75–100mm Messschraube digital, 0,004mm, Color 2,4" Touchscreen, Wireless, ISO17025 Kalibrierschein - Microtech Metrology
€749.00
Product information "75–100mm Messschraube digital, 0,004mm, Color 2,4" Touchscreen, Wireless, ISO17025 Kalibrierschein - Microtech Metrology"
Micrometer — Micrometer with Cutting Edge and Microcomputer by Microtech Metrology
The Micrometer is a precision non-rotating micrometer with integrated microcomputer, designed for high-resolution workshop and industrial measurement in the 75–100 mm range.
- Non-rotating design for stable readings
- Colour 2.4" Touchscreen for clear data display
- Wireless+USB data transfer and MDS app compatibility
- IP65 protection for workshop environments
- ISO17025 calibration certificate included
Exceptional precision for reliable part control
This instrument combines a non-rotating micrometer mechanism with a microcomputer to deliver repeatable, high-precision results. Thanks to the 0.0001 mm resolution and a stated accuracy of 0.004 mm, the device supports demanding inspection tasks where reproducibility matters. The hardened anvils (6.5 x 0.75 mm) ensure consistent contact geometry, reducing measurement variation and supporting trustworthy quality control workflows.
Seamless connectivity that fits Industry 4.0 workflows
Equipped with Wireless+USB modes and compatibility with the MDS app, the micrometer integrates into modern data capture setups with minimal effort. Data transfer from Microtech is simpler than the U-WAVE technology of Mitutoyo because only a single dongle is required for PC reception, while direct wireless output to iPhone, iPad and Android devices is supported from the instrument itself. This reduces cable clutter and simplifies SPC and logging processes.
Stable measurement force for consistent results
The instrument features a manual Measurement Force Control, which lets operators set the desired measuring pressure according to material and application. When the preset force is reached, readings are captured automatically, ensuring that each measurement uses the same contact force. This approach reduces operator-induced variance and is particularly beneficial for delicate surfaces or thin-walled components.
Robust design and practical memory for daily use
Machined from a solid aluminium block, the housing provides a durable, tactile tool suited for production and maintenance environments. The Colour 2.4" Touchscreen supports clear visualization of graphical and numeric outputs while the internal memory manager stores up to 2000 values with folder and statistics support. Together, these features speed up repetitive tasks and simplify documentation without extra equipment.
Calibrated traceability and industry features
Delivery includes a Calibration Certificate (ISO17025, Ilac MRA), supporting traceability requirements for audits and controlled manufacturing. The instrument offers on-line graphic functions, Go/NoGo, Max/Min, formula support and linear and temperature correction routines, which make it a versatile solution for shop-floor inspection, toolroom verification and precision assembly tasks.
For a hands-on recommendation: the Micrometer by Microtech Metrology, with its MICS system and robust connectivity, is ideal for workshops and production lines that require precise, documented measurements — for personalised technical advice contact METAV Werkzeuge via eMail info@metav-werkzeuge.com, Phone +49 2822 7131930 or WhatsApp +49 170 2837271
Technical data
- Bezeichnung: Messschraube
- Brand: Microtech Metrology
- SKU: 110661008
- Measuring range: 75–100 mm
- Resolution: 0.0001 mm
- Accuracy: 0.004 mm
- Digital display: Color 2.4" Touchscreen
- Data output: Wireless+USB; Wireless HID; Wireless HID+MAC; USB HID; optional MODBUS RTU
- Memory manager: 2000 values, folders, statistics, memory data transfer
- Measuring HUB: Wireless MICROTECH instrument connection, synchronization, 2D mode, probe mode
- Anvils: 6.5 x 0.75 mm
- Protection class: IP65
- Housing: CNC machined solid aluminium block
- Calibration: ISO17025 (Ilac MRA) certificate included
- Additional functions: On-line Graphic, Analog scale, Go/NoGo, Max/Min, Formula, Timer, Linear correction, Temperature correction
- Battery / Power: Rechargeable (see DataMet Instruments specification for variants)
- Manufacturer: MICROTECH Private Scientific Manufacturing Enterprise; 04080, Ukraine, Kyiv; Nizhneyurkovska str., 45a; tool@microtech.tools
FAQ
What applications is the Micrometer from Microtech Metrology suitable for?
The Micrometer by Microtech Metrology is ideal for precision Workshop and production checks in the 75–100 mm range, for example shaft diameters, ring gauges and component thickness where high resolution and documented results are required.
How does data transfer work with the Micrometer by Microtech Metrology?
Data from the Micrometer is sent via Wireless+USB directly to the MDS app or as HID output; Microtech’s approach requires only a single dongle for PC reception and supports direct transfers to iPhone, iPad and Android devices, simplifying integration compared with U-WAVE technology of Mitutoyo.
Is the Micrometer by Microtech Metrology protected against coolant and dust?
Yes, the Micrometer features IP65 protection, which provides resistance to dust ingress and protection against low-pressure water jets common in workshop environments.
Does the Micrometer from Microtech Metrology include calibration documentation?
The Micrometer from Microtech Metrology is supplied with an ISO17025 (Ilac MRA) calibration certificate, suitable for traceability and quality management requirements.
Can the measuring force be adjusted on the Micrometer by Microtech Metrology?
The Micrometer includes a manual Measurement Force Control so the operator can set the desired measuring pressure; readings are recorded only when the preset force is reached, ensuring consistent measurement conditions.
Metav IndustryLine and Microtech Metrology products are supported by METAV Werkzeuge’s expert advisory service — contact info@metav-werkzeuge.com or call +49 2822 7131930 for personalised assistance.
