Quick, secure clamping with lever clamps
Lever clamps provide rapid, repeatable workholding for fixture building, assembly, welding and testing, using the kinematic knee-lever principle to deliver self-locking retention and resist process vibrations. Designed for metalworking applications and made from high-strength materials such as zinc-plated steel or stainless steel, these clamps reduce setup and handling times while enabling high holding forces with minimal operator effort. Available in vertical and horizontal versions as well as thrust bar and closure styles, lever clamps ensure consistent positioning, long service life and enhanced process reliability for serial production. Key advantages include self-locking mechanism, high repeatability, reduced setup time and robust construction.
0 16mm Rod Clamp With Small Angle Foot M4x20 Pressure Screw, 800 N Holding Force - AMF
Take advantage of the compact design and reliable clamping performance: the small angled foot enables flexible mounting while the 800 N maximum clamping force and 16 mm stroke ensure secure operation in confined fixture and jig applications. Order the clamp directly via Metav Werkzeuge or contact their consultants for further technical advice. AMF push-rod clamp No. 6841, Size 0 – small angled foot The AMF push-rod clamp No. 6841 is a compact push-rod clamping element for fixture and jig construction, designed for versatile mounting where space is limited and repeatable clamping force is required. Compact size 0 for confined fixture spaces Maximum clamping force 800 N 16 mm stroke for secure engagement Small angled foot for flexible mounting Secure clamping performance in tight spaces The push-rod locking element delivers a consistent maximum clamping force of 800 N, making it suitable for light to medium fixture tasks where dependable force is essential. The 16 mm stroke provides a defined travel distance for the actuator rod, so engagement and release are repeatable and measurable. This characteristic reduces setup time and contributes to process stability on assembly jigs and test fixtures. The compact size 0 format is specifically suited for installations with limited clearance while still providing measurable holding capability and mechanical reliability. Flexible installation and clear mechanical interfaces Installation is simplified by the small angled foot, which allows the clamp to be mounted in challenging orientations without the need for custom brackets. The unit includes a pressure screw M4 x 20 for fine adjustment of contact pressure and an interface thread M10x1 for secure attachment. These standardised connections enable straightforward integration into existing tooling plates and modular fixtures. The defined dimensions (for example, A = 6.5 mm, B range = 17–33 mm) support precise positioning during fixture design and help to avoid interference with moving parts. Designed for dependable production use and easy specification This clamping device is engineered for repeatable operation, with a clear separation between actuation travel and applied force that eases specification in technical drawings and bills of materials. The mechanical design focuses on longevity and low-maintenance performance, which in turn supports higher uptime in small-batch production and specialised fixtures. For clarification of fit or compatibility with other components, further technical data can be supplied and additional measurements provided on request; Metav Werkzeuge is available to assist with component selection and integration queries. Contact Metav Werkzeuge for tailored advice on integrating the AMF push-rod clamp No. 6841 into production fixtures or for immediate ordering from Emmerich. Technical data Article number: 4000833515NW Type: 6841 Product: Push-rod clamp Manufacturer: AMF Packaging unit: 1 Core data Max clamping force: 800 N Max holding force: 800 N Stroke: 16 mm A: 6.5 mm B min: 17 mm B max: 33 mm D: 4.5 mm E: 13 mm H: 12 mm H1: 49.3 mm K: 6.5 mm L1: 66.5 mm L2: 10 mm M max: 16 mm Thread M2: M10x1 N: 25 mm P: 16 mm Design & special features Size: 0 Pressure screw: M4 x 20 Small angled foot Compact design for fixture and jig mounting FAQ What is the maximum clamping force of this clamp? The AMF push-rod clamp No. 6841 provides a maximum clamping force of 800 N, suitable for light to medium fixture operations. What is the stroke of the clamping rod and why does it matter? The device has a 16 mm stroke; this defines the travel distance for engagement and ensures repeatable clamping positions in jigs and fixtures. Which mounting options are available for constrained spaces? The small angled foot allows flexible mounting orientations, enabling the clamp to be positioned where straight-foot clamps may not fit. What thread and adjustment interfaces are provided? The clamp includes a pressure screw M4 x 20 for contact adjustment and a thread M10x1 for secure attachment into the fixture layout. Is the clamp suitable for standard fixture plates and modular systems? Yes, the dimensional data (for example A = 6.5 mm, B = 17–33 mm) is intended to support integration into standard tooling plates and modular fixture systems using common fastening threads and adjustments. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
0 Vertical Clamp With Horizontal Foot M4 x 25 Pressure Screw, 500 N Holding Force - AMF
Compact, reliable clamping with a small footprint and precise adjustment makes this vertical clamp an efficient choice for modular fixtures; its horizontal base allows flexible mounting while holding forces up to 700 N secure workpieces reliably — order directly via Metav Werkzeuge or contact the consultants for application advice. Vertical Clamp No. 6800, Size 0 — horizontal base (AMF) Vertical Clamp No. 6800, Size 0 is a compact vertical clamping device with a horizontal base designed for flexible fixture mounting and secure workholding in small to medium machining setups Compact size 0 for tight fixtures Horizontal base for versatile mounting Holding force up to 700 N Max pressing force 500 N Secure, high-force clamping in a compact format The vertical clamping device No. 6800 delivers concentrated holding performance despite its reduced dimensions, providing a holding force of 700 N and a maximum pressing force of 500 N. This combination ensures secure fixation of components in high-repeatability setups, reducing slippage and rework. The compact footprint suits fixture plates and modular bedding systems where space is limited, while the vertical actuation keeps the clamping profile low. The mechanical design translates clamping input into reliable workpiece retention, which supports consistent cycle times and improved process stability. Flexible mounting and positioning with a horizontal base The integrated horizontal base permits a variety of mounting orientations on fixture plates and subplates, increasing layout options without additional adapters. The clamp offers an adjustable clamp range of 8.5–13.5 mm, allowing compensation for minor part-height variations. Dimensions such as L1 49 mm and L2 50 mm result in predictable centre distances during layout planning. Because the base sits flat, the device can be positioned beside locating elements or toolpaths without obstructing access, making it well suited to versatile jigs and progressive fixture designs. Fine adjustment and dependable mechanical interface Adjustment is achieved via the pressing screw M4 x 25, which enables controlled actuation and straightforward re-tensioning during set-up. The design tolerates a height variation between -1.5 mm and 3.5 mm, offering practical leeway for repeat setups and slight workpiece offsets. Precision features such as a defined clamp arm geometry and specified contact points (for example A = 4 mm, B = 31 mm) help maintain repeatable engagement and simplify datum alignment. These attributes support streamlined tooling changes and predictable clamping behaviour across series production or prototyping runs. Applications, efficiency and workshop integration This vertical clamp is particularly suited to toolrooms, small-batch production and fixtures for milling or drilling operations where compactness and repeatability matter. The size 0 configuration is optimised for narrow workpieces and dense fixture layouts, supporting higher part-per-fixture utilisation and shorter setup times. Integrating such a clamp into modular systems reduces the need for bespoke fixtures and contributes to a leaner tooling inventory. Confidence in workholding also minimises inspection rework, which benefits throughput and overall shop-floor productivity. For application-specific advice or to secure an AMF Vertical Clamp No. 6800 for modular fixtures, contact Metav Werkzeuge for tailored recommendations and availability — Metav Werkzeuge is available by e‑mail at info@metav-werkzeuge.com or by phone at +49 2822 7131930 Technical data Article number: 4000833500NW Type: 6800 Product: Vertical clamp No. 6800 Size 0 horizontal foot AMF Manufacturer: AMF Packaging unit: 1 Facts Max pressing force: 500 N Max holding force: 700 N A: 4 mm B: 31 mm C: 8.5–13.5 mm D: 4.5 mm E: 14 mm F: 5.5 mm H: 18 mm H1: 81 mm HW min.: -1.5 mm HW max.: 3.5 mm I: 8 mm K: 5.5 mm L1: 49 mm L2: 50 mm M: 23 mm N: 32 mm P: 22 mm a: 95° Pressing screw: M4 x 25 Special features Size 0 configuration Horizontal foot for flat mounting Compact vertical actuation Adjustable clamp range 8.5–13.5 mm FAQ What clamping force can be expected from this device? The vertical clamp offers a maximum holding force of 700 N and a pressing force of 500 N, providing secure fixation for a wide range of small to medium components. Can the clamp accomodate different part heights? Yes, the device provides a usable height window between -1.5 mm and 3.5 mm and an adjustable clamp range of 8.5–13.5 mm for compensating minor height variations. What size and mounting orientation does the clamp require? The clamp is Size 0 and features a horizontal base, permitting flat mounting on fixture plates or subplates where compact placement is required. Which screw is used for actuation and adjustment? Actuation and fine adjustment are performed via a pressing screw M4 x 25, allowing controlled tensioning during setup. Is this clamp suitable for modular fixtures and jigs? Yes, the compact vertical design and horizontal base make it particularly suitable for modular fixture systems, toolroom jigs and dense layouts where space efficiency is essential. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
0-140mm Horizontal Base Quick-Action Clamp, Screw-Type Lever Clamp - Kukamet
Take advantage of a robust workholding solution that combines a 0–140 mm adjustable opening with a maximum clamping force of 8,000 N for reliable, repeatable fixation. The galvanised construction and horizontal-foot mounting deliver corrosion resistance and secure bench attachment—order the clamp directly via Metav Werkzeuge or consult our specialists for integration advice. Quick-Release Clamp 831 — lever clamp with 0–140 mm opening and 8,000 N force (Kukamet) The Quick-Release Clamp 831 is a lever-style clamp designed for fast, repeatable workholding in workshops and production jigs, offering precise adjustment and strong retention for a wide range of tasks. Lever quick-release design for rapid clamping 0–140 mm adjustable opening 8,000 N maximum clamping force Galvanised steel for corrosion resistance Faster clamping with consistent holding power The lever mechanism delivers rapid actuation while the screw-clamp style allows fine setting before locking, combining speed and precision for high-throughput tasks. With a rated maximum clamping force of 8,000 N, this clamp keeps components steady during machining, assembly or inspection, reducing setup downtime and scrap rates. The adjustable 0–140 mm opening covers common workpiece sizes, enabling the same fixture to handle varied parts without time-consuming exchanges. Built to withstand workshop conditions and stay put Constructed from galvanised steel, the unit resists corrosion in humid or coolant-prone environments, extending service life and lowering replacement frequency. The horizontal-foot mounting provides a compact attachment point to workbenches, plates or fixture assemblies, ensuring lateral stability where space is limited. At approximately 2.3 kg, the clamp balances mass for vibration damping with manageable handling during installation. The combination of robust material and practical mounting supports uninterrupted operation in daily production. Integrates easily into jigs, fixtures and production cells The clamp’s lever concept and compact footprint make it suitable for manual workstations, CNC fixtures and assembly lines where repeatable clamping is required. The screw-clamp element permits micro-adjustment so that sealing faces and delicate components are held without overloading. Compatibility with common fixture layouts simplifies retrofitting; the design supports consistent clamping cycles that benefit process reliability and operator confidence. Technical identifiers and format make it straightforward to document and reorder for standardised setups. For consistent, high-performance clamping, contact Metav Werkzeuge to request the Kukamet Quick-Release Clamp 831 and discuss integration into existing fixtures — eMail info@metav-werkzeuge.com or call +49 2822 7131930. Technical Data SKU: 831-3 GTIN: 8680731506631 Manufacturer: Kukamet Category: Clamp Facts Opening range: 0–140 mm Maximum clamping force: 8,000 N Weight: 2.3 kg Special features Galvanised steel Horizontal-foot mounting Screw-clamp style Lever quick-release concept eClass: 21020701 ETIM: EC011973 FAQ What is the effective opening range of the clamp? The clamp provides an adjustable opening of 0–140 mm, suitable for a wide variety of fixtures and workpieces. What clamping force can be expected from this model? The Kukamet Quick-Release Clamp 831 delivers a maximum clamping force of 8,000 N, offering secure retention for machining and assembly tasks. Is the clamp suitable for humid or coolant-exposed environments? Yes, the clamp is made from galvanised steel, improving resistance to corrosion and making it appropriate for workshop conditions where fluids or humidity are present. How is the clamp mounted to a workbench or fixture? The unit uses a horizontal-foot mounting, designed for secure attachment to benches, plates or fixture bases where a lateral mounting point is required. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
0-90mm Quick-Action Toggle Clamp, Screw Clamp Type, Zinc Plated, 8,000 N Thrust - Kukamet
Take advantage of the combination of a compact horizontal mounting, sturdy 8,000 N clamping force and a corrosion-resistant galvanized finish for reliable fixture work and faster set-up times. Order the Kukamet 831 quick-action lever clamp directly via Metav Werkzeuge or consult our specialists for integration advice. 831 Quick-Action Lever Clamp by Kukamet — 0–90 mm opening, 8,000 N clamping force The 831 is a robust quick-action lever clamp designed for horizontal mounting in assembly jigs, fixtures and workshop benches. Horizontal base for stable mounting Galvanized finish for corrosion resistance 0–90 mm adjustable opening 8,000 N clamping force for dependable hold Faster fixture set-up where repeatability matters The lever-action mechanism provides a quick-action workflow that reduces clamping time and increases throughput in repetitive tasks. The adjustable 0–90 mm opening allows flexible positioning of workpieces without extra adapters, while the specified 8,000 N rating indicates the maximum holding force available under normal operation. For practical terms: clamping force given in newtons describes the mechanical push the clamp can apply, ensuring a secure hold for many assembly and machining aid scenarios. This results in fewer re-clamps and improved consistency in small- to medium-batch production. Built for corrosive workshop environments and long service life Constructed with a galvanized finish, the clamp resists moisture and workshop contaminants, which reduces maintenance intervals and extends service life. At 1.61 kg, the unit is lightweight enough for easy handling during fixture assembly yet substantial enough to remain vibration-stable under load. The protective coating lowers the risk of surface corrosion on contact points and helps maintain reliable repeatability across shifts, so downtime for replacement or repair is minimised. Simple integration with horizontal fixtures and safe operation The horizontal foot design allows direct installation on fixture plates, machine tables or workbenches, providing a low-profile clamping solution where vertical clearance is limited. The combination of a screw-clamp style interface and lever action enables controlled closing and secure locking with visible mechanical engagement. This design supports precise positioning and reduces the likelihood of slippage, offering an operational advantage in quality-critical applications and improving operator confidence during clamping cycles. Contact Metav Werkzeuge for tailored fixture recommendations and to secure the Kukamet 831 for your production line from our Emmerich stock Technical Data SKU: 831-2 GTIN: 8680731505351 Brand: Kukamet eClass: 21020701 ETIM: EC011973 Facts Max clamping force: 8,000 N Opening range: 0–90 mm Weight: 1.61 kg Special features Material: galvanized Mounting: horizontal base Clamp type: screw-clamp style, lever-action Category: spanner FAQ What maximum clamping force does this clamp provide? The Kukamet 831 quick-action lever clamp delivers a maximum clamping force of 8,000 N, suitable for secure holding in many workshop and fixture applications. What is the adjustable opening range of the clamp? The 831 offers an adjustable opening of 0–90 mm, allowing flexible accommodation of varied workpiece thicknesses without additional adapters. How is the clamp mounted in a fixture? The clamp features a horizontal base for direct mounting to fixture plates or benches, providing a low-profile attachment for constrained workspaces. Is the clamp suitable for use in humid or corrosive workshop environments? Yes, the galvanised finish on the Kukamet lever clamp provides enhanced corrosion resistance, reducing maintenance and extending service life in demanding environments. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
0.23kg Vertical Clamp 212 With Safety Lock, M6x40 Pressure Spindle, Galvanised - Kukamet
Reliable jigs benefit from a combination of built-in safety lock, zinc-plated corrosion resistance and a 1,200 N clamping force, delivering stable and repeatable hold-down performance. Order the vertical toggle clamp directly via Metav Werkzeuge or consult the technical advisers for application support. Kukamet 212 — Vertical toggle clamp with safety lock and zinc plating Kukamet 212 is a vertical toggle clamp designed to secure workpieces with a compact footprint and dependable locking. Zinc-plated finish for corrosion resistance Built-in safety lock for secure clamping 1,200 N clamping force, 1,400 N holding Vertical foot for direct bench mounting Proven clamping performance for production jigs The compact vertical clamp delivers a clear performance advantage where consistent pressure is required. Its 1,200 N clamping force and 1,400 N holding force provide measurable securing power suitable for medium-duty jigs and fixtures, reducing the need for repeated adjustments. The mechanical action is straightforward and reliable, which translates into less downtime and more predictable cycle times in repetitive operations. Technical teams benefit from a component that was engineered for steady, quantifiable results in assembly and machining support. Robust construction with user-centred safety Durability and operator safety are built into the design: a zinc-plated surface offers corrosion resistance for long service life in workshop environments, while the integrated safety lock prevents accidental release during handling or vibration. The clamp’s low mass contributes to easier handling without sacrificing strength—its lightweight construction supports quick fixture changes and reduces strain during setup. For environments where tool integrity and operator protection matter equally, this clamp balances robust materials with practical safety features. Simple mounting and maintenance for efficient workflows Installation is straightforward thanks to the vertical foot mounting arrangement, allowing direct attachment to benches or fixture plates. The pressure element is a M6x40 pressure spindle, providing a standardised interface for contacting variable workpiece heights and for fine adjustment of clamp pressure. Routine upkeep is minimal because of the plated finish and simple mechanical construction; occasional lubrication of pivot points preserves smooth action. The result is a clamp that integrates cleanly into existing tooling concepts and supports efficient maintenance regimes. For reliable hold-down in production and workshop fixtures, contact Metav Werkzeuge to discuss integration of the Kukamet 212 vertical toggle clamp or to request bespoke advice — email info@metav-werkzeuge.com or call +49 2822 7131930 Technical data Article number: 212-2-L GTIN: 8680731501575 ETIM: EC011973 Performance data Clamping force: 1,200 N Holding force: 1,400 N Weight: 0.23 kg Features & materials Material: zinc-plated Safety lock: yes Pressure spindle: M6x40 Mounting: vertical foot Category: clamp (spanner) FAQ What clamping force can be expected from this clamp? The Kukamet 212 vertical toggle clamp provides a clamping force of 1,200 N and a holding force of 1,400 N, suitable for medium-duty jigs and fixtures. Does the clamp include a safety mechanism? Yes, the clamp features a built-in safety lock that secures the toggle in the closed position to prevent accidental opening under vibration or impact. How is the clamp mounted to a fixture or bench? Mounting is via a vertical foot arrangement; the Kukamet 212 is designed for direct attachment to bench tops or fixture plates. What material and finish does the clamp have? The clamp is zinc-plated, offering corrosion resistance for workshop use and reduced maintenance requirements. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
0.8 kN Push Rod Clamp Vertical Foot, Stainless Steel, M5x35 Spindle - Kukamet
Take advantage of the combination of stainless steel construction, compact weight and precise adjustment for reliable clamping in production and fixtures; the M5 x 35 spindle and vertical foot mounting ensure repeatable setups and stable force transmission. Order the clamp directly via Metav Werkzeuge or consult our advisors for specification support. Push-rod clamp 512 (Kukamet) — stainless steel, vertical foot mounting A Push-rod clamp 512 intended for compact, repeatable clamping tasks in workshops and light industrial fixtures, combining fine adjustment with corrosion-resistant material for long service life. Kukamet push-rod clamp model 512 Robust stainless steel construction Vertical foot for secure mounting M5 x 35 pressure spindle for fine adjustment Precise, measurable clamping for repeatable setups The clamp delivers a defined 800 N clamping force and a 970 N holding force, giving a measurable and stable result for jig and fixture work. The integrated M5 x 35 spindle permits fine positional adjustment of the push rod, enabling accurate contact pressure without additional shims. Such quantifiable parameters simplify process documentation and quality checks, supporting efficient setup changes in production environments while reducing variability between cycles. Corrosion resistance and compact design for workshop durability Constructed from stainless steel, the device resists corrosion and stands up to regular cleaning or coolant exposure, which extends service intervals and lowers total cost of ownership. At 0.135 kg the clamp is notably lightweight, allowing simple retrofitting into existing jigs or portable fixtures without adding bulk. The vertical foot mounting provides stable support where vertical clamp orientation is required, securing components reliably while keeping the clamping footprint minimal. Easy integration and straightforward maintenance for uninterrupted workflow The compact form factor and standard thread sizes make the clamp straightforward to incorporate into custom tooling or modular assemblies, reducing engineering time for fixturing. The robust mechanics of the push-rod system provide consistent performance with minimal adjustment, and the simple spindle arrangement allows routine inspection and easy replacement of wear parts. By offering clear force figures and a corrosion-resistant build, the unit supports predictable cycle times and maintenance planning in busy workshops. Contact Metav Werkzeuge to specify the Kukamet stainless-steel push-rod clamp 512 for immediate supply and technical advice — info@metav-werkzeuge.com • +49 2822 7131930 Technical Data Article number: S512-1 GTIN: 8680731509656 Manufacturer: Kukamet Model: 512 Material: stainless steel Facts Weight: 0.135 kg Clamping force: 800 N Holding force: 970 N Spindle: M5 x 35 mm Special features Mounting: vertical foot Type: push-rod clamp Compact, lightweight construction FAQ What clamping and holding forces does the clamp provide? The Kukamet push-rod clamp 512 provides a clamping force of 800 N and a holding force of 970 N, values suitable for repeatable fixture work. How is the clamp mounted in a fixture? Mounting is via a vertical foot; the design of the vertical foot enables direct attachment to plates or fixture bases where a vertical clamp orientation is required. Is the clamp suitable for humid or coolant-exposed environments? Yes, the stainless steel construction of this clamp offers corrosion resistance suitable for environments with regular cleaning or light coolant exposure. What adjustment is available for the push rod? Adjustment is achieved via an M5 x 35 spindle, permitting fine positional and pressure adjustment of the push rod for precise contact setting. Can the clamp be retrofitted into existing jigs? The compact, lightweight design and standard spindle thread make the clamp easy to integrate into existing jigs and modular fixture systems. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
0.9kg Vertical Clamp 3000N Holding Force With Safety Lock, Horizontal Foot - Kukamet
The combination of a robust safety latch, compact mounting via a horizontal foot and a 3,000 N clamping capacity ensures stable, repeatable workholding in fixtures and small production setups — order the clamp directly via Metav Werkzeuge or consult our technical team for specification support. Vertical clamp 211 – Vertical clamping unit with safety latch, 3,000 N capacity (Kukamet) The Vertical clamp 211 is a compact vertical clamping unit designed for secure fixture mounting and reliable repeatability in workshop and light industrial applications. Integrated safety locking mechanism 3,000 N clamping force rating Horizontal foot for stable mounting Blackened finish for corrosion resistance Secure clamping that keeps production moving A dependable workholding solution, the Vertical clamp 211 provides a rated 3,000 N clamping force and a holding force of 3,300 N, delivering consistent pressure for repetitive operations. High clamping and holding values reduce slippage and rework, which directly improves process reliability and cycle-time predictability. In practice, this means fewer interruptions for repositioning and a more stable setup when machining, assembly or inspection tasks demand repeatable positioning. Fast mounting and straightforward adjustment for fixtures The clamp’s horizontal foot allows direct installation on flat fixture plates or machine tables, while the M10×70 pressure spindle gives a clear specification for spindle thread and usable travel. The M10 thread with 70 mm spindle length supports fine adjustment and durable engagement with clamping surfaces. Compact footprint and a mass of 0.9 kg make the unit simple to integrate into existing jig layouts without adding unnecessary bulk, preserving access and visibility at the workpoint. Built for safety and long-term workshop use Durability and operator safety are central to the design: a safety latch prevents unintended opening under load, and the blackened finish improves surface wear resistance while reducing glare in the workplace. The solid construction and secure lock reduce the risk of accidental release during handling, offering both operational confidence and lower downtime. This combination of features suits repetitive production tasks where predictable clamping behaviour and safe operation are priorities. Contact Metav Werkzeuge for tailored advice on integrating the Kukamet Vertical clamp 211 into fixtures and for procurement from our Emmerich stock. Technical data SKU: B211-4-L GTIN: 8680731507768 eClass: 21041717 Brand: Kukamet Model: 211 Weight: 0.9 kg Facts Clamping force: 3,000 N Holding force: 3,300 N Pressure spindle: M10×70 Special features Safety locking mechanism Horizontal foot mounting Blackened finish Category: Vertical clamp FAQ What clamping and holding forces does the clamp provide? The Kukamet Vertical clamp 211 delivers a clamping force of 3,000 N and a holding force of 3,300 N as stated in the technical specification for SKU B211-4-L. How is the clamp mounted and adjusted on fixtures? Mounting is via a horizontal foot for stable attachment to plates or tables, and adjustment is achieved using the M10×70 pressure spindle to set clamping travel and contact pressure. Does the clamp include a mechanism to prevent accidental release? Yes, the unit is equipped with an integrated safety latch that secures the clamping arm and prevents unintended opening while under load. What surface protection does the clamp have for workshop use? The device features a blackened finish which enhances wear resistance and offers basic protection against corrosion in standard workshop conditions. Is the clamp suitable for use in machining fixtures and assembly jigs? The vertical configuration, horizontal foot mounting and specified spindle size make this clamp suitable for fixture work, jigs and small-scale production setups where repeatable, secure clamping is required. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
1.2 kN Vertical Clamp Senkrechter Foot, Zinc-Plated, 1.4 kN Holding Force - Kukamet
Robust galvanised construction and precise force values make this clamp a dependable choice for small fixtures; its low weight and vertical foot mounting support simple integration into jigs. Order the product directly via Metav Werkzeuge or consult the technical advisers for application-specific guidance. Kukamet Vertical Clamp 212 — galvanised vertical hold-down clamp, 1,400 N holding force The Kukamet Vertical Clamp 212 is a compact hold-down device for vertical fixtures and jigs, featuring a vertical foot and an M6x40 pressure spindle for controlled clamping Galvanised corrosion-resistant finish Max holding force 1,400 N Max clamping force 1,200 N Compact weight 0.23 kg Consistent performance for fixture stability The 1,400 N holding force and 1,200 N clamping force provide clearly defined performance parameters for fixture design and process planning. These measured values enable calculation of required clamp numbers per workpiece and support repeatable set-ups on assembly benches or small CNC fixtures. The pressure spindle is specified as M6x40, which standardises replacement parts and simplifies maintenance planning. For engineers, the distinction between holding and clamping force is essential: the holding force indicates the maximum sustained retention, while the clamping force denotes the initial securing action. Low mass, straightforward mounting for quick integration At 0.23 kg, the device is lightweight, allowing for easy handling during fixture assembly and minimised added mass on moving sub-assemblies. The vertical foot mounting suits vertical hold-down applications and permits secure attachment to plates or sleds without complex adapters. This compact footprint supports dense fixture layouts and reduces the space required for each clamp, helping to optimise the usable tooling area on small- to medium-scale production runs. Galvanised finish for reduced maintenance The galvanised surface treatment increases resistance to corrosion in workshop environments, lowering the frequency of surface maintenance and preserving functional reliability over time. For operations where occasional exposure to humidity or cutting fluids occurs, a corrosion-resistant finish contributes to sustained clamping performance and reduces long-term replacement costs. This choice of material and coating is particularly useful in general workshop settings where robust, low-maintenance components are preferred. Practical compatibility and application notes Designed as a traditional lever-style hold-down solution, the clamp’s simple mechanics and defined specifications make it suitable for manual and semi-automatic fixtures. The absence of an articulated arm (arm not applicable) keeps the mechanism compact and reduces points of wear. When planning an application, reference the SKU 212-2 and the technical figures provided here to ensure correct selection and to calculate the number of clamps required for safe and repeatable fixation. Contact Metav Werkzeuge for tailored fixture advice and to secure the Kukamet Vertical Clamp 212 from stock in Emmerich Technical specifications SKU: 212-2 GTIN: 8680731501506 Manufacturer: Kukamet Core figures Clamping force max: 1,200 N Holding force max: 1,400 N Weight: 0.23 kg Pressure spindle: M6x40 Mounting: vertical foot Features Material: galvanised Arm: not applicable Fastening type: vertical foot Type: lever clamp eClass: 21041717 ETIM: EC011973 FAQ How much holding force does the clamp provide? The Kukamet Vertical Clamp 212 provides a maximum holding force of 1,400 N, suitable for small fixture retention tasks. What is the clamping spindle specification? The clamp uses an M6x40 pressure spindle as specified for the Vertical Clamp 212. Is the clamp suitable for humid workshop environments? The galvanised finish on the Vertical Clamp 212 offers enhanced corrosion resistance, making it appropriate for typical workshop conditions. How should the clamp be mounted in a jig? The device is fitted via a vertical foot for direct attachment to plates or sleds; reference the core figures to plan fixation points. Which identifier should be quoted when ordering? Please refer to SKU 212-2 and the GTIN 8680731501506 when requesting this Kukamet vertical hold-down clamp. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
1.2kN Vertical Clamp With Horizontal Foot, Massive Holding Arm & Safety Lock - Kukamet
Take advantage of the robust combination of a massive holding arm, a safety lock and compact mounting to secure fixtures reliably in small production runs. The clamp delivers high holding performance with a 112 mm lever while remaining lightweight for simple positioning. Order the vertical clamp directly via Metav Werkzeuge or consult their advisors for application support. Vertical clamp 211 by Kukamet — 112 mm arm, safety lock The Vertical clamp 211 is a vertical lever clamp designed for secure workholding in jigging, assembly and light fixture applications across workshops and small-batch production environments. Massive holding arm with safety lock 112 mm operating arm length Horizontal mounting foot for stability 1,400 N maximum holding force Consistent clamping force for reliable fixing The clamp is engineered to provide repeatable holding capacity, making it suitable for fixtures where consistent pressure prevents part movement and rework. With a 1,400 N maximum holding force and a separate closing capacity of 1,200 N, the unit keeps clamped components stable under load, reducing process interruptions. The integrated safety lock prevents accidental release during handling or machining, which contributes directly to process reliability and operator confidence. The construction supports frequent operation in production jigs without complex adjustments, allowing a smoother workflow and fewer checks between cycles. Space-saving mounting and easy integration A horizontal mounting foot and compact geometry make the clamp straightforward to install on benches, fixture plates or brackets. The 112 mm lever arm provides sufficient reach for many standard holding tasks while the low mass—just 0.235 kg—keeps added inertia minimal when fitted to moving assemblies. The external finish is a blackened finish, offering basic surface protection and a professional appearance that integrates well with existing toolroom hardware. These design choices mean the device can be incorporated into new or existing tooling layouts with minimal redesign, saving engineering time and reducing machine downtime. Durable mechanism and practical operation A massive holding arm and robust lever mechanism deliver durable performance under frequent actuation. The clamp’s lever action allows rapid engagement and disengagement, which accelerates repeat operations on assembly lines or test stations. The blackened surface treatment and solid construction support long service intervals with straightforward maintenance; regular cleaning and occasional lubrication of pivot points suffice to retain smooth function. Where secure, quick clamping is required without complex hydraulic or pneumatic systems, this lever-type clamp combines simplicity with industrially relevant performance. Contact Metav Werkzeuge to discuss delivery options and application suitability for the Kukamet vertical clamp 211; request technical details or a tailored supply recommendation by phone or email Technical data Article number: B211-2-D-L-C2 Brand: Kukamet eClass: 21041717 ETIM: EC011973 Facts Arm length: 112 mm Maximum pressing force: 1,200 N Maximum holding force: 1,400 N Weight: 0.235 kg Special features Massive holding arm and safety lock Horizontal mounting foot Finish: blackened FAQ What is the maximum holding force of the clamp? The Kukamet vertical clamp 211 provides a maximum holding force of 1,400 N, suitable for secure positioning in jig and assembly operations. How is the clamp mounted to a fixture? Mounting is via the horizontal mounting foot supplied; the design allows direct attachment to fixture plates or bench surfaces for rigid installation. Which parts of the clamp improve safety during use? The integrated safety lock prevents unintentional opening, while the robust arm construction ensures stable clamping under repeated actuation. Is the clamp suitable for frequent industrial use? Yes. The lever mechanism and solid arm construction are intended for repetitive use in workshop and light production settings with routine maintenance. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
1.5 kN Horizontal Foot Clamp With Silicone‑Coated Handle, 50mm Thread Length, Stainless Steel - Kukamet
Take advantage of a compact, corrosion-resistant clamp that combines high clamping and holding forces with a non-slip, silicone-coated grip for dependable fixture retention. Order the component directly via Metav Werkzeuge or consult the Metav team for specification support. Toggle Latch Clamp 361 by Kukamet — horizontal mounting foot, stainless steel The Toggle Latch Clamp 361 is a stainless steel toggle clamp designed for secure fastening of covers, fixtures and removable panels in workshop and industrial assemblies. Stainless steel construction for corrosion resistance Silicone-coated handle for secure grip Horizontal mounting foot for flush installation 1,500 N clamping force, 1,725 N holding force Dependable clamping where precision matters Built for repetitive use in production and assembly environments, this stainless steel toggle latch delivers measurable performance: a clamping force of 1,500 N and a holding force of 1,725 N, values that translate into secure retention under dynamic loads. The metal grade supports consistent duty cycles and reduces the risk of deformation, while the quantified force figures provide a reliable basis for fixture design and quality assurance. This makes the clamp suitable for jigs, access panels and removable fixturing where repeatable clamping behaviour is essential. Rapid mounting and ergonomic operation The horizontal mounting foot allows flush installation, saving space on worktops and within assemblies. A silicone-coated handle improves manual control during engagement and release, reducing slippage and operator fatigue over long shifts. The component features a thread length 50 mm for secure attachment and fine adjustment during setup; the integrated hook provides positive latching without additional hardware. These design choices support fast cycle times and minimise the effort needed for regular tool changes or maintenance operations. Low-maintenance durability for workshop use A compact design with a weight of approximately 0.1 kg combines structural robustness with minimal mass, avoiding unnecessary load on moving fixtures. The corrosion resistance of the stainless steel body reduces upkeep and extends service intervals, contributing to lower total cost of ownership in corrosive or humid environments. Simple geometry and accessible fastenings allow basic inspection and replacement without specialist tooling, so maintenance routines remain efficient while production uptime is preserved. For specification advice or to secure the Kukamet toggle latch clamp S361-2-K for reliable, corrosion-resistant clamping, contact Metav Werkzeuge for tailored guidance and order facilitation. Technical data Article number: S361-2-K GTIN: 8680731509533 Manufacturer: Kukamet Facts Clamping force: 1,500 N Holding force: 1,725 N Thread length: 50 mm Weight: 0.1 kg eCl@ss: 21041718 ETIM: EC011973 Special features Material: stainless steel Mounting: horizontal foot Handle: silicone-coated Includes hook Category: toggle clamp / latch clamp FAQ What types of fixtures is this clamp suited for? The Kukamet toggle latch clamp S361-2-K is suitable for removable covers, jigs and panels where a horizontal, flush-mounted retention solution is required. Can the clamp be used in humid or mildly corrosive environments? Yes, the stainless steel body of the S361-2-K provides enhanced corrosion resistance, making it appropriate for damp workshop conditions and many industrial settings. How is the clamp mounted and adjusted? Mounting uses the horizontal foot; adjustment is achieved via the threaded connection with a thread length of 50 mm, allowing precise alignment during installation of the latch. Is the handle suitable for repetitive manual operation? The silicone-coated handle improves grip and operator comfort during frequent engagement and release cycles, reducing slippage and fatigue. What are the measurable holding characteristics of the clamp? The clamp provides a clamping force of 1,500 N and a holding force of 1,725 N, values intended for integration into fixture load calculations. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
1.5 kN Push Rod Clamp Vertical Base, Black Oxide Finish, M6x40 Actuating Spindle - Kukamet
Compact and ready for fixture work, the B512-2 combines a high holding force of 1,700 N with a pressing force of 1,500 N and a low mass of 0.28 kg for easy integration into light to medium-duty jigs. Order the push-rod clamp directly via Metav Werkzeuge or consult our specialists if further specification is required. Kukamet B512-2 push-rod clamp (512) — 1,700 N holding force, vertical foot B512-2 is a compact push-rod clamp designed for use in fixtures and small jigs, featuring a vertical foot and an M6x40 pressure spindle for precise contact and repeatable clamping. Compact 0.28 kg body Holding force 1,700 N Pressing force 1,500 N Vertical-foot mounting with M6x40 spindle Reliable clamping where space is limited The Kukamet B512-2 push-rod clamp delivers a high holding force of 1,700 N from a compact housing weighing just 0.28 kg, making it suitable where fixture mass must be kept low. The combination of solid holding capacity and reduced weight supports faster cycle times and less inertia in automated positioning, while still providing stable workpiece retention for repeatable machining or assembly steps. Straightforward mounting and exact pressure transmission A vertical foot mounting simplifies installation into pallets, plates or bespoke jigs; the integrated M6x40 pressure spindle allows fine adjustment of contact pressure and compensates for small height differences. The mechanical design ensures direct force transfer, so set-up is efficient and alignment remains stable during operation, reducing set-up time and the need for frequent re-adjustment. Durable finish and broad application range Finished in a blackened finish for corrosion resistance and low reflectivity, the unit performs reliably in workshop environments and light industrial use. With a pressing force of 1,500 N, the clamp is suitable for a wide range of clamping tasks in production and assembly, offering consistent results in series processes and short runs where secure, repeatable clamping is required. Specify the Kukamet B512-2 for compact, high-force clamping via Metav Werkzeuge — contact our technical team at +49 2822 7131930 or email info@metav-werkzeuge.com for tailored recommendations Technical Data SKU: B512-2 GTIN: 8680731508703 Manufacturer: Kukamet Facts Weight: 0.28 kg Max pressing force: 1,500 N Max holding force: 1,700 N Pressure spindle: M6x40 Special features Mounting: vertical foot Finish: blackened finish Category: Spanner eClass: 21041716 ETIM: EC011973 FAQ What clamping capacity does the device offer? The Kukamet B512-2 push-rod clamp provides a holding capacity of 1,700 N and a pressing force of 1,500 N, suitable for light to medium clamping tasks. How is the clamp mounted in a fixture? Mounting is by a vertical foot; the B512-2 is designed for straightforward integration into pallets, plates or custom jigs. Which spindle is used to adjust pressure? Pressure is adjusted via an M6x40 pressure spindle, enabling fine contact compensation and repeatable pressure settings on the unit. What is the surface treatment and why does it matter? The clamp has a blackened finish that improves corrosion resistance and reduces reflections, maintaining consistent performance in workshop environments. Is the clamp suitable for automated or high-cycle applications? The compact mass and high holding force of the B512-2 make it suitable for many automated and high-cycle setups where low fixture inertia and repeatable retention are required. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
1.6 kN Horizontal Base Toggle Clamp With Hook, 25 mm Thread Length - Kukamet
Benefit from a robust, corrosion-resistant stainless steel design combined with a compact horizontal-foot mount and up to 1,800 N holding force for reliable retention in demanding fixtures. Order the latch clamp directly via Metav Werkzeuge or consult our advisers for specification help. Latch clamp 362 by Kukamet — stainless steel, horizontal-foot mount, with hook A robust latch clamp intended for workshop fixtures and closures, featuring a horizontal foot for secure mounting and a hook for fast engagement. Stainless steel construction for corrosion resistance Horizontal foot for secure bench mounting Holding force up to 1,800 N for secure retention Integrated hook and compact, lightweight design Consistent, measurable clamping performance for production use The latch clamp 362 provides a dependable combination of clamping force and repeatability required for jigs, fixtures and small assemblies. With a rated clamping force of 1,600 N and a holding force of 1,800 N, the device offers quantifiable performance that supports process standardisation and reduces rework. The clear numeric ratings enable comparison with alternative clamps and help to define safe working envelopes for repetitive operations, promoting predictable throughput in small-batch and light-industrial production. Durable, corrosion-resistant construction that reduces downtime Manufactured from stainless steel, the clamp resists corrosion in workshop environments and requires minimal surface maintenance. The compact body and a listed mass of 0.16 kg make the unit easy to integrate into fixtures without adding unnecessary inertia, while the horizontal foot ensures a flat, stable mounting surface. These design choices reduce the frequency of replacement and simplify cleaning procedures, contributing to continuous operation and lower lifetime maintenance effort. Installation and handling that support rapid setup The latch incorporates a horizontal foot mounting pattern and a threaded engagement with a thread length of 25 mm, permitting straightforward attachment to benches or fabricated plates. The integrated hook speeds engagement and alignment, shortening cycle setup time when compared with multi-component retainers. The compact footprint and low weight simplify manual handling during installation and enable close packing of multiple clamps on a single jig without compromising access or ergonomics. Practical suitability for workshop fixtures and closures Engineered as a closure and lever-style clamping solution, the unit is intended for use in a range of workshop applications where a secure, repeatable latch is required. The stainless steel body is well suited to environments where occasional exposure to moisture or cleaning agents occurs. The clamp’s measurable force ratings and simple mounting facilitate its use in inspection fixtures, small enclosures and access panels where reliable retention and quick release are essential. Confidence from a tested supply chain and accessible expertise Sourced through Metav Werkzeuge, the product benefits from a European distribution channel that emphasises quality assurance and available technical support. Metav’s position as a precision partner and its broad product range help to reduce procurement complexity and ensure consistent availability for production needs. For purchasers seeking verified performance and dependable delivery, the combined offering supports efficient supply management and long-term reliability. For specification assistance, ordering or to request the technical datasheet for the Kukamet latch clamp, contact Metav Werkzeuge; detailed advice is available by email at info@metav-werkzeuge.com or by phone at +49 2822 7131930 Technical Data Article number: S362-2 GTIN: 8680731504712 SKU: S362-2 Material: Stainless steel Mounting: Horizontal foot Clamping force max: 1,600 N Holding force max: 1,800 N Thread length: 25 mm Weight: 0.16 kg ECLASS: 21041718 ETIM: EC011973 Facts Clamping force: 1,600 N Holding force: 1,800 N Thread length: 25 mm Weight: 0.16 kg GTIN: 8680731504712 Special features Horizontal foot mounting Integrated hook for fast engagement Stainless steel construction Compact, low-mass design Image and datasheet available (PDF) FAQ What maximum holding force does the latch clamp deliver? The latch clamp provides a maximum holding force of 1,800 N, suitable for secure retention in light-industrial fixtures. Which material is the housing made from? The housing is made of stainless steel, offering corrosion resistance for workshop use. How is the clamp mounted? Mounting is via a horizontal foot, designed for secure bench or plate attachment; the thread length is 25 mm. Is the clamp suitable for compact fixtures and jigs? Yes, the compact design and low weight (0.16 kg) make the clamp well suited to closely packed jigs and small fixtures. What is the article number or SKU for ordering? Order using the article number / SKU S362-2 (GTIN 8680731504712) for accurate identification. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
1.66kg Vertical Clamp 118.5mm Arm, 4.5kN Closing Force, Massive Hold Arm, Zinc Plated - Kukamet
Take advantage of the combination of a galvanised finish, a solid holding arm and high clamping forces to secure workpieces reliably in production and workshop environments; order directly via Metav Werkzeuge or consult our technical advisors for application-specific guidance. Vertical clamp 213 — Kukamet vertical lever clamp with galvanised finish and solid holding arm The Vertical clamp 213 is a vertical lever clamp designed for firm, repeatable workholding on jigs, fixtures and assembly benches in industrial and workshop settings Galvanised steel construction Solid holding arm for stable clamping Angle base for secure mounting Up to 5,000 N holding force Robust construction for dependable daily use Built for repetitive operation, this vertical clamp combines a galvanised surface treatment with a solid holding arm to resist corrosion and bending under load. The robust arm reduces deflection during clamping cycles, so the clamping position remains consistent. This stability is particularly beneficial for assembly and welding jigs where repeatability minimises rework. The unit's compact mass (approx. 1.66 kg) keeps fixture inertia low while maintaining mechanical strength for frequent operation. Precise clamping performance that supports process reliability Designed to deliver measurable clamping capacity, the device provides a max holding force of 5,000 N and a max pressing force of 4,500 N, which are suitable for a wide range of medium-duty clamping tasks. The arm length of 118.5 mm provides an extended lever for effective force transmission without requiring excessive handle travel. Where consistent clamp pressure is required, the mechanical design ensures forces are applied predictably, contributing to reduced variability in downstream machining, inspection or assembly steps. Simple mounting and long-term durability for production workflows Mounted via an angle base, the clamp can be fixed securely to plates or fixture rails, enabling quick integration into existing setups. The galvanised finish prolongs service life in workshop environments, and the straightforward mechanical construction allows for fast replacement or repositioning when layouts change. Weight and form factor make the clamp suitable for portable fixtures as well as fixed production jigs, offering a practical balance between robustness and adaptability. For secure, repeatable clamping from Kukamet choose the Vertical clamp 213 — contact Metav Werkzeuge for order placement or technical advice at info@metav-werkzeuge.com or +49 2822 7131930 Technical data SKU: 213-5-D-C1 GTIN: 8680731502114 Model: 213 Manufacturer: Kukamet ECLASS: 21041717 ETIM: EC011973 Core technical data Weight: 1.66 kg Arm length: 118.5 mm Max holding force: 5,000 N Max pressing force: 4,500 N Special features Material: galvanised steel Mounting: angle base Solid holding arm Type: vertical lever/toggle clamp Category: Clamping technology — clamp FAQ What maximum holding force does the clamp provide? The clamp delivers a maximum holding force of 5,000 N, specified for the Vertical clamp 213 to ensure secure fixation of workpieces. Which materials is the clamp suitable for in workshop use? The galvanised steel construction is suitable for general workshop environments and fixtures; selection of contact pads or workpiece support should be matched to the work material to prevent marking. How is the clamp mounted to a fixture? Mounting is carried out via the angle base; the clamp can be bolted to plates or fixture rails for stable installation. What is the arm length and why does it matter? The arm length is 118.5 mm, which provides effective lever action for force transmission while keeping handle travel moderate for rapid operation. Is the clamp suitable for repetitive production cycles? Yes, the robust design and solid holding arm are intended for repetitive clamping in production and workshop workflows. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
1.6kg Quick Clamping Toggle Clamp Horizontal Base, 4,000 N Thrust/6,000 N Hold - Kukamet
Take advantage of the high holding capacity, robust galvanised construction and straightforward horizontal-foot mounting for consistent, repeatable clamping in production environments. Order this toggle clamp via Metav Werkzeuge for quick delivery or contact the consultants for technical guidance. Kukamet 811 Toggle Clamp – Horizontal-foot, galvanised lever clamp 811 is a horizontal-foot toggle clamp designed for secure, repeatable holding in industrial and workshop fixtures. Heavy-duty holding force 6,000 N Maximum clamping force 4,000 N Galvanised steel for corrosion resistance Horizontal-foot mounting for stable fixation Consistent results through high holding performance The toggle clamp delivers a reliable working hold thanks to a holding force of 6,000 N and a maximum clamping force of 4,000 N. These figures mean fixtures remain secure under machining, welding or assembly operations, reducing rework and downtime. Where repeatability matters, the robust force curve of this lever clamp ensures the workpiece is kept immobile once the clamp is engaged. The distinction between holding and clamping force is technical: holding force indicates how strongly the clamp resists displacement, while clamping force denotes the direct pressure applied at the contact point; both contribute to stable processing and predictable cycle times. Built to last with galvanised corrosion protection Constructed from galvanised steel, this clamp is prepared for workshop conditions where humidity, coolant splash or occasional outdoor use can accelerate corrosion. The galvanised finish prolongs service life and maintains appearance without frequent surface treatments. Maintenance is straightforward: periodic inspection and light lubrication at the pivot points preserves function. Choosing corrosion-resistant components reduces the frequency of replacements and supports a consistent production environment, which is particularly valuable for small and medium-sized operations seeking durable, low-maintenance tooling. Space-conscious mounting and fixture versatility The horizontal-foot mounting makes the clamp easy to integrate into existing jigs and benches. This mounting orientation keeps the actuator parallel to the base, saving vertical space and permitting compact fixture designs. The clamp’s geometry allows placement close to other components or tooling, improving workflow in crowded setups. Because the base is designed for stable fixation, vibration during machining is minimised; this improves both surface finish and process reliability when the fixture is subjected to lateral forces. Precise adjustment and straightforward upkeep Classified as a screw-clamp style lever, the clamp permits fine adjustment of the contact point, enabling delicate positioning without sacrificing grip. The screw-type spindle allows the clamping pressure to be tuned to the material and operation — useful where workpiece deformation must be avoided. Replacement parts and routine service are uncomplicated due to the simple mechanical design, and wear components are accessible without full disassembly. For workshops aiming to standardise on dependable fast-acting clamps, this lever clamp supports efficient set-up and predictable performance. Choose Kukamet’s 811 toggle clamp for robust, space-efficient fixturing — contact Metav Werkzeuge in Emmerich for ordering and expert advice via info@metav-werkzeuge.com or by phone on +49 2822 7131930 Technical data Article number: 811-3 GTIN: 8680731503227 ETIM: EC011973 Eclass: 21020701 Facts Weight: 1.6 kg Maximum clamping force: 4,000 N Maximum holding force: 6,000 N Features Material: galvanised steel Mounting: horizontal foot Clamp style: screw-clamp type Type: lever (toggle) clamp FAQ What materials can this clamp be used with? The 811 toggle clamp is suitable for a wide range of workpiece materials; its adjustable screw-clamp spindle allows pressure to be set to avoid deformation while maintaining the holding force required for secure processing. How is the clamp mounted to a fixture or bench? Mounting is effected via the horizontal foot supplied; the horizontal-foot design permits close placement to other tooling and provides stable fixation under lateral loads. Is the galvanised finish suitable for wet environments? Yes, the galvanised surface enhances corrosion resistance, making the clamp appropriate for workshop areas where occasional coolant contact or humid conditions occur. Can clamping pressure be fine-tuned for delicate parts? Adjustment is achieved through the screw-type spindle characteristic of this clamp style, allowing precise control of the contact pressure to protect sensitive components. Which industries benefit most from this clamp? The robust holding and clamping figures make the 811 ideal for metalworking, assembly, welding and general workshop fixturing where repeatable, fast clamping is required. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
1.85 kN Push Rod Clamp With Spring, Horizontal Foot, Zinc Plated - Kukamet
Take advantage of a compact, spring-loaded clamp that combines reliable clamping force, durable zinc-plated construction and simple horizontal-foot mounting for consistent fixture performance; order directly via Metav Werkzeuge or consult our specialists for application advice. 511 Push-rod clamp (Kukamet) — spring-loaded horizontal-foot lever clamp, zinc-plated The 511 push-rod clamp is a spring-loaded lever clamp designed for repeatable workholding in fixtures and jigs across workshops and production lines. Spring-loaded horizontal-foot mounting Zinc-plated steel for corrosion resistance Clamping force up to 1,850 N Holding force up to 1,950 N Consistent, measurable clamping for repeatable setups The spring mechanism delivers a predictable pre-tension that keeps components seated during handling and machining, ensuring consistent results on every cycle. With a rated clamping force of 1,850 N and a holding force of 1,950 N, this lever clamp provides quantifiable performance that supports process reliability and reduces rework. The specification gives planners and buyers a clear basis for fixture design and cycle-time calculations. Easy integration with fixtures and robust corrosion protection Equipped with a horizontal foot mounting, the clamp mounts flush to standard fixture plates and saves vertical space in compact jigs. The zinc-plated finish provides a protective barrier against light corrosion in workshop environments, extending service intervals and reducing maintenance. At approximately 0.93 kg, the unit is light enough for precise positioning yet substantial enough to feel solid during operation. Practical benefits for production and tooling workshops As a straightforward lever clamp, the device shortens setup times and supports frequent repositioning without complex adjustments. The spring-loaded actuation maintains contact during handling and assembly tasks, which helps to prevent part movement before final clamping. For engineers and technicians designing simple or duplex fixtures, this clamp offers an efficient combination of repeatability and space-saving mounting. Contact Metav Werkzeuge for tailored advice on implementing the Kukamet 511 push-rod clamp in your fixtures or to request a technical quote; our Emmerich team can advise on compatibility and delivery options Technical data SKU: 511-5-Y GTIN: 8680731506105 Manufacturer: Kukamet Key figures Clamping force (max): 1,850 N Holding force (max): 1,950 N Weight: 0.93 kg eClass: 21041716 ETIM: EC011973 Materials & features Material: zinc-plated steel Mounting: horizontal foot Special feature: spring-loaded lever clamp Product type: push-rod / lever clamp Brand: Kukamet FAQ What maximum clamping force does this clamp deliver? The 511 push-rod clamp provides a maximum clamping force of 1,850 N, which is suitable for many light to medium-duty fixture tasks. How is the clamp mounted in a fixture? Mounting is via a horizontal foot, allowing the lever clamp to be secured directly to a fixture plate or tooling board for compact installation. Is the unit suitable for workshop environments with occasional moisture? The zinc-plated finish on the Kukamet 511 offers corrosion resistance for typical workshop conditions, though highly corrosive environments may require additional surface protection. Can this clamp be used for jigs that require repeatable positioning? Yes, the spring-loaded actuation maintains pre-tension and supports repeatable positioning, making it appropriate for jigs and assembly fixtures. What identifiers should be used when ordering or specifying this clamp? Refer to SKU 511-5-Y and GTIN 8680731506105 when specifying or ordering the Kukamet 511 push-rod clamp. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
10,000 N Toggle Clamp Horizontal Base With Hook, Blackened Steel - Kukamet
Take advantage of a robust combination of high holding capacity and compact design for reliable fixture work; the horizontal-base lever ensures rapid clamping while the blackened finish improves wear resistance. Order directly via Metav Werkzeuge or consult the technical team for application-specific advice. Toggle clamp 351 – Horizontal-base lever clamp, 11 kN holding force (Kukamet) The Toggle clamp 351 is a horizontal-base lever clamp designed for secure, repeatable fastening in jigs, fixtures and assembly operations. Horizontal base for stable mounting 11,000 N holding force for secure retention Blackened finish for improved wear resistance Integrated hook for versatile engagement High holding force for secure, repeatable clamping Built for production environments where repeatability matters, this lever clamp delivers a 11,000 N holding force with a 10,000 N clamping force, providing the security required for machining, welding and assembly operations. The lever mechanism converts operator input into consistent pressure with minimal movement, reducing cycle times and lowering the risk of slippage. The combination of high retention and compact footprint supports denser fixture layouts, enabling efficient use of bench and machine table space while maintaining process reliability. Durable construction and practical adjustment options Constructed with a blackened finish, the unit resists surface wear and provides basic corrosion protection for workshop conditions. The clamping element is fitted with a 110 mm threaded spindle, permitting straightforward height adjustment and fine-tuning of clamping position without elaborate tools. With a mass of 0.945 kg, the component balances robustness with ease of handling during fixture assembly. The integrated hook extends mounting and engagement options, making the design adaptable to a variety of workpiece geometries and retention strategies. Efficient integration into fixtures and production jigs The horizontal base allows the clamp to be mounted close to the workpiece, offering solid anchoring for repetitive tasks. Its lever action supports fast manual operation and is suitable for series production where cycle time and operator ergonomics are relevant. The compact profile and reliable retention make this model a practical choice for fixture construction, welding jigs and assembly stations where stable positioning and quick access are required. Specification-driven selection reduces rework and increases process throughput in short and medium production runs. For reliable clamping from Kukamet, order the Toggle clamp 351 via Metav Werkzeuge for dependable supply from Emmerich and expert consultation on fixture integration; contact info@metav-werkzeuge.com or call +49 2822 7131930 for technical clarification and stock information Technical data Article number: B351-5 GTIN: 8680731508581 Manufacturer: Kukamet Facts Weight: 0.945 kg Clamping/pressing force: 10,000 N Holding force: 11,000 N Thread length: 110 mm Mounting: horizontal base Special features Material/finish: blackened finish Integrated hook included Lever clamp design Category: Spanner eClass: 21041718 ETIM: EC011973 FAQ What mounting method does this clamp require? The clamp uses a horizontal base for secure mounting; the Toggle clamp 351 is designed for bolting to fixtures or machine tables and offers stable anchoring for repetitive operations. Is the clamping force adjustable? Adjustment is provided via the 110 mm threaded spindle; the threaded length allows fine height and pressure modification on the Kukamet lever clamp. Which workshop tasks is this clamp suited for? The model is suitable for fixture construction, welding jigs and manual assembly where consistent retention and quick actuation are required. Does the finish protect against corrosion? The blackened finish provides enhanced surface wear resistance and basic protection suitable for standard workshop environments. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
10,000 N Toggle Clamp Horizontal Base With Hook, Zinc-Plated, 110mm Thread Length - Kukamet
Robust zinc-plated construction and high clamping force make this toggle latch ideal for repeatable, secure closures in production and workshop environments; benefit from its compact weight and straightforward mounting for faster assembly. Order the clamp directly via Metav Werkzeuge or request consultancy for application-specific advice. Toggle latch clamp 351 — zinc-plated closure clamp with horizontal foot and hook A toggle latch clamp 351 designed for secure, repeatable fastening in production, jigs and fixtures, featuring a horizontal-foot mount and integrated hook for positive locking Zinc-plated corrosion resistance 11 kN holding force for secure retention Horizontal foot for simple installation Integrated hook for positive locking High clamping performance for industrial applications The clamp delivers an impressive 11 kN holding force and up to 10 kN clamping force, providing reliable retention for medium-duty fixtures and closures. These values translate into consistent part security during machining, transport and assembly, reducing rework and downtime. The combination of measurable clamping data and a compact form factor supports predictable process planning and helps meet quality metrics in serial production. Simple integration and precise adjustment for fixtures Designed with a horizontal foot for straightforward mounting and a thread length 110 mm for fine adjustment, the unit integrates quickly into existing jigs and panels. The integrated hook ensures positive locking without additional components, while the modest 0.945 kg mass keeps the fixture lightweight. Together these features reduce assembly time and enable precise setting of clamping position, improving repeatability and cycle reliability. Built for durability and dependable supply A zinc-plated finish offers corrosion resistance suitable for diverse workshop conditions and extends service intervals. The robust design reduces maintenance frequency and supports long-term use in production lines. Sourcing through Metav Werkzeuge, a recognised partner with a comprehensive product range and a strong European quality filter, ensures reliable availability and traceable quality; Metav’s established distribution supports stable replenishment for continuous operation. For secure, repeatable fastening with the Kukamet toggle latch clamp 351, contact Metav Werkzeuge for stock information and tailored technical advice – call +49 2822 7131930 or e‑mail info@metav-werkzeuge.com Technical Data Article number: 351-5 GTIN: 8680731504835 Model: 351 Core specifications Holding force max: 11,000 N Clamping force max: 10,000 N Weight: 0.945 kg Thread length: 110 mm Materials & features Material: zinc-plated Mounting: horizontal foot Hook: integrated ECLASS: 21041718 ETIM: EC011973 FAQ What is the maximum holding force of this clamp? The clamp provides a maximum holding force of 11,000 N as stated for the Kukamet toggle latch clamp 351 (SKU 351-5). Is the clamp suitable for use in damp workshop environments? Yes, the zinc-plated finish on the toggle latch clamp 351 offers corrosion resistance suitable for typical workshop conditions. How is the clamp mounted? Mounting is via a horizontal foot; the design allows for direct panel or fixture attachment using standard fasteners. Can the clamping position be adjusted? Adjustment is possible via the threaded spindle with a thread length of 110 mm, enabling fine setting of the clamping distance. What is the weight of the clamp and how does that affect fixtures? The unit weighs 0.945 kg, keeping added mass low for fixtures while maintaining structural stability during use. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
100 mm Vertical Clamp Horizontal Base Stainless Steel 750 N Closing Force, 1000 N Holding Force - Kukamet
Take advantage of stainless steel construction, a 1,000 N holding force and a compact, lightweight design for reliable fixture holding in continuous production. Order directly via Metav Werkzeuge or consult the technical team for application advice. Vertikalspanner 211 — vertical toggle clamp in stainless steel with 1,000 N holding force The Vertikalspanner 211 is a robust vertical toggle clamp designed for secure workholding in assembly, welding and light machining operations, fitted with a horizontal-foot mounting for stable installation. Stainless steel construction, corrosion resistant Holding force 1,000 N for secure clamping Press spindle M5×35 for fine adjustment Horizontal foot mount for stable installation Secure holding for repeatable production A compact vertical toggle clamp delivers dependable fixture performance where repeated engagement is required. The clamp’s holding force of 1,000 N ensures reliable retention of workpieces during handling and light machining, reducing the risk of slippage and rework. The mechanism transfers clamping force efficiently, and the separate pressing force of 750 N provides the controlled contact pressure needed for delicate or thin components. This combination of retention and controlled contact supports consistent cycle times and lowers the incidence of quality deviations. Corrosion resistance and simple integration Constructed from stainless steel, the device stands up to humid or mildly corrosive shop environments without additional surface treatment, extending service life and maintaining appearance. The horizontal foot mounting makes mechanical integration straightforward on jigs and benches, enabling quick retrofitting into existing fixtures. The threaded press spindle M5×35 allows precise adjustment of contact height and pressure, helping to protect delicate surfaces while securing parts firmly. Compact design that eases handling and storage Weighing just 0.155 kg, the clamp is notably lightweight and space-efficient, which simplifies handling during fixture assembly and reduces load on rotating or indexed tooling plates. The small footprint and stable base permit dense fixture layouts, increasing usable clamping positions per jig and supporting higher throughput without enlarging the clamping station. The compact form also helps in transport and storage logistics, contributing to a tidy and efficient workshop environment. Contact Metav Werkzeuge today to specify the Vertikalspanner 211 for fixtures or to request application recommendations from the technical team in Emmerich Technical data Article number: S211-1 GTIN: 8680731503999 eClass: 21041717 ETIM: EC011973 Facts Weight: 0.155 kg Holding force (max): 1,000 N Pressing force (max): 750 N Press spindle: M5×35 Special features Material: stainless steel Mounting: horizontal foot Arm: not applicable Special feature: none Story trigger: lever clamp FAQ What is the maximum holding force of this clamp? The vertical toggle clamp provides a maximum holding force of 1,000 N, making the device suitable for secure retention in assembly and light machining tasks. Can this clamp be adjusted for different part heights? Yes. The unit is equipped with a press spindle M5×35 that permits fine height and contact-pressure adjustment for a range of component thicknesses. Is the clamp suitable for workshop use in humid environments? The clamp is made from stainless steel, offering corrosion resistance and suitability for damp or mildly corrosive workshop conditions. Which mounting option does the clamp use? A horizontal foot mounting is provided for stable installation on jigs, benches and fixture plates, facilitating straightforward integration. What is the item number for ordering and reference? Ordering reference: SKU S211-1; GTIN 8680731503999. The SKU is quoted on Metav Werkzeuge documentation for procurement. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
1000 N Clamp Toggle Clamp Horizontal Foot With Hook, Blackened Finish - Kukamet
Take advantage of a compact, robust clamping solution that combines a horizontal base for stable mounting with a hooked toggle for rapid, reliable closure; the result is faster assembly cycles and secure retention under load. Order the latch directly via Metav Werkzeuge or request guidance from our consultants for specification matching. Toggle Latch Clamp 321 — horizontal-base toggle clamp with hook by Kukamet The Toggle Latch Clamp 321 is a lever-operated clamp designed for securing removable panels, jigs and fixtures where a low-profile horizontal mounting foot and a hook-style latch are required. Horizontal base for stable mounting Integrated hook for secure latching Clamping force 1,000 N, holding 1,500 N Blackened finish for corrosion resistance Fast, repeatable clamping for production workflows The Toggle Latch Clamp 321 delivers a compact, lever-driven closure that speeds up repetitive joining tasks. The toggle mechanism converts short lever travel into a strong locking action, enabling quick engagement and disengagement with consistent results. For production environments this means reduced cycle times and fewer manual adjustments, while the horizontal base ensures the clamp sits flush on jigs or panels for a low-profile installation. The integrated hook secures the mating part without the need for additional fasteners. Measurable performance and adjustability for engineered applications Specified clamping and holding values make the performance predictable in assemblies: clamping force of 1,000 N for active closure and holding force of 1,500 N for static retention. The device includes a thread length of 45 mm to allow fine height adjustment and alignment during setup. At approximately 0.115 kg the unit is lightweight yet robust. The blackened finish provides a degree of surface protection and a uniform appearance suitable for workshop environments. Where a clear separation between closing and retention is required, these figures support engineering decisions and fixture design. Practical fitment and application benefits in workshop and light industry Installed via its horizontal mounting foot, the clamp integrates into sliding doors, removable covers, test fixtures and mobile equipment. The lever action reduces operator effort compared with screw clamps and offers tactile feedback when fully engaged. The compact footprint keeps adjacent components accessible and simplifies jig layouts. For maintenance and replacement, the straightforward hook-and-lever arrangement allows rapid swapping with minimal downtime, contributing to a reliable production flow and reduced fixture complexity. Contact Metav Werkzeuge for technical advice or to specify the Kukamet Toggle Latch Clamp 321 for bespoke fixtures; email info@metav-werkzeuge.com or call +49 2822 7131930 to discuss compatibility and delivery from Emmerich Technical data Article number: B321-2 GTIN: 4061905080517 eClass: 21041718 ETIM: EC011973 Facts Clamping force: 1,000 N Holding force: 1,500 N Thread length: 45 mm Weight: 0.115 kg Special features Horizontal mounting foot Hooked latch design Lever-operated toggle action Blackened surface finish FAQ What loading can the clamp withstand in continuous use? The clamp offers a clamping force of 1,000 N and a holding force of 1,500 N; the Toggle Latch Clamp 321 is intended for intermittent closure and retention in workshop and light industrial applications rather than continuous dynamic loading. Is the latch suitable for panel doors and removable covers? Yes. The horizontal base and hooked latch are designed to secure removable panels, covers and access hatches where a low-profile mounting solution is required. How is height adjustment achieved? Adjustment is provided via the threaded engagement (thread length 45 mm) which permits fine alignment of the hook with the mating catch for precise closure. What surface protection does the clamp have? The component is supplied with a blackened finish which offers basic corrosion resistance and a discreet, uniform appearance for workshop environments. Can the clamp be replaced easily in existing fixtures? The lever-and-hook design enables quick replacement and minimal alteration to fixture layouts; the horizontal foot keeps mounting points consistent for retrofitting. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
1000 N Clamp With Vertical Foot, Hook, 45mm Thread Length, Blackened - Kukamet
Take advantage of the combination of compact design, 1,500 N holding force and a secure hook latch for dependable clamping in repetitive fixtures. Order the clamp directly via Metav Werkzeuge or consult our specialists for compatibility and delivery options. Toggle latch clamp 332 — vertical-foot toggle clamp with hook by Kukamet A Toggle latch clamp 332 engineered for secure, repeatable closures in jigs and fixtures, featuring a vertical mounting foot and a hook latch for fast engagement. Vertical mounting foot for upright installation Hook latch for positive engagement Blackened (brunished) corrosion-resistant finish Up to 1,500 N holding force Consistent clamping performance that keeps processes running The clamp delivers reliable mechanical locking through a compact toggle mechanism, offering a holding force of 1,500 N and a maximum pressing force of 1,000 N. This combination ensures secure fixation of parts during assembly or transport without requiring complex adjustment. The design converts operator input into consistent clamp force, reducing variation between cycles and supporting higher repeatability in production processes. The light overall mass of 0.095 kg makes the device easy to position and integrate into fixtures. Space-saving mounting and fast operation for efficient workflows Installed via its vertical mounting foot, the latch occupies minimal horizontal space and is suitable for tight tooling arrangements where a low profile is essential. The incorporated hook enables quick release and engagement, shortening cycle times in repetitive tasks. A thread length of 45 mm allows for straightforward adjustment or connection to mating components, providing installation flexibility across different fixture geometries. The compact footprint helps maintain clear access around the clamped workpiece, supporting safer and more ergonomic handling. Robust finish and straightforward specification for workshop use The component is supplied in a blackened (brunished) finish, which enhances surface hardness and provides basic corrosion resistance appropriate for general workshop environments. The simple mechanical construction limits maintenance needs and can be inspected visually for wear or deformation. Where material compatibility or cleaning procedures matter, the specification highlights its suitability for standard industrial settings rather than specialised corrosive atmospheres. Technical identifiers such as SKU and GTIN support traceability in procurement and inventory management. For precise clamping solutions and supply information, contact Metav Werkzeuge to discuss the Kukamet toggle latch clamp 332, mounting options and delivery from our Emmerich warehouse Technical Data SKU: B332-1 GTIN: 8682843522509 Model: 332 Facts Weight: 0.095 kg Holding force max: 1,500 N Pressing force max: 1,000 N Thread length: 45 mm ECLASS: 21041718 ETIM: EC011973 Special features Vertical mounting foot With hook Material: blackened (brunished) Category: Spanner Files: catalogue page and image available FAQ What maximum holding and pressing forces does the clamp provide? The Kukamet toggle latch clamp 332 offers a holding force of up to 1,500 N and a maximum pressing force of 1,000 N, suitable for many light to medium-duty fixturing tasks. Is the clamp suitable for tight fixture layouts? Yes, the vertical mounting foot and compact construction of the 332 make it well suited to confined spaces where a low-profile clamp is required. What is the mounting interface and adjustability? The component includes a threaded connection with 45 mm thread length for straightforward adjustment and attachment within a fixture. What surface treatment does the clamp have and what does that mean? The item is supplied blackened (brunished), providing improved surface hardness and basic corrosion resistance for standard workshop environments. Which SKU should be ordered for procurement and stock control? Use SKU B332-1 and GTIN 8682843522509 when ordering or recording the Kukamet toggle latch clamp 332 for inventory purposes. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
1000 N Closing Clamp Horizontal Base With Safety Lock, Blackened Finish - Kukamet
Combining a compact horizontal base, an integrated safety lock and a reliable 1,500 N holding capacity, this clamp secures fixtures quickly and reduces rework in repetitive operations; order the toggle clamp directly via Metav Werkzeuge or consult our specialists for application advice. Toggle clamp 351 — horizontal-base toggle clamp with safety lock (Kukamet) Toggle clamp 351 is a horizontally mounted closure clamp designed for secure holding and repeatable fixture locking in light-duty jigs and assembly work Horizontal base for secure mounting Safety lock prevents accidental release 1,500 N holding capacity Blackened finish resists corrosion Consistent clamping performance for repetitive tasks The unit delivers dependable force control thanks to a defined clamping stroke and a 1,000 N maximum pressing force combined with a 1,500 N holding capacity. That combination means fixtures remain stable during machining, assembly or inspection, reducing part movement and scrap. The mechanism operates with an over-centre action, which converts lever travel into a firm closure; this toggle action is easy to understand and speeds up cycle times without complex adjustments, supporting efficient production sequences. Space-saving design that simplifies fixturing With a horizontal base for direct panel mounting and a compact footprint, the clamp fits into tight jigs and tooling plates. The adjustable spindle offers a 45 mm thread length for fine height compensation, while the integrated hook provides positive engagement with mating fixtures. The lightweight construction (approx. 0.135 kg) helps keep moving mass low on fixtures, so actuation remains smooth and wear on pivot points is reduced. These aspects support quicker set-up and flexible retrofitting into existing tooling. Safety and corrosion protection for everyday reliability A mechanical safety lock prevents unintended release under vibration or accidental actuation, improving operator safety and process reliability. The blackened finish gives basic corrosion resistance and a uniform appearance on the shop floor, while the simple lever geometry enables fast visual checks and straightforward maintenance. Fewer adjustments and clear locking status mean predictable operation, lowering downtime and enabling steady throughput in routine production environments. For application-specific guidance or to secure Kukamet quality for your workshop, contact Metav Werkzeuge for tailored advice and ordering: info@metav-werkzeuge.com or +49 2822 7131930 Technical data SKU: B351-1-L GTIN: 8680731508512 ECLASS: 21041718 ETIM: EC011973 Manufacturer: Kukamet Core technical data Max pressing force: 1,000 N Max holding force: 1,500 N Thread length: 45 mm Weight: 0.135 kg Special features Mounting: horizontal base Safety lock With hook Material/finish: blackened FAQ What clamping forces can be expected from this clamp? The clamp provides a maximum pressing force of 1,000 N and a holding capacity of 1,500 N, giving reliable retention for small to medium fixtures when using the toggle clamp 351 from Kukamet. Is the clamp suitable for retrofitting into existing jigs? Yes, the horizontal base and adjustable spindle with a 45 mm thread length allow straightforward retrofitting into existing tooling plates and fixture assemblies. How does the safety lock affect operation? The mechanical safety lock prevents accidental release during vibration or incidental contact; it secures the lever in the closed position until intentionally released. What does the blackened finish provide? The blackened finish offers basic corrosion protection and a uniform appearance, supporting longer service life under normal workshop conditions. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
1000 N Closure Clamp With Hook, Horizontal Base, 45mm Thread Length - Kukamet
Take advantage of the combination of compact design, a 1,500 N holding capacity and a secure hook engagement for reliable closure retention in jigs and fixtures; order the latch clamp directly via Metav Werkzeuge or consult the team for specification advice. Kukamet B351-1 toggle latch clamp — horizontal-foot mounting with hook and high holding force The Kukamet B351-1 toggle latch clamp is a compact horizontal-foot clamp designed to secure closures and fixtures with positive hook engagement across industrial and workshop applications. Horizontal-foot mounting for stable installation 1,500 N maximum holding force Integrated hook for positive engagement Blackened finish for surface protection Dependable retention for repetitive securing tasks The latch provides a predictable combination of closing force and holding capacity, making it suitable where repetitive, visible clamping operations are required. The defined closing force of 1,000 N ensures secure engagement during latch actuation, while the holding capacity of 1,500 N keeps doors, lids or movable fixtures in place under load. These measurable values support process planning and safety calculations, permitting straightforward comparison with alternative clamps and enabling selection based on required clamping and retention performance. Robust finish and compact engineering for long service life Constructed with a blackened finish, the unit resists surface wear and offers basic protection against corrosion in typical workshop environments. The compact mass of 0.135 kg reduces inertia on moving assemblies and simplifies balancing when multiple clamps are used on the same jig. The thread length 45 mm facilitates standard fastening options and adjustment, allowing installers to set clamping travel and preload precisely. The result is a small but durable component that integrates cleanly into fixtures without adding unnecessary bulk. Versatile mounting and secure hook engagement for positive locking The horizontal-foot fixing provides a stable attachment point on flat surfaces and plates, avoiding sideways play common with some base types. The integrated hook gives positive mechanical engagement rather than relying solely on friction; this prevents accidental release under vibration or lateral loads. For batches and production fixtures this improves repeatability and reduces rework. Where simple, reliable closure retention is essential, the latch’s geometry reduces the need for frequent adjustment and supports efficient workflow. Practical advantages for workshop and light industrial use The latch’s straightforward design simplifies specification and maintenance: limited moving parts, a recognisable performance envelope and easy replacement if required. The combination of explicit performance data and compact dimensions supports procurement decisions in industrial settings: planners receive clear numbers to use in fixture design, and workshop technicians benefit from a component that is easy to handle and install. For applications that prioritise reliability and uncomplicated mounting, this latch is a pragmatic choice. For robust fixture retention, choose the Kukamet B351-1 toggle latch clamp and contact Metav Werkzeuge for procurement and technical guidance via info@metav-werkzeuge.com or +49 2822 7131930 Technical data Article number: B351-1 GTIN: 8680731508505 SKU: B351-1 ECLASS: 21041718 ETIM: EC011973 Core specifications Maximum closing force: 1,000 N Maximum holding force: 1,500 N Weight: 0.135 kg Thread length: 45 mm Design & features Horizontal-foot mounting Hook included Blackened finish No additional special features FAQ What load can the latch safely hold? The Kukamet B351-1 toggle latch clamp is specified with a maximum holding capacity of 1,500 N, which indicates the sustained retention force it can provide in typical fixture conditions. Is the clamp suitable for plate mounting? Yes, the horizontal-foot mounting is designed for stable attachment to flat plates and baseboards, enabling secure installation of the Kukamet B351-1 latch clamp. What protection does the surface finish provide? The blackened finish on the latch offers basic resistance to wear and mild corrosion, prolonging service life in workshop and light industrial environments. How is the latch secured during installation? The component features a 45 mm thread length for standard fastening; installers can use the thread to set travel and preload when securing the latch to a fixture. Is this latch appropriate for vibration-prone applications? The integrated hook provides positive mechanical engagement, which improves resistance to accidental release under vibration compared with non-hooked designs. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
1000 N Combination Clamp Horizontal Base Zinc-Plated, 0.405 kg - Kukamet
Benefit from the compact design, galvanised corrosion resistance and a reliable 1,000 N clamping force for secure bench work; order the clamp directly via Metav Werkzeuge or consult our specialists for application advice. Kombispanner 712 — horizontal-foot combination clamp, galvanised, lever operation (Kukamet) A robust combination clamp designed for workshop and light industrial bench mounting, the Kombispanner 712 combines a compact build with dependable holding power for a wide range of clamping tasks. Compact combination clamp for workshop use Galvanised finish for corrosion protection 1,000 N clamping and holding force Horizontal-foot mounting for bench installation Secure clamping where consistency matters The clamp delivers a defined clamping force of 1,000 N, providing repeatable pressure for jigs, fixtures and assembly tasks. The measured holding force ensures components remain stationary during machining or inspection, reducing rework and downtime. Where process stability is essential, the lever-style actuator gives quick engagement and clear tactile feedback, turning manual clamping into a predictable, efficient step within production sequences. Built for durable, space-saving integration With a galvanised finish and a horizontal foot for bench mounting, this clamp resists workshop environments while occupying minimal space. The lightweight construction (approx. 0.405 kg) enables easy retrofitting into existing fixtures or portable test rigs without heavy modification. The lever mechanism is designed for rapid operation, supporting frequent clamp/unclamp cycles while keeping setup times short and shop-floor ergonomics straightforward. Practical advantages for purchasing and implementation Sourcing through Metav brings operational benefits beyond the component itself: centralised availability from Emmerich, a broad product range and a documented track record in precision supplies support predictable procurement and stock management. For technical questions or to verify suitability with specific fixtures and materials, Metav’s advisory team can supply application guidance and additional specifications by email or phone. Contact Metav Werkzeuge today to secure the Kukamet Kombispanner 712 and ensure reliable, repeatable clamping in your workshop — advice and order support available from Metav Werkzeuge. Technical data Article number: 712-1 GTIN: 8680731504293 Brand: Kukamet Facts Weight: 0.405 kg Maximum clamping force: 1,000 N Maximum holding force: 1,000 N eClass: 21041716 ETIM: EC011973 Special features Material: galvanised Mounting: horizontal foot Operation: lever clamp style Category: clamp FAQ What maximum clamping force does this clamp provide? The Kombispanner 712 (Kukamet clamp, SKU 712-1) offers a maximum clamping force of 1,000 N and an equivalent holding force for secure fixation. Is the clamp suitable for bench mounting? Yes, the unit features a horizontal foot for bench or fixture mounting, designed to integrate with workbenches and jig plates. What finish protects the clamp against corrosion? The clamp is supplied with a galvanised finish, improving resistance to workshop humidity and general corrosion. Can the clamp be used for frequent clamp/unclamp cycles? The lever clamp operation is suited to repetitive manual use; the design supports rapid engagement while maintaining consistent clamping pressure. Who supplies the clamp and where can technical advice be obtained? The clamp is supplied by Kukamet and distributed via Metav Werkzeuge; for technical queries, Metav Werkzeuge can be contacted for application advice. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
1000 N Combination Clamp Horizontal Foot, Zinc Plated, 0.4 kg - Kukamet
A compact galvanised combination lever clamp that provides up to 1,000 N clamping and holding force and mounts via a horizontal foot for secure, repeatable fixturing. Order the Kombispanner 711 directly via Metav Werkzeuge or ask our consultants for detailed specification support. Kombispanner 711 — galvanised combination lever clamp with horizontal-foot mount (Kukamet) The Kombispanner 711 is a robust, compact combination lever clamp designed for light- to medium-duty workshop fixtures and production jigs, offering fast setup and reliable holding performance. Galvanised finish for corrosion resistance 1,000 N clamping/holding force Horizontal-foot mount for bench fitting Lightweight at 0.4 kg for easy handling Secure clamping that reduces setup time The combination lever clamp delivers dependable holding power with a rated 1,000 N clamping and holding capacity, enabling secure fixation of small workpieces during machining, assembly or inspection tasks. The galvanised finish provides corrosion resistance, keeping contact surfaces stable over repeated cycles and reducing the need for frequent replacement. Designed for repetitive use, this clamp shortens fixture build time and lowers the risk of movement during processing, contributing directly to improved process stability and fewer scrapped parts. Flexible mounting and straightforward operation The horizontal-foot mounting arrangement allows bench or fixture-plate attachment with simple fastening, making the clamp suitable for modular jig systems and bench fixtures. With a weight of 0.4 kg, the component is easy to position and handle during setup yet substantial enough to remain vibration-resistant in typical workshop environments. The device separates clamping action from holding action: clamping force refers to the pressure applied during engagement, while holding force indicates the residual resistance against displacement once the clamp is engaged. This distinction helps in selecting the correct fixture strategy and in calculating safety margins for delicate components. Low maintenance and dependable supply for professional use Galvanised steel construction ensures long service life with minimal upkeep, requiring only occasional inspection and lubrication at pivot points. The simple lever mechanism is engineered for repeatability and can be integrated into manual or semi-automated workflows. Backed by Metav’s quality filter and European distribution from Emmerich, this clamp benefits from reliable stock management and consistent product quality—factors that support uninterrupted production. Metav’s experience and broad product range further simplify procurement and spare-part planning for industrial and trade customers. For personalised advice on integrating the galvanised Kukamet combination lever clamp into existing fixtures, contact Metav Werkzeuge for expert procurement and technical consultation. Technical Data Article number: 711-1 GTIN: 8680731504286 Facts Clamping force (max): 1,000 N Holding force (max): 1,000 N Weight: 0.4 kg eCl@ss: 21041716 ETIM: EC011973 Special features Material: Galvanised steel Mounting: Horizontal foot Type: Combination lever clamp FAQ What clamping force can be expected from this clamp? The Kombispanner 711 provides a maximum clamping and holding force of 1,000 N, suitable for light- to medium-duty fixtures. Is the clamp suitable for bench mounting? Yes, the horizontal-foot mount is designed for secure bench or fixture-plate attachment and is compatible with standard workshop fastening methods. What material is the clamp made from and how durable is it? The clamp is made from galvanised steel; the coating increases corrosion resistance and extends service life under normal workshop conditions. Can the clamp be used in modular jig systems? The compact design and horizontal-foot fixing make it well suited for integration into modular jig systems and repeatable production setups. What is the article number and brand of this clamp? This product is the Kukamet combination lever clamp, article number 711-1, marketed as the Kombispanner 711. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
Fast, secure workpiece clamping with toggle clamps
Toggle clamps, also known as knee lever clamps or lever clamps, are mechanical clamping elements used to fix components quickly and reliably in fixture construction, assembly, welding and testing. Their kinematic knee lever principle provides a one-motion closure that locks beyond a mechanical dead centre, delivering consistent clamping force with minimal operator effort.
How the locking principle benefits production
The kinematic dead-centre action means the clamp self-locks once closed, so no continuous force is required on the handle and the workpiece remains form-stable even under process-induced vibration. That behaviour translates directly into higher process reliability and faster cycle times: operators close the clamp in one swift move, parts stay in position during machining or inspection, and changeover times are reduced.
Practical advantages for everyday workshop use
- Reduced set-up time through single-motion clamping
- Consistent repeatability and process stability under vibration
- High holding force with low operator effort thanks to the dead-centre mechanism
- Durable construction for long service life in repetitive production
- Versatile mounting options for vertical, horizontal, push‑rod and draw applications
Technical overview
- principle: kinematic knee lever (dead-centre) locking
- application areas: fixture construction, assembly, welding, testing
- design variants: vertical clamp, horizontal clamp, push-rod clamp, draw/closure clamp
- material: high-strength zinc-plated steel; stainless steel options
- handle: ergonomic, oil-resistant handles
- joints: wear-resistant joint bushes
- process suitability: holds under strong, process-induced vibration; enables high repeatability
Metav as your precision partner
Metav combines decades of specialist knowledge with a broad, dependable assortment for industry and trade. With more than 48,000 customers, a catalogue exceeding 250,000 products and a quality filter based in Emmerich, Metav offers a practical, low-risk route to robust toggle clamps and accessories—ideal for buyers who need dependable stock, expert selection and consistent product quality.
In short: toggle clamps (knee lever clamps / lever clamps) deliver rapid, repeatable clamping with minimal operator effort, making them a straightforward productivity upgrade for demanding production environments.
FAQ
What exactly is a toggle clamp and how does it lock?
A toggle clamp uses a kinematic knee lever that passes a mechanical dead centre during closure; once over‑centre, the clamp self-locks, maintaining clamping force without continuous pressure on the handle.
Which toggle clamp type should I choose for sheet assembly or for pulling covers together?
Use vertical or horizontal toggle clamps for holding sheets and assemblies; choose draw/closure clamps when axial pulling or form closing is required. The variety of toggle clamp designs matches different fixture geometries and force directions.
Are toggle clamps suitable for high-vibration processes?
Yes. The dead‑centre locking of toggle clamps secures the workpiece even under strong, process-induced vibration, ensuring positional stability during machining or testing.
What materials and handle options are available for toggle clamps?
Common materials: zinc-plated steel and stainless steel. Handles are typically ergonomic and oil-resistant; joints use wear-resistant bushes for extended service life.
Can Metav help specify the right toggle clamp for my application?
Metav supplies a wide selection of toggle clamps and technical information, enabling selection based on application, material and required holding force; the assortment is supported by decades of precision experience and a large customer base.
