Enhanced inspection with loupe viewing
Loupes provide quick, magnified visual assessment for metalworking and quality assurance, helping operators detect surface defects and measure fine features with minimal setup; they serve applications from metallography to workshop inspection by offering handheld, folding and stand-mounted options that suit different tasks and working distances. The tools are designed to deliver a clear virtual, upright image via a converging lens, where magnification depends on focal length, and they support both rapid checks and more precise measurements when equipped with a scale. Using a loupe improves throughput by enabling early detection of faults, protecting downstream processes and reducing rework through faster decision-making based on visual inspection, surface analysis and dimensional checking.
100x Peak Template Type 45 - Peak
Benefit from the combination of 100x magnification and a compact Type 45 format for reliable optical comparison and rapid inspection cycles; order directly via Metav Werkzeuge or request advice from our consultants. Peak template Typ 45 — optical template with 100x magnification The Peak template Typ 45 is a compact optical template designed for precise visual comparison and inspection tasks in optical measurement and laboratory workflows at 100x magnification. 100x magnification for fine inspection Compact Type 45 format for tight spaces Peak brand precision for optical checks Suitable for microscopes and optical benches Sharper detail for confident inspection The compact optical template provides a practical way to inspect small features under magnification. With 100x magnification, fine edges, surface textures and pattern fidelity become visible, enabling controlled visual comparison and quality checks. The template’s Type 45 format is intended for use where space is limited; it supports quick placement and repeatable alignment so that inspection time is reduced without compromising result reliability. This benefit is particularly relevant for bench-level assessment and sample verification tasks. Seamless fit into inspection routines As a reference tool, the template simplifies routine checks and visual documentation. The MS905.240 designation identifies the specific template variant for stock and ordering. Because the template is designed for optical comparison, it can be integrated into existing microscope setups and optical benches to speed up process verification and first-article inspections. The clear visual grid and defined features allow unambiguous assessment and make acceptance criteria easier to apply in production or laboratory environments. Practical advantages for workshops and labs The template’s straightforward function reduces training overhead and supports repeatable outcomes during manual inspections. Using an optical reference removes ambiguity when assessing miniature components or patterned surfaces; this increases throughput and reduces rework. The tool’s simple form factor makes storage and handling efficient, while compatibility with standard optical viewing equipment ensures flexible application across multiple inspection stages. For applications requiring dependable optical comparisons with Peak quality, contact Metav Werkzeuge to confirm availability of the MS905.240 and to discuss how the Type 45 template can be integrated into current inspection routines. Technical data Article number: MS905.240 Product name: Peak template Typ 45 Brand: Peak Facts Magnification: 100x SKU: MS905.240 Special features Category: Optics Image: https://files.plytix.com/api/v1.1/file/public_files/pim/assets/57/c3/98/62/6298c3575d155f1bc7e497fd/images/74/4a/d0/67/67d04a746977996463b6e3b4/MS905245-main.jpg FAQ What level of detail is visible with this template? The Peak template Typ 45 (MS905.240) is specified for 100x magnification, which reveals fine surface features and small pattern details suitable for visual comparison and inspection. Can the template be used with any microscope? The template is intended for use with standard inspection microscopes and optical benches; compatibility depends on the microscope’s stage and field of view at 100x magnification. Is the material of the template specified? The product data for the Peak template Typ 45 (MS905.240) does not include a material specification. How is the template identified for ordering and stock? The template is listed under article number MS905.240 and appears as Peak template Typ 45 in product catalogues. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
100x Standard Inspection Template Type 44 - Peak
Take advantage of the combination of precise 100× magnification, straightforward visual comparison and compact format for reliable routine inspections — order the template directly via Metav Werkzeuge or contact the consultants for application advice. Peak standard template Typ 44 — calibrated optical reference with 100× magnification Peak standard template Typ 44 is a compact optical reference designed for routine visual checks and measurement verification in microscopy and optical inspection tasks. 100× magnification for fine detail Compact reference for microscope checks Suitable for standard optical inspections Clear graduated markings for quick comparison Accurate reference for routine optical checks The 100× magnification delivers a clear enlargement level for visual assessment of surface features and pattern fidelity, making it an effective optical standard for quality control stations. By providing stable, repeatable reference marks, the template supports faster decisions during inspection rounds and helps to document visual conformity without complex instrumentation. The robust layout of the reference areas reduces interpretation time and enables consistent comparisons against production parts and controls. Seamless integration into microscopy and inspection workflows Designed as a straightforward inspection aid, the template slots easily into common microscopy routines and bench checks. Its layout complements standard imaging setups and simple eyepiece comparisons, helping to maintain throughput in busy inspection labs. Where digital capture is used, the reference areas assist in quick visual calibration and alignment of images. The item supports improved workflow efficiency by offering an immediately legible standard that speeds up routine acceptance checks and visual pass/fail assessments. Clarity that strengthens quality assurance documentation Clear graduation and visible reference patterns increase certainty when assessing small defects or dimensional cues at high magnification. The template contributes to better repeatability in visual inspections and aids traceability in quality records. For teams less familiar with optical nomenclature: magnification labelled as 100× means the viewed image appears one hundred times larger than the object, providing the resolution needed to judge fine surface details without resorting to higher-magnification methods for every check. This balance of clarity and practicality supports sustained inspection performance across shifts. For technical advice or to source the Peak standard template Typ 44 directly from Metav Werkzeuge, please contact Metav Werkzeuge GmbH in Emmerich by email at info@metav-werkzeuge.com or by phone on +49 2822 7131930 — expert guidance and reliable supply from Emmerich to the workshop bench. Technical data Article number: MS905.238 Brand: Peak Product name: Peak standard template Typ 44 Facts Magnification: 100× Special features Category: Optics Image: https://files.plytix.com/api/v1.1/file/public_files/pim/assets/57/c3/98/62/6298c3575d155f1bc7e497fd/images/74/4a/d0/67/67d04a7452eeab2aa78be171/MS905243-main.jpg FAQ What inspection tasks is this template intended for? The template serves as a visual reference for routine optical inspections; the Peak standard template Typ 44 is suitable for quick assessments and comparison checks at 100× magnification. Can the template be used with digital imaging systems? Yes, the reference areas on the template facilitate image alignment and quick calibration when capturing images with microscopes or camera-equipped inspection setups. How does 100× magnification help in quality control? At 100×, small surface features and pattern deviations become visible without needing ultra-high magnification, enabling efficient visual verification and quicker decision-making with the Peak template. Is this template suited for laboratory and workshop environments? The Peak standard template Typ 44 is designed for bench and lab inspection routines where a compact, reliable optical reference is required. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
10mm Inspection Loupe 30X With LED, 0.05mm Resolution, Plastic Body - Metav IndustryLine
Take advantage of the combination of 30× magnification, compact design and LED illumination for fast, repeatable visual inspections of small bores and fine line widths. Order the Measuring loupe M503.128.1 directly via Metav Werkzeuge or ask our consultants for application advice. Measuring loupe M503.128.1 — 30× magnification, LED illuminated The Measuring loupe M503.128.1 is a compact optical inspection aid designed for precise evaluation of small bores and ink or paint line widths in workshop and quality‑control environments. 30× magnification for fine detail Measurement range 0–10 mm precision LED illumination for clear contrast Compact viewing area 30 × 25 mm Precision where space and accuracy matter This inspection aid combines high magnification with a defined measurement range to deliver reliable visual checks in confined applications. The 30× magnification and 0–10 mm measurement capacity permit clear assessment of tiny features such as bores from 0.05–2.5 mm and line widths between 0.005–0.04 mm, making the instrument well suited to tasks where repeatable visual verification prevents rework. With a 0.05 mm resolution, the device supports routine dimensional checks that complement tactile measuring tools, accelerating decision processes on the shop floor and in the inspection station. Reliable optics and dependable illumination Optical performance is improved by the coated lens, which reduces stray reflections and increases contrast for fine detail recognition. Integrated LED illumination provides steady, shadow‑free light for consistent image quality across the viewing field (approx. 30 × 25 mm). The loupe includes a 20 dioptre correction to accommodate near‑vision aid needs and is powered by three AG3 button cells for portable, cable‑free operation. A lightweight plastic housing keeps handling comfortable during repeated inspections and simplifies positioning over small components. Designed for workshop routines and quick decision making Handheld and compact, the device integrates seamlessly into visual inspection workflows where speed and clarity are essential. Its combination of magnification, defined measurement band and illumination supports fast pass/fail judgements and reduces dependency on larger measuring systems for preliminary checks. The optical aid is particularly effective alongside precision calipers for initial assessment of bores and surface lines, improving throughput in production and saving time in repair or adjustment cycles. The robust, serviceable design suits both bench use and mobile inspection rounds. For fast, accurate visual checks with 30× magnification, contact Metav Werkzeuge GmbH in Emmerich for technical advice and local availability — email info@metav-werkzeuge.com or call +49 2822 7131930 Technical Data Article number: M503.128.1 GTIN: 4054469169200 Tariff number: 90138090 Brand: Metav IndustryLine Weight: 0.1 kg Housing material: Plastic Lens: Coated Facts Magnification: 30× Measurement range: 0–10 mm Resolution: 0.05 mm Dioptre: 20 Viewing area: 30 × 25 mm Battery: 3 × AG3 Special features LED illumination Anti‑reflection coated lens Compact, lightweight housing Suitable for bore measurement 0.05–2.5 mm Suitable for line‑width measurement 0.005–0.04 mm FAQ What is the useful measurement range for this loupe? The loupe supports a measurement range of 0–10 mm and is optimised for bores from 0.05–2.5 mm as well as line widths of 0.005–0.04 mm. How is the device illuminated? Integrated LED illumination provides consistent, shadow‑reduced lighting for clear observation of fine details. Which batteries are required and how long do they last? The instrument uses three AG3 button cells; typical lifetime depends on usage but the design emphasises portable, maintenance‑friendly power. Is the lens treated to improve contrast? Yes, the optical element is anti‑reflection coated to increase contrast and reduce glare during inspections. Can the loupe be used alongside precision calipers? Yes, the loupe is intended to complement handheld measuring tools such as precision calipers for quick visual verification. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
10x Foldable Magnifier Rectangular Aluminium With Engraved Mm Scale, 10x - Peak
Take advantage of the combination of 9× magnification, a compact aluminium housing and an engraved millimetre scale for faster, more reliable visual inspections. Order the loupe directly via Metav Werkzeuge or consult our advisors for application advice and rapid delivery. Peak folding loupe MS905.230 — 9× magnification, aluminium rectangular frame A durable Peak folding loupe designed for close inspection and simple measurement tasks in workshops, laboratories and quality-control stations. 9× magnification for fine detail Rectangular aluminium housing Engraved millimetre scale for quick checks Compact folding design for easy transport Inspect small details quickly with reliable 9× magnification The 9× magnification provides a clear enlargement of fine structures, making scratches, print defects and component marks easier to spot. With a defined field of view of 10 × 10 mm, the loupe balances magnification and visibility so areas can be scanned efficiently without constant refocusing. The optical concept is explained for non-specialists: higher magnification narrows the visible area but reveals more surface detail, which speeds up decision-making during inspection. Durable, portable design that suits the workshop environment A rectangular aluminium housing combines lightness with robustness, resisting everyday knocks and handling. The compact folding design protects the lens when not in use and allows the tool to be carried in a pocket or toolbox. This physical resilience reduces downtime and replacement cycles, supporting a smooth workflow on the shop floor or at the inspection bench. Integrated scale for instant measurements and documentation The engraved millimetre scale enables immediate, low-effort measurement without switching to separate tools. For basic quality checks—such as verifying thread widths, label print alignment or component dimensions—the integrated scale turns the loupe into a dual-purpose instrument: visual inspection and quick measurement. This reduces handling time and the risk of losing small parts between tools. Suitable for professionals and precise hobby applications Designed for technicians, watchmakers, jewel‑setters and print inspectors, the loupe offers practical benefits where repeated close-up checks are routine. The simple optical setup needs no calibration, which makes it convenient for multi-user environments. For more advanced measurement tasks, this device serves as a fast first check before employing higher‑precision instruments. For a reliable workshop loupe from Peak, contact Metav Werkzeuge to arrange supply from Emmerich; technical advice and order support are available via info@metav-werkzeuge.com or +49 2822 7131930 Technical Data Article number: MS905.230 Product name: Peak folding loupe Material: Aluminium Manufacturer: Peak Facts Magnification: 9× Sight field: 10 × 10 mm Lens: single Special features Engraved millimetre scale Rectangular aluminium housing Folding protection for lens FAQ What magnification does the loupe provide? The Peak folding loupe MS905.230 offers 9× magnification, suitable for detailed visual inspection of small parts. Can the loupe be used for simple measurements? Yes, the integrated engraved millimetre scale in the loupe allows quick, approximate measurements during inspection. Is the housing suitable for workshop use? The loupe features a rectangular aluminium housing that is lightweight yet robust enough for regular workshop handling. What is the visible area when using the loupe? The loupe provides a 10 × 10 mm sight field, balancing detail with sufficient scanning area for efficient inspections. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
10x Inspection Loupe Small Anti-Fog Tubus Vent Hole, Aluminium - Peak
Benefit from precise 10× magnification, a robust aluminium housing and an anti‑fog vent for consistent, time‑saving inspections — order directly via Metav Werkzeuge or consult our specialists for tailored guidance. Peak eye loupe A40D — 10× magnification, aluminium housing Peak eye loupe A40D is a compact inspection loupe for detailed work on small items such as watches and jewellery, delivering a clear, stable view for fine assembly and quality checks. 10× magnification for fine detail Aluminium housing, robust and lightweight Anti‑fog vent in the tube prevents condensation Ideal for watches and jewellery inspection Faster, more reliable visual inspection through high magnification The A40D provides 10× magnification, which enables rapid detection of defects and precise alignment tasks. This level of enlargement reduces iteration times in inspection workflows and supports measurable improvements in throughput. The optical performance is designed for close‑range work, so measurements and visual checks are more accurate and less error‑prone than with unaided sight. For technicians and watchmakers, this translates into consistently better results with fewer rechecks. Long‑term durability without sacrificing ease of handling Constructed from aluminium, the housing combines robustness with low weight, making the loupe comfortable for extended use. The lightweight design minimises fatigue during repetitive tasks while the metal casing withstands workshop wear. Maintenance is straightforward: occasional cleaning of the lens and exterior keeps the unit operational for years. The combination of durable materials and simple upkeep makes the inspection loupe a practical investment for busy benches and precision workshops. Clear vision guaranteed by anti‑fog design A small drilled vent in the tube prevents lens fogging, ensuring a clear view even when working in environments with fluctuating temperatures or humidity. Condensation can obscure critical detail and slow down inspection; the built‑in vent addresses this issue directly, reducing downtime and the need for repeated lens cleaning. The optical path remains unobstructed, so fine contours, solder joints and gem settings are visible without distraction. Designed for specialist applications and everyday reliability This inspection loupe is optimised for watches, jewellery and other small components, permitting careful assembly, polishing checks and quality control. The tool supports craftsmen and technicians who rely on consistent optical clarity to perform delicate operations. Its straightforward functionality and robust construction make it suitable for both bench top use and portable applications, while fostering confidence in repeatable inspection outcomes. For precision inspection tasks, choose the Peak eye loupe A40D and contact Metav Werkzeuge in Emmerich for expert advice and reliable supply. Technical data Article number: MS905.394 Type: A40D Brand: Peak Category: Optics Facts Magnification: 10× Special features Material: Aluminium Anti‑fog vent (small drilled hole in the tube) Suitable for watches and jewellery inspection FAQ What magnification does the loupe provide? The loupe delivers 10× magnification, which is suitable for detailed inspection and fine manual tasks. Is the housing sturdy enough for workshop use? Yes, the aluminium housing offers robustness and low weight, making it suitable for regular workshop and bench use. How does the anti‑fog feature work? A small drilled vent in the tube prevents condensation on the lens, ensuring a clearer view during temperature changes or prolonged inspections. Is the loupe suitable for watchmaking and jewellery work? The design and magnification make the loupe well suited to watches and jewellery, supporting detailed assembly and quality checks. Can the loupe be used for portable inspections? Its compact size and lightweight aluminium construction make it convenient for portable use at different workstations. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
10x Inspection Magnifier with Illumination, Ø32mm Field, Ø47x45x185mm, 2x C Batteries - Peak
Peak Measuring Magnifier 10x with Illumination Peak Measuring Magnifier 10x with Illumination is a compact measuring magnifier designed for precise inspection and documentation in workshops, laboratories and quality control environments. Achromatic lenses for minimal aberration Large Ø32 mm field of view for clear overview Built-in illumination for detailed inspection Lightweight design, 134 g (excl. batteries) Supplied with protective case Precision optics for reliable measurement and documentation The measuring magnifier integrates high-quality achromatic lenses that reduce chromatic aberration and ensure a true, sharp image across the full view. This optical correction makes measurements and visual inspections more reliable, particularly when comparing fine details or marking tolerances. The device’s 10x magnification combined with a Ø32 mm field of view delivers both enlargement and context, so single features can be examined without losing sight of surrounding reference points. Comfortable handling for repetitive inspection tasks Ergonomic design and a lightweight construction (134 g excluding batteries) make the magnifier comfortable to hold during extended use. The built-in illumination provides even, shadow-free lighting for close-up work, reducing eye strain and improving focus. The compact dimensions (Ø47 x 45 x 185 mm) allow easy positioning over small components, while the supplied protective case keeps the instrument safe when transported between workstations. Where this tool adds the most value This measuring magnifier is particularly suited for precision trades and quality assurance: electronics assembly, jewellery inspection, stamp and print review, and textile quality checks. The combination of achromatic optics and integrated light supports professionals and hobbyists who require clear detail recognition rather than only high magnification. For users needing quick verification and documentation, the device balances clarity, portability and durability. Power, maintenance and simple technical background The magnifier is powered by 2 × Type C batteries (not included), offering convenient field operation without cables. Achromatic lenses are built from paired lens elements that compensate colour dispersion; in practice this means sharper edges and more accurate visual assessment compared with simple single-element lenses. The product is shipped in a case for immediate use and protected storage, reducing wear and ensuring readiness for inspection tasks. We recommend the Peak Measuring Magnifier 10x with Illumination for professional inspection and quality control; for personalised technical advice or supplementary data please contact METAV Werkzeuge by eMail: info@metav-werkzeuge.com, Telephone: +49 2822 7131930 or WhatsApp: +49 170 2837271 Technical specifications Peak Measuring Magnifier 10x with Illumination Brand: Peak SKU: MS905.178 Magnification: 10x Field of view: Ø32 mm Dimensions: Ø47 x 45 x 185 mm Mass: 134 g (excluding batteries) Power supply: 2 × Type C batteries (not included) Optics: Achromatic lenses to reduce aberrations and increase resolution Packaging: Supplied with protective case Manufacturer: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; www.metav-shop.de; info@metav-werkzeuge.com FAQ What tasks is the Peak Measuring Magnifier 10x with Illumination best suited for? The Peak Measuring Magnifier 10x with Illumination from Peak is ideal for precision inspection tasks such as electronics assembly checks, jewellery appraisal and print quality control where clear detail recognition and a wide field of view are required. How is the Peak Measuring Magnifier 10x with Illumination powered and maintained? The Peak Measuring Magnifier 10x with Illumination uses 2 × Type C batteries (not included); replace batteries as needed and store the Measuring Magnifier in its protective case to avoid dust and scratches on the lenses. Do the lenses of the Peak Measuring Magnifier 10x with Illumination reduce colour fringing? Yes, the Peak Measuring Magnifier 10x with Illumination features achromatic lenses designed to minimise chromatic aberration, resulting in sharper edges and more accurate visual assessment. Can METAV Werkzeuge provide technical advice about the Peak Measuring Magnifier 10x with Illumination? Yes, METAV Werkzeuge offers comprehensive and competent consultation; contact info@metav-werkzeuge.com or call +49 2822 7131930, or message via WhatsApp +49 170 2837271 for further technical data or purchasing support.
10x Magnifying Glass Set With Five Templates, 0.1mm Scale, ø35mm Field - Peak
Set of 10x Magnifier with Five Templates in Plastic Case — Peak measuring magnifier The Set of 10x Magnifier with Five Templates in Plastic Case is a compact measuring magnifier designed for precise inspection and accurate dimensional checks across jewellery, watchmaking and quality control tasks. Precision 10x magnification for clear inspection Achromatic lenses minimise optical aberrations Large 35 mm field of view for broad visibility Fine 0.1 mm scale division for accurate readings Lightweight at 74 g for comfortable handling Precision optics that ensure reliable measurement results The measuring loupe combines 10x magnification with high-quality achromatic lenses to deliver a sharp image with reduced chromatic aberration. This optical configuration provides a high resolution and a generous 35 mm field of view, so details remain visible across a wide area rather than only at the centre. For measurement tasks, the integrated 0.1 mm scale division and a standard measuring range of 30 mm support repeatable and traceable inspections. This makes the instrument ideal for tasks where measurable detail and visual clarity matter most Practical design for comfortable, repeatable use Lightweight construction and ergonomic proportions make handling straightforward during extended inspection sessions. With overall dimensions of ø 46 x 44 mm and a mass of 74 g, the device sits comfortably in hand or on the bench, reducing user fatigue. The robust plastic case protects the optics and the Templates numbered 2, 3, 7, 8 and 10, keeping accessories organised and ready for fast workflow integration. The portable design supports mobility between workstations without compromising optical stability Where this magnifier adds most value This measuring magnifier is tailored for precision trades such as Jewellery, Watchmaking, Electronics assembly and Quality Control labs where visual inspection and tactile measurement combine. The clear, distortion-minimised viewing and the fine scale enable technicians to confirm tolerances, inspect surface details and document small features quickly. For professionals requiring fast verification rather than bench microscopy, this loupe offers a balance of clarity and portability suited to in-line checks and field service visits Simple explanations for technical features An achromatic lens is a multi-element lens designed to bring two wavelengths (typically red and blue) to the same focus, reducing colour fringing and improving sharpness. The field of view (ø 35 mm) describes the diameter of the visible area seen through the loupe; a larger field reduces the need to constantly reposition the object. A scale division of 0.1 mm indicates the smallest marked increment on the scale, allowing users to estimate measurements to a tenth of a millimetre. These properties translate into clearer images and more reliable measurements during everyday inspection work Peak recommends this measuring magnifier for precision inspection tasks — for further technical data or personalised advice METAV Werkzeuge, the retailer, offers comprehensive support. Not sure if this tool meets your requirements or need additional information? Contact METAV Werkzeuge via 📧 info@metav-werkzeuge.com ☎️ +49 2822 7131930 ✔️ WhatsApp +49 170 2837271 Set of 10x Magnifier with Five Templates in Plastic Case Brand: Peak SKU: MS905.195 Magnification: 10x Field of View: ø 35 mm Measuring Range (standard template): 30 mm Scale Division: 0.1 mm Dimensions: ø 46 x 44 mm Mass: 74 g Accessories: Templates No. 2, 3, 7, 8 and 10 Set: Yes Manufacturer: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; www.metav-shop.de; info@metav-werkzeuge.com FAQ What inspection tasks is the Set of 10x Magnifier with Five Templates in Plastic Case by Peak best suited for? The Peak Set of 10x Magnifier with Five Templates in Plastic Case is ideal for jewellery, watch repair, electronics inspection and quality control tasks where high detail and quick measurement checks are required How precise are measurements made with the Peak measuring magnifier? Measurements with the Peak measuring magnifier rely on the integrated scale with a 0.1 mm division and a standard measuring range of 30 mm, enabling reliable checks to a tenth of a millimetre for most routine inspections Is the Set of 10x Magnifier with Five Templates in Plastic Case portable for field work? Yes, the compact dimensions (ø 46 x 44 mm) and lightweight construction of 74 g make the Peak set easy to carry, while the plastic case protects optics and Templates during transport Can METAV Werkzeuge provide additional technical data or support for the Peak measuring magnifier? METAV Werkzeuge, as retailer, offers comprehensive advice and can provide additional technical details or help to determine suitability for specific applications; contact via info@metav-werkzeuge.com or +49 2822 7131930
10x10 Field, 9x Magnification Thread Counter with Engraved mm Scale, Rectangular, Aluminium - Peak
Peak Thread Counter, rectangular 9x The Peak Thread Counter is a compact rectangular thread-counting tool with 9x magnification designed for precise measurement and inspection in textile and optical applications. Compact design for easy handling Engraved mm scale on both sides 9x magnification for clear counting Durable black aluminium construction Scale matches field width for accurate reading Precise counting for consistent quality control The Peak Thread Counter offers reliable, repeatable measurements thanks to its 9x magnification and clearly engraved mm scale. The instrument includes a single lens (x1) delivering a defined Field of View 10x10, which simplifies alignment with the textile sample. For quality control and production checks, the fixed magnification and matching scale length reduce interpretation errors and speed up inspection cycles. Robust design that supports frequent use Built from Aluminium (black), the Thread Counter combines low weight with good durability. Its small overall dimensions make handling straightforward during repetitive tasks, while the rectangular shape provides stable placement on fabrics. The engraved scales on each side of the foot resist wear and ensure long-term legibility, so routine inspections remain precise without frequent replacement. Ideal for textile inspection, laboratories and workshops Designed for technicians, textile specialists and optical inspectors, this Rectangle 9x Thread Counter is suitable for counting threads, checking weave density and verifying sample consistency. Its compact footprint makes it easy to include in inspection kits or to use on-site, while the clear scale facilitates fast decisions in production or laboratory settings. Easy to read scale and simple operation for all skill levels An engraved mm scale on both sides of the foot gives immediate, objective readings; the scale length corresponds to the width of the Field of View 10x10 so users can directly count threads across the visible area. For users less familiar with optical tools, the combination of a single lens (x1) and fixed magnification reduces adjustment steps and delivers direct, comprehensible results for every measurement. Strong recommendation: Choose the Peak Thread Counter for dependable thread measurement and contact Metav Werkzeuge for expert advice and support — Email: info@metav-werkzeuge.com — Phone: +49 2822 7131930 — WhatsApp: +49 170 2837271 Peak Thread Counter Brand: Peak SKU: MS905.377 Type: rectangular, 9x Material: Aluminium (black) Lens: x1 Field of View: 10x10 Magnification: 9x Special feature: with engraved mm scale Additional note: Due to its small dimensions, this Thread Counter is easy to use; a mm scale is engraved on each side of the foot and the scale length corresponds to the width of the Field of View UID: MS905.377 Manufacturer: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; www.metav-shop.de; info@metav-werkzeuge.com FAQ How do I read the scale on the Peak Thread Counter from Peak for textile inspections? The Peak Thread Counter from Peak has an engraved mm scale on both sides of the foot; align the fabric so the threads span the Field of View 10x10 and count the threads across the visible width, using the scale for a direct millimetre-based reading. Is the Peak Thread Counter suitable for laboratory use? Yes, the Peak Thread Counter by Peak is suitable for laboratory and workshop use where a compact, robust rectangular 9x instrument is required for consistent thread counting and quick inspections. What makes the Peak Thread Counter durable for frequent use? Durability comes from the Aluminium (black) construction of the Peak Thread Counter, combined with the engraved mm scale that resists wear and maintains legibility during repeated measurements. Can beginners use the Peak Thread Counter from Peak without specialised training? Beginners can use the Peak Thread Counter effectively because the single lens (x1) and fixed 9x magnification simplify operation and the engraved mm scale provides an immediate, easy-to-interpret reference.
115mm Stand Magnifier Flexible Arm With Stable Base, 1.7x Magnification - Peak
Take advantage of the combination of a flexible arm, a stable base and a clear 115 mm lens to speed up visual inspection and reduce handling errors in assembly and quality control. Order the Peak stand magnifier MS905.279 directly via Metav Werkzeuge or ask our consultants if needed. Peak Stand Magnifier MS905.279 — 1.7× magnification, 115 mm lens A Peak Stand Magnifier MS905.279 designed for benchtop inspection and light assembly tasks, featuring a movable arm and a sturdy base for repeatable positioning 115 mm lens diameter 1.7× magnification Flexible arm with stable base Compact footprint for benchtop use Clear, low‑magnification optics for fast inspection The magnifier provides 1.7× magnification, delivering an enlarged view that makes routine inspection, parts sorting and assembly verification quicker and less strenuous. The optical configuration is chosen for a balance between field of view and clarity, so operators can maintain situational awareness while examining details. The combination of a large 115 mm lens and modest magnification reduces the need for constant refocusing and repositioning, which supports higher throughput in repetitive tasks and helps to prevent handling mistakes. Stable support and adaptable positioning for precise work A flexible arm paired with a stable base allows accurate, repeatable placement above the workpiece. The articulated support system permits fine adjustments without disturbing the setup, which is particularly useful during soldering, component fitting and visual checks. The solid base minimises vibration and drift; as a result, the device supports steadier inspection sequences and reduces rework caused by misalignment. The compact overall footprint keeps the workbench organised while offering secure support for small or medium components. Practical design that integrates into workshop workflows With compact dimensions of 145 × 120 × 485 mm, the unit occupies minimal bench space while delivering a wide viewing area, making it suitable for electronics workstations, inspection benches and light mechanical assembly. The form factor facilitates quick placement and clearance around tools and fixtures. The straightforward setup and stable support mean less time spent adjusting equipment and more time spent on productive inspection, contributing to smoother process flows in small-scale manufacturing and repair environments. Built for dependable, everyday use Constructed for practical workshop conditions, the device is a reliable visual aid for technicians and quality personnel who require consistent results rather than high magnification. The generous lens diameter and robust support reduce operator fatigue during repeated tasks, offering an ergonomic advantage over handheld solutions. Sourcing through Metav Werkzeuge ensures transparent delivery and a dependable supply chain for workshop consumables and inspection equipment. For purchase advice, additional specification details or to arrange delivery from Metav Werkzeuge in Emmerich, please contact Metav Werkzeuge GmbH for personalised assistance and supply coordination. Technical Data Article number: MS905.279 Manufacturer: Peak Dimensions: 145 x 120 x 485 mm Lens diameter: 115 mm Magnification: 1.7× Special feature: flexible arm with stable base Image: https://files.plytix.com/api/v1.1/file/public_files/pim/assets/57/c3/98/62/6298c3575d155f1bc7e497fd/images/74/45/d0/67/67d04574ff45ece17661fea2/MS905279-main.jpg Facts Lens diameter 115 mm Magnification 1.7× Compact benchtop dimensions Special features Flexible articulated arm Sturdy, stable base for repeatable positioning Suited to inspection, assembly and visual checks FAQ What magnification does this magnifier offer? The Peak stand magnifier MS905.279 offers 1.7× magnification, giving an enlarged but wide field of view suited to routine inspection tasks. Is the lens size suitable for checking larger components? Yes, the 115 mm lens provides a broad viewing area that is favourable for components and assemblies that require a wider perspective during inspection. Can the arm be adjusted and locked in position? The flexible arm enables adaptable positioning and the stable base keeps the unit secure for repeatable inspection work, as specified for the MS905.279. Is this device appropriate for electronics benchwork? The sizeable lens and modest magnification make the unit well suited to electronics inspection and light assembly where a balance of detail and field of view is required. What are the overall dimensions for bench planning? The magnifier measures 145 × 120 × 485 mm, offering a compact footprint that integrates readily into standard benchtop layouts. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
122 x 12 mm Pen Microscope 25×, No Scale, Aluminium/Polyamide Body - Metav IndustryLine
Benefit from a compact inspection tool that combines 25× magnification, a coated lens and a slim 122 × 12 mm housing for reliable visual checks in confined areas; order the instrument directly via Metav Werkzeuge or request advice from our consultants if further specification is required. Pen microscope M503.101 by Metav IndustryLine — 25×, 122 × 12 mm The Pen microscope M503.101 is a compact handheld inspection microscope designed for visual quality control, maintenance work and detailed inspections in confined or hard-to-reach places. 25× magnification for detailed inspection Coated lens for improved contrast and durability Compact 122 × 12 mm housing for tight spaces Lightweight 0.1 kg handheld design Precision inspection in confined spaces Compact optics deliver measurable advantages when access is limited. With 25× magnification and a field of view 4 mm, the instrument reveals fine surface structure and small defects that are otherwise hard to see with the naked eye. The coated lens reduces stray reflections and improves contrast, which supports faster, more reliable visual assessments on production lines or at the inspection bench. This concentrated optical performance makes the device a practical choice where clarity and repeatability matter. Durable, ergonomic construction for everyday use A combination of aluminium/polyamide housing and a low mass yields a tool that balances robustness with manoeuvrability. At lightweight 0.1 kg, the device is easy to handle during repeated checks without excessive operator fatigue, while the mixed-material construction resists workshop wear. The compact form factor preserves rigidity in the optical path, which helps maintain consistent viewing geometry and simplifies handling during serial inspections or mobile service calls. Designed for visual quality control across industries This pen-style microscope is tailored to visual inspection rather than dimensional metrology: the instrument is supplied without scale, so it is best used for identification of surface faults, solder joint inspection, textile checks, watchmaking and component verification. The compact format is particularly useful in electronics assembly and small-part manufacturing where space is restricted but visual certainty is required. The specification emphasises visual clarity and handling rather than measurement traceability. Practical handling, traceability and confidence Every detail supports rapid inspection workflows: compact dimensions, a coated optical system and proven mechanical construction provide dependable results with minimal setup. The product is listed under Metav IndustryLine and carries a clear SKU for procurement and inventory control, enabling straightforward integration into purchasing and quality-management processes. Backed by Metav’s position as a trusted supplier for precision tools, the instrument benefits from reliable European distribution and a consistent quality filter for professional users. For straightforward procurement and technical guidance on the Metav IndustryLine pen microscope M503.101, contact Metav Werkzeuge in Emmerich by email at info@metav-werkzeuge.com or by telephone on +49 2822 7131930 to discuss availability and suitability for specific inspection tasks Technical data Article number: M503.101 GTIN: 4054469144412 Customs tariff number: 90111090 Category: Optik Core technical data Magnification: 25× Dimensions: 122 × 12 mm Field of view: 4 mm Weight: 0.1 kg Materials and special features Housing: aluminium / polyamide Coated lens No scale (visual inspection only) FAQ Is this pen microscope suitable for taking measurements? The pen microscope M503.101 is supplied without a scale and is intended for visual inspection and defect detection rather than for precise dimensional measurements. What magnification and viewing area does the device provide? The instrument delivers 25× magnification with a field of view of approximately 4 mm, which is suitable for close visual inspection of small components and fine surfaces. Is the lens treated to reduce reflections? Yes, the optical system in the M503.101 features a coated lens that improves contrast and reduces stray reflections for clearer visual assessment. What materials are used for the housing and how heavy is the device? The housing is made from aluminium and polyamide, and the complete instrument weighs 0.1 kg, providing a durable yet lightweight handheld solution. Which applications is this pen microscope best suited to? The M503.101 is ideal for electronics inspection, watchmaking, maintenance checks, solder joint and surface inspections where compact, handheld visual inspection is required. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
122mm Pin Microscope 50× Aluminium/Polyamide Body, No Scale, 2mm Field Of View - Metav IndustryLine
Compact and robust, the pen microscope combines 50× magnification with a coated lens and a slim 122 × 12 mm body for fast visual inspection; order the pen microscope directly via Metav Werkzeuge or ask our consultants if needed. Pen microscope M503.103 — 50× inspection tool, 122 × 12 mm (Metav IndustryLine) Pen microscope M503.103 is a compact inspection instrument for quick visual checks in workshops and production monitoring Compact 122 x 12 mm aluminium/polyamide body 50× magnification for detailed inspections Anti‑reflection coated lens for clearer images Lightweight 0.1 kg handheld operation See defects quickly with high contrast optics The compact inspection loupe delivers 50× magnification and a narrow 2 mm field of view, making it well suited for detecting surface defects, solder joints or fine engraving details on small components. The coated lens reduces reflections and improves contrast, which shortens visual inspection times and supports quicker decision‑making in assembly or incoming goods inspections. For routine checks where a measuring scale is not required, this optical tool provides a reliable visual assessment step that complements dimensional metrology. Designed for handheld comfort and repeatable inspection A slim 122 x 12 mm housing of aluminium/polyamide keeps the instrument rugged yet comfortable for prolonged handheld use. At only 0.1 kg, the device minimises operator fatigue and is simple to manoeuvre around complex geometries. The form factor and robust materials ensure resistance to workshop conditions so that visual checks remain repeatable across shifts, improving throughput without compromising on handling comfort. Integrates into workshop and quality workflows This inspection instrument is optimised for visual quality control rather than quantitative measurement: it is supplied without a scale, which simplifies use when absolute dimensions are not necessary. As a visual inspection aid, it speeds up fault localisation before parts are passed to precision measuring devices or returned to machining. The pen‑style design suits bench checks, bin inspections and spot checks on the shop floor, helping to reduce rework and keep production flow efficient. Practical care and industrial fit Maintenance is straightforward: clean the lens with a lint‑free cloth and appropriate optical cleaner to preserve image clarity. The robust housing materials withstand typical workshop environments; routine visual inspections therefore remain reliable with minimal upkeep. Supplied by Metav IndustryLine, the instrument benefits from the supplier’s quality filtering and logistics in Emmerich, aligning compact inspection capability with dependable delivery and aftermarket advice. Contact Metav Werkzeuge for specific application advice on the Metav IndustryLine pen microscope M503.103 and to arrange a tailored supply solution for workshop inspection needs Technical data Article number: M503.103 GTIN: 4054469144436 Dimensions: 122 x 12 mm Weight: 0.1 kg Material: Aluminium/Polyamide Magnification: 50× Field of view: 2 mm Lens: Coated Label: Pen microscope, 50× 122 x 12 mm, without scale Facts Magnification: 50× Field of view: 2 mm Dimensions: 122 x 12 mm Weight: 0.1 kg GTIN: 4054469144436 Special features Coated lens for reduced reflections Housing: aluminium/polyamide Supplied without scaling Category: Optik SKU: M503.103 FAQ What is the primary use of this pen microscope? The pen microscope M503.103 from Metav IndustryLine is intended for visual inspection tasks such as surface checks, solder joint review and small-component scrutiny where rapid optical assessment is required rather than direct measurement. Does the instrument provide measurement scales? No, this inspection tool is supplied without a scale; it is optimised for visual evaluation and quick defect localisation rather than quantitative dimensioning. How durable is the housing material for workshop use? The housing made of aluminium and polyamide gives the instrument resilience against everyday workshop wear while remaining lightweight for handheld inspection. How should the lens be maintained? Clean the coated lens with a lint‑free cloth and suitable optical cleaner to maintain clarity; the anti‑reflection coating improves contrast but benefits from careful handling. Is the field of view suitable for small electronic components? Yes, the narrow 2 mm field of view combined with 50× magnification is appropriate for focused inspection of electronic components, fine engravings and similar small details. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
122x12 50X Pocket Microscope With 0.02mm Scale, Aluminium/Polyamide Body - Metav IndustryLine
Compact 50× magnification and a 0.02 mm scale deliver quick, reliable visual checks; the aluminium/polyamide housing keeps the instrument robust yet portable. Benefit from a coated optic for improved contrast and straightforward handling — order the Metav IndustryLine pen microscope directly via Metav Werkzeuge or ask our consultants if needed. Metav IndustryLine Pen Microscope M503.104 — 50× magnification, 0.02 mm scale The Metav IndustryLine Pen Microscope M503.104 is a compact inspection instrument for close visual checks and simple comparative measurements in production and quality control. 50× magnification for detailed inspection 0.02 mm scale for fine visual measurement Aluminium/polyamide housing for robust lightness Coated lens for improved image clarity Precise, visual measurement for fast quality checks The instrument combines 50× magnification with a finely graduated 0.02 mm scale to support rapid assessment of small features, surface defects and print checks. The visible scale allows immediate comparative readings without additional tools, which shortens inspection cycles and reduces throughput bottlenecks. The compact form makes the device suitable for quick on‑the‑spot verifications where a stereo microscope would be impractical, yet the optical coating ensures a clear, contrast‑rich view for consistent visual decisions. Designed for portability and repetitive use With overall dimensions of 122 x 12 mm and a weight of approximately 0.1 kg, the instrument is pocket‑sized and easy to carry between workstations. The aluminium/polyamide housing balances strength with low mass, so frequent handling is comfortable and tool fatigue is reduced during repeated checks. The light construction supports mobile inspection workflows and machine‑side sampling routines, enabling reliable visual control without compromising durability. Optical quality and construction explained The objective features a coated lens, providing improved light transmission and reduced reflections for sharper contrast on fine details. The optical finish supports clearer edge detection on microstructures and printed scales. Mechanical construction uses durable materials selected for workshop conditions; the compact barrel form minimises torsion and keeps alignment stable during handheld measurements. Where visual confirmation and simple scale readings are required, this pocket microscope presents a pragmatic alternative to bulkier setups. For reliable, portable visual inspection choose the Metav IndustryLine pen microscope M503.104 — contact Metav Werkzeuge in Emmerich for tailored advice at info@metav-werkzeuge.com or by phone on +49 2822 7131930 Technical data Article number: M503.104 GTIN: 4054469144443 Dimensions: 122 x 12 mm Weight: 0.1 kg Magnification: 50× Scale division: 0.02 mm Optical coating: coated lens Housing material: aluminium/polyamide Tariff number: 90111090 Facts eClass: 21170509 ETIM: EC001685 Visible field indicator: 2 Measurement length indicator: 2 Scale type: B Division: 0.02 Diopter: 50 Special features Includes scale Coated optics for improved contrast Compact, pocket format Robust aluminium/polyamide housing Label: Stiftmikroskop, 50X, Skalierung 0,02 mm 122 x 12 mm, mit Skalierung FAQ What magnification does the pen microscope provide? The instrument offers 50× magnification, which is suitable for detailed visual checks and close inspection of small features. Can the device be used for simple measurements? Yes, the built‑in 0.02 mm scale allows straightforward comparative measurements and rapid visual checks without auxiliary gauges. What materials is the housing made from? The housing is produced from aluminium/polyamide, combining lightweight handling with workshop durability. Is the lens treated to improve image quality? The lens is coated to enhance contrast and reduce reflections, improving clarity for repeatable visual inspections. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
122x12 mm Pen Microscope 100× Without Scale, Aluminium/Polyamide Body - Metav IndustryLine
Combine 100× magnification, a coated lens and a compact 122 × 12 mm aluminium/polyamide housing to achieve fast, reliable visual checks of small parts and solder joints. Order the pen-style microscope directly via Metav Werkzeuge or consult our technical advisors for integration into inspection workflows. Pen Microscope M503.105 — 100× magnification, aluminium/polyamide housing (Metav IndustryLine) A Pen Microscope M503.105 designed for rapid, close-up visual inspection of small components in workshops, laboratories and quality-control stations. 100× magnification for detailed visual inspection Coated lens for improved contrast and clarity Aluminium/polyamide housing for robust handling Compact 122 × 12 mm pen-style design for portability Precision imaging in a pocket instrument The Pen Microscope M503.105 provides 100× magnification with a field of view 1.2 mm, delivering the visual resolution needed to identify surface defects, solder bridges and fine material structures without complex set-up. The coated lens reduces reflections and improves contrast, which translates into clearer observations under shop-floor lighting. For processes where rapid visual verification shortens inspection cycles, this compact instrument brings consistent optical performance in a form factor that fits a pocket or tool roll. Durable, lightweight construction for regular use Crafted from an aluminium/polyamide housing, the device combines stiffness with low weight—approximately 0.1 kg—so handling fatigue during repeated checks is minimised. The slim 122 × 12 mm profile supports easy one-handed use and stable positioning close to the workpiece, while the robust casing resists workshop knocks and handling. The construction balances portability and durability, ensuring a dependable inspection aid that integrates seamlessly into routine quality-control tasks. Simple visual inspection where a scale is unnecessary This pen-style microscope is supplied without a scale, which emphasises its role as a visual inspection tool rather than a precision measuring instrument. The absence of graduations keeps the eyepiece uncluttered and is well suited to applications such as component sorting, PCB inspection, surface quality checks and fast acceptance testing where qualitative assessment and defect detection are the priority. The straightforward optical approach reduces training time and speeds throughput on repetitive inspection lines. Compact companion for consistent quality workflows As a portable visual aid, the instrument supports mobile checks on benches, in assembly cells and at incoming goods inspections. The compact design simplifies transportation between stations and reduces the need for dedicated bench micrsocopes for every workstation. Backed by Metav’s inventory and supply chain in Emmerich, the tool is a practical choice for teams seeking reliable visual verification without complex instrumentation, helping to democratically raise inspection capability across production and service departments. Contact Metav Werkzeuge in Emmerich for specification sheets or to arrange purchase of the Metav IndustryLine pen microscope (M503.105) via info@metav-werkzeuge.com or by phone on +49 2822 7131930 Technical data SKU: M503.105 GTIN: 4054469144450 Tariff number: 90111090 Category: Optik Net weight: 0.1 kg Facts Magnification: 100× Field of view: 1.2 mm Dimensions: 122 × 12 mm Weight: 0.1 kg Special features Coated lens (vergutet) Housing made from aluminium/polyamide No scaling included Pen-style, compact design Main use: visual inspection FAQ What magnification and field of view does this pen-style microscope offer? The Pen Microscope M503.105 delivers 100× magnification with a field of view of approximately 1.2 mm, suitable for detailed visual inspection of small components. Is the lens treated to reduce glare and improve contrast? Yes, the instrument features a coated lens (vergutet) to enhance contrast and reduce reflections under workshop lighting. Does the device include a measurement scale for dimensional checks? No, the Metav IndustryLine pen microscope (M503.105) is supplied without a scale and is intended for visual inspection rather than precision measurement. How portable and robust is the pen microscope for daily use? With a slim 122 × 12 mm profile and a housing made from aluminium/polyamide, the unit is lightweight (0.1 kg) and built for regular handling in shop and lab environments. For which applications is this pen-style microscope best suited? The device is ideal for PCB inspection, solder-joint checks, surface defect detection and rapid visual acceptance testing where high magnification and clear imagery are required. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
122x12 mm Pen Microscope 100×, 0.01 mm Scale, Aluminium/Polyamide Body - Metav IndustryLine
Take advantage of the compact design and high optical performance of this inspection instrument: a 100× magnification combined with a 0.01 mm graduated scale and a slim 122 × 12 mm aluminium/polyamide body enables precise visual checks and quick comparative measurements. Order the instrument directly via Metav Werkzeuge or consult the Metav team for application advice. Pen microscope M503.106 — 100× magnification, 0.01 mm scale The pen microscope M503.106 is a compact handheld inspection microscope for visual checks and scaled measurements in workshops and quality‑control stations. 100× magnification for fine detail 0.01 mm graduated scale for precise measures Compact 122 × 12 mm aluminium/polyamide body Coated optics for improved contrast Inspect fine detail in the smallest components The combination of 100× magnification and a narrow field of view (1.2 mm) makes this pen‑style microscope especially suited to tasks where concentrated, high‑contrast visual inspection is required. The coated lens improves light transmission and reduces reflections, which helps to reveal surface defects, burrs or fine markings that standard magnifiers can miss. This optical configuration is well matched to quality control in electronics, small mechanical parts and jewellery, where seeing microscopic features directly speeds decision‑making and reduces handling time. Quick scaled checks to support faster decisions A clearly readable 0.01 mm scale is integrated into the optical path, permitting immediate comparative measurements without transferring parts to a bench instrument. The slim 122 × 12 mm profile and low weight (0.1 kg) allow rapid handheld use and straightforward placement for a visual reference measurement. This reduces the need for additional measuring devices during first‑level inspection and supports efficient sorting workflows, contributing to fewer process interruptions and shorter inspection cycles. Durable construction for everyday workshop use The housing combines aluminium with polyamide, striking a balance between robustness and lightness that suits mobile inspection routines. The materials provide resistance to routine workshop wear while keeping handling comfortable during extended use. The combination of metal and engineering plastic also minimises the instrument’s thermal sensitivity compared with all‑plastic designs, which helps preserve visual stability during repeated checks in varying ambient conditions. Integrates with established inspection practices Designed for easy adoption into existing routines, the instrument provides immediate visual feedback and a fine graduated reference for rapid pass/fail decisions. Its compact format supports storage in tool racks or inspection kits and complements bench optics and handheld gauges by offering a fast visual step before detailed measurement. For operators who value speed and clarity, this tool acts as a practical first‑check solution that reduces throughput delays and guides the next measurement steps. For compact, high‑magnification inspection from Metav IndustryLine, contact Metav Werkzeuge GmbH in Emmerich for tailored advice and efficient delivery to the workshop Technical data Article number: M503.106 GTIN: 4054469144467 Weight: 0.1 kg Dimensions: 122 × 12 mm Magnification: 100× Facts Field of view: 1.2 mm Scale division: 0.01 mm Housing materials: aluminium / polyamide Lens: coated optics Special features Compact handheld pen microscope design Integrated graduated scale for comparative measurement Slim format for confined spaces FAQ What level of detail can be expected with this microscope? The pen microscope M503.106 delivers high visual resolution at 100× magnification, making it suitable for detecting surface defects, fine markings and micro‑geometry on small components. Can the integrated scale be used for accurate measurements? The built‑in 0.01 mm graduation enables quick comparative checks and rough sizing at the point of inspection; for traceable dimensional measurement, follow‑up with a calibrated measuring instrument is recommended. Is the instrument suitable for use in an industrial environment? Yes. The aluminium/polyamide housing and coated optics are designed for everyday use in workshop and production settings where a compact, durable inspection tool is required. How portable is the device for mobile inspections? With slim dimensions (122 × 12 mm) and a low weight of 0.1 kg, the instrument is easy to carry in an inspection kit and to handle for short‑cycle visual checks. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
122x12 mm Pocket Microscope 25× Scale 0.05 mm Aluminium/Polyamide Body - Metav IndustryLine
Compact 25× magnification and an integrated 0.05 mm scale enable rapid, reliable surface checks; the aluminium/polyamide housing keeps the instrument both robust and lightweight for everyday workshop use. Order the M503.102 pen microscope directly via Metav Werkzeuge or ask our consultants for application advice. M503.102 pen microscope — 25× magnification with 0.05 mm scale (Metav IndustryLine) The M503.102 pen microscope is a compact handheld inspection tool designed for quick visual checks and simple linear measurements in production, maintenance and quality inspection environments. 25× magnification for detailed inspection 0.05 mm engraved scale for quick measurements Aluminium/polyamide housing, robust and lightweight Coated lens for improved contrast and durability Fast, measurable inspection for production workflows The combination of 25× magnification and an engraved 0.05 mm scale allows immediate, measurable assessment of small features and surface conditions. Inspections that would otherwise require transfer to a bench top instrument can be performed at the component or assembly station, reducing handling time and the risk of damage. The clear, coated lens improves contrast and helps spotting micro‑defects, while the compact format supports handheld operation during routine quality checks. Built to withstand workshop demands without fatigue A housing made from aluminium/polyamide balances stiffness with low weight, so the device resists knocks and repeated handling while remaining easy to hold for longer checks. At about 0.1 kg, the instrument is lightweight enough for serial inspection tasks yet solid enough to feel precise in the hand. The robust construction and material choice translate into consistent performance in production areas where reliability and repeatability matter. Practical integration into quality and maintenance routines The simple engraved scale and generous field characteristics support quick pass/fail decisions and documentation of defect sizes directly at the bench. As a handheld inspection aid, the instrument complements established metrology equipment by offering a fast screening step before more precise measurements are taken. The Metav IndustryLine origin signals a focus on accessible precision: compact tools that help standardise routine checks and maintain throughput in busy workshops. For dependable, workshop-ready inspection tools from Metav IndustryLine, contact Metav Werkzeuge in Emmerich for tailored advice and supply options. Technical Data SKU: M503.102 GTIN: 4054469144429 ECLASS: 21170509 ETIM: EC001685 Facts Magnification: 25 Dimensions: 122 x 12 mm Scale division: 0.05 mm Field of view: 4 Weight: 0.1 kg Measuring length: 3 Tariff number: 90111090 Special features Housing: aluminium/polyamide Lens: coated Scale type: A Scale included FAQ What magnification and scale division does the instrument provide? The instrument offers 25× magnification with an engraved 0.05 mm scale for immediate linear assessment. Is the lens treated for improved contrast and durability? Yes, the lens is coated, which enhances contrast and resists surface wear during regular use. Which environments and tasks suit this pen microscope? Suited to production inspections, maintenance checks and workshop quality control where quick visual and simple dimensional checks are required. How portable is the device for routine use on the shop floor? Designed for handheld operation, the device is lightweight and robust, making it appropriate for serial inspections and mobile quality tasks. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
127mm Precision Work Magnifier 5 Dioptre LED 600 lm, 12W Table Clamp Arm 400+400 - Metav IndustryLine
Benefit from precise bench inspection, long-lived illumination and flexible positioning: the combination of a 127 mm glass lens, 5 dioptre optics and a stable table-clamp mount delivers repeatable, comfortable inspections for assembly and QC tasks. Order the M503.164 work magnifier directly via Metav Werkzeuge or ask our consultants if needed M503.164 Work Magnifier with LED, 5 dioptre — Table-clamp loupe with 127 mm glass lens and 2.25× magnification (Metav IndustryLine) M503.164 Work Magnifier with LED, 5 dioptre is a bench-mounted inspection loupe designed for detailed assembly, inspection and repair work where a wide, distortion-free view and reliable illumination matter 5 dioptre magnification for fine detail 127 mm glass lens for wide field of view Articulated arms 400+400 mm for flexible positioning 600 lm LED light, 12 W — approx. 20,000 h service life Precision optics that improve inspection quality The M503.164 integrates a large 127 mm glass lens with a 5 dioptre correction, producing a comfortable 2.25× magnification that expands the field of view while keeping image distortion low. This combination is particularly useful in electronics assembly, quality control and delicate repair work, where distinguishing fine features quickly reduces rework time. The use of a proper glass lens rather than inexpensive plastics improves optical clarity and scratch resistance, supporting consistent visual judgements across repeated inspections. Flexible support for faster, safer workflows A dual articulated arm (400+400 mm) and a secure table-clamp base enable rapid repositioning and stable holding close to the workpiece. The articulated reach allows the loupe to be set exactly where it is needed without obstructing tools or fixtures; once clamped, the 3.5 kg assembly remains vibration-resistant, which aids steady hands and repeatable checks. This mechanical stability directly contributes to throughput and reduces operator fatigue by removing the need for awkward postures. Bright, efficient lighting that reduces eye strain Built-in 60 LEDs provide 600 lm of uniform illumination while consuming only 12 W, offering a neutral, shadow-minimising light that improves contrast on textured or glossy surfaces. The LED array is rated for approximately 20,000 h service life, keeping maintenance intervals long and total cost of ownership low. Running on 220–240 V / 50 Hz, the lighting delivers immediate brightness without warm-up, which shortens inspection cycles and supports continuous bench work. Built for workshop reliability and practical handling Constructed around robust components and an industrial table clamp, this loupe balances optical performance with everyday usability. The assembly’s mass and joint geometry ensure stability during fine adjustments, while the lens size and illumination together provide a generous working area beneath the loupe. The unit suits bench environments in production, labs and craft workshops where dependable, repeatable visual inspection is a routine requirement. Choose the Metav IndustryLine M503.164 for reliable bench inspection with long‑life LED illumination — contact Metav Werkzeuge for tailored advice and secure supply at info@metav-werkzeuge.com or by phone on +49 2822 7131930 Technical data SKU: M503.164 GTIN: 4054469144702 ECLASS: 21170614 Tariff number: 90138090 Manufacturer: Metav IndustryLine Facts Magnification: 2.25× Dioptre: 5 dpt Lens diameter: 127 mm Illumination: 600 lm LED count: 60 Power: 12 W Voltage: 220–240 V / 50 Hz Arm reach: 400+400 mm Weight: 3.5 kg Lifespan (LED): approx. 20,000 h Special features Glass lens Table-clamp base Dual articulated arm Wide-field inspection loupe Integrated LED illumination Brand: Metav IndustryLine FAQ What magnification and dioptre does the loupe provide? The M503.164 work magnifier delivers 2.25× magnification with a 5 dioptre lens, combining enlargement and comfortable focus for fine inspection tasks. Can the loupe be securely mounted to a workbench? Yes. The unit features a robust table-clamp base that fixes the loupe to a bench edge and prevents unwanted movement during close visual work. How bright is the lighting and how long will it last? The integrated 60-LED array produces 600 lm at 12 W and is specified for approximately 20,000 hours of service, providing long-term, low-maintenance illumination. Is the lens material suitable for precision work? The lens is made of glass and measures 127 mm in diameter, offering a wide, clear viewing area with minimal distortion for reliable visual assessments. Which tasks and environments is this loupe suited to? Its combination of stable clamping, articulated reach and even illumination suits electronics assembly, quality control, watchmaking and workshop inspection benches. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
127mm/5" Magnifying Lamp 5 Dioptre, 2.25x Magnification, Dimmer, Dual 300mm Articulated Arms, Table Clamp, 24W 1200lm - Metav IndustryLine
Take advantage of the combination of precise optics, adjustable LED illumination and a stable table clamp to speed up inspection tasks and improve reproducibility. Benefit from a wide 127 mm viewing field and a 5 dioptre lens that delivers clear 2.25× magnification for detailed assembly and quality control. Order the unit directly via Metav Werkzeuge or consult the specialists for suitability and delivery. M503.166 Workbench magnifier with LED — 5 dioptre, 127 mm lens (Metav IndustryLine) The M503.166 is a table-clamp workbench magnifier designed for inspection, assembly and fine-detail work, combining a 127 mm glass lens with dimmable LED lighting and articulated arms for precise positioning. 5 dioptre magnification for precise inspection 127 mm glass lens delivers wide field of view Dimmable LED light 1,200 lm with 117 LEDs Robust table clamp and 2 × 300 mm articulated arms Precision optics for reproducible inspection results A large 127 mm lens made from optical glass provides a generous field of view that reduces the need to re‑position components during inspection. The unit’s 5 dioptre optical system corresponds to a 2.25× magnification, which is well suited to electronics assembly, fine mechanical inspection and detailed quality checks. The heavy base and clamp arrangement ensure the magnifier remains steady, so measurements and visual inspections stay consistent even during soldering or small adjustments. The construction balances reach and rigidity: 2 × 300 mm articulated arms allow flexible placement while maintaining optical alignment. Illumination and ergonomic control that reduces fatigue Integrated illumination uses 117 LEDs to deliver 1,200 lm of evenly distributed light while consuming 24 W, offering a bright working plane without excessive heat. The light is dimmable, enabling tailored contrast for different tasks and materials and helping to reduce eye strain during prolonged sessions. A mains supply of 220–240 V / 50 Hz provides universal compatibility in standard workshop environments. With an expected service life of approx. 20,000 h, the LED module sustains consistent performance and lowers the need for frequent lamp changes, supporting uninterrupted production workflows. Robust mounting and practical handling for busy workshops Mechanical design focuses on repeatability and convenience: a secure table clamp and substantial unit weight (approx. 6.6 kg) deliver stability, while the articulated joints permit accurate alignment over components without complex re‑setup. The magnifier is engineered for routine industrial use — inspection, assembly, fine rework and quality control tasks — where reliable optical clarity and steady illumination are essential. The combination of a glass lens, robust mounting and long‑life LEDs results in a durable inspection tool that supports lean processes and reduces downtime for maintenance. Contact Metav Werkzeuge for tailored advice and fast delivery from Emmerich — specialists will confirm suitability and lead times for the M503.166 workbench magnifier Technical data Article number: M503.166 Manufacturer: Metav IndustryLine GTIN: 4054469164595 Tariff number: 90138090 Facts Magnification: 2.25× Dioptre: 5 dioptre Lens diameter: 127 mm / 5" Light output: 1,200 lm LEDs: 117 Power consumption: 24 W Supply: 220–240 V / 50 Hz Rated lifetime: approx. 20,000 h Weight: 6.6 kg Arm lengths: 300 + 300 mm (articulated) Special features Glass lens for high optical clarity Dimmable LED illumination Table clamp mounting for stability Two articulated arms for wide reach and positioning Designed for inspection, assembly and fine rework FAQ What magnification does the magnifier provide? The magnifier delivers 2.25× magnification via a 5 dioptre lens, optimised for detailed inspection and assembly work. Is the lens material suitable for precise visual inspection? Yes, the lens is made of optical glass, providing sharp detail and a wide viewing field compatible with fine mechanical tasks. How bright is the illumination and can it be adjusted? The unit produces 1,200 lm from 117 LEDs and the light is dimmable, enabling contrast control for different materials and tasks. What mounting options are available for bench installation? The device uses a robust table clamp and two articulated arms (2 × 300 mm) for secure bench mounting and flexible positioning. Is the lighting energy efficient and long lasting? The LEDs consume 24 W and have an expected life of approx. 20,000 h, reducing maintenance intervals and total operating cost. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
12x Eyeglass Magnifier Small Vent Tubus Anti-Fog Aluminium - Peak
Take advantage of the combination of 12x magnification, lightweight aluminium construction and an anti-fog vent for fast, reliable inspection of delicate parts; order the loupe directly via Metav Werkzeuge or ask our consultants if further guidance is required. Peak 12x loupe (A48D) — aluminium housing with anti-fog vent Peak 12x loupe (A48D) is a compact inspection loupe designed for close visual work on small components such as watches, jewellery and precision parts 12x magnification for fine detail Lightweight aluminium housing Vent prevents lens fogging Ideal for watches and jewellery Faster, more accurate visual inspection of fine parts Equipped with 12x magnification and a single lens, this inspection loupe delivers clear enlargement for quality control and assembly inspection. The magnification helps to detect hairline defects, burrs and surface irregularities that are difficult to see with the naked eye, reducing rework and inspection time. Where a numeric value is required for comparison with measuring tools, pairing the loupe with a precision caliper supports consistent dimensional verification. The optical arrangement is explained in plain terms so that operators unfamiliar with lens technology understand that a single, well-corrected element provides a sharp central image ideal for detailed scrutiny. Robust, lightweight design for everyday workshop use The housing is manufactured from aluminium, offering a favourable strength-to-weight ratio that keeps handheld use comfortable during extended tasks. The compact form factor is built to withstand routine workshop handling while remaining easy to carry between benches or to a worksite. Corrosion-resistant material and a solid finish ensure long service life under normal industrial conditions, which contributes to predictable maintenance cycles and lower total cost of ownership. Ergonomic handling reduces fatigue during repetitive inspection routines, improving operator efficiency and throughput. Consistent clarity in changing environments A small bore in the tube provides an anti-fog vent, preventing condensation from forming on the lens when moving between temperature zones or when an operator’s breath would otherwise mist the optics. This practical detail preserves image clarity and minimises interruptions during inspection, a direct advantage when tight schedules leave little room for delays. The vent also reduces the need for frequent cleaning, supporting uninterrupted workflow and reliable results even in humid conditions. Basic cleaning instructions for optical surfaces prolong performance and protect the lens coating. Practical applications and benefits for quality workflows Designed for fine work on watches and jewellery, the loupe also suits electronics assembly, component sorting and other precision tasks where visual detail is critical. The combination of compactness, lightweight build and reliable optics speeds up inspection, helps avoid costly production errors and supports artisan craftsmanship. For workshops that already rely on measurement tools, the loupe complements dimensional checks and visual inspection steps, creating a tighter quality loop between measurement and assessment. With its straightforward features, this inspection loupe integrates smoothly into established processes and contributes to more consistent inspection outcomes. Arrange technical advice with Metav Werkzeuge for this Peak 12x loupe (A48D) and secure prompt delivery from our Emmerich hub — email info@metav-werkzeuge.com or call +49 2822 7131930 Technical data Article number: MS905.299 Type: A48D Category: Optics Facts Magnification: 12x Lens count: 1 Material: Aluminium Special features Small bore in tube prevents lens fogging Suitable for fine work on watches and jewellery FAQ What magnification does this loupe offer? The Peak 12x loupe (A48D) provides 12x magnification, suitable for detailed inspection of small components. Is the lens a single element or multi-element design? The loupe uses a single lens configuration that gives a sharp central image for fine visual inspection. Will the loupe fog up during temperature changes? A small vent in the tube prevents fogging, so the loupe maintains clarity when moving between different temperature or humidity conditions. Can this loupe be used together with a precision caliper? Yes, the loupe complements dimensional checks and pairs well with a precision caliper for combined visual and measurement inspection. Which workshop tasks is the loupe best suited to? Ideal applications include inspection of watches and jewellery, electronics assembly and any task where enhanced visual detail improves quality control. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
15 kg LED Light With Adjustable Focal Length And Tilt, Ø50x10 Base, 250mm Height - Metav IndustryLine
Secure, portable workshop illumination that combines a 15 kg magnetic hold with an adjustable focal length for task-focused lighting; lightweight and battery‑powered for flexible positioning. Order the LED light directly via Metav Werkzeuge or consult our specialists for bespoke advice. LED light with permanent magnet, adjustable focal length 15 kg — Metav IndustryLine task lamp LED light with permanent magnet, adjustable focal length 15 kg is a compact, battery‑operated work lamp designed for secure attachment and precise illumination in workshops and inspection stations. Round permanent magnet base Ø50 mm Adjustable tilt and focal length Secure hold with 15 kg magnetic force Battery-operated for mobile use Concentrated illumination that improves task efficiency The magnetic work lamp delivers crisp, directed light so operators can concentrate on fine operations without relocating heavy fixtures. With a permanent magnet base and an adjustable focal length, the lamp reduces setup time and improves repeatability when inspecting components or aligning tools. The lamp’s compact form and 15 kg holding force allow it to remain reliably fixed to steel surfaces while the beam is focused where it is needed most, cutting the time spent re‑positioning and reducing potential rework. Portable design for flexible workshop and inspection use Built for mobility, this battery‑operated lamp runs on 3x Micro‑AAA cells (not included), giving freedom to move between machines, benches and inspection jigs without trailing cables. The device’s low mass (0.45 kg) and 250 mm overall height make it comfortable to handle and quick to position. The adjustable tilt keeps the light oriented on critical areas, while the focused beam helps to reveal surface defects, burrs or fine features that ambient lighting can miss. Robust attachment and safe handling for industrial environments The round magnetic base (Ø50 x 10 mm) combined with 15 kg magnetic force ensures a secure hold even on slightly curved or uneven ferrous surfaces. The lamp’s mechanism permits controlled tilt and focus adjustments, so the light can be locked into place once aligned; this stability supports consistent inspection results and reduces measurement variability. The housing and mounting geometry are tuned for frequent workshop use, delivering a dependable tool for assembly, maintenance and optical inspection tasks. Choose the Metav IndustryLine magnetic LED lamp M208.116 for dependable, focused illumination in the workshop — contact Metav Werkzeuge in Emmerich by phone +49 2822 7131930 or email info@metav-werkzeuge.com for tailored guidance and fast dispatch. Technical Data SKU: M208.116 GTIN: 4054469151571 Label: LED light with permanent magnet, adjustable focal length 15 kg, without batteries Category: Optik ETIM: EC001959 Facts Magnet force: 15 kg Total height: 250 mm Weight: 0.45 kg Base: Ø50 x 10 mm Batteries: 3x Micro‑AAA (not included) Special features Permanent magnet base, round Tilt angle adjustable Adjustable focal length Battery‑operated portable lamp Supplied without batteries FAQ How strong is the magnetic attachment? The magnetic base provides a holding force of 15 kg, enabling secure fixation to suitable ferrous surfaces for stable illumination. Does the lamp require batteries and which type? This lamp runs on 3x Micro‑AAA cells (not included); battery operation makes the unit portable and quick to deploy. Can the beam be focused and angled? Yes, the tilt angle and focal length are both adjustable to concentrate light precisely where required for inspection or assembly tasks. Is the lamp suitable for machine‑side mounting? The round permanent magnet and compact base (Ø50 x 10 mm) make it well suited for temporary mounting on machine tables, fixtures and housings for close‑up work. Which product designation should be quoted when ordering? Please refer to the Metav IndustryLine LED light with permanent magnet, adjustable focal length 15 kg (SKU M208.116) for ordering and enquiries. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
15.5mm Foldable Loupe 10x With Chromatic Correction - Peak
Take advantage of the compact design and chromatic correction for reliable, colour-accurate inspections; the combination of 10x magnification and a focused Ø15.5 viewing area supports precise visual checks. Order the Peak folding loupe directly via Metav Werkzeuge or consult the team for application advice. Peak folding loupe — 10x folding loupe with chromatic correction Peak folding loupe for close visual inspection and quality control in optics, electronics and jewellery work. Folding design for compact storage 10x magnification for fine detail Chromatic correction lens for true colour Ø15.5 mm field of view for precise checks Optical accuracy that supports exact inspection The loupe pairs 10x magnification with a lens featuring chromatic correction, which reduces colour fringing at high magnification and delivers a clearer image with true colour rendition. This correction is especially valuable when distinguishing subtle colour differences or inspecting fine print and solder joints, because lateral chromatic aberration is minimised. The optical specification therefore supports faster, more reliable visual judgements in inspection workflows. Portable design for everyday workshop use A folding mechanism protects the optics when not in use and makes the loupe easy to store in a pocket or toolbox. The compact external dimensions (39x24x22) mean the instrument occupies little space without compromising viewing performance. The retractable housing reduces the risk of lens damage during transport and ensures consistent readiness for routine checks, whether on the bench or on-site. Focused field of view for targeted quality control With a Ø15.5 viewing area, the loupe concentrates the operator’s attention on a precise section of the component under inspection. This focused field supports tasks that demand accurate visual assessment, such as examining solder joints, inspecting gemstone facets, or verifying small mechanical parts. The concentrated view reduces fatigue and speeds up repetitive checks, leading to more consistent quality control results. Practical handling, minimal upkeep The design emphasises straightforward handling and low maintenance. The folding action secures the lens against contaminants and simplifies cleaning routines; any routine wipe with a microfibre cloth restores clarity quickly. The Peak instrument is engineered for long-term usability, offering dependable performance as a handheld inspection tool across light-industry and hobbyist applications. Technical queries regarding suitability can be referred to Metav’s advisors for precise guidance. For tailored advice on integrating the Peak folding loupe into inspection procedures or to enquire about availability, contact Metav Werkzeuge by e‑mail at info@metav-werkzeuge.com or by phone at +49 2822 7131930 — the Metav team will assist with compatibility and procurement details Technical data Article number: MS905.202 Name: Peak folding loupe Variant: rund, 10x Manufacturer: Peak Image: https://files.plytix.com/api/v1.1/file/public_files/pim/assets/57/c3/98/62/6298c3575d155f1bc7e497fd/images/fe/10/d0/67/67d010fe2285a7cc9c2fed1f/MS905200-main.jpg Facts Magnification: 10x Field of view: Ø15.5 Dimensions: 39x24x22 Special features Lens: mit chromatischer Korrektur Shape: rund Category: Optik FAQ What magnification does the loupe provide? The Peak folding loupe provides 10x magnification, suitable for detailed visual inspections of small components. How large is the usable viewing area? The loupe offers a focused viewing area of Ø15.5, designed to target specific regions for precise checks. Is the lens treated to reduce colour errors? Yes — the lens of the Peak folding loupe includes chromatic correction, which reduces colour fringing and improves colour fidelity at higher magnification. How is the loupe stored when not in use? A folding housing protects the optics; the compact dimensions (39x24x22) allow safe storage in a pocket or toolbox. Which tasks is this loupe suitable for? The instrument is appropriate for inspection tasks such as jewellery appraisal, electronics assembly checks, watchmaking and other fine-detail visual work where 10x magnification and accurate colour rendition are required. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
150mm Foot For Magnifier, Opal Glass - Peak
Take advantage of a robust opal glass support that provides steady positioning and reduced glare together with direct compatibility with the Peak magnifier MS905.290. Order the base directly via Metav Werkzeuge or request specialist advice from our consultants for a seamless integration into the inspection station. MS905.291 Base for magnifier by Peak — opal glass support MS905.291 is a compact support base made from opal glass, designed to hold the Peak magnifier MS905.290 securely and to improve visual clarity during inspection tasks Opal glass construction for diffuse light Compatible with Peak magnifier MS905.290 Compact, stable support design Improved inspection clarity through diffuse illumination The opal glass construction provides a diffuse light effect that helps to reduce direct reflections and harsh glare on inspected surfaces. This optical characteristic is particularly useful when examining reflective or textured parts, because the softened illumination improves contrast without altering the object. The support’s material choice therefore contributes directly to more reliable visual assessments and fewer repeated inspections, making the process more efficient for workshop and laboratory routines. Stable positioning for consistent measurements Designed as a support base, the component offers stable support for hand-held and mounted magnifiers alike, minimising unintended motion during close inspection. Stable positioning reduces measurement variability and the risk of fatigue when carrying out repetitive checks. For quality control departments and repair benches, consistent alignment of the magnifier means quicker acceptance decisions and a smoother workflow, while preserving the integrity of delicate samples. Seamless compatibility with existing Peak optics The base is specified for use with the Peak magnifier MS905.290, ensuring straightforward integration into established inspection set-ups. Compatibility eliminates the need for adapters or modifications, simplifying procurement and installation. Where a compact footprint and neat visual integration are priorities, the support’s opal glass finish also lends a discreet, professional appearance to the inspection bench, combining practicality with an organised workspace aesthetic. Contact Metav Werkzeuge for tailored purchasing advice or a quotation and speak directly with our consultants at +49 2822 7131930 or info@metav-werkzeuge.com to ensure the base meets the intended application Technical data SKU: MS905.291 Material: Opal glass Compatible with Peak magnifier MS905.290 Category: Optics Brand: Peak Data No numerical specifications available Special features Opal glass construction Support base for magnifier Image available: https://files.plytix.com/api/v1.1/file/public_files/pim/assets/57/c3/98/62/6298c3575d155f1bc7e497fd/images/db/60/c8/67/67c860dba8658cbb791b0ea4/MS905291-main.jpg FAQ Is this base suitable for use with other magnifiers? Compatibility is specified for the Peak magnifier MS905.290; other magnifiers may fit depending on their mounting geometry, but MS905.291 is designed for Peak’s MS905.290 How does opal glass benefit inspection tasks? The opal glass of MS905.291 softens and diffuses light, reducing glare and improving surface contrast for clearer visual inspection Can the support be integrated into an existing inspection station? MS905.291 is intended as a compact support base and can be integrated into existing benches where the Peak magnifier MS905.290 is used, without additional adapters for typical set-ups Where can technical advice or further product details be obtained? Technical advice and further information are available from Metav Werkzeuge; the MS905.291 base can be specified and discussed with their specialists Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
150mm Illumination Lamp LED, Battery Powered - Peak
The compact, battery-powered illumination delivers consistent light for close optical inspection while remaining fully compatible with Peak Zoom loupes; ideal where mobility and quick visual checks are essential. Order the lighting module directly from Metav Werkzeuge or consult their advisors for application guidance. Peak Lighting MS904.028 — compact illumination for precision optical work, battery powered The Peak Lighting MS904.028 is a compact illumination unit developed for close-up inspection tasks and intended for use with optical magnification aids in laboratory, clinic or workshop environments. Battery operation: 2× Type C cells Compatible with Peak Zoom loupes Compact optical lighting for inspection Easy retrofitting to magnification aids Delivering reliable illumination for detailed inspection Bright, consistent light is fundamental when inspecting fine detail under magnification. The MS904.028 offers a battery-powered source of illumination that reduces shadowing and improves contrast during close visual inspection, making surface defects and small features easier to see. By providing stable, task-focused lighting, the unit helps to reduce eye strain during extended checks and supports more reliable visual assessments. Improved visibility directly contributes to fewer missed defects and a more efficient inspection routine. Integration with magnification aids for practical workflows Designed to match the form and function of popular magnification systems, this lighting module is compatible with Peak Zoom loupes, enabling straightforward integration into existing inspection setups. The compact design keeps the optical axis unobstructed and preserves working ergonomics, so operators can maintain a natural posture while examining components. Compatibility with established zoom loupes means minimal adaptation time and predictable results when switching between unaided and magnified inspection. Portable power for flexible use on the go Powered by 2× Type C batteries (not included), the illumination unit avoids tethering to mains power and supports inspections in locations without convenient outlets. Battery operation delivers flexibility for quick checks on the production line, at customers’ premises or during field service calls. The straightforward power concept simplifies logistics: replacement cells are widely available, and swapping depleted batteries restores full functionality without specialised tools. Practical benefits for quality assurance and day-to-day work By combining portability with targeted light output, this lighting solution helps standardise visual inspection conditions across different workstations and environments. The consistent illumination supports more repeatable assessments and can shorten the time needed for visual checks, contributing to smoother production flow. For purchasers seeking dependable optics accessories, Metav’s distribution ensures rapid availability and transparent order handling from Emmerich, with the reassurance of a broad product range and decades of precision expertise. For tailored advice on application and compatibility, contact Metav Werkzeuge for purchasing and delivery information; their specialists can confirm suitability for specific inspection tasks and arrange prompt supply from Emmerich. Technical Data Article number: MS904.028 Manufacturer: Peak Category: Optics Facts Batteries: 2× Type C (not included) Special features Compatible with Peak Zoom loupes Lighting for close-up inspection Image available: https://files.plytix.com/api/v1.1/file/public_files/pim/assets/57/c3/98/62/6298c3575d155f1bc7e497fd/images/b4/5f/c8/67/67c85fb49bcec1e3dfe77429/MS904028-main.jpg FAQ What power source does the lighting use? The lighting unit requires 2× Type C batteries; the MS904.028 is supplied without batteries. Is this illumination compatible with zoom loupes? Yes, the MS904.028 is designed to be compatible with Peak Zoom loupes for inspection and magnification tasks. Can the lighting be used away from a mains supply? Battery operation allows the unit to be used independently of mains power, suitable for mobile or field inspections. Does the product include mounting accessories? The delivery contents do not list mounting hardware; the MS904.028 is intended for integration with compatible magnification aids. Where can technical advice for applications be obtained? Application-specific guidance and compatibility checks can be provided by Metav Werkzeuge for the MS904.028 lighting module. Metav IndustryLine: Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
150mm Peak Standard Template Nr. 1 - Peak
Take advantage of a compact, standard template that streamlines optical inspection and supports consistent alignment across repeated checks. The combination of a clear reference format and straightforward handling helps reduce inspection time while improving repeatability. Order the Peak Standard Template No. 1 directly via Metav Werkzeuge or ask our consultants if needed. Peak Standard Template No. 1 — Optical alignment template for inspection A Peak Standard Template No. 1 designed as a simple reference for optical inspection and alignment in workshop inspection routines Peak standard template for optics Compact format for easy storage Enables consistent alignment during inspection Suitable for optical workshop workflows Faster, repeatable optical checks with less uncertainty The standardised reference offered by this template allows rapid, comparable checks during visual and optical inspection routines. By providing a fixed pattern for positioning and alignment, measurement variation is reduced and process times are optimised. For repetitive tasks, the template contributes to a predictable workflow and supports quality control measures that rely on consistent visual references rather than ad hoc setups. Integrates with common inspection workflows for greater efficiency Designed for use in optical environments, the template fits naturally into bench-based inspection stations and complements microscope-assisted checks. The simple format means it can be positioned quickly and reused across batches, which helps to maintain throughput without compromising the clarity of each inspection. This straightforward integration reduces setup steps and keeps the focus on the inspection result. Supports reliable documentation and process consistency Using a constant reference improves traceability in routine inspections and makes it easier to document conformity or deviations. The template is intended to assist with alignment and visual comparison tasks, helping teams achieve consistent outcomes across shifts and operators. Backed by Metav’s commitment to accessible precision, the product aligns with workshop needs for dependable, easy-to-adopt tools that support reproducible results. For reliable optical alignment in busy workshops, request the Peak Standard Template No. 1 from Metav Werkzeuge — call +49 2822 7131930 or e‑mail info@metav-werkzeuge.com for tailored advice and order support Technical data Article number: MS905.273 Name: Peak Standard Template Type: No. 1 Facts Image file size: 470836 bytes Category path: Optik Special features Brand: Peak Asset URL: https://files.plytix.com/api/v1.1/file/public_files/pim/assets/57/c3/98/62/6298c3575d155f1bc7e497fd/images/d1/33/d0/67/67d033d142e38a433141d0ab/MS905273-main.jpg FAQ What is the Peak Standard Template No. 1 intended for? The Peak Standard Template No. 1 (SKU MS905.273) is intended as a reference for optical inspection and alignment tasks in workshop and inspection-bench environments. Can the template be used alongside microscopes for fine inspection? Yes. The template is suitable for use in conjunction with microscopes and other optical inspection equipment to support consistent visual checks. Which product category does this item belong to? This item is listed under the Optik category and serves as a basic alignment and reference tool for optical workflows. How does the template improve serial inspection routines? By providing a fixed reference, the template enables consistent placement and alignment across multiple parts, reducing variability between checks and supporting repeatable documentation. What information identifies this product for ordering? The product is identified as Peak Standard Template No. 1 with SKU MS905.273, which should be referenced when enquiring or ordering. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
15x Illuminated Magnifier Ø25 With LEDs, Battery Powered - Peak
Take advantage of 15× magnification, integrated illumination and compact dimensions to speed up visual inspections and reduce rework; order directly via Metav Werkzeuge or contact our consultants for technical guidance. Peak Illuminated Magnifier MS905.119 — 15× magnification with illumination The Peak Illuminated Magnifier is a compact optical aid designed for close inspection tasks in workshops, laboratories and jewellery workbench applications. 15× magnification for fine-detail inspection Integrated illumination for even lighting Wide Ø25 field of view for easier scanning Compact 180×36×42 dimensions for workshop use Inspect finer detail with reliable 15× magnification The combination of 15× magnification and a clear, Ø25 field of view enables precise visual checks of small components and surface features. This level of enlargement makes hairline defects, solder joints and fine engravings easier to evaluate, which reduces the need for repeated handling and speeds up quality assurance. The optical performance is geared towards repetitive inspection tasks where clarity and repeatability matter. Consistent illumination to reveal hidden faults An integrated illumination source delivers even, shadow‑reducing light across the viewing area so that textures and contrasts become more visible. For delicate work on circuit boards, jewellery or printed markings, the lit lens reduces eye strain and improves accuracy. The lighting is powered by Type C batteries (2× Type C, not included), ensuring portability and the freedom to work away from fixed power supplies. Compact, practical design for workshop workflows With compact 180×36×42 dimensions, the tool is easy to position at a workbench or pass between technicians without obstructing other tasks. The housing and form factor prioritise manoeuvrability in confined spaces, making the device suitable for inspection rounds and bench work alike. Portability, combined with the illumination and high magnification, supports efficient inspection cycles and smoother production flows. Clear specifications for purchasing and inventory The instrument is categorised in optics and supplies practical benefits for routine quality checks. The construction focuses on optical clarity and user convenience rather than complex electronics, which simplifies maintenance and replacement planning. Technical features such as magnification, field size and battery type are presented plainly to support procurement and ensure the magnifier integrates seamlessly into existing inspection routines. Contact Metav Werkzeuge today to discuss the Peak illuminated magnifier MS905.119, confirm suitability for specific inspection tasks or arrange swift delivery from our Emmerich hub at info@metav-werkzeuge.com or +49 2822 7131930 Technical data Article number: MS905.119 Brand: Peak Product name: Peak Illuminated Magnifier Facts Magnification: 15× Field of view: Ø25 Dimensions: 180×36×42 Battery: 2× Type C (not included) Special features Integrated illumination Category: Optics Compact design FAQ What level of magnification does the magnifier offer? The magnifier provides 15× magnification, suitable for detailed inspection of small components and fine craftsmanship. Is the lighting built in and what powers it? Yes, the device features integrated illumination powered by 2× Type C batteries (not included), allowing cordless use at the bench. Which inspection tasks is this magnifier best suited to? The instrument is ideal for tasks such as solder joint inspection, jewellery appraisal, stamp and print examination, and general small-part quality checks. How large is the visible area through the lens? The viewing area is specified as Ø25, offering a balance between magnified detail and a usable field for scanning small surfaces. Can the illuminator be used on portable inspection rounds? Yes, the integrated lighting and compact 180×36×42 dimensions make it convenient for mobile inspections and bench transfers. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
inspect faster and with greater certainty using magnifiers
Magnifiers (also known as loupe and magnifying glass) are optical instruments that render small objects and surface details visibly larger, producing a virtual, upright image through a converging lens. In metallography and industrial quality assurance they represent the first stage of optical inspection, offering a fast, reliable check before more detailed analysis with microscopes.
how magnifiers work and where they belong in the workflow
A magnifier’s enlargement is determined mainly by the focal length of its lens: the shorter the focal length, the higher the achievable magnification. Typical workshop types include the hand magnifier for quick surface checks, the folding or inspection magnifier for stable close-up work at the bench, the measuring magnifier with an integrated reticle for direct dimension checks, and the stand magnifier for fatigue-free, repeatable inspection at a fixed working distance. In practice they are indispensable for spotting hairline cracks, corrosion, tiny burrs and for reading fine engravings on components.
practical advantages that improve production throughput
- Rapid first-pass inspection, reducing time sent to downstream process steps and avoiding unnecessary rework.
- Direct measurement capability with measuring magnifiers, enabling quick quantitative checks without switching tools.
- Stable positioning with stand magnifiers, lowering operator fatigue and increasing repeatability.
- Compact, portable options (hand and folding magnifiers) for in-situ checks on assemblies or machines.
- Simple optical design: robust, low-maintenance tools that complement microscopes for layered inspection strategies.
why choose metav as your precision partner
Metav democratises precision by making high-quality measuring tools affordable for every workshop. From our base in Emmerich we act as a quality filter for the European market, supplying over 250,000 products and trusted by more than 48,000 customers. That breadth ensures you can reduce supplier complexity while sourcing the right magnifiers — from portable hand lenses to calibrated measuring models — backed by a consistent supply chain and industrial expertise.
In short, magnifiers provide immediate, reliable optical inspection for workshop and production environments, combining simplicity with measurable time and quality benefits.
faq
What types of magnifiers are commonly used in metal inspection?
Common types used in metal inspection include the hand magnifier for quick checks, the folding or inspection magnifier for close work, the measuring magnifier with reticle for dimension assessment, and the stand magnifier for prolonged, stable inspection.
How does magnification relate to focal length?
Magnification is primarily governed by the focal length of the lens: a shorter focal length results in higher magnification, which determines how much larger the virtual, upright image appears compared with the naked eye.
Can magnifiers replace microscopes for quality assurance?
Magnifiers are intended as a first-line optical inspection tool; they are ideal for rapid checks and measurements but do not replace detailed analysis performed with microscopes, which are required for higher-magnification examination and microstructural evaluation.
Are measuring magnifiers suitable for quantitative checks on welds and cracks?
Yes. Measuring magnifiers with an integrated reticle or scale enable direct, quantitative assessment of features such as crack widths, groove depths or small weld defects, speeding up in-process decisions.
