100mm Micrometer With 20mm Anvil Faces, Digital Display, ISO 17025 Calibration Certificate - Microtech Metrology
€449.00
Product information "100mm Micrometer With 20mm Anvil Faces, Digital Display, ISO 17025 Calibration Certificate - Microtech Metrology"
High-precision measurement with 0.005 mm accuracy and 0.001 mm resolution ensures reproducible results for fine mechanical and laboratory work; the instrument is fitted with 20 mm disc faces and a non-rotating spindle for gentle, repeatable contact and is delivered fully calibrated to ISO 17025 with a calibration certificate. Order the Microtech Metrology digital micrometer via Metav Werkzeuge or contact our consultants for specification support.
Digital micrometer by Microtech Metrology — 75–100 mm, 0.005 mm accuracy
The Digital micrometer provides precise thickness and external measurements for fine mechanical, watchmaking and laboratory applications in the 75–100 mm measuring range.
- High accuracy 0.005 mm
- 0.001 mm reading resolution
- 20 mm disc measuring faces
- Delivered calibrated to ISO 17025
Precision and performance for fine work
The digital micrometer combines a fine resolution of 0.001 mm with an overall accuracy of 0.005 mm, delivering measurement stability that supports traceable quality control. The instrument’s non-rotating spindle prevents rotation-induced run-out while the 20 mm disc faces distribute contact force evenly, reducing local deformation on thin or delicate parts. These features translate into consistent, reproducible results when comparing batches or verifying incoming components, and the digital readout minimises reading errors common to mechanical scales.
Compact range tailored to delicate components
Classified in the micro range (measuring range 75–100 mm), this micrometer is optimised for compact yet precise tasks where stiffness and handling balance is critical. The shorter frame improves rigidity and makes the instrument easy to position in confined setups, which is helpful for watchmakers, small-part assembly and precision laboratory measurements. The disc-shaped anvils are particularly suitable for measuring flat or slightly rounded surfaces without marking, so delicate samples remain undamaged while measurement repeatability is maintained.
Digital ergonomics and assured calibration
The instrument features a clear digital display with 0/MODE, SET, UNIT and HOLD keys for straightforward zeroing, function selection, unit switching and locking of readings. These controls support a fast measurement routine and simplify data capture during inspection sequences. Delivered fully calibrated to ISO 17025, the micrometer arrives with a calibration certificate, providing documented traceability for in-house quality systems and audit requirements. The combination of ergonomic controls and certified calibration supports efficient, auditable workflows on the shop floor.
Contact Metav Werkzeuge to request detailed specifications or to reserve the Microtech Metrology digital micrometer for precision measurement tasks — local stock and expert advice available from Emmerich.
Technical Data
- SKU: 110781001
- GTIN: 4061905457999
- Manufacturer: Microtech Metrology
Facts
- Accuracy: 0.005 mm
- Resolution: 0.001 mm
- Measuring range: 75–100 mm
- Measuring face diameter: 20 mm
Special features
- Digital display with 0/MODE, SET, UNIT and HOLD buttons
- Non-rotating spindle
- Delivered calibrated to ISO 17025 with calibration certificate
- Category: Micrometer
FAQ
Is the instrument delivered calibrated?
Yes. The Microtech Metrology digital micrometer (SKU 110781001) is delivered fully calibrated to ISO 17025 and includes a calibration certificate.
What accuracy and resolution can be expected?
The device provides an accuracy of 0.005 mm and a resolution of 0.001 mm, suitable for fine mechanical and laboratory checks.
What is the measuring range and which tasks is it suited for?
The measuring range is 75–100 mm, making it ideal for compact components, precision workshop tasks, watchmaking and small-part inspection.
Which measuring faces are fitted and why are they used?
Equipped with 20 mm disc measuring faces, the micrometer offers gentle contact and even force distribution; the spindle is non-rotating to improve repeatability.
How are readings and functions handled on the display?
Readings are shown on a digital display controlled by 0/MODE, SET, UNIT and HOLD keys for zeroing, mode selection, unit change and measurement hold.
Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
