number: D130TM Manufacturer: Teknik Makina Product: SVJB for VBMT Indexable Inserts ISO designation: SVJBR 1616 Weight: 0.204 kg Overall length: 100 mm Shank height: 16 mm Head width: 16 mm Cutting height: 25 mm Approach angle: 93° Suitable for inserts: VBMT 1103 Cutting direction: right‑hand Bar reference: H11‑F SKU: D130TM FAQ Which insert types fit this holder? The holder accepts VBMT 1103 indexable inserts; the pocket and clamp are produced to suit the VBMT geometry for secure seating and repeatable positioning. Is the holder suitable for right‑hand turning only? Yes — the toolholder is configured for right‑hand cutting, matching standard turning directions on conventional lathes. What is the ISO designation and why does it matter? The ISO code SVJBR 1616 identifies the shank/profile size and helps ensure the holder matches toolpost clearances and fixture designs used in production. How long is the holder and does that help in tight set‑ups? The overall length is 100 mm, which makes it particularly useful where reduced overhang is needed to lower toolpost leverage and improve rigidity. Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
100mm Klemmhalter 95° PWLNL 1616 H06-IKG1/8 For WNMG 0604 Innenkühlung Left-Hand Cutting - Teknik Makina
Combine reliable left-hand clamping with through-tool coolant and a compact 100 mm body for stable turning operations; order the holder directly via Metav Werkzeuge or consult our specialists for application advice. PWLN for WNMG Indexable Inserts — Left-hand PWLNL 1616 Clamp Holder by Teknik Makina (internal coolant, 95° cutting angle) A PWLN for WNMG Indexable Inserts clamp holder designed for left-hand external turning with through-tool coolant and compatibility with WNMG 0604 inserts. Left-hand orientation for external turning Internal coolant for improved chip evacuation Compatible with WNMG 0604 inserts Compact PWLNL 1616 body, 100 mm length Consistent left-hand performance with through-tool cooling The clamp holder is configured for left-hand turning and features internal coolant to support sustained cutting conditions. By directing coolant to the cutting zone, the design helps to manage tool temperature and chip control, which contributes to longer insert life and more repeatable surface finishes. The solution is aimed at precise external turning operations where cooling and chip evacuation are critical for process reliability and reduced rework. Secure clamping and straightforward insert compatibility Designed as a PWLNL-style clamping system, the toolholder accepts WNMG 0604 indexable inserts and uses a robust clamping screw (TH617) together with a matching U-plate (TA021) for stable fixation. This arrangement reduces micro-movement at the cutting edge and shortens setup time when inserts need replacing. The clear interface and standard ISO designation support backwards compatibility with common turrets and holders, delivering measurable gains in uptime and process control. Compact footprint that fits existing toolposts with precision With a total length of 100 mm and a low-profile body, the holder balances rigidity and accessibility for tight setups. The 95° cutting angle and a cutting height of 30 mm allow effective tool positioning for a range of turning profiles, while the modest mass of 0.218 kg keeps inertial loads low on smaller lathes. The PWLNL 1616 form factor simplifies integration into existing tool stations, enabling rapid changeover without elaborate modifications. Choose the Teknik Makina PWLNL 1616 clamp holder for dependable left-hand turning with coolant-through capability — contact Metav Werkzeuge for tailored application support at info@metav-werkzeuge.com or call +49 2822 7131930 Technical data SKU: AP164TM Manufacturer: Teknik Makina Designation: PWLN for WNMG Indexable Inserts ISO designation: PWLNL 1616 Cutting direction: Left Internal coolant: Yes Facts Overall length: 100 mm Holder height: 16 mm Head width: 20 mm Body width: 16 mm Cutting height: 30 mm Cutting angle: 95° Weight: 0.218 kg Compatible insert size: WNMG 0604 Accessories & features Clamping screw: TH617 U-plate: TA021 Dowel pin: TS3 Lever: TL3 Hex key: 2.5 Allen Toolholder shank reference: H06-IKG1/8 FAQ Which inserts fit this clamp holder? The holder is specified for WNMG 0604 indexable inserts; the PWLNL 1616 geometry ensures secure seating and correct cutting height for these inserts. Is the coolant supplied through the tool body? Yes, the clamp holder features internal coolant to direct lubricant to the cutting zone and improve chip evacuation during machining. Can the holder be used for right-hand turning? This model is configured for left-hand operations; for right-hand turning, a mirrored toolholder should be selected. What are the main components for assembly? Assembly and clamping rely on the TH617 clamping screw, U-plate TA021 and dowel TS3, which together secure the insert seat and enable repeatable clamping. Will the toolholder fit standard turret pockets? The PWLNL 1616 form factor and the documented dimensions (100 mm length, 16 mm height) are compatible with many standard toolposts; confirm turret clearance before final installation. Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
100mm PCLN Holder PCLNL 1616 H12 For CNMG 1204 Inserts Innenkühlung Left-Handed - Teknik Makina
Take advantage of a compact, ISO‑compliant toolholder that delivers stable clamping for CNMG inserts and predictable chip control; its 16 mm shank height and 95° cutting angle support repeatable setups and consistent surface finish. Order the clamping holder directly via Metav Werkzeuge or consult the team for application-specific advice. PCLNL 1616 clamping holder — PCLN for CNMG indexable inserts, left‑hand The PCLNL 1616 clamping holder is designed for left‑hand turning with CNMG 1204 indexable inserts, offering a compact 100 mm overall length and robust clamping geometry for reliable machining in workshop and light production environments Left‑hand PCLN holder for CNMG inserts Secure clamp for CNMG 1204 indexable inserts 16 mm shank height, 20 mm head width 100 mm overall length, robust 95° cutting angle Stable clamping for consistent surface quality The holder’s clamping geometry is configured to secure CNMG inserts firmly, which reduces micro‑movement and vibration during cutting. This stability translates into a measurable improvement in surface finish and extended insert life, because less chatter means smaller wear rates on the cutting edge. The left‑hand orientation and the roughly 95° cutting angle also create a predictable cutting force vector, simplifying toolpath planning and helping to maintain repeatable results across batches. Exact dimensions for fast setup and interchangeability With a 16 mm shank height, 20 mm head width and 100 mm overall length, the toolholder matches common toolpost interfaces and makes replacement and indexing straightforward. The ISO designation PCLNL 1616 signals compatibility with standard clamping systems, so set‑up time is reduced and machine downtime is minimised. The specified insert compatibility (CNMG 1204) ensures that indexable inserts can be swapped quickly—keeping maintenance simple and stocking efficient for the workshop. Designed for efficient shopfloor use and low maintenance The construction prioritises easy insert seating and reliable clamping, so wear is localised to the replaceable insert rather than the whole assembly. The combination of compact form and modest weight (0.225 kg) makes the holder convenient to handle while remaining rigid under typical turning loads. By enabling cost‑effective indexable inserts and quick changes, the toolholder supports higher machine utilisation and a lower cost per component, which is particularly valuable for small batches and mixed‑series work. Contact Metav Werkzeuge today to discuss Teknik Cutting Tools’ PCLNL 1616 clamping holder for left‑hand turning and to request application guidance directly from our Emmerich team via info@metav-werkzeuge.com or by phone at +49 2822 7131930 Technical data Article number: P139TM Manufacturer: Teknik Makina Designation (EN): PCLN for CNMG Indexable Inserts ISO designation: PCLNL 1616 Dimensions & weight Shank height: 16 mm Head width: 20 mm Insert height: 30 mm Overall length: 100 mm Weight: 0.225 kg Cutting angle: 95° Features & compatibility For CNMG 1204 indexable inserts Left‑hand cutting direction Shank designation: H12 Suitable for PCLN insert geometry SKU: P139TM FAQ What inserts fit this holder? This holder is designed for CNMG 1204 indexable inserts and secures them using the PCLN clamping geometry specified by the PCLNL 1616 form factor. Is the holder suitable for left‑hand turning only? Yes, the toolholder is specified for left‑hand cutting direction, matching lathe setups that require left‑hand tool orientation. What are the key dimensions to check for machine compatibility? Verify the 16 mm shank height, 20 mm head width and 100 mm overall length against the machine toolpost and toolpost pocket to ensure correct fit and clearance. How does the 95° cutting angle affect machining? The approximately 95° cutting angle provides a conservative clearance and helps control cutting forces, improving stability and aiding consistent surface finish. Can this holder improve insert life? By providing secure clamping and reduced vibration, the holder contributes to more uniform wear on the insert, which can extend usable insert life in many turning operations. Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
100mm Precision Clamp Holder PCLNL 1616 PCLN for CNMG 1204 Inserts, 95° Cut Angle, Internal Coolant, Left-Hand Cutting - Teknik Makina
Benefit from a compact, left‑hand PCLN toolholder with internal coolant and a secure screw clamp — precise chip control and stable insert seating for efficient turning operations. Order the holder directly via Metav Werkzeuge or consult the technical team for application advice. PCLNL 1616 PCLN toolholder – left‑hand, internal coolant, for CNMG inserts (Teknik Makina) PCLNL 1616 PCLN toolholder is a left‑hand clamping toolholder designed for turning with CNMG indexable inserts; suited to standard toolposts and compact lathe setups. Left‑hand PCLN toolholder with internal coolant Fits CNMG 1204 indexable inserts Compact 16 x 16 mm shank body 95° cutting angle for versatile turning Secure clamping and consistent cutting performance Built from workshop‑grade specifications, this toolholder delivers reliable clamping and predictable behaviour during cyclic turning operations. The PCLNL 1616 format provides a familiar interface for indexable insert tooling, with a robust clamping screw (TH818) and matching support parts (U‑plate TA016‑1, dowel TS‑4, knee lever TL4) for stable insert seating. At 16 x 16 mm shank dimensions and a head width of 20 mm, the holder balances rigidity and compactness; the modest mass of 0.236 kg helps reduce unbalanced loads on smaller toolposts. These attributes reduce vibration and contribute to consistent surface finish and tool life. Optimised for CNMG inserts and left‑hand turning cycles The holder is engineered specifically for turning with CNMG 1204 indexable inserts and supports a 95° cutting angle, enabling effective approach geometry for a wide range of diametral cuts. Left‑hand orientation makes the assembly suitable for operations that require opposite feed or for machines configured for left‑hand turning. The integrated internal coolant channel directs lubricant close to the cutting edge, promoting chip evacuation and improved thermal control; the result is extended insert service life and fewer interrupted cycles for regrinding or replacement. Designed for quick set‑up and low maintenance in production Assembly and maintenance are straightforward thanks to standardised fittings: the clamping screw designation TH818, the locating plate TA016‑1, dowel TS‑4 and lever TL4 ensure repeatable seating and rapid replacement when turnarounds are required. The holder’s 100 mm overall length and defined cutting height of 28 mm enable predictable tool offsets and simple programme setup on CNC lathes. Internally routed coolant minimises manual coolant management and reduces downtime related to chip build‑up, supporting higher process uptime and smoother production flows. Contact Metav Werkzeuge to specify the right Teknik Makina PCLN toolholder and confirm compatibility with existing toolposts and CNMG inserts Technical Data Article number: AP139TM Manufacturer: Teknik Makina Type designation: PCLNL 1616 Facts Shank width: 16 mm Shank height: 16 mm Head width: 20 mm Cutting height: 28 mm Total length: 100 mm Weight: 0.236 kg Cutting angle: 95° Cutting direction: left Special features Internal coolant For CNMG 1204 indexable inserts Clamping screw TH818 U‑plate TA016‑1 Dowel TS‑4 Knee lever TL4 Allen key: 3 Allen Compatible with H12‑IKG1/8 drill‑bar designation FAQ What inserts are compatible with this holder? The holder is designed for CNMG 1204 indexable inserts; the PCLN format and clamping arrangement match standard CNMG seat geometries. Is the coolant routed to the cutting edge? Yes, the toolholder features internal coolant that directs fluid towards the insert to improve chip evacuation and temperature control. Which clamping components are required for assembly? Assembly uses the clamping screw TH818, locating plate TA016‑1, dowel TS‑4 and knee lever TL4, which provide repeatable clamping and alignment. Is this a left‑hand or right‑hand holder? This is a left‑hand PCLN toolholder intended for left‑hand turning applications. What are the shank dimensions and overall length? Shank dimensions are 16 x 16 mm with a 100 mm overall length and a head width of 20 mm, allowing compact mounting and predictable offsets. Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
100mm PWLN for WNMG Indexable Inserts PWLNR 1616 H06 For WNMG 0604 Innenkühlung Rechtsschneidend 95° - Teknik Makina
Take advantage of the combination of precise clamping, compatibility with standard WNMG inserts and compact dimensions for reliable turning operations; order this toolholder directly via Metav Werkzeuge or consult our specialists for application advice. Klemmhalter — PWLN for WNMG indexable inserts, right-hand, ISO PWLNR 1616 (Teknik Cutting Tools) The Klemmhalter is a right-hand turning toolholder designed for external machining with WNMG 0604 indexable inserts, offering a compact 100 mm overall length for use on conventional and CNC lathes For WNMG 0604 indexable inserts Right-hand turning orientation Holder height 16 mm for stable clamping Overall length 100 mm for compact setups Maximise cutting stability and repeatability The PWLN-style toolholder delivers a rigid connection between insert and shank, which reduces vibration and improves surface finish during external turning. The cutting angle 95° and the well-defined cutting head width 20 mm create a stable cutting geometry that supports consistent chip formation and tool life. Reduced vibration translates directly into fewer reworks and longer service intervals for inserts, improving production efficiency and lowering total operating cost. Fast integration with standard inserts and tooling systems Compatibility with WNMG 0604 indexable inserts and the ISO designation PWLNR 1616 means straightforward integration into existing tooling rigs. The clamping geometry facilitates quick insert changes and secure seating, while the bohrstangen designation H06 indicates the matching shank standard for modular carriers. These standard interfaces shorten setup time and keep machine downtime to a minimum, making the holder particularly suited to mixed-batch and series production environments. Compact dimensions designed for shop-floor versatility With a holder height 16 mm, holder width 16 mm and modest cutting height 30 mm, this clamping holder fits tight-tooling layouts and small carriage clearances. The overall length 100 mm and low mass (0.223 kg) reduce leverage on the toolpost, enhancing rigidity for light to medium turning tasks. The right-hand orientation supports conventional turning cycles and is suitable for general workshop and industrial applications where space and repeatability matter. Practical benefits for production workflows Choosing this PWLN holder helps standardise tooling across multiple lathes thanks to its adherence to common ISO sizing, which simplifies inventory and spare-part management. The combination of compact form factor and robust clamping improves machining reliability while keeping the tool-change routine efficient. For operations aiming to balance precision and throughput, the holder offers a pragmatic compromise between rigidity and footprint. Contact Metav Werkzeuge GmbH for a tailored quotation and compatibility check for this Teknik Cutting Tools PWLN clamping holder (SKU P158TM) — call +49 2822 7131930 or e‑mail info@metav-werkzeuge.com to discuss suitability for specific machines and applications Technical data SKU: P158TM Manufacturer: Teknik Makina Product: PWLN for WNMG Indexable Inserts ISO designation: PWLNR 1616 Suitable for: WNMG 0604 inserts Cutting direction: right Facts Holder height: 16 mm Holder width: 16 mm Cutting head width: 20 mm Cutting height: 30 mm Cutting angle: 95° Overall length: 100 mm Weight: 0.223 kg Special features Right-hand turning orientation Bohrstangen designation H06 Compact 100 mm overall length Designed for standard WNMG 0604 indexable inserts FAQ Is this holder compatible with WNMG 0604 inserts? Yes. The PWLN holder is specified for WNMG 0604 indexable inserts and is built to the ISO-related PWLNR 1616 dimensions for reliable fit and clamping. Can the holder be used on CNC lathes and manual lathes? The clamping holder is suitable for both CNC and conventional lathes; its compact overall length 100 mm and standard interface make it adaptable to typical toolposts and turret systems. What does the ISO designation PWLNR 1616 indicate? PWLNR 1616 denotes the standardised shank and clamping geometry used for this PWLN-style holder, ensuring interchangeability and predictable installation when matching to compatible tool systems. Does the holder support right-hand cutting only? This model is configured for right-hand cutting orientation; select the corresponding left-hand variant if left-handed machining cycles are required. Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
100mm PWLN Turning Holder for WNMG 0604, 95° - Teknik Makina
Turning Holder PWLN for WNMG Indexable Inserts — Teknik Makina The Turning Holder is a compact, precision tool designed for right-hand turning with WNMG 0604 indexable inserts, ideal for professional workshop and lathe applications. Compatible with WNMG 0604 inserts Internal Cooling for improved Chip Evacuation Robust clamp system with TH617 screw 100 mm Overall Length for versatile reach Right-hand Cutting with 95° cutting angle Precision and Compatibility for Accurate Turning Built around compatibility with WNMG 0604 indexable inserts, this holder delivers consistent Precision in external turning operations. The 95° cutting angle and right-hand configuration ensure stable contact and predictable Chip Flow, reducing vibration and improving Surface Finish. For shops that demand repeatable results, the combination of insert fit and holder geometry supports reliable toolpaths and predictable machining outcomes. Robust Construction and Practical Features The holder combines a compact profile with practical mechanical parts to simplify workshop routines. With a 100 mm Length, a 16 mm Width and 16 mm Height, plus a 20 mm Cutting Head Width, the design balances rigidity and access. The clamping system uses the TH617 clamp screw and TL3 knee lever for secure fixation, while the Internal Cooling feature assists in temperature control and Chip Evacuation during longer cuts. Who Benefits and When to Use This Tool This Turning Holder is developed for machining professionals, CNC turning centres and manual lathe operators who use WNMG 0604 inserts and require a compact, reliable tooling solution. Operators will appreciate faster Insert Changes and consistent clamp performance, which help reduce setup time and maintain machining quality across batch runs. The holder’s format suits short to medium overhangs where rigidity and cooling support are priorities. Easy Setup and Low-Maintenance Operation Assembly and maintenance are straightforward: the holder matches the ISO designation PWLNR 1616, uses a 2.5 mm Allen key for adjustments, and includes straightforward locating features such as the TS3 dowel pin. Regular inspection of the clamp screw and knee lever keeps performance stable, and the open design allows quick visual checks of insert seating to avoid interruptions during production. For technical assistance or to confirm compatibility with your machine, contact METAV Werkzeuge for expert advice and support — they provide competent consultation for complex tooling decisions and can help specify the right configuration for your application. 📧 info@metav-werkzeuge.com ☎️ +49 2822 7131930 ✔️ WhatsApp +49 170 2837271 Technical Specifications Designation: Turning Holder Brand: Teknik Makina SKU: AP158TM Compatible Indexable Inserts: WNMG 0604 ISO Designation: PWLNR 1616 Secondary Designation: H06-IKG1/8 Overall Length: 100 mm Width: 16 mm Height: 16 mm Cutting Head Width: 20 mm Cutting Height: 30 mm Clamp Screw: TH617 Knee Lever: TL3 Dowel Pin: TS3 Hex Key: 2.5 mm Allen key Internal Cooling: Yes Cutting Direction: Right Cutting Angle: 95° Weight: 0.218 kg GTIN: 4061905150371 Manufacturer: Teknik Makina, Nolu Sokak, No 9, Selcuklu, Turkey, eMail: info@teknik-makina.com Responsible Person: Metav Werkzeuge GmbH, Parkring 45, 46446 Emmerich, eMail: info@metav-werkzeuge.com FAQ What inserts fit the Turning Holder and which insert size is recommended? The Turning Holder from Teknik Makina is designed for WNMG 0604 indexable inserts; this size ensures correct seating and chip control when used with the holder’s 95° geometry. Does the Teknik Makina Turning Holder support coolant-through operation? Yes, the Turning Holder features Internal Cooling, which aids chip evacuation and temperature management when coolant supply is available. Which tools are needed for assembly and maintenance of the Turning Holder? Assembly and basic maintenance of the Teknik Makina Turning Holder require a 2.5 mm Allen key for clamp adjustments and inspection of the TH617 clamp screw and TL3 knee lever for secure fixation. Is the Turning Holder suitable for right-hand and left-hand turning? The Teknik Makina Turning Holder is configured for right-hand cutting with a 95° cutting angle and is intended for standard right-hand turning operations; left-hand versions would require a corresponding left-hand variant. 100mm PWLN Turning Holder for WNMG 0604, 95° Angle, Internal Coolant - Teknik Makina
100mm SCACR 1616 SCACR-F For CCMT 09T3 Inserts, 90° Cutting Angle, H09-F, Right-Handed, Internal Cooling - Teknik Makina
Take advantage of stable clamping and standardised compatibility: the holder’s SCACR 1616 geometry and compact 16 × 16 mm toolhead deliver reliable rigidity for light to medium turning tasks, while the right-hand orientation ensures predictable chip flow and repeatable results; order directly via Metav Werkzeuge or consult the Emmerich team for application advice SCACR-F for CCMT Indexable Inserts — Right-hand turning holder, SCACR 1616 by Teknik Cutting Tools The SCACR-F for CCMT Indexable Inserts is a right-hand turning toolholder engineered for CCMT 09T3 inserts, offering a compact 16 × 16 mm head and a 100 mm overall length for confined turning operations Right-hand turning orientation Compatible with CCMT 09T3 inserts SCACR 1616 toolhead, 16 × 16 mm 100 mm overall length, solid build Stable clamping for consistent turning results This turning holder uses a proven clamping concept to secure indexable inserts reliably under cutting loads. The SCACR 1616 geometry provides a low centre of gravity and short overhang, which improves rigidity and reduces vibration during interrupted cuts. For workshops requiring repeatable diameters and surface finish, the holder’s compact head (16 × 16 mm) and firm insert seating translate into reduced tool chatter and longer insert life, delivering measurable process stability in serial or single-part production. Standard compatibility simplifies tooling decisions Designed specifically for CCMT 09T3 inserts, the holder accepts widely available triangular-turning inserts used across industry. The ISO designation SCACR 1616 denotes the holder’s standardized shank and head dimensions, enabling easy integration with existing toolposts and toolpost adaptors. Using a toolholder that matches common insert formats minimises inventory complexity and facilitates fast replacement during tool changes, supporting efficient shop-floor logistics and predictable machining cycles. Compact geometry for improved access and chip control With a 100 mm overall length and a 90° cutting angle, the holder delivers close access to workpiece shoulders and bores while preserving clearance for chip evacuation. The right-hand cutting direction aligns chip flow away from the operator and fixture in conventional turning set-ups, lowering the risk of entanglement and easing post-process cleaning. The combination of a small head dimension and a robust clamping interface makes this holder especially suitable where tool overhang must be minimised without compromising on clamping security. Arrange an application review with Metav Werkzeuge for the SCACR 1616 turning holder or request tailored advice from our Emmerich specialists to match the holder to the machining task Technical data Article number: D414TM Designation: SCACR-F for CCMT Indexable Inserts ISO designation: SCACR 1616 Manufacturer: Teknik Makina Facts Overall length: 100 mm Toolhead height: 16 mm Toolhead width: 16 mm Cutting angle: 90° Weight: 0.221 kg Cutting direction: Right-hand Special features Compatible inserts: CCMT 09T3 Shank designation: H09-F Right-hand turning holder Compact head for restricted access FAQ Which insert type fits this holder? The holder accepts CCMT 09T3 indexable inserts and is optimised for that insert geometry. What is the ISO designation of the toolholder? The toolholder is listed as SCACR 1616, indicating the standard head and shank dimensions. Is this a right-hand or left-hand holder? This is a right-hand turning holder, designed for conventional right-hand cutting directions. What are the compact dimensions of the toolhead? The toolhead measures 16 × 16 mm, providing a low-profile solution for tight turning applications. What is the overall length of the holder? Overall length is 100 mm, suitable for reduced overhang and better rigidity. Who manufactures this toolholder? The toolholder is produced by Teknik Makina and supplied via Metav Werkzeuge. Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
100mm SDJC 1616 H11 For DCMT 11T3 Indexable Inserts Left-Hand Cutting Innenkühlung - Teknik Makina
Combine stable 16 × 16 mm shank rigidity, compatibility with DCMT 11T3 indexable inserts and a precise 93° cutting angle to secure reliable left-hand external turning — order via Metav Werkzeuge or consult our specialists for application support. SDJCL 1616 clamping holder — SDJC for DCMT indexable inserts, left-hand, 93° cutting angle The SDJCL 1616 clamping holder is a left-hand toolholder for DCMT 11T3 indexable inserts, designed for stable external turning and straightforward insert changes in workshop and light industrial lathe work. Left-hand turning orientation Compatible with DCMT 11T3 inserts Shank 16 × 16 mm for stable clamping 100 mm overall length for external turning Secure clamping for consistent surface quality The holder is engineered to deliver clamping stability through its 16 × 16 mm shank and compact head geometry, which reduces micro-movement during cuts. With a cutting height 25 mm and a well-defined seating for the insert, the arrangement promotes repeatability from one set-up to the next, translating into improved surface finish and longer insert life. This stability is particularly valuable in batch production and repair work where consistent results matter. Tailored for DCMT inserts and left-hand cutting Compatibility with DCMT 11T3 indexable inserts ensures access to a broad range of grades and geometries for finishing or medium-duty turning. The left-hand configuration and 93° cutting angle give the cutting edge the clearance and support required for secure external turning, while the insert pocket design simplifies indexing and reduces downtime associated with insert changes. The result is a combination of flexibility and operational efficiency for common turning tasks. Reach and rigidity to boost productivity A 100 mm overall length provides practical reach without excessive overhang, helping to minimise leverage and reduced vibration during cuts. At a weight of 0.204 kg the unit balances rigidity with manageable mass for rapid tool changes. Together, these attributes contribute to a cost-efficient machining process: fewer rejects, steadier feeds and the option to run higher effective cutting parameters within the stability limits of the lathe. Quick installation and workshop compatibility The clamping system accepts bar designation H11 and follows established ISO sizing as SDJCL 1616, enabling straightforward integration into existing toolposts and quick-change setups. Its form factor and simple insert access make it suitable for precision workshops, maintenance departments and small-scale production, where dependable toolholding and easy servicing support tight schedules and predictable maintenance intervals. For tailored advice or to order this Teknik Makina SDJCL 1616 clamping holder via Metav Werkzeuge, please contact Metav Werkzeuge directly at info@metav-werkzeuge.com or call +49 2822 7131930 for expert guidance and fast supply from Emmerich. Technical data SKU: D364TM Manufacturer: Teknik Makina Article designation: SDJC for DCMT Indexable Inserts ISO designation: SDJCL 1616 Facts Shank height: 16 mm Shank width: 16 mm Cutting head width: 20 mm Cutting height: 25 mm Overall length: 100 mm Cutting angle: 93° Weight: 0.204 kg Cutting direction: left Special features Left-hand toolholder For DCMT 11T3 indexable inserts Bar designation: H11 FAQ Which indexable inserts fit this holder? The holder is designed for DCMT 11T3 indexable inserts; the SDJCL 1616 seating supports standard DCMT geometry for quick indexing and replacement. Is this toolholder for left- or right-hand turning? This version is left-hand; the SDJCL 1616 is configured for left-hand cutting operations with a 93° cutting angle. What are the essential dimensions to check before ordering? Key dimensions are shank 16 × 16 mm, cutting head width 20 mm, cutting height 25 mm and overall length 100 mm — SKU D364TM. Which applications suit this clamping holder? The holder is suitable for external turning on lathes in precision workshops and small-scale production, where DCMT inserts provide flexible grades and edge geometries. How does the 93° cutting angle affect performance? A 93° cutting angle provides clearance and robust support at the insert corner, improving edge strength for general external turning while helping to avoid interference with workpiece features. Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
10mm SDJC For DCMT Indexable Inserts 93° SDJCR 1010 J07-F For DCMT 0702 Innenkühlung Rechtsschneidend - Teknik Makina
Take advantage of a compact, rigid toolholder that combines a 93° cutting angle with compatibility for DCMT 0702 indexable inserts to deliver stable external turning; order directly via Metav Werkzeuge or consult the technical advisers for suitability and rapid supply. Clamping holder SDJCR 1010 — SDJC toolholder for DCMT indexable inserts, 93° right-hand (Teknik Makina) The Clamping holder SDJCR 1010 is a right-hand turning toolholder engineered for use with DCMT 0702 indexable inserts, intended for precise external turning applications in production and workshop settings. 93° cutting angle for stable external turning Compatible with DCMT 0702 indexable inserts SDJCR 1010 ISO designation, right-hand orientation 110 mm overall length with 10 mm head width Greater process stability from 93° geometry The 93° geometry provides a stable cutting stance that reduces radial forces during external turning, which in turn contributes to more consistent diameters and surface finishes. By combining a 93° cutting angle with a secure clamping system, the holder minimises micro-vibration and supports predictable tool life. The right-hand configuration is matched to standard lathe tool-post orientations, ensuring straightforward integration into existing turning operations. This technical design yields measurable gains in repeatability and reduces scrap rates where tight tolerances are required. Built for common DCMT 0702 inserts and quick integration Compatibility with DCMT 0702 indexable inserts makes the holder a practical choice for workshops that require readily available tooling. The SDJCR 1010 designation conforms to ISO-style naming, facilitating straightforward matching with insert catalogues and reducing procurement complexity. The clamping concept permits reliable seating of the insert, so insert changes are rapid and alignment remains stable after each swap. Where supply chain consistency matters, the use of a standard insert format simplifies stock control and shortens setup times. Compact dimensions for limited overhang and improved rigidity With an overall length of 110 mm, a head width of 10 mm and a head height of 10 mm, the holder is dimensioned for situations where minimal overhang is essential. Less projection from the toolpost improves rigidity and lowers deflection under load, which is particularly valuable on smaller lathes or when machining thin-walled workpieces. The modest mass (approx. 0.103 kg) helps when rapid tool indexing is required and reduces inertial loads during acceleration. These compact dimensions favour stable machining and support higher machining reliability in close-tolerance turning tasks. Suitable for production and jobbing workshops seeking consistency As a production-ready clamping solution, the holder supports reliable external turning cycles and predictable performance in repetitive work. The J07-F shank designation aligns the holder to common toolpost and shank systems, facilitating immediate mounting without additional adapters. Its right-hand orientation and robust clamping reduce downtime associated with tool seating and adjustment, which benefits throughput and cost-efficiency in batch runs. Metav’s logistics and quality filtering further ensure consistent availability, giving procurement teams confidence in delivery and ongoing supply. Contact Metav Werkzeuge for a suitability check and delivery details for the SDJCR 1010 clamping holder; technical advisers in Emmerich can confirm fitment, lead times and dispatch options Technical Data Article number: D452TM Manufacturer: Teknik Makina Product name: SDJC for DCMT Indexable Inserts Brand: Teknik Makina Facts Overall length: 110 mm Cutting angle: 93° Head height: 10 mm Head width: 10 mm Body width: 10 mm Weight: 0.103 kg Direction: Right eClass: 21181004 Special features ISO designation SDJCR 1010 For DCMT 0702 indexable inserts Shank designation J07-F Right-hand toolholder FAQ What insert type fits this toolholder? The clamping holder accepts DCMT 0702 indexable inserts; the SDJCR 1010 format is specified for this insert size and ensures standardised interchangeability. Is the holder right- or left-hand oriented? The toolholder is manufactured as a right-hand turning holder, suitable for standard right-hand turning setups. What are the key dimensions to check for machine compatibility? Check the 110 mm overall length, the 10 mm head width and the 10 mm head height to ensure sufficient clearance and minimal overhang in the existing toolpost arrangement. Which shank designation is used for mounting? The holder uses the J07-F shank designation, which aligns it with common toolpost and bar-clamping systems for direct mounting. How does the 93° cutting angle affect machining? A 93° cutting angle offers a stable engagement for external turning, reducing radial deflection and supporting consistent diameters and surface quality. Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
10mm SDNCN 1010 Clamp Holder 62.5° for DC-- 0702 Indexable Inserts, J07, Internal Cooling, Right-Hand Cutting - Teknik Makina
Combine compact dimensions, a 62.5° cutting geometry and proven compatibility with DC-- 0702 indexable inserts for accurate, repeatable turning results; order the clamping holder directly via Metav Werkzeuge or ask the consultants for specification support. SDNCN 1010 clamping holder — 62.5° approach, 110 mm length (Teknik Makina) The SDNCN 1010 is a compact clamping holder engineered for turning with DC-- 0702 indexable inserts, designed to deliver stable finish machining and effortless insert changes in light to medium-duty applications 62.5° cutting geometry for fine finishing 110 mm overall length for stable reach Compatible with DC-- 0702 indexable inserts Lightweight 96 g for quick tool changes Precise cutting geometry for consistent surface quality The holder's defining attribute is its 62.5° approach angle, which concentrates cutting forces for improved surface finish and predictable chip flow. As an SDNCN-style toolholder, this device pairs specifically with DC-- 0702 indexable inserts to produce repeatable turning outcomes. The geometry reduces vibration on short overhangs and, when combined with correct insert grade and machine settings, contributes to measurable improvements in process stability and part quality. This makes the toolholder especially suitable for precision profiling and finishing passes where dimensional consistency matters. Compact design that supports efficient tool changes With an overall length of 110 mm and a mass of just 96 g, the holder supports compact set-ups and quicker tool rotations in multi-station turrets. The short cutting-head width of 5 mm and modest holder dimensions (height 10 mm, width 10 mm) permit closer tool spacing and reduced interference in clustered tool arrangements. The J07 shank designation affords straightforward mounting in standard boring bars and adaptors; the light weight helps to lower centrifugal loads and simplifies handling during retooling, which in turn reduces downtime between operations. Robust fit and application guidance for reliable throughput The clamping mechanism is designed for secure retention of DC-- 0702 inserts, while a cutting height of 15 mm ensures the correct cutting-edge position relative to the toolpost on many common lathes. The holder's ISO designation SDNCN 1010 indicates its compatibility class, supporting straightforward replacement planning in production environments. For process planners, the combination of compact geometry and secure clamping delivers a practical balance between accessibility and reliability, helping to maintain steady cycle times without compromising finish quality. Contact Metav Werkzeuge to confirm the SDNCN 1010 suitability for your turning application and to arrange fast supply or technical advice — call +49 2822 7131930 or email info@metav-werkzeuge.com Technical data Article number: D117TM Manufacturer: Teknik Makina ISO designation: SDNCN 1010 Suitable for inserts: DC-- 0702 Dimensions & weight Overall length: 110 mm Holder height: 10 mm Holder width: 10 mm Cutting head width: 5 mm Cutting height: 15 mm Weight: 96 g Geometry & shank Approach angle: 62.5° Shank designation: J07 Compatible with indexable inserts SKU: D117TM FAQ Which inserts are compatible with this holder? The SDNCN 1010 clamping holder is specified for DC-- 0702 indexable inserts and is designed to retain that insert format securely for turning operations. What is the holder's approach angle and why does it matter? The approach angle is 62.5°, a geometry that helps concentrate cutting forces for improved surface finish and controlled chip formation during finishing passes. What are the key dimensions and weight of the toolholder? Overall length is 110 mm; holder height and width are 10 mm each; cutting-head width is 5 mm and cutting height is 15 mm. Weight is approximately 96 g. Which shank designation does the holder use? The toolholder uses the J07 shank designation, compatible with standard adaptors and bar mounts that accept that format. Is the SDNCN 1010 suitable for finishing applications? Yes. The combination of 62.5° geometry and precise cutting height makes the holder well suited to finishing and light profiling with the appropriate DC-- 0702 inserts. Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
10mm SVJB for VBMT Indexable Inserts 93° SVJBR 1010 J11-F-IK For VBMT 1103 Inserts Innenkühlung Rechtsschneidend - Teknik Makina
Benefit from secure clamping, integrated coolant and a precise 93° cutting angle for consistent turning performance; order the SVJB clamp holder directly via Metav Werkzeuge or consult our product specialists if required. SVJB for VBMT Indexable Inserts — flat clamp holder with internal coolant and 93° cutting angle (Teknik Makina) A compact SVJB for VBMT Indexable Inserts clamp holder designed for right‑hand turning operations, optimised for VBMT 1103 inserts and workshop toolposts. Flat clamp for VBMT 1103 inserts Integrated internal coolant channel 93° cutting angle, right-hand orientation M2.5x6.5 Torx screw with T8 key Consistent clamping for repeatable turning results The flat clamp design delivers stable clamping for indexable inserts, reducing micro‑movement and ensuring repeatable part geometry during series turning. The holder accepts VBMT 1103 inserts and is secured with an M2.5x6.5 Torx screw, tightened with a T8 key, which simplifies assembly and maintenance. Low mass and a compact profile minimise tool overhang and contribute to improved surface finish by lowering vibration. For workshop planners, the SVJBR 1010 ISO designation indicates compatibility with standard toolholding systems, enabling straightforward integration without reworking existing setups. Coolant-through routing to protect insert life and process stability An internal coolant channel feeds cutting fluid directly to the insert seat, promoting controlled chip evacuation and thermal management at the cutting zone. This design reduces heat build‑up, which in turn extends insert life and allows more consistent cutting conditions across shifts. For precision operations where tool life and stable forces matter, the coolant-through capability supports steady state cutting and fewer unscheduled tool changes, improving overall machine uptime and lowering per‑part production costs. Compact dimensions engineered for workshop integration Measured at 110 mm overall length with a 10 mm wide clamp head and a total height of 10 mm, the holder fits tightly into confined setups while providing the required rigidity for turning tasks. The cutting height of 30 mm and a cutting angle of 93° produce predictable tool engagement for right‑hand turning operations. Weighing approximately 0.07 kg, the unit contributes minimal dynamic load to the turret, making it suitable for both single‑piece and batch production where quick index and stable repeatability are needed. Fast maintenance, clear compatibility and robust assembly The holder is presented in a flat execution for easy seat alignment and is designated J11‑F‑IK for its shank reference, simplifying procurement of replacement components. The right‑hand cutting direction is clearly specified to avoid tooling mismatches on multi‑spindle machines. Routine service is expedited by the standard Torx screw and key interface, allowing rapid insert changes and re‑clamping with consistent torque. Where operator training varies, the straightforward mechanical design reduces assembly errors and supports reliable throughput over long production runs. For technical advice or stock availability of Teknik Cutting Tools’ SVJB clamp holder, contact Metav Werkzeuge in Emmerich at info@metav-werkzeuge.com or call +49 2822 7131930 for tailored recommendations and prompt dispatch from our warehouse. Technical data Article number: AP547TM Manufacturer: Teknik Makina ISO designation: SVJBR 1010 Shank designation: J11-F-IK For inserts: VBMT 1103 Cutting direction: right Core technical data Clamp width: 10 mm Clamp height: 10 mm Cutting head width: 10 mm Overall length: 110 mm Cutting height: 30 mm Cutting angle: 93° Weight: 0.07 kg Torx screw: M2.5x6.5 Special features Internal cooling Flat design (flat execution) Right‑hand orientation Torx key size: T8 Suitable for VBMT indexable inserts FAQ Is the holder compatible with all VBMT insert manufacturers? Compatibility depends on insert seat geometry; the SVJB is specified for VBMT 1103‑style inserts and will accept inserts from manufacturers that conform to that format, but insert seat fit should be checked before series use. Does the holder supply coolant directly to the insert? Yes, the clamp holder features internal coolant routing that feeds fluid to the insert location, improving chip control and thermal stability during machining. What is the required screw and key for securing the insert? The assembly uses an M2.5x6.5 Torx screw, operable with a T8 key for consistent fastening and straightforward maintenance. Can the holder be used for left‑hand turning? This particular version is specified for right‑hand turning operations; for left‑hand cutting a corresponding left‑hand holder should be used to ensure correct geometry. Which shank and ISO designation should be referenced when ordering? Reference the shank designation J11‑F‑IK and the ISO designation SVJBR 1010 to ensure correct replacement and system compatibility. Manufacturer/Responsible: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
110mm Clamp Holder 95° SCLCR 1212 J09 For CC-- 09T3 Inserts Inner Cooling Right-Hand Cutting - Teknik Makina
Take advantage of a compact, high-rigidity turning solution that pairs a standard SCLCR 1212 profile with compatibility for CCMT indexable inserts; the short overhang and 12 × 12 mm shank reduce vibration and increase tool life. Order or request advice through Metav Werkzeuge for straightforward integration and reliable supply. SCLCR 1212 clamping holder (SCLC for CCMT indexable inserts) — right-hand, 12×12 mm shank A SCLCR 1212 clamping holder engineered for external turning with CCMT indexable inserts, offering compact dimensions and robust clamping for production and workshop use. SCLCR 1212 profile for CCMT inserts 12 × 12 mm shank for compact toolposts 110 mm overall length for tight bores Rigid clamping with 16 mm cutting height Precision and rigidity for repeatable turning The holder is designed to deliver stable clamping and predictable performance in external turning applications. Built to the SCLCR 1212 ISO form, the tool provides a low-mass, rigid interface between machine and insert; the 12 × 12 mm shank and short overall length reduce overhang and thus minimise vibration. Compatibility with CCMT format inserts ensures easy tool changes and familiar insert geometry, so production tolerances remain consistent and downtime for tool swaps is reduced. Compact design for confined machining envelopes With an overall length of 110 mm and a compact head width of 16 mm, this turning holder suits machines and bores where access is limited. The reduced reach translates directly into better deflection control and improved surface finish when working in tighter spaces. The right-hand cutting direction and a 95° cutting angle are optimised for standard external turning cycles, enabling stable chip control and predictable cutting forces during moderate to light turning operations. Simple compatibility and dependable workshop workflow Integration is straightforward: the holder accepts CC-- 09T3 style inserts (CCMT family) and references the J09 boring-bar designation for fitting checks. The modest weight (approx. 0.14 kg) and standard shank size make mounting in common toolposts uncomplicated, while the 16 mm cutting height aligns with many insert geometries to keep insert projection minimal. For production environments this means fewer adjustments between jobs and a predictable tool life that supports efficient machining planning. For tailored technical advice and reliable supply of the Teknik Cutting Tools SCLCR 1212 clamping holder, contact Metav Werkzeuge in Emmerich at +49 2822 7131930 or info@metav-werkzeuge.com to confirm machine compatibility and delivery options. Technical Data Article number: D400TM Manufacturer: Teknik Makina ISO designation: SCLCR 1212 Facts Overall length: 110 mm Shank size: 12 × 12 mm Cutting height: 16 mm Cutting head width: 16 mm Weight: 0.14 kg Cutting angle: 95° Direction: right-hand Special features Compatible inserts: CC-- 09T3 (CCMT) Boring-bar designation: J09 Intended for external turning with indexable inserts FAQ Which inserts fit this holder? The SCLCR 1212 clamping holder is compatible with CC-- 09T3 style inserts (CCMT family), designed to accept standard CCMT geometry. Is this a right-hand or left-hand tool? This turning holder is supplied for right-hand cutting; the SCLCR 1212 geometry and 95° approach angle are configured for right-hand external turning. What shank and mounting size is required? The holder uses a 12 × 12 mm shank and is suitable for compact toolposts accepting that standard square profile; refer to the SCLCR 1212 dimensions for mounting checks. What is the overall length and where is it best used? With an overall length of 110 mm, the holder works well in confined machining envelopes and short-reach turning operations where reduced overhang is beneficial. Can this holder be used in serial production? Yes — the consistent clamping, standard insert compatibility and compact design of this holder support repeatable results and efficient tool-change procedures in series machining. Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
110mm Clamping Holder 93° SVJBL 1010 J11 For VBMT 1103 Indexable Inserts Left-Hand Cutting Interior Coolant - Teknik Makina
Combine secure clamping, compact geometry and precise compatibility with VBMT 1103 inserts to reduce setup time and improve surface finish — order the holder via Metav Werkzeuge or ask our specialists for application guidance. Klemmhalter SVJB — SVJB for VBMT Indexable Inserts, left‑hand holder (Teknik Makina) Klemmhalter SVJB for VBMT Indexable Inserts is a left‑hand turning toolholder designed to accept VBMT 1103 indexable inserts, offering compact dimensions for confined toolposts and reliable seating for repeatable turning operations Left‑hand cutting direction Designed for VBMT 1103 inserts ISO SVJBL 1010 designation Compact 110 mm overall length Improve machining efficiency with precise insert compatibility The holder is engineered primarily for compatibility with VBMT 1103 indexable inserts and carries the ISO SVJBL 1010 designation, which standardises mounting and geometry across toolmakers. By matching the insert pocket and clamping plane to the insert form, repeatable seating is achieved and downtime for adjustment is reduced. The 93° cutting angle helps maintain predictable chip flow and tool engagement, translating into steadier cutting forces and fewer scrap parts. For production environments where cycle time and consistency matter, the standardised interface is a direct contributor to process reliability. Compact profile to reduce overhang and vibration With an overall length of 110 mm, a head width of 12 mm and a holder width of 10 mm, this toolholder is suited to tight toolpost arrangements. The reduced overhang and compact head minimise vibrational tendency, which benefits surface finish and extends insert life. At just 0.097 kg, the body contributes very little inert mass to the tool turret, making it a practical choice when short radii and confined spaces demand a small but rigid solution. These dimensional advantages support higher feeds and uninterrupted production on small‑batch and batch‑size‑one work. Secure clamping and straightforward mounting for reliable turning A clear mechanical interface and the shank designation J11 allow compatibility with standard mounting systems, while the defined clamping geometry supports fast insert changes and firm fixation during heavy cuts. The left‑hand cutting direction is specified for operations where tool orientation relative to spindle rotation is critical. The design simplifies the use of indexable carbide inserts — a replaceable cutting edge that reduces tooling cost and simplifies stockkeeping — and is particularly effective for facing and medium‑depth external turning. The Teknik Makina holder combines a user‑oriented layout with industrial robustness to support uninterrupted shopfloor performance. For dependable left‑hand turning with VBMT 1103 inserts, request application advice or place an order via Metav Werkzeuge — email info@metav-werkzeuge.com or call +49 2822 7131930 Technical Data Article number: D370TM Manufacturer: Teknik Makina Designation: SVJB for VBMT Indexable Inserts ISO designation: SVJBL 1010 Cutting direction: left Compatible inserts: VBMT 1103 Shank designation: J11 Weight: 0.097 kg Key Measurements Overall length: 110 mm Head width: 12 mm Holder width: 10 mm Holder height: 10 mm Cutting height: 21 mm Cutting angle: 93° Features Left‑hand cutting direction For VBMT 1103 indexable inserts ISO SVJBL 1010 interface Shank designation J11 FAQ Which inserts are compatible with this holder? The holder accepts VBMT 1103 indexable inserts; compatibility is defined by the insert form and the ISO SVJBL 1010 pocket used on the SVJB toolholder (SKU D370TM). Is this toolholder for left‑hand or right‑hand turning? This SVJB holder is configured for left‑hand turning, matching the specified cutting direction and the intended spindle rotation for left‑side operations. What are the main dimensions to check for toolpost clearance? Key dimensions are overall length 110 mm, head width 12 mm and holder width 10 mm; these values are useful when assessing clearance in a confined toolpost. How does the ISO designation affect setup? The ISO SVJBL 1010 designation standardises the pocket geometry and seating, simplifying insert changes and ensuring repeatable positioning across compatible holders. Can this holder be mounted on standard J11 shanks? Yes — the toolholder lists shank designation J11, indicating compatibility with corresponding mounting systems designed for that shank form. Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
110mm Cutting Holder SVJBL 1212 J11-F For VBMT 1103 Inserts Innenkühlung Linksschneidend - Teknik Makina
Benefit from precise left-hand turning, a compact 12 mm head and compatibility with VBMT 1103 indexable inserts; the result is stable clamping, predictable repeatability and efficient changeovers — order the clamping toolholder directly via Metav Werkzeuge or ask our consultants for tailored advice. SVJB clamping toolholder for VBMT indexable inserts — SVJBL 1212, 12 mm head, left-hand (Teknik Makina) The SVJB clamping toolholder for VBMT indexable inserts is a left-hand turning holder designed to secure VBMT 1103 inserts for consistent, shop-floor turning operations. Turning toolholder SVJBL 1212 Compatible with VBMT 1103 inserts 12 mm head width and height Left-hand cutting direction Precision clamping for repeatable turning results A compact toolholder with a 12 mm head dimension and ISO designation SVJBL 1212 provides a small footprint without compromising stability. The design yields a reliable clamping position that translates into improved repeatability part after part. With a cutting angle of 93° and a 22 mm cutting-edge height, the holder supports consistent tool geometry, which reduces set-up deviations and helps maintain dimensional tolerances on serial runs. The combination of compact geometry and robust clamping is particularly advantageous where space is limited but process reliability is essential. Fast changeovers and predictable machining behaviour The holder’s overall length of 110 mm and lightweight construction (0.132 kg) simplify handling and tool-station layout while keeping the centre of mass close to the spindle. The shank designation J11-F facilitates mounting in standard tool posts and contributes to stability during cutting. Designed for indexable inserts such as VBMT 1103, the system enables quick insert changes and predictable cutting performance, reducing downtime and improving throughput. The left-hand orientation makes it suitable for operations that require cutting in the left direction without adapting insert geometry. Practical advantages for workshop and production environments This clamping solution addresses common workshop needs: compact installation, easy insert replacement and consistent clamping force for repeat production. The holder’s compatibility with industry-standard VBMT inserts ensures access to a wide range of grades and geometries for different cutting tasks. For production engineers and toolroom managers, the clear ISO designation and standard shank form help standardise tool inventory and simplify reordering. Where reliable, repeatable turning is required, the compact holder supports stable cutting conditions and lean tool management. For expert guidance on integrating this Teknik Makina SVJBL 1212 holder into existing setups, contact Metav Werkzeuge in Emmerich — phone +49 2822 7131930 or email info@metav-werkzeuge.com for specification matching and procurement assistance Technical data Article number: D396TM Manufacturer: Teknik Makina SKU: D396TM Designation: Klemmhalter / SVJB for VBMT indexable inserts Facts Overall length: 110 mm Head width: 12 mm Head height: 12 mm Cutting-edge height: 22 mm Weight: 0.132 kg Cutting angle: 93° Special features ISO designation: SVJBL 1212 Shank designation: J11-F Compatible insert: VBMT 1103 Cutting direction: Left FAQ What insert type fits this holder? The holder accepts VBMT 1103 indexable inserts; the SVJBL 1212 designation confirms compatibility with that insert format. Is the toolholder left- or right-hand oriented? This clamping toolholder is specified for left-hand cutting operations, suited to left-direction turning tasks. What are the key dimensions that affect setup? Relevant dimensions include a 12 mm head width and height, 110 mm overall length and a 22 mm cutting-edge height. Can this holder be mounted in standard tool posts? Yes — the J11-F shank designation aligns with common tool-post interfaces for straightforward mounting. How does the holder support repeatability in production? The compact head, clear ISO designation and stable clamping geometry deliver consistent seating and repeatable tool positioning for serial turning. Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
110mm Klemmhalter 62.5° SDNCN 1212 J11 for DC-- 11T3 Inserts Innenkühlung Rechtsschneidend - Teknik Makina
Compact 110 mm overall length combined with ISO SDNCN 1212 compatibility and a fixed 62.5° cutting angle delivers precise external turning in tight toolings; the robust clamping geometry and simple insert interface enable stable machining and consistent surface finish. Order the clamping holder directly via Metav Werkzeuge or ask our consultants if needed. Clamping holder SDNCN 1212 — SDNCN tool holder for DC-- 11T3 indexable inserts, 110 mm overall length (Teknik Makina) A Clamping holder SDNCN 1212 engineered for external turning with DC-- 11T3 indexable inserts, optimised for compact setups and repeatable tool positioning SDNCN mounting for DC-- 11T3 inserts Compact 110 mm overall length 12 × 12 mm shank format for stable clamping 62.5° cutting angle for consistent chip flow Stable external turning in confined setups The SDNCN 1212 tool holder is designed to deliver consistent cutting geometry in restricted tool spaces. Its compact 110 mm overall length reduces overhang and improves rigidity, which directly benefits repeatability and dimensional stability during short-run and batch turning. By accepting standard indexable inserts of the DC-- 11T3 family, the holder shortens changeover times and minimises downtime while preserving a predictable tool path for accurate part tolerances. Rigid fit for reduced vibration and longer insert life A focused clamping cross-section of 12 × 12 mm and a narrow cutting-head width of 6 mm provide a secure seat for the insert, lowering micro-movement at the cutting edge. The defined 25 mm cutting height and fixed 62.5° approach angle help to control chip formation and heat input, which typically leads to improved surface finish and extended insert life. With a mass of 0.131 kg, the tool holder balances low inertia with structural stiffness, supporting stable spindle dynamics for short to medium-length turning operations. Quick integration and workshop-friendly specification Marked as SDNCN 1212 to match ISO tool-holder conventions, the unit fits common tool blocks and is compatible with a J11 shank designation for straightforward mounting. The straightforward design removes complex adjustments while maintaining a positive clamping face for the DC-- 11T3 inserts, enabling rapid assembly into existing turning stations. Backed by the Teknik Makina designation, the component suits workshops that prioritise compact, reliable tooling without introducing unnecessary setup complexity. Contact Metav Werkzeuge for tailored advice on integrating the Teknik Makina SDNCN 1212 clamping holder into production: info@metav-werkzeuge.com | +49 2822 7131930 Technical Data Article number: D118TM Manufacturer: Teknik Makina ISO designation: SDNCN 1212 Compatible insert type: DC-- 11T3 Facts Overall length: 110 mm Shank height: 12 mm Shank width: 12 mm Cutting-head width: 6 mm Cutting height: 25 mm Cutting angle: 62.5° Weight: 0.131 kg Features Shank designation: J11 For use with indexable inserts DC-- 11T3 SDNCN tool holder style SKU: D118TM Brand: Teknik Makina FAQ Which insert families fit the holder? The clamping holder accepts DC-- 11T3 indexable inserts; the SDNCN 1212 interface is matched to that insert geometry for secure seating and consistent cutting orientation. What are the shank and mounting dimensions? Shank dimensions are 12 × 12 mm with an overall length of 110 mm, and the holder is designated J11 for mounting compatibility with standard tool posts. How does the 62.5° cutting angle affect machining? A fixed 62.5° approach angle focuses the cutting forces and improves chip control for many external turning tasks, helping to maintain surface quality and predictable insert wear with the SDNCN 1212. Can the holder be used for high-speed turning? The SDNCN 1212’s compact geometry and low mass (0.131 kg) reduce overhang and support stable spindle dynamics; suitability for high-speed applications depends on insert grade and machine parameters. What is the ISO designation for ordering and referencing? Order and reference the part as SDNCN 1212 (SKU: D118TM) from Teknik Makina for consistent identification. Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
110mm Klemmhalter 93° SVJBL 1212 J11 For VBMT 1103 Wendeplatten Innenkühlung Linksschneidend - Teknik Makina
Robust left-hand clamping, standard ISO fitting and compact dimensions combine to deliver stable, repeatable turning performance with VBMT 1103 inserts; the SVJB design reduces set-up time and improves process reliability when fitted into medium-reach turning operations. Order or request application advice directly from Metav Werkzeuge for fast, expert procurement. SVJB for VBMT Indexable Inserts (SVJBL 1212) — left-hand clamping holder, 110 mm overall length — Teknik Makina The SVJB for VBMT Indexable Inserts is a left-hand clamping holder engineered for secure mounting of VBMT 1103 turning inserts in general turning and finish operations, offering standard ISO fitting and compact geometry for stable chip control Compatible with VBMT 1103 inserts Left-hand tool holder for turning 110 mm overall length for deep reach Solid clamping with a 93° cutting angle Precision clamping for consistent turning outcomes The tool holder delivers a measurable increase in process stability through a solid clamping arrangement and an engineered tool geometry that supports consistent insert seating. Compatibility with VBMT 1103 indexable inserts ensures a wide selection of carbide grades and chipbreakers can be used, allowing optimisation for both roughing and finishing. The holder’s 110 mm overall length balances access to workpieces with reduced overhang, lowering vibration and contributing to longer insert life. Geometry that improves cutting control and productivity A dedicated left-hand configuration with a 93° cutting angle concentrates cutting forces into a controlled vector, which reduces chatter and helps maintain surface finish. The holder’s compact cutting head — 16 mm width — and a cutting height of 21 mm enable predictable tool positioning and repeatable depth-of-cut results. Reduced variability in setup translates into fewer adjustments at the machine, improving throughput in small- to medium-batch production. Practical design for faster changeovers and safe handling Built to ISO reference SVJBL 1212 with shank designation J11, the holder is light and manageable at 0.141 kg, easing manual handling during tool changes and storage. A 12 mm holder height ensures a low centre of gravity in many tool posts, simplifying alignment and reducing the need for additional shims. These characteristics minimise downtime during insert changes and support reliable returns to size after each re-installation. Suited to mixed-shop workflows and repeatable results This left-hand clamping solution is appropriate for workshops requiring flexible tooling that interfaces with standard VBMT inserts and conventional tool posts. The combination of compact dimensions, ISO conformity and the Teknik Makina design philosophy gives machining centres and manual lathes a dependable option for turning tasks where repeatability and secure clamping are priorities. The straightforward specification eases procurement and inventory management across multi-machine environments. For procurement guidance or application-specific advice on this Teknik Makina SVJB clamping holder contact Metav Werkzeuge in Emmerich for direct supply and technical consultation: info@metav-werkzeuge.com or +49 2822 7131930 Technical Data Article number: D372TM Manufacturer: Teknik Makina Designation: SVJB for VBMT Indexable Inserts ISO designation: SVJBL 1212 Core specifications Overall length: 110 mm Cutting height: 21 mm Cutting head width: 16 mm Holder height: 12 mm Weight: 0.141 kg Cutting angle: 93° Direction: left Special features For inserts: VBMT 1103 Shank designation: J11 Left-hand orientation Brand: Teknik Makina FAQ Which inserts fit this holder? The holder is specified for VBMT 1103 indexable inserts and accepts the standard insert geometry for that designation. Is the holder left- or right-hand? This tool holder is a left-hand orientation; it is designed for turning operations taking the cut in the left direction. What is the overall length and how does it affect reach? Overall length is 110 mm, offering a balance between reach and rigidity suitable for medium-reach turning tasks. What is the cutting height and why does it matter? Cutting height is 21 mm, which determines the insert tip position relative to the tool post and affects tool set-up and geometry. What ISO identification should be used for ordering and mounting? Order using the ISO designation SVJBL 1212 and check shank reference J11 for compatible tool posts and bores. Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
110mm Klemmhalter 93° SVJBR 1212 J11-F For VBMT 1103 Indexable Inserts Innenkühlung Rechtsschneidend - Teknik Makina
Compact right-hand design with a 12 × 12 mm cutting head, 93° cutting angle and a 110 mm total length for stable turning performance; combine precision, compatibility and low mass for productive machining — order through Metav Werkzeuge or consult our technical advisors for application-specific recommendations. Klemmhalter (SVJBR 1212) – Right-hand clamping holder for VBMT 1103 inserts by Teknik Makina The Klemmhalter is a right-hand clamping holder intended for turning operations using VBMT 1103 indexable inserts; designed for small- to medium-batch production and workshop use Right-hand orientation for turning operations Compatible with VBMT 1103 indexable inserts 12 × 12 mm cutting head dimensions 110 mm total length for extended reach Consistent rigidity and repeatable machining results The holder delivers mechanical stability by concentrating mass where it matters: at the cutting head. The compact 12 × 12 mm cutting head and a 22 mm cutting height are engineered to reduce vibration and maintain a consistent chip former geometry when used with VBMT 1103 inserts, which supports repeatable surface finish and dimensional control. The modest mass (approx. 0.132 kg) and the clear 93° cutting angle favour quick acceleration on CNC turrets and manual lathes alike, improving cycle times without compromising process stability. Faster insert changes and secure clamping for uptime The SVJBR 1212 designation identifies a straightforward clamping concept that prioritises safe and fast insert replacement. The toolholder accepts standard VBMT 1103 inserts and secures them reliably with a proven clamp geometry, enabling short maintenance intervals and reduced machine downtime. The shank designation J11‑F aids configuration in modular tooling systems, while the right-hand orientation aligns with common turning setups, resulting in predictable tool paths and fewer setup adjustments. Optimised for workshop and production environments With a 110 mm total length and a compact footprint, this holder is suitable where access is limited but rigidity remains essential. The combination of compact dimensions and a defined cutting geometry supports both roughing passes and small finishing cuts, making the product a practical choice for jobbers and contract manufacturers. Its lightweight construction simplifies handling during tool changes and tooling inventory management, while compatibility with established insert grades keeps spare-stock requirements minimal. For application advice on the Teknik Cutting Tools SVJBR 1212 clamping holder or to discuss suitable insert grades and machining parameters, contact Metav Werkzeuge in Emmerich via info@metav-werkzeuge.com or call +49 2822 7131930 to receive tailored assistance and procurement support Technical data Article number: D129TM Manufacturer: Teknik Makina ISO designation: SVJBR 1212 For inserts: VBMT 1103 Facts Cutting head width: 12 mm Cutting head height: 12 mm Cutting height: 22 mm Total length: 110 mm Weight: 0.132 kg Cutting angle: 93° Direction: right-hand Special features Compatible with VBMT 1103 indexable inserts Shank designation: J11-F SVJB design for secure clamp retention FAQ Which indexable inserts fit this holder? The holder is designed for VBMT 1103 indexable inserts; the clamping geometry matches standard VBMT insert sizes used in turning. Is the holder right- or left-hand oriented? This toolholder is a right-hand clamping holder and is intended for standard right-hand turning operations. What are the key dimensions to check for turret mounting? Relevant dimensions include the 12 × 12 mm cutting head, 110 mm total length and the shank designation J11‑F for mounting compatibility. Can this holder be used for finishing passes? Yes, the combination of a 93° cutting angle and the stable clamping design makes the holder suitable for light finishing when paired with appropriate inserts. What is the SKU and manufacturer reference? The SKU is D129TM and the holder is supplied by Teknik Makina under the ISO designation SVJBR 1212. Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
110mm Klemmhalter 93° SVJBR 1212 J11-IK For VBMT 1103 Indexable Inserts Innenkühlung Right-Hand Cutting - Teknik Makina
Benefit from a robust combination of internal coolant, compatibility with VBMT 1103 inserts and precise right-hand cutting geometry to streamline turning operations; order the clamp holder directly via Metav Werkzeuge or request technical advice from our consultants. Teknik Makina SVJBR 1212 clamp holder — SVJB for VBMT indexable inserts, internal coolant, right-hand SVJBR 1212 clamp holder designed for right-hand turning with VBMT 1103 indexable inserts, offering internal coolant and compact dimensions for stable machining in workshop and light industrial setups Right-hand cutting orientation Internal coolant supply Compatible with VBMT 1103 inserts 110 mm overall length Consistent right-hand turning with predictable chip control The SVJBR 1212 clamping system is engineered to deliver repeatable turning results on right-hand operations. Its 93° cutting angle and defined cutting height of 32 mm set a stable geometry that reduces vibration and improves surface finish during medium-duty turning. The combination of a 16 mm cutter-head width and a compact 110 mm overall length makes the toolholder suitable for confined setups where rigidity and consistent tool projection are required. This predictable behaviour supports higher process yields and reduced scrap rates in batch production. Internal coolant for improved tool life and process reliability Built-in internal coolant directs cutting fluid close to the insert edge, cooling the contact zone and aiding chip evacuation. This targeted cooling helps to extend insert life, particularly when using VBMT 1103 grade inserts in interrupted cuts or when machining harder materials. The presence of internal coolant is a pragmatic feature for shops seeking to increase tool-change intervals and lower tooling costs per part, while maintaining cutting performance under sustained cycle times. Compact design that simplifies set-up and increases versatility With a holder width of 12 mm and a clamp height of 12 mm, the unit combines a space-saving profile with clear mechanical stability. The ISO designation SVJBR 1212 and the J11-IK mounting form ensure straightforward interchangeability with compatible boring bars and tool posts. The tool’s modest mass of 0.141 kg contributes to lower centrifugal loads at higher spindle speeds and makes handling simpler during tool changes, while the precise Torx fastener interface (T8 key, M2.5x6.5 screw) ensures secure and repeatable clamping of the insert. Practical features for workshop efficiency Assembly and adjustment are streamlined by the Torx screw fixation and standardised shank interface, which reduce setup time and alignment effort. The holder’s dimensions and right-hand orientation are chosen to match common turning applications where access and chip flow demand a compact, coolant-fed solution. For operations prioritising process stability and cost-effective tooling, this indexable-insert holder provides a balanced combination of precision, practicality and straightforward maintenance. For a tailored recommendation on incorporating the Teknik Makina SVJBR 1212 clamp holder into existing turning centres, contact Metav Werkzeuge for detailed specifications or to discuss compatibility with current tooling at info@metav-werkzeuge.com or call +49 2822 7131930 Technical data Article number: AP541TM Manufacturer: Teknik Makina Designation: Klemmhalter / SVJB for VBMT Indexable Inserts Dimensions and key figures Overall length: 110 mm Cutter head width: 16 mm Holder width: 12 mm Clamp height: 12 mm Cutting height: 32 mm Cutting angle: 93° Weight: 0.141 kg ECLASS: 21181004 Compatibility and features For inserts: VBMT 1103 Cutting direction: Right Internal coolant: Yes ISO designation: SVJBR 1212 Mounting: J11-IK Torx key: T8 Torx screw: M2.5x6.5 FAQ Which inserts fit this clamp holder? The clamp holder is compatible with VBMT 1103 indexable inserts and is optimised for that insert form factor and edge geometry. Is the holder suitable for internal coolant delivery? Yes, the Teknik Makina SVJBR 1212 clamp holder features internal coolant to support cooling and chip evacuation at the cutting edge. What is the cutting orientation of the holder? The toolholder is designed for right-hand cutting operations and provides a 93° cutting angle for stable turning. Which Torx key is required for insert clamping? Clamping is secured using a T8 Torx key with an M2.5x6.5 Torx screw for repeatable fixation. Can this holder be mounted on common boring bars? The holder uses the J11-IK mounting designation, enabling straightforward integration with compatible tool posts and boring-bar systems. Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
110mm Klemmhalter 93° SVJCR 1010 J11 For VCMT 1103 Indexable Inserts Innenkühlung Rechtsschneidend - Teknik Makina
Take advantage of a compact, right-hand tool holder that combines secure clamping and precise indexable-insert compatibility for consistent turning results; order or request technical advice from Metav Werkzeuge to ensure optimal integration into existing CNC workflows. Klemmhalter SVJCR 1010 — SVJC tool holder for VCMT inserts by Teknik Makina The Klemmhalter SVJCR 1010 is a right-hand turning holder designed for use with VCMT 1103 indexable inserts, suitable for medium-duty external turning and finishing applications Right-hand turning holder For VCMT 1103 indexable inserts 10 mm shank width, 12 mm head width Robust 110 mm overall length Stable clamping for reliable chip control The holder is engineered for secure clamping of triangular indexable inserts, providing repeatable seating that reduces micro-vibration and contributes to a consistent surface finish. The specified cutting angle of 93° ensures an optimised tool geometry for common external turning tasks, while the right-hand orientation matches standard machine-tool setups. Compatibility with VCMT 1103 inserts offers quick insert replacement and predictable cutting behaviour across batches, supporting process stability in serial production. Clear mechanical seating and an appropriately sized clamp contribute to reduced rework and improved cycle-time consistency. Compact dimensions that support rigidity and access Space-conscious workshops benefit from the holder's measured form factor: a 10 mm shank width, 12 mm head width and 21 mm cutting height are combined into a compact 110 mm overall length, yielding low overhang and improved stiffness at the cutting edge. The modest mass (about 0.086 kg) minimises inertial loads while preserving clamping force, which helps when working on smaller lathes or tooling stations with limited clearance. These dimensions allow close tool placement in multi-tool turrets and reduce the risk of chatter when paired with appropriately rated inserts and machine settings. Industry-ready design for predictable production Designated SVJCR 1010 to the ISO-style convention, the holder is suited for integration into standard turning tool inventories and is compatible with commonly stocked VCMT 1103 grades. The combination of a compact profile and standard mounting geometry facilitates quick tool changes and straightforward programming adaptations on CNC machines. As a production-grade clamping solution from Teknik Makina, this holder supports repeatability across shifts and operators, helping to maintain throughput while reducing scrap rates and setup times. Contact Metav Werkzeuge for tailored advice on integrating the Teknik Cutting Tools SVJCR 1010 holder into production — technical consultation and parts supply are available by phone +49 2822 7131930 or via e‑mail info@metav-werkzeuge.com Technical data Article number: D239TM Designation: SVJC for VCMT indexable inserts (SVJCR 1010) Brand: Teknik Makina Weight: 0.086 kg Key dimensions Shank width: 10 mm Head (cutting) width: 12 mm Holder height: 10 mm Cutting height: 21 mm Cutting angle: 93° Overall length: 110 mm Special features Compatible with VCMT 1103 indexable inserts ISO-style designation: SVJCR 1010 Right-hand orientation Boring bar designation: J11 FAQ Which inserts fit this holder? The holder accepts VCMT 1103 indexable inserts; SVJCR 1010 is configured for the standard clamping geometry of that insert type. Is the holder right- or left-hand? This tool holder is supplied as a right-hand turning holder suitable for conventional turning directions. What are the key dimensions affecting rigidity? Relevant dimensions are the 10 mm shank width, 12 mm head width and 110 mm overall length, which together influence stiffness and overhang. Can the holder be used for finishing operations? Yes; the combination of a 93° cutting angle and compatibility with finishing grades of VCMT inserts makes this holder suitable for many finishing and light roughing tasks. Manufacturer: Teknik Cutting Tools; Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
110mm Klemmhalter 95° SCLCR 1010 J06 for CC-- 0602 Wendeplatten Innenkühlung Rechtsschneidend - Teknik Makina
Take advantage of a compact, ISO‑specified toolholder that delivers stable clamping and predictable chip control thanks to a 10 mm insert height and a 95° cutting angle; procure the component directly via Metav Werkzeuge or consult the technical team for configuration advice. Clamping holder SCLC for CCMT indexable inserts (SCLCR 1010), right‑hand — Teknik Makina Clamping holder SCLC for CCMT indexable inserts, a right‑hand toolholder for standard turning tasks offering secure clamping and consistent cutting geometry Right‑hand SCLC toolholder for CCMT inserts ISO designation SCLCR 1010 10 mm cutting height for stable clamping Consistent turning performance for repeatable results The compact toolholder is engineered to provide repeatable performance in batch production and maintenance work. Its compatibility with CCMT 0602 indexable inserts and the 95° cutting angle create a cutting geometry that favours predictable chip flow and steady cutting forces, which in turn reduces vibration and improves surface finish. The holder’s constructive stability contributes to longer insert life and fewer re‑set operations, supporting more efficient machine cycles and reduced downtime. Fast, secure set‑up that streamlines workshop routines A clear ISO reference — SCLCR 1010 — and standardised shank designation simplify ordering and fixturing. The toolholder’s 10 mm cutting height and head width of 12 mm make for straightforward alignment with common toolposts, while the overall length of 110 mm balances reach with rigidity. The modest mass (0.105 kg) reduces carriage inertia during rapid traverses and helps preserve toolpath accuracy. These features combine to cut set‑up time and improve reproducibility between jobs. Practical application and technical fit for turning operations Designed for right‑hand turning, this SCLC toolholder accepts CCMT 0602 inserts and is suited to routine contouring and facing operations where secure clamping and defined cutting angle matter. The ISO designation ensures interchangeability with existing toolsets and assists in process planning. For material‑specific guidance or to confirm the best insert grade and geometry for a given machining task, Metav Werkzeuge’s consultants are available to advise on the optimal combination of holder, insert and cutting data. For ordering, technical recommendations or to discuss mounting options for the Teknik Makina SCLC toolholder (SKU D398TM), contact Metav Werkzeuge — available by e‑mail at info@metav-werkzeuge.com or by phone at +49 2822 7131930 for prompt, workshop‑centred advice Technical data SKU: D398TM Manufacturer: Teknik Makina Article designation: SCLC for CCMT indexable inserts Core measurements Cutting height: 10 mm Head width: 12 mm Body width: 10 mm Overall length: 110 mm Cutting angle: 95° Weight: 0.105 kg Special features ISO designation: SCLCR 1010 Compatible insert format: CCMT 0602 Cutting direction: right Shank / bar designation: J06 FAQ Which insert size fits this toolholder? The toolholder is specified for CCMT 0602 indexable inserts; the geometry and clamping seat are matched to that insert format. Is the holder right‑hand or left‑hand? This SCLC toolholder is a right‑hand version, designed for conventional right‑hand turning operations. What is the ISO designation for ordering and replacement? Ordering and replacement reference is SCLCR 1010, which helps ensure interchangeability across standard tool posts. How does the 10 mm cutting height affect setup? A 10 mm cutting height places the insert at a standard working centre, reducing setup adjustments and simplifying alignment with common toolposts. Can this holder be used with alternative insert grades? The clamping seat accepts CCMT 0602 inserts, allowing selection of different grades and geometries according to the work material and machining strategy; Metav Werkzeuge can advise on grade selection. Manufacturer / Responsible: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
110mm Klemmhalter 95° SCLCR 1010 J06-F For CCMT 0602 Indexable Inserts Innenkühlung Rechtsschneidend - Teknik Makina
Take advantage of a compact, ISO‑conforming turning holder that combines precise clamping for CCMT 0602 inserts with a defined 95° cutting angle and a convenient 110 mm overall length — the result is consistent external turning and reliable insert indexing. Order directly via Metav Werkzeuge or contact the technical sales team for application advice. SCLC for CCMT Indexable Inserts (SCLCR 1010) – right‑hand turning holder by Teknik Makina A robust SCLC for CCMT Indexable Inserts designed for right‑hand external turning, compatible with CCMT 0602 indexable inserts and engineered to fit standard ISO SCLCR 1010 toolpost systems. Compatible with CCMT 0602 inserts ISO SCLCR 1010 designation Right‑hand orientation 95° cutting angle Precision clamping for repeatable turning results The SCLCR 1010 style holder offers precise clamping and a compact profile that supports repeatable indexable insert seating. With a head height of 10 mm and a defined seating for CCMT 0602 inserts, the design reduces play at the cutting edge and keeps tool run‑out low. That stability translates into more consistent surface finish and prolonged insert life, because the insert is held firmly at the designed bite point rather than relying on ad‑hoc fixtures. The ISO designation guarantees compatibility with existing toolposts and simplifies tool inventory management. Stable geometry for controlled cuts and easy set‑up Engineered with a 95° cutting angle and a right‑hand orientation, the holder directs cutting forces predictably for external turning operations. The unit’s 110 mm overall length and modest mass (0.106 kg) make it simple to position in a toolpost while maintaining rigidity; shorter overhang reduces deflection and vibration. The SCLC form factor permits quick indexable insert replacement and re‑seating, which minimises machine downtime. For shops seeking consistent cycle times and lower scrap rates, the controlled geometry is a tangible operational advantage. Practical supply and application support for workshop integration Supplied with a standard SCLCR interface and identified as SKU D422TM, the holder integrates into common lathe setups and forms part of a pragmatic tooling strategy. Metav’s distribution from Emmerich acts as a quality checkpoint for the European market, ensuring dependable availability and clear traceability. For applications that demand predictable machining outcomes, this holder delivers a compact, industry‑aligned solution while allowing selection of insert grades and coatings to match specific material challenges. Contact Metav Werkzeuge for tailored application advice on the Teknik Cutting Tools SCLC turning holder (SKU D422TM) and to discuss the optimal insert grade and set‑up for the intended machining task. Technical data Article number: D422TM Type designation: SCLCR 1010 For inserts: CCMT 0602 Orientation: right‑hand Cutting angle: 95° Overall length: 110 mm Head height: 10 mm Head width: 10 mm Holder width: 10 mm Weight: 0.106 kg Boring bar designation: J06‑F Brand: Teknik Makina Measurements Overall length: 110 mm Head height: 10 mm Head width: 10 mm Holder width: 10 mm Weight: 0.106 kg Cutting angle: 95° Special features SCLC design for CCMT indexable inserts Compatible with CCMT 0602 ISO: SCLCR 1010 Right‑hand orientation 95° cutting angle Boring bar designation: J06‑F FAQ Which inserts fit this holder? Compatible with CCMT 0602 indexable inserts; the holder is configured for standard CCMT pocket seating. Is the holder right‑hand or left‑hand? This SCLC holder is a right‑hand version, intended for conventional right‑hand external turning. What does the 95° cutting angle mean in practice? A 95° cutting angle provides a near‑orthogonal approach to the workpiece that balances cutting edge strength with accessibility for profiling and facing operations. How is the holder referenced and ordered? The item is listed as SKU D422TM, type SCLCR 1010, from Teknik Makina; use that reference when specifying the component for procurement. Can the holder be used with different insert grades for various materials? Yes, the mechanical seat fits CCMT 0602 inserts; select the appropriate insert grade and coating separately to match the workpiece material and cutting conditions. Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
Precision coolant delivery for demanding turning operations
Tool holders with internal coolant are precision components used in machining, particularly turning, to hold indexable inserts securely and feed them to the workpiece. Also referred to as through-coolant tool holders or internal coolant toolholders, these systems channel coolant directly to the cutting edge to reduce thermal load and improve chip control in heavy or high-speed machining.
How they work and where they help most
Standard holders without internal coolant rely on external nozzles, which can be blocked by chips and fail to reach the insert tip reliably. In contrast, holders with internal coolant contain integrated coolant channels and boreholes in the tool shank that guide the coolant under pressure straight to the insert. This targeted supply is particularly valuable for difficult-to-machine materials, high cutting speeds, deep cuts and internal turning where conventional coolant delivery struggles.
Key facts
| characteristic | detail |
|---|---|
| category | tool holders with internal coolant |
| common synonyms | internal coolant toolholders; coolant-through tool holders |
| typical application | turning, heavy machining, internal bore finishing |
| coolant routing | internal channels and boreholes delivering coolant to the insert seat |
| key technical effect | direct cooling at the cutting edge, improved chip evacuation, reduced thermal load |
| comparison | standard holders use external nozzles; internal coolant holders route coolant through the shank |
Measurable benefits for production
- Direct coolant feed reduces the thermal stress on the insert, extending tool life.
- Improved pressure at the cutting zone enhances chip evacuation, reducing recutting and tool damage.
- More consistent cooling helps achieve better surface finish and dimensional stability.
- Reliable coolant delivery under challenging chip conditions supports higher cutting speeds and heavier cuts.
Metav: precision supply and industrial competence
Metav positions itself as the practical partner for workshops and production: a European quality filter based in Emmerich that combines broad product availability with technical expertise. With over 48,000 customers and more than 250,000 products, Metav supplies through-coolant tool holders and related accessories with dependable logistics and application guidance, making sophisticated cooling solutions accessible for every workshop.
In short
Tool holders with internal coolant deliver targeted, high-efficiency coolant to the insert tip, improving chip control, tool life and surface quality in demanding turning tasks.
FAQ
When should I choose tool holders with internal coolant over standard holders?
Choose tool holders with internal coolant when external coolant nozzles cannot reliably reach the cutting edge, for deep cuts, internal turning, heavy machining or when machining difficult materials at high speeds. The internal coolant toolholders ensure direct cooling and better chip evacuation in these scenarios.
Can internal coolant toolholders be used with all insert types?
Internal coolant toolholders are compatible with most indexable inserts provided the holder and insert interface are specified for coolant-through operation. Verify seat type and manufacturer recommendations for coolant-through compatibility.
What performance improvements can I expect from coolant-through tool holders?
Typical improvements include longer tool life, fewer interruptions from clogged external nozzles, improved chip control and a more consistent surface finish due to reduced thermal distortion at the cutting edge.
How is coolant delivered inside an internal coolant toolholder?
Coolant is channelled through boreholes and internal passages in the tool shank directly to the insert pocket; this focused path creates sufficient pressure at the cutting edge to flush chips away and cool the insert effectively.
