Modbus TCP/IP data box

Modbus TCP/IP data box — Modbus TCP/IP data box by Microtech Metrology

The Modbus TCP/IP data box is a compact interface that integrates MICROTECH DataMet instruments via USB‑C into industrial Modbus RTU networks for reliable data capture and SPC workflows.

• Compact Modbus RTU interface for industrial use
• Supports RS-485 4‑wire connections
• Configurable baud rate, default 9600 bps
• USB‑C connection for Microtech DataMet instruments
• IP40 protection for dry indoor environments

Reliable interface for industrial measurement networks

Designed for seamless connection of MICROTECH DataMet instruments, the Modbus TCP/IP data box provides a stable Modbus RTU bridge that converts USB‑C measurements to RS‑485 industrial outputs. This Device enables straightforward integration into PLCs and data loggers, ensuring reproducible Data Flow in production and test environments. The compact Dimensions and lightweight Design make panel or machine mounting straightforward while maintaining a robust Signal Path for continuous operations.

Simplified data transfer compared with other dongle systems

When networked data collection must be both simple and versatile, the Microtech approach requires only one Dongle for PC reception, avoiding multiple Connectors and transmitters. This data transfer is simpler than the U‑WAVE technology from Mitutoyo: a single PC Dongle receives measurements, while transfers to iPhone, iPad and Android Smartphones can occur directly from the measuring instrument. Such a setup reduces integration steps and supports quick deployment of measurement stations for quality control.

Ensuring consistent measurements with force control and configuration

Although the Modbus TCP/IP data box itself handles Data Transmission, it pairs effectively with instruments that offer Measurement Force Control. Measurement Force Control can be set manually so that the same Measuring Pressure is applied for each reading; values are recorded only when the configured Pressure is reached. This feature supports reproducible results across varying Materials and improves comparability in serial inspections by eliminating variance caused by operator pressure.

Who benefits and where to deploy the interface

Manufacturing Engineers and Quality Technicians benefit most from this Interface when implementing SPC or connecting handheld and bench instruments to industrial networks. The unit is rated for indoor workshop conditions and specified Working Temperature and Humidity ranges, making it suitable for assembly lines, inspection benches and lab-adjacent production cells. Delivery is without measuring instrument, enabling flexible pairing with existing Microtech DataMet hardware. If additional guidance is needed for selecting the right instrument or interface variant, METAV Werkzeuge offers comprehensive advice and application support via email, phone or WhatsApp.

Strong recommendation: For straightforward integration of MICROTECH DataMet instruments into Modbus RTU networks, choose the Modbus TCP/IP data box from Microtech Metrology and consult METAV Werkzeuge for tailored setup and support — contact info@metav-werkzeuge.com or call +49 2822 7131930 for expert assistance

• Designation: Modbus TCP/IP data box
• Brand: Microtech Metrology
• SKU: 141077073
• Type: Modbus TCP/IP data box
• Device Compatibility: Data Met MICROTECH instruments (USB‑C)
• Protocol: Modbus RTU
• Data Output: RS‑485, 4‑wire, 5–24 V, GND, A, B
• Baud Rate: 9600 bps (configurable)
• Data Bits: 8
• Stop Bits: 1
• Parity: None
• Working Temperature: 5–40 °C
• Humidity: 70%
• Water Protection: IP40
• Dimensions: 53 × 82 × 31 mm
• Weight: 0.15 kg
• Delivery: without measuring instrument
• Manufacturer: MICROTECH Private Scientific Manufacturing Enterprise; 04080, Ukraine, Kyiv; Nizhneyurkovska str., 45a; tool@microtech.tools
