1000mm Independent Four-Jaw Chuck With 8-M20 T-Slots, 150 rpm - Vertex
Take advantage of the combination of high-capacity clamping, flexible centring and robust construction to keep large-part turning precise and productive. Order this workholding solution directly via Metav Werkzeuge or ask the consultants for tailored mounting and balancing options. VKC-40 independent four-jaw chuck – 1000 mm diameter, 150 rpm (Vertex) The VKC-40 is an independent four-jaw chuck designed for heavy-duty turning of large-diameter components in workshop and production environments. Robust 536 kg body for heavy work 1000 mm clamping diameter Independent jaws for flexible centring Large-diameter capacity for stable, precise turning The chuck offers a 1000 mm clamping diameter and a substantial mass that translates into stability during machining. With a rated rotational speed of 150 rpm, the solution is optimised for heavy, slow-speed turning where vibration damping and consistent contact pressures reduce chatter and rework. The substantial construction supports repeatable mounting and contributes to consistent precision across long production runs. Flexible centring that reduces setup complexity Featuring independent jaws, the workholding solution enables centring of asymmetrical or irregular components without relying on self-centring forces. This flexibility shortens setup time for bespoke workpieces and small series, while allowing precise, manual adjustment of each jaw. The specified T-nut 8-M20 interface provides a clear mounting standard for attachment and fixture integration, supporting varied clamping arrangements and accessory use. Robust design for continuous heavy-duty operation Built for demanding environments, the chuck combines a rugged construction with a form factor suited to large-part turning. The design prioritises secure clamping and mechanical endurance so that the workholding remains reliable under sustained loads. As a Vertex-manufactured workholding solution the unit is intended to integrate into production lines where predictable performance and longevity reduce downtime and overall machining costs. For technical clarification or to discuss mounting and balancing options with Metav Werkzeuge in Emmerich, please contact info@metav-werkzeuge.com or call +49 2822 7131930 for a personalised recommendation and delivery details. Technical data Article number: VKC-40 Brand: Vertex GTIN: 4061905094897 Facts Diameter: 1000 mm Maximum speed: 150 rpm Weight: 536 kg T-nut: 8-M20 Special features Independent four-jaw chuck Designed for large-diameter turning Robust construction for heavy-duty use FAQ What types of workpieces is this chuck suitable for? The VKC-40 independent four-jaw chuck is designed for large and heavy workpieces, especially where individual jaw adjustment is required for irregular shapes. What is the maximum workpiece diameter? The chuck accepts a clamping diameter of up to 1000 mm. Can irregular or off-centre parts be reliably centred? Yes, the independent jaws allow flexible centring and individual adjustment for asymmetrical components. What rotational speed is specified for this chuck? The rated maximum speed is 150 rpm, suited to heavy-duty turning operations. How is the chuck mounted to a machine table or faceplate? Mounting uses a T-nut configuration specified as 8-M20 for fixture attachment and integration. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
100mm Four-Jaw Independent Lathe Chuck 2300r.p.m., 3.5kg - Vertex
Take advantage of the combination of independent jaw control, a 100 mm clamping diameter and a 2300 rpm rating to streamline small-batch turning operations; order the VKC-4 directly via Metav Werkzeuge or consult our specialists for integration advice. VKC-4 – independent four-jaw chuck, 100 mm diameter, 2300 rpm The VKC-4 independent four-jaw chuck is a compact clamping solution for versatile turning applications in workshops and small production lines, providing flexible gripping for irregular and standard workpieces. Independent jaw adjustment for asymmetric parts 100 mm clamping diameter for compact workpieces Rated for up to 2300 rpm operation Compact, low-inertia mass of 3.5 kg Accurate gripping for irregular shapes and precision turning The independent jaw mechanism delivers true flexibility: each jaw can be adjusted separately to centre off‑axis or irregular workpieces without additional fixtures. This design simplifies seating of non-cylindrical parts and reduces the number of secondary operations required. The independent jaws support controlled clamping forces while maintaining concentricity, which helps to shorten cycle times and improve machining outcomes for short runs and bespoke components. With a 100 mm clamping diameter, the unit suits smaller workpieces commonly encountered in toolrooms and craft workshops. Stable performance that speeds up set-up and repeatability A compact mass of 3.5 kg contributes to low rotational inertia, which assists quicker spin-up and stable running at the specified maximum of 2300 rpm. The chuck’s balance and construction promote consistent seating of parts, enhancing repeatability between set-ups. Fewer adjustments are required over successive parts, so throughput improves without sacrificing quality. These operational efficiencies translate directly into measurable time savings on the shop floor and a more predictable production rhythm. Designed for workshop integration and flexible production The VKC-4 is aimed at small to medium workshops and independent turners who need adaptable clamping without complex fixturing. The compact form factor allows easy handling and fast tool changes, making it well suited to short-series production, prototyping and repair work. By enabling quick reconfiguration for different part geometries, the chuck supports efficient job switching and reduces idle machine time. Emphasis on practical functionality ensures the component contributes to smoother workflows and better resource utilisation. Practical maintenance for long service life Routine inspection and basic maintenance preserve clamping accuracy and operational safety. Accessible jaw adjustment points and a straightforward layout make cleaning and occasional lubrication simple tasks for in‑house technicians. Regular checks for jaw wear and runout keep performance predictable and reduce the likelihood of unscheduled downtime. The design encourages a pragmatic maintenance routine that supports ongoing productivity and prolongs service intervals. Contact Metav Werkzeuge to discuss supply options and technical compatibility for the Vertex VKC-4 independent four-jaw chuck, or request tailored advice from our consultants at Metav Werkzeuge. Technical data Article number: VKC-4 GTIN: 4061905083822 EClass: 21020490 Manufacturer: Vertex Facts Clamping diameter: 100 mm Maximum speed: 2300 rpm Mass: 3.5 kg T-slot/thread detail: 4-M8 Special features Independent jaw adjustment Compact design for small workpieces Suitable for workshop and short-series use FAQ What workpieces are best suited to this chuck? The VKC-4 independent four-jaw chuck is particularly effective for irregular, square or otherwise non-cylindrical workpieces where separate jaw adjustment enables precise seating. Is 2300 rpm the safe operating limit for the chuck? Yes, the specified maximum operating speed of 2300 rpm defines the safe rotational limit for this Vertex VKC-4 chuck; adherence ensures reliable performance. How does the independent jaw setup improve workflow? Independent jaws allow individual positioning to centre asymmetrical parts quickly, reducing fixture time and improving process throughput with the VKC-4 chuck. What maintenance is recommended to retain accuracy? Periodic cleaning, inspection for jaw wear and light lubrication of moving parts will keep the VKC-4 chuck running accurately and help extend service life. Can the chuck be used for short-series production? The compact form and rapid reconfiguration capability make the VKC-4 well suited to short-series production and frequent job changes. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
108mm Universal Centre With Running Tailstock, Accuracy 0.005mm, 3200r.p.m. - Vertex
Take advantage of precise, high-speed centring combined with robust alloy construction for consistent turning results; secure supply and expert advice directly via Metav Werkzeuge or request consultation for application-specific guidance. VPC‑MT1 Live Centre — 108 mm, 3200 r.p.m., Vertex The VPC‑MT1 is a revolving live centre designed to support turning operations in workshop lathes, offering high concentricity and dependable running at elevated spindle speeds. High precision 0.005 mm runout Alloy steel construction for longevity Suitable for 3200 r.p.m. turning Compact 108 mm overall length Maintain concentricity with measurable precision The live centre delivers a 0.005 mm accuracy which directly reduces vibration and runout during rotation; this measurable performance improves surface finish and lowers scrap rates in repetitive turning tasks. A revolving support that maintains concentricity enables higher machining consistency, meaning fewer reworks and predictable tolerances for production batches. The specification of 3200 r.p.m. confirms suitability for moderate high-speed applications where stability and repeatability are priorities. Built for sustained use in workshop environments Constructed from alloy steel, the component offers enhanced wear resistance compared with standard steel alternatives, extending service life under regular use. The rotating tip is designed to follow the workpiece rotation, reducing friction and heat build-up at the contact point. This results in reduced maintenance intervals and a lower risk of premature failure, which contributes to improved uptime on the shopfloor and reliable daily performance. Compact form that simplifies setups and throughput With an overall length of 108 mm and a weight of 0.3 kg, the revolving centre is compact and easy to handle within confined lathe applications. The small footprint supports flexible fixturing and helps maintain clearance in multi-operation setups. Practical benefits include simplified changeovers and consistent centring across short-run and batch production, providing operational efficiency without sacrificing robustness. Choose the Vertex live centre for reliable high-speed centring — contact Metav Werkzeuge for tailored application advice and assured European supply from Emmerich: info@metav-werkzeuge.com | +49 2822 7131930 Technical data Article number: VPC‑MT1 GTIN: 4061905083600 Product: Universal centre, revolving Core specifications Length: 108 mm Maximum speed: 3200 r.p.m. Accuracy: 0.005 mm Weight: 0.3 kg Materials & features Material: alloy steel Type: live / revolving centre Brand: Vertex FAQ Is the live centre suitable for high-speed turning? The VPC‑MT1 is specified for operation up to 3200 r.p.m., making this revolving centre suitable for many high-speed turning tasks where maintained concentricity is required. What level of concentricity can be expected? The device provides an accuracy of 0.005 mm, which supports tight concentricity demands and contributes to improved surface finish during turning operations. What material is the centre made from and what are the benefits? Manufactured from alloy steel, the centre combines toughness with wear resistance, offering prolonged service life under regular workshop use. Is the VPC‑MT1 easy to handle and install in standard setups? The compact 108 mm length and light weight (0.3 kg) allow straightforward handling and integration into space-limited lathe setups without complex adjustments. Which brand produces this live centre? This revolving centre is produced by Vertex and supplied under the designation VPC‑MT1 for workshop and industrial turning support. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
112mm Self-Centring 6-Jaw Chuck High Speed 1200r.p.m. - Vertex
Take advantage of reliable, fast clamping through the combination of a six-jaw, self-centring design and a 112 mm clamping diameter for consistent production results; order via Metav Werkzeuge or consult the technical team for machine-specific integration. VAS-4 Vertex six-jaw self-centring chuck, 112 mm, 1,200 rpm A VAS-4 six-jaw, self-centring chuck engineered for precise clamping in machining and assembly environments 112 mm clamping diameter Six-jaw self-centring design Rated up to 1,200 rpm Robust build at 4.2 kg High-performance clamping for steady throughput The primary design focus is repeatable clamping accuracy under production conditions. The six-jaw layout provides even force distribution around the workpiece, which reduces vibration and enhances concentricity compared with fewer-jaw solutions. Rated for up to 1,200 rpm, the chuck supports efficient spindle speeds while maintaining secure holding power. Built to be compact yet substantial, the device’s 4.2 kg mass contributes to mechanical stability during machining cycles, thereby improving final part quality. Precision mechanics that simplify setup and increase uptime A self-centring jaw system reduces the need for repeated manual alignment, shortening setup times and lowering the risk of misalignment during batch runs. The 112 mm diameter accommodates a range of common part sizes while the six-jaw configuration enables uniform gripping force, which helps to protect delicate surfaces and maintain dimensional tolerances. For environments where repeatability matters, this clamping solution offers a straightforward method to improve process consistency and reduce scrap rates. Designed for dependable operation and straightforward maintenance Mechanical simplicity is a key benefit: the chuck’s construction prioritises long service intervals and predictable behaviour under load. The robust components support everyday industrial use, and the accessible design facilitates inspection and routine lubrication without complex disassembly. Using a well-engineered clamping device reduces unplanned downtime and contributes to a more productive workflow, translating directly into lower operational costs over the long term. Confidence through partnership and practical service Choosing this Vertex clamping solution brings both a technical benefit and a reliable supply route: the product is available through Metav Werkzeuge, which provides a wide selection of precision tools and a practical logistics base in Emmerich. For procurement planning and integration into existing tool inventories, expert advice from the supplier helps ensure the chuck matches machine interfaces and process requirements, supporting a smooth commissioning phase. For specification confirmation or tailored advice on integrating the Vertex VAS-4 into a production cell, contact Metav Werkzeuge via info@metav-werkzeuge.com or call +49 2822 7131930 to discuss compatibility and delivery options. Technical data Article number: VAS-4 GTIN: 4061905083754 Brand: Vertex Product type: chuck Facts Diameter: 112 mm Max. speed: 1,200 rpm Weight: 4.2 kg Special features Six-jaw, self-centring Precision clamping for machining applications Compact, robust construction FAQ What is the maximum rotational speed for this chuck? The chuck is rated for up to 1,200 rpm; this limit should be observed to maintain optimal clamping performance of the VAS-4 Vertex chuck. Is the chuck self-centring and what benefit does that provide? Yes, the VAS-4 is a six-jaw, self-centring unit; the feature reduces setup time and improves concentricity across production batches. Which clamping diameter does the chuck support? The chuck provides a nominal clamping diameter of 112 mm, suitable for a wide range of standard workpieces. How heavy is the chuck and why does weight matter? The device weighs 4.2 kg; the mass contributes to mechanical stability and helps dampen vibration during machining. Can this chuck be used for precision production runs? Designed for repeatable clamping, the VAS-4 Vertex chuck is suited to precision production where consistent concentricity and minimal setup variation are required. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
1250mm Independent Four-Jaw Chuck, 150 rpm, 8-M20 T-Slots - Vertex
High-capacity clamping, precise independent jaw control and rugged construction combine for consistent heavy-duty turning of large components; benefit from the Ø 1250 mm capacity, the rated 150 rpm operating speed and the substantial 905 kg mass for stable machining. Order the VKC-50 independent four-jaw chuck directly via Metav Werkzeuge or ask our consultants if needed VKC-50 Independent four-jaw chuck – Ø 1250 mm, 150 rpm – Vertex The VKC-50 independent four-jaw chuck is a heavy-duty workholding solution designed for large-diameter turning on industrial lathes Independent four-jaw design for exact centring Large Ø 1250 mm gripping capacity Rated speed 150 rpm for heavy work Robust build, approx 905 kg mass High-capacity workholding for large components The VKC-50 delivers a Ø 1250 mm clamping range that enables secure handling of substantial parts. Its mass of 905 kg contributes to inherent stability during turning, reducing vibration and improving surface finish; this stability is particularly important when machining large diameters where rigidity determines process reliability. The result is a workholding device that supports continuous production runs in heavy industries by providing the structural basis for repeatable machining operations. Accurate, independent clamping for irregular and complex parts Thanks to its independent four-jaw concept, each jaw can be set separately, which enables precise centring of asymmetrical or irregular workpieces. This flexibility reduces the need for special fixtures and simplifies the setup of one-off or batch runs requiring individual jaw adjustment. The independent jaw control supports high precision clamping, making the chuck suitable for tasks where concentricity and part geometry demand careful alignment rather than relying on a single fixed centre point. Engineered for reliable operation on industrial lathes Operational parameters such as the rated 150 rpm indicate suitability for heavy turning rather than high-speed applications, aligning the chuck with slow, high-torque machining operations. The T-nut 8-M20 mounting arrangement offers a standardised interface for secure attachment to a variety of spindle faces or adaptors, ensuring compatibility within robust turning setups. The combination of deliberate speed rating and substantial mass optimises torque transfer and reduces centrifugal effects, supporting safe, stable use in demanding environments. Workshop integration and productivity benefits In a production context, the chuck’s capacity and independent jaw control help to cut setup time for non-standard parts and to reduce reliance on specialised clamping fixtures, contributing to improved workflow efficiency. Specifying this workholding element supports a pragmatic approach to heavy machining: the robust construction minimises unplanned downtime and the standardised mounting eases integration into existing machine fleets. For buyers seeking a dependable partner in precision, Metav’s supply chain and quality filter for the European market ensure consistent delivery and technical guidance. Contact Metav Werkzeuge for tailored configuration advice on the Vertex VKC-50 independent four-jaw chuck and to request detailed technical documentation; email info@metav-werkzeuge.com or call +49 2822 7131930 Technical data Article number: VKC-50 GTIN: 4061905094903 Manufacturer: Vertex ECLASS: 21020490 Facts Diameter: 1250 mm Speed: 150 rpm Weight: 905 kg Special features Type: Independent four-jaw chuck Mounting: T-nut 8-M20 Designation: Vierbackenfutter (independent) FAQ What maximum workpiece diameter can be clamped with this chuck? The VKC-50 provides a clamping capacity of 1250 mm, suitable for large-diameter components used in heavy turning operations. Is the chuck suitable for irregular or non-cylindrical parts? Yes; the independent jaw arrangement of the Vertex VKC-50 allows each jaw to be adjusted separately, enabling precise centring of asymmetrical or irregular workpieces. What is the recommended operating speed for this workholding solution? The VKC-50 is rated for 150 rpm, which matches heavy-duty, high-torque turning processes rather than high-speed machining. How is the chuck mounted to the machine spindle? Mounting is via a T-nut 8-M20 arrangement, providing a secure and standardised interface for attachment to compatible spindle faces or adaptors. For which workshop applications is this chuck intended? This Vertex independent four-jaw chuck is intended for industrial lathe applications where large diameters, rigid clamping and precise jaw adjustment are required, such as heavy fabrication, rotor turning and large-part servicing. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
125mm Independent Four-Jaw Lathe Chuck, 4×M8 T-Slots, 1900 RPM - Vertex
Take advantage of the independent jaw operation, 125 mm nominal diameter and a 1,900 r.p.m. rating for reliable machining of non-cylindrical and uneven parts; order the component directly via Metav Werkzeuge or consult our advisors for fitment and mounting details. Vertex VKC-5 Independent Four-Jaw Chuck — 125 mm, 1,900 r.p.m. A Vertex VKC-5 independent four-jaw chuck designed for secure, adjustable clamping of irregular, square or asymmetrical workpieces on lathes and turning centres Independent four-jaw operation 125 mm nominal diameter Rated speed 1,900 r.p.m. T-slots 4 × M8 Precise, adaptable clamping for diverse workpieces The independently adjustable jaws deliver flexibility when handling off-centre or non-circular stock. By setting each jaw separately, the clamping device allows controlled positioning of the workpiece for turning or profiling operations while maintaining stable contact under load. This approach reduces the need for custom fixtures and speeds up set-up for small series or maintenance tasks, improving throughput without sacrificing repeatability. Balanced design for safe, high-speed operation With a nominal diameter of 125 mm and a maximum permitted speed of 1,900 r.p.m., the VKC-5 is sized for a broad range of medium-duty turning applications. The unit's mass of 5.1 kg contributes to mechanical stability while the mounting interface features T-slots 4 × M8, enabling secure attachment to standard spindle faces or adapter plates. These characteristics combine to support reliable rotational balance and compatibility with many workshop machines. Practical benefits that reduce setup time The unit's configuration simplifies clamping of square, rectangular or odd-shaped blanks, cutting down on improvisation and secondary tooling. Fewer bespoke fixtures mean shorter lead times and a more consistent workflow on the shop floor. Paired with Metav's logistics and product range, the chuck fits into an efficient supply chain that emphasises accessibility of precision components and dependable stock levels for industry users. For secure, versatile clamping choose the Vertex VKC-5 — order or request mounting advice from Metav Werkzeuge in Emmerich: info@metav-werkzeuge.com, +49 2822 7131930 Technical data SKU: VKC-5 GTIN: 4061905086588 Brand: Vertex Facts Diameter: 125 mm Rated speed: 1,900 r.p.m. Weight: 5.1 kg T-slots: 4-M8 eClass: 21020490 Special features Independent four-jaw design Suitable for clamping irregular and square workpieces Category: Vertex FAQ How do independent jaws affect clamping precision? Independent jaws allow individual adjustment of each jaw, so the VKC-5 can centre and secure non-round or eccentric parts with controlled contact and reduced need for special fixtures. Which machines is this chuck compatible with? The VKC-5 is intended for lathes and turning centres that accept a 125 mm chuck and can operate within the stated maximum speed of 1,900 r.p.m. How is the chuck mounted to a spindle face? Mounting uses T-slots (4 × M8) as specified; ensure appropriate adapter plates and correct torque on fastenings for safe operation. Can the chuck hold square or rectangular stock reliably? Yes — the independent jaw arrangement is particularly suited to square and rectangular workpieces, enabling stable contact points without special jaws. What basic maintenance does the chuck require? Regular cleaning of the jaw slides, light lubrication of moving parts and inspection of mounting fastenings prolong service life and preserve performance. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
132mm Universal Centre With Live Centre Mounting, 0.005mm Accuracy, Alloy Steel - Vertex
Take advantage of precision, robust alloy construction and high operational speed for dependable spindle support and consistent concentricity in turning operations. Benefit from a compact 132 mm length and a runout tolerance of 0.005 mm that together maintain machining quality and repeatability. Order directly via Metav Werkzeuge or consult the technical team for application-specific advice. Universal live centre VPC-MT2 — alloy steel, 132 mm by Vertex Universal live centre VPC-MT2 for lathe work, providing revolving tailstock support and stable axial alignment across general turning applications Universal revolving centre for lathes Accuracy within 0.005 mm Up to 2,800 rpm operational speed Alloy steel construction for long service life Precision where concentricity matters The revolving tailstock point delivers a defined support point that reduces axial runout and maintains workpiece concentricity throughout turning cycles. Built to an accuracy of 0.005 mm, the centre stabilises the cutting process, which translates into fewer rework cycles and improved first-pass yields. The close tolerance is particularly beneficial when producing tight-shaft diameters or precision components where concentricity is decisive for assembly or balancing. Stable performance at practical spindle speeds Rated for operation up to 2,800 rpm, the centre is suitable for a broad range of workshop turning speeds without compromising bearing life. Its rotating bearing assembly minimises friction and heat generation, supporting continuous operation during longer batch runs. The modest weight of 0.5 kg and compact profile help maintain lathe balance and reduce axial deflection, supporting reliable machining of medium-duty parts. Durable construction for everyday workshop use Manufactured from alloy steel, the centre is engineered for wear resistance and dimensional stability under cyclic loading. The material choice safeguards the running surface against premature abrasion, extending service intervals and lowering lifetime costs. The robust construction makes the centre a sound component for mixed-material workflows where consistent support and repeatability are required. Practical dimensions and workshop integration With a length of 132 mm, the centre suits common tailstock configurations and leaves sufficient engagement for shorter and medium workpieces. The compact form factor eases storage and handling while the balanced design supports steady rotation under typical lathe forces. Where interchangeability and compatibility with existing setups are priorities, the compact profile and industry-standard format facilitate straightforward use in general workshop environments. Contact Metav Werkzeuge in Emmerich for tailored application advice and ordering details; the Metav team provides technical guidance and reliable European supply from stock Technical Data SKU: VPC-MT2 GTIN: 4061905085635 Manufacturer: Vertex Facts Length: 132 mm Weight: 0.5 kg Maximum speed: 2,800 rpm Accuracy (runout): 0.005 mm Special features Material: alloy steel Revolving/live centre design Compact form factor for standard tailstocks FAQ What turning applications suit this live centre? The VPC-MT2 universal live centre is designed for general lathe work where axial support and concentricity are required; it performs well on medium-duty turning tasks and routine batch production. How does the VPC-MT2’s accuracy affect finished parts? An accuracy of 0.005 mm reduces runout-related errors, improving surface finish and dimensional repeatability for turned components produced with the centre. Is the material suitable for heavy-duty machining environments? Constructed from alloy steel, the centre offers enhanced wear resistance for everyday workshop use; for extreme-duty or specialised alloys, application-specific assessment is recommended. Which lathe speeds are appropriate for this centre? The centre is rated up to 2,800 rpm, covering a wide range of common turning speeds without compromising bearing durability. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
140mm Clamping Ring For Soft Jaw Inserts, 1 kg - Vertex
Secure, precise clamping for soft jaw setups with a 140 mm nominal diameter and lightweight handling for faster changeovers. Benefit from compatibility with 5" chuck jaws and dependable repeatability — request the ring directly via Metav Werkzeuge or consult our advisers for accessory matching. Clamping ring VFR-05 — for soft chuck jaws, 140 mm (Vertex) A robust Clamping ring VFR-05 engineered to secure soft jaw liners on 5-inch chucks, ideal for workshop turning and light industrial applications. 140 mm nominal diameter Compatible with 5" soft chuck jaws Robust design for repeatable clamping SKU VFR-05 by Vertex Faster setup through secure, repeatable clamping The clamping ring provides a stable interface between the chuck and soft jaw liners, delivering consistent contact pressure across the clamped component. With a 140 mm nominal diameter and compatibility with standard 5" chucks, the accessory reduces the need for frequent readjustment. This results in shorter setup times and fewer interruptions to production, supporting a measurable increase in operational efficiency while maintaining workpiece integrity. Protects delicate surfaces and reduces rework Using soft jaw liners together with the ring minimises surface damage on sensitive parts. The combination of the ring and liners offers repeatable clamping that keeps components aligned within close tolerances, lowering the risk of rejects and subsequent rework. For jobs where finish quality matters, this approach preserves machining tolerances and contributes to a more consistent end result. Designed for practical workshop handling Weighing approximately 1 kg, the clamping accessory is light enough for quick handling yet sturdy enough to hold workpieces securely during rotation. Its straightforward form factor simplifies installation and removal, supporting fast tool changes and reduced downtime. Combined with fast shipping from the Metav webshop, the component is suited to busy shops that value downtime reduction and predictable tooling supply. Clear compatibility checks and straightforward use Compatibility is indicated for 5" soft chuck jaws; fitment can be confirmed by measuring the jaw seating and nominal diameter. A precision caliper is useful to verify the 140 mm dimension and ensure the ring matches the backing geometry of the soft jaws. Where minor adjustments are needed, simple alignment checks are sufficient — the design keeps fitting and removal intuitive for shopfloor staff with basic tooling knowledge. Request the Vertex VFR-05 clamping ring via Metav Werkzeuge for reliable workshop clamping — contact Metav Werkzeuge in Emmerich at info@metav-werkzeuge.com or call +49 2822 7131930 for precise compatibility advice Technical Data Article number: VFR-05 GTIN: 4061905084478 Manufacturer: Vertex Core data Diameter: 140 mm Weight: 1 kg Special features Suitable for 5" soft chuck jaws For soft jaw liners / soft jaw faces Fast shipping from Metav webshop FAQ Is this ring compatible with my 5" chuck? The VFR-05 clamping ring is designed specifically for use with 5" soft chuck jaws and a nominal diameter of 140 mm, ensuring correct fit where those dimensions match. Can the ring be used to protect delicate components? Yes, paired with soft jaw liners the clamping ring minimises surface damage and supports secure, gentle holding of delicate parts during machining. How heavy is the accessory and is it easy to handle? The clamping ring weighs about 1 kg, offering lightweight handling for quick installation while maintaining sufficient mass for stable clamping. What tool is recommended to check fitment? A precision caliper is recommended to measure the jaw seating and confirm the 140 mm diameter for a reliable fit. How quickly is delivery arranged? Fast shipping is available through the Metav webshop, facilitating prompt replenishment of workshop supplies. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
153mm Centre Punch With Interchangeable Tips 60° MT3 Stainless Steel - Vertex
Benefit from a combination of precise runout control, durable stainless‑steel construction and MT3 taper compatibility to maintain reliable turning operations and reduce rework. Order the centre via Metav Werkzeuge or consult the Metav team for application-specific advice. VLC-313 Interchangeable‑Tip Lathe Centre — Stainless Steel, MT3 Taper (Vertex) The VLC-313 is a robust lathe centre with replaceable 60° tips for accurate turning and marking in workshop environments. Stainless steel body for long service life MT3 taper for standard lathe mounting Interchangeable 60° tips for versatile use Balanced for operation up to 3,000 r.p.m. Precision where concentricity matters The VLC-313 delivers consistent axial accuracy with a runout tolerance of 0.008 mm, reducing the need for repeated setup checks and limiting scrap. Built from stainless steel, the centre resists corrosion and wear in daily shop use, which helps to preserve alignment and cutting results. This combination of precision and durable materials leads to fewer stoppages and a smoother production flow for small‑batch turning and inspection tasks. Quick tip changes and proven machine fit Interchangeable tips with a 60° angle allow rapid adaptation for different workpiece geometries, while the MT3 taper ensures firm seating in standard lathe tailstocks or live‑centre housings. For those less familiar with taper designations: MT3 denotes a Morse taper size 3, a common interface that simplifies tool selection and integration. The replaceable tip system reduces maintenance time and inventory complexity, supporting efficient changeovers and predictable tool life. Stable performance at workshop speeds Designed and balanced for operations up to 3,000 r.p.m., this centre combines a compact profile (length 153 mm) with a serviceable mass (approx. 1.4 kg) to provide rotational stability without excessive inertia. The result is reliable centre support during turning, facing and marking operations, with less vibration and improved surface finish. The Vertex design philosophy behind this accessory emphasises repeatable results and straightforward upkeep, making it suitable for production benches and maintenance shops alike. Contact Metav Werkzeuge in Emmerich for tailored advice on Vertex lathe accessories — email info@metav-werkzeuge.com or call +49 2822 7131930 for technical guidance and ordering information Technical data Article number: VLC-313 GTIN: 4061905087004 Manufacturer: Vertex Facts Length: 153 mm Weight: 1.4 kg Speed rating: 3,000 r.p.m. Runout accuracy: 0.008 mm Tip angle: 60° Special features Material: stainless steel Taper interface: MT3 (Morse taper 3) Interchangeable tips included Brand: Vertex FAQ What is the recommended mounting for this lathe centre? The VLC-313 is supplied with an MT3 taper, making it compatible with tailstocks and live‑centre housings fitted for Morse taper size 3. Can the tips be replaced on the VLC-313 and where does it suit best? Yes — the model features interchangeable 60° tips, which makes the centre suitable for general turning, marking and centre‑support applications in workshop and light production environments. What speed can be used safely with this centre? The centre is balanced for operation up to 3,000 r.p.m., which covers typical lathe turning speeds for small to medium diameter workpieces. How does the stated accuracy benefit everyday machining? A runout tolerance of 0.008 mm improves concentricity during turning, reducing rework and ensuring more consistent finishes on machined parts. What material is the centre made from and how does that affect durability? Constructed from stainless steel, the centre offers elevated resistance to corrosion and wear, supporting long service life under normal workshop conditions. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
160mm Independent Four-Jaw Chuck, 4×M10 T-Slots, 1500 rpm - Vertex
Take advantage of the combination of adaptable clamping, stable rotation and straightforward mounting to keep setups efficient and parts secure; order the unit directly via Metav Werkzeuge or ask our consultants for application guidance. Independent Four-Jaw Chuck VKC-6 – 160 mm, independent jaws by Vertex An Independent Four-Jaw Chuck VKC-6 for versatile workholding on lathes and turning centres, designed to grip irregular, round and square components with individual jaw adjustment Independent jaw adjustment for irregular workpieces 160 mm diameter for medium-sized components Max speed 1,500 r.p.m. for reliable turning 4 × M10 mounting; robust 8.3 kg construction Faster setups and repeatable clamping for varied parts The independent jaws enable each jaw to be positioned separately, which is particularly useful when securing off-centre or irregularly shaped components. This flexibility reduces the need for specialised fixtures and shortens set-up time, supporting higher throughput in jobbing environments. With a nominal 160 mm diameter, the clamping range covers many medium-sized parts while maintaining the repeatability required for consistent turning and finishing operations. Stable rotation and secure attachment improve surface quality Built for dependable rotation, the chuck reaches up to 1,500 r.p.m., matching the demands of common lathe and turning-centre cycles. Attachment uses 4 × M10 mounting points for a secure backplate connection, and the unit’s 8.3 kg mass contributes to damping and better torque transfer. Together, these characteristics help to reduce vibration, improve surface finish and lower the risk of scrap—attributes that translate directly into time and cost savings on the shop floor. Practical compatibility and workshop benefits As a robust four-jaw solution from Vertex, the VKC-6 supports a wide range of workshop tasks without the immediate need for special jaws or complex fixtures. The individual jaw control suits batch work with varying part profiles, while the solid construction gives confidence in repeated operations. Combined with Metav’s quality-controlled stocking in Emmerich and access to product expertise, the chuck is a pragmatic choice for maintenance departments and small to medium-sized production cells seeking reliable, flexible clamping. Contact Metav Werkzeuge in Emmerich for tailored advice on integrating the Vertex VKC-6 independent four-jaw chuck into existing setups; email info@metav-werkzeuge.com or call +49 2822 7131930 Technical Data SKU: VKC-6 Type: Independent four-jaw chuck Diameter: 160 mm Max speed: 1,500 r.p.m. Weight: 8.3 kg Mounting: 4 × M10 GTIN: 4061905085291 Facts Diameter 160 mm Maximum speed 1,500 r.p.m. Mass 8.3 kg Special features Independent jaw operation 4 × M10 mounting points Robust construction for improved damping Suitable for irregular, round and square workpieces FAQ What types of components can be clamped with this chuck? The VKC-6 independent four-jaw chuck from Vertex is suitable for round, square and irregular workpieces, providing adaptable holding without the immediate need for special jaws. How is the chuck mounted to the machine? Mounting is via 4 × M10 attachment points; the VKC-6 is designed for secure connection to standard backplates. What is the maximum permitted rotational speed? The unit is rated to operate up to 1,500 r.p.m., which aligns with many conventional lathe and turning-centre applications. Is the chuck suitable for CNC and manual lathes? The VKC-6’s specifications make it appropriate for many conventional and CNC turning operations; machine spindle and backplate compatibility should be confirmed before installation. What basic maintenance does this chuck require? Regular inspection of jaw seating and lubrication of sliding surfaces is recommended to maintain consistent clamping performance for the Vertex VKC-6. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
164mm Centre Tip Live Centre, 0.005mm Accuracy, Alloy Steel, 2000 rpm - Vertex
Take advantage of 0.005 mm concentricity together with a robust alloy steel construction and a compact 164 mm length for reliable turning support; order the VPC‑MT3 directly via Metav Werkzeuge or ask our consultants for tailored advice. VPC‑MT3 Universal live centre — 0.005 mm runout, 2000 r.p.m., Vertex A VPC‑MT3 Universal live centre for rotating workpiece support in lathe turning, designed to maintain concentricity and reduce deflection during machining. High precision: 0.005 mm runout Designed for speeds up to 2000 r.p.m. Alloy steel body for durability 164 mm overall length for deep support Maintain concentric turning with measurable accuracy The VPC‑MT3 delivers exceptionally low runout of 0.005 mm, a specification that directly improves repeatability and surface finish in turning operations. Low runout means the centre point runs closer to the true axis, reducing radial vibration and minimising rework. For workshops aiming to keep tolerances tight, this level of precision supports repeatable part quality and consistent inspection results. Reliable rotation at practical lathe speeds Designed for rotation at up to 2000 r.p.m., this revolving centre suits a wide range of medium‑speed turning tasks. The controlled rotational capability ensures stable support of the workpiece, which in turn maintains machining tolerances and reduces tool wear. With an overall length of 164 mm and a compact mass of 0.9 kg, the unit provides deep support where longer reach is required while remaining easy to handle during setup. Durable construction for everyday workshop use Constructed from alloy steel, the live centre is built for longevity under routine workshop conditions. The material choice balances toughness with dimensional stability, keeping the centre point concentric over many cycles. As a universal support device, the centre is suited for general turning applications where robust, repeatable support is required rather than specialised or medical precision use. For precision turning tasks where concentricity and dependable rotation matter, choose the Vertex VPC‑MT3 — contact Metav Werkzeuge in Emmerich for product availability and application guidance via info@metav-werkzeuge.com or by phone. Technical Data Article number: VPC-MT3 GTIN: 4061905085567 Manufacturer: Vertex Facts Runout accuracy: 0.005 mm Maximum speed: 2000 r.p.m. Length: 164 mm Weight: 0.9 kg Special features Material: alloy steel Type: revolving / live centre Brand: Vertex FAQ What degree of concentricity can be expected from this live centre? The VPC‑MT3 achieves a runout accuracy of 0.005 mm, which supports high concentricity in standard turning operations. Is the VPC‑MT3 suitable for medium‑speed lathes? Yes, the unit is specified for operation up to 2000 r.p.m., making it appropriate for many medium‑speed lathe applications. What materials is the centre made from and why does that matter? The body is made from alloy steel, chosen for its toughness and dimensional stability, which helps preserve alignment and service life under workshop use. How does the length of 164 mm affect its application? An overall length of 164 mm provides extended reach for deeper support into the spindle or over long workpieces while keeping handling straightforward. Which SKU should be ordered for this universal live centre? Order the VPC‑MT3 (SKU: VPC-MT3) for the universal live centre in Vertex’s range Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
165mm 60° Carbide Centre Punch Fixed Tip, DIN 806 - Vertex
Take advantage of the combination of carbide tip longevity, a 60° centre angle for standardised marking and a robust 165 mm length for controlled reach — all contributing to smoother production and less rework. Order the part directly via Metav Werkzeuge or consult our specialists for application advice. VLC-114 centre punch tip — fixed carbide marking point, 60° (Vertex) The VLC-114 centre punch tip is a fixed, carbide-tipped marking point designed for precise centre punching and layout work in workshop and production environments, conforming to DIN 806. Fixed carbide tip for long-lasting precision 60° centre angle for standard marking Length 165 mm for controlled reach DIN 806 compliant manufacturing quality Reliable marking that reduces rework and downtime A hard-wearing carbide tip delivers consistently sharp impressions over long production runs, which improves precision and reduces the need for repeat marking. The standard 60° centre angle ensures marks are compatible with common tooling and centre drills, enabling predictable alignment during drilling and machining operations. With a robust design, the tool supports steady contact force and repeatable results, contributing to faster cycle times and fewer corrections in downstream processes. Stable design to streamline workshop routines The fixed design of the tip eliminates play between components, giving stable contact and a uniform mark every time; this supports consistent part set‑up and inspection. Compliance with DIN 806 provides a recognised performance baseline, simplifying integration into existing toolsets and quality procedures. A length of 165 mm offers a good balance between reach and control, allowing safer handling when marking assemblies or parts positioned within fixtures without sacrificing operator accuracy. Material advantages explained for confident selection Carbide as a tip material offers superior wear resistance compared with conventional steel points, preserving geometry under repeated impact and abrasive conditions; this equates to extended service life and lower lifetime costs per mark. The compact, robust construction and the tip material together deliver high durability and stable imprint geometry, which supports reliable inspection and repeatability across batches. For production environments that prioritise uptime and predictable tool behaviour, this configuration provides an economical and technically sound solution. Metav as a dependable procurement partner As a precision partner, Metav combines decades of expertise with a broad catalogue to simplify procurement: a single source for measurement and workshop supplies reduces supplier complexity while ensuring product consistency. With a large European stock and established logistics from Emmerich, Metav offers transparent order handling and steady supply — factors that matter for uninterrupted production planning and dependable workshop inventories. Contact Metav Werkzeuge for application guidance on the VLC-114 centre punch tip and secure a reliable marking solution tailored to workshop requirements; Metav’s consultants in Emmerich assist with technical details and delivery arrangements. Technical Data Article number: VLC-114 GTIN: 4061905088216 Material: Carbide tip Standard: DIN 806 Data Length: 165 mm Tip angle: 60° Weight: 0.8 kg Special features Fixed tip design Manufacturer: Vertex SKU: VLC-114 FAQ What is the main benefit of a carbide-tipped centre punch? A carbide-tipped centre punch provides higher wear resistance and longer service life than standard steel points, resulting in more consistent marking and fewer tool changes for the VLC-114 centre punch tip (Vertex, SKU VLC-114). Is the tool suitable for standard drilling preparation? Yes, the 60° tip geometry produces standardised centre marks that are suitable for subsequent drilling and centre-drilling operations, helping to maintain repeatable alignment. Does the product conform to industry standards? The tool is manufactured in accordance with DIN 806, offering a recognised specification for form and function in marking applications. Is the tip replaceable or permanently fixed? The part is specified as a fixed tip design; replaceability is not listed in the standard specification for this item. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
167mm Self-Centring 6-Jaw Chuck, 1200 rpm - Vertex
Take advantage of precise, repeatable clamping thanks to the combination of a self-centring 6-jaw design and a compact Ø 167 mm diameter, ensuring stable turning at up to 1,200 r.p.m. Order directly via Metav Werkzeuge or consult our specialists for tailored delivery and fitment advice. VAS-6 – 6‑jaw self‑centring chuck, Ø 167 mm, Vertex The VAS-6 is a 6‑jaw self‑centring chuck for lathe workholding, engineered to provide consistent clamping and fast set-up for production and workshop applications 6-jaw self-centring design Diameter 167 mm for medium workpieces Max speed 1,200 r.p.m. for efficient turning Robust construction, 9.2 kg mass Repeatable centring for consistent part quality The 6-jaw layout delivers uniform gripping force around the workpiece, reducing runout and improving repeatability across batch production. The self-centring mechanism shortens setup times compared with independent-jaw systems, which supports higher throughput without sacrificing accuracy. For operations where concentricity and surface finish are critical, the chuck’s geometry helps maintain steady cutting conditions and predictable results. Balanced mass and speed for stable machining A mass of 9.2 kg combined with a rated maximum of 1,200 r.p.m. provides a stable rotating assembly that resists chatter in medium‑duty turning. The Ø 167 mm jaw span suits a wide range of round and slightly irregular components often encountered in maintenance, prototyping and small-series manufacture. Clear specification of rotational speed supports process planning and helps avoid exceeding safe operational limits during roughing and finishing passes. Practical integration and workshop efficiency Designed for straightforward mounting in standard lathe setups, the chuck simplifies workholding choices and reduces the number of bespoke fixtures required. The robust construction supports frequent clamping cycles in daily workshop use, while the compact footprint preserves access to tooling and measurement points. Combining predictable clamping behaviour with straightforward handling, this chuck supports leaner workflows and reduces non-productive time in the machine cycle. For reliable, production-ready clamping trust Vertex’s VAS-6—contact Metav Werkzeuge in Emmerich for personalised advice and swift supply via info@metav-werkzeuge.com or +49 2822 7131930 Technical Data SKU: VAS-6 GTIN: 4061905086946 Manufacturer: Vertex Numbers / Core Technical Data Diameter: 167 mm Max speed: 1,200 r.p.m. Weight: 9.2 kg Special features 6 jaws Self-centring chuck design eClass: 21020590 FAQ How does the 6-jaw design affect concentricity? The six-jaw layout increases contact points and balances clamping forces, so the VAS-6 achieves improved concentricity and repeatability compared with three-jaw designs for many medium-sized parts. What is the maximum safe rotational speed for this chuck? The chuck is rated to operate at up to 1,200 r.p.m., which should be observed to ensure safe and stable machining conditions when the VAS-6 is mounted. Which workpiece diameters are suitable for this chuck? With a diameter of 167 mm, the chuck is intended for medium workpieces commonly processed in general workshop and light production turning operations. Can the chuck be used for high-precision finishing operations? Yes, the self-centring mechanism and uniform jaw engagement of the VAS-6 support finishing passes where concentricity and surface consistency are required. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
168mm Clamping Ring For Soft Jaw Attachments, For 6" Jaw Caliper - Vertex
Combining a 168 mm nominal diameter with compatibility for 6" soft-jaw attachments and a compact mass of 1.5 kg, this clamping ring provides steady holding with minimal handling effort; Order the clamping ring VFR-06 directly via Metav Werkzeuge or ask our consultants if needed Clamping Ring VFR-06 — 168 mm for 6" soft-jaw attachments, Vertex The clamping ring VFR-06 is a compact workholding accessory engineered to secure soft-jaw fixtures, optimising set-ups in workshop and bench-mount applications 168 mm nominal diameter Compatible with 6" soft-jaw attachments Lightweight at 1.5 kg for easy handling Robust retention for repeatable clamping Faster, repeatable workholding for consistent parts The clamping ring is designed to deliver reliable clamping in fixtures that use soft jaws, helping to maintain concentricity and repeatability across short production runs. Its 168 mm nominal diameter fits common jaw layouts, enabling straightforward integration with existing chucks and fixtures. By focusing on secure radial retention rather than bulk, the component reduces micro-movement during machining and finishing, which supports higher first-pass accuracy and fewer adjustments between cycles. The result is a measurable improvement in throughput and part consistency without complex retrofitting. Reduced setup effort and safer handling At just 1.5 kg, the component lowers handling strain during tool changes and jaw swaps, shortening changeover time and improving operator ergonomics. The light mass also simplifies manual positioning and alignment when paired with standard soft-jaw attachments, making quick fixtures practical even on compact benches. Combined with the clamping geometry tailored for soft materials, the solution minimises the risk of workpiece deformation while preserving a secure hold—an advantage when sensitive or finished surfaces require gentle yet firm retention. Seamless integration for workshop workflows Compatibility with 6" soft-jaw attachments ensures the ring can be introduced into familiar workholding systems without extensive modification. Produced under the Vertex name, the unit supports routine maintenance strategies and straightforward inventory control in precision workshops. Where traceability is important, the VFR-06 designation and associated identifiers simplify stock management and reorder procedures. For operations seeking to harmonise fixtures across machines, the ring offers a compact, purpose-built option that balances accessibility, repeatability and workshop efficiency. Discuss application needs with Metav Werkzeuge to confirm fit for soft-jaw systems and to reserve the VFR-06 for immediate dispatch from our Emmerich facility Technical data Article number: VFR-06 GTIN: 4061905086861 Brand: Vertex Core specifications Diameter: 168 mm Weight: 1.5 kg Suitable for: 6" soft-jaw attachments Applications and features For use with soft-jaw attachments Compatible with 6" soft-jaw workholding systems SKU: VFR-06 FAQ Is this clamping ring compatible with standard 6" soft jaws? Yes. The clamping ring VFR-06 is designed for use with 6" soft-jaw attachments and fits standard workholding arrangements that accept that jaw size. What is the nominal diameter of the component? The ring has a nominal diameter of 168 mm, which accommodates a wide range of chuck and fixture layouts commonly used in workshop environments. How much does the clamping ring weigh? The unit weighs 1.5 kg, a balance between robustness and easy handling during jaw changes and set-up operations. For which applications is this component suitable? The product is intended for workholding scenarios that use soft jaws—holding, finishing and light machining where secure retention and minimal surface deformation are required. What identifiers help with ordering and stock control? Order using SKU VFR-06 or GTIN 4061905086861; both identifiers are provided to simplify procurement and inventory tracking. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
176mm Live Centre Rotating For High Speeds, Accuracy 0.005 - Vertex
Take advantage of precise runout control and high‑speed capability to improve surface finish and reduce rework. Benefit from the combination of recognised Vertex manufacturing and Metav Werkzeuge’s reliable supply – order directly via Metav Werkzeuge or consult the Metav team for technical guidance. Vertex live centre MT3A – high‑speed rotating centre with 0.005 mm runout The Vertex live centre MT3A is a lathe accessory designed to support rotating workpieces at elevated spindle speeds, offering precise support for turning operations and reduced vibration in demanding production environments. High-speed rotation up to 4,000 r.p.m Precision runout 0.005 mm Morse taper MT3A interface Length 176 mm, weight 1.3 kg Consistent precision for improved component quality The primary advantage of this live centre is its focus on precision: with a measured runout 0.005 mm, the centre minimises radial error at the tailstock end, which directly improves concentricity and surface finish during turning. Reduced runout means less corrective machining and fewer rejected parts, supporting predictable cycle times. The specification for accuracy is particularly relevant in serial production and jobbing shops where repeatability influences downstream processes; the compact, engineered bearing assembly within the centre ensures this level of performance without complex setup procedures. Built for high‑speed turning and smoother machining Designed as a high‑speed rotating centre, the unit sustains operation up to 4,000 r.p.m., allowing higher cutting speeds and optimised material removal rates on modern lathes. The Morse taper MT3A interface provides straightforward mounting and secure seating in the tailstock, while the live rotation reduces tool chatter and promotes low vibration conditions. For materials and cycle types that benefit from increased spindle speed, the rotating support provided by the centre helps maintain dimensional stability and extends tool life through steadier cutting conditions. Compatibility, handling and workshop integration The compact form‑factor (length 176 mm; weight 1.3 kg) and standard taper make the centre easy to integrate into existing setups without additional adapters. As a robust lathe accessory, it is suitable for everyday workshop use and for operators who require reliable workpiece support during prolonged runs. For less experienced staff, the concept of a live centre is simple: the rotating tip follows the workpiece rotation, eliminating the sliding friction seen with fixed centres and thereby reducing heat and wear at the contact point. This tangible operational benefit improves both efficiency and safety at the machine. For reliable high‑speed support and workshop compatibility, choose the Vertex live centre MT3A and contact Metav Werkzeuge for ordering or tailored technical advice: Metav Werkzeuge, Parkring 45, 46446 Emmerich; info@metav-werkzeuge.com | +49 2822 7131930 Technical data Article number: VLC-MT3A GTIN: 4061905083594 Type: MT3A Designation: Live centre Brand: Vertex Facts Length: 176 mm Weight: 1.3 kg Accuracy (runout): 0.005 mm Max speed: 4,000 r.p.m Angle: 60° Special features Live rotating centre for high speeds Morse taper MT3A Suitable for lathe turning applications FAQ What maximum spindle speed is supported by this live centre? The live centre supports operation up to 4,000 r.p.m., allowing higher cutting speeds for compatible turning operations. How does a 0.005 mm runout affect machining results? A runout of 0.005 mm reduces radial error and vibration, improving surface finish and dimensional accuracy compared with centres that have higher runout. Is the MT3A taper compatible with standard tailstocks? Yes, the Morse taper MT3A is a common interface and fits tailstocks or adaptors designed for an MT3 taper. Can the centre be used for long production runs? The Vertex live centre is designed for routine workshop use and sustained operation, offering robust support for serial turning tasks. What advantages does a rotating centre offer over a fixed centre? A rotating (live) centre reduces sliding friction and heat at the contact point, lowering wear and promoting steadier cutting conditions. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
188mm Universal Centre Tip Running, 0.005mm Accuracy, Alloy Steel, 1800 rpm - Vertex
Take advantage of the combination of high rotational capacity, fine runout accuracy and robust alloy construction to ensure reliable support of rotating workpieces. Benefit from reduced rework and consistent concentricity by specifying the live centre from Vertex; order directly via Metav Werkzeuge or consult our technical advisors for application guidance. VPC-MT4 Universal live centre — alloy steel, 0.005 mm accuracy (Vertex) The VPC-MT4 is a universal live centre engineered to support rotating workpieces in lathes and turning centres, combining compact dimensions with stable running for general workshop and toolroom turning operations. High precision 0.005 mm runout accuracy Alloy steel construction for robust duty Operates up to 1800 r.p.m. reliably Compact 188 mm length, 1.3 kg weight Proven accuracy for consistent turning results The live support delivers a verified runout of 0.005 mm, which translates into measurably improved concentricity and fewer scrap parts. This level of precision is achieved through a balanced spindle and careful bearing selection, so that the applied clamping forces are transmitted with minimal deflection. For production runs where repeatability matters, the fine runout reduces the need for secondary turning passes and inspection overhead. The explained tolerance gives purchasing and production planners a verifiable specification to compare against alternative support centres. Robust material and dependable rotational performance Constructed from alloy steel, the centre is built for sustained workshop use and resists deformation under normal machining loads. Rated for continuous operation up to 1800 r.p.m., the component maintains stability across common turning speeds while its 188 mm compact length and 1.3 kg mass aid in rapid mounting and repositioning. The material choice provides a balance between hardness and toughness, offering wear resistance where contact occurs yet avoiding brittleness that can reduce service life. Where higher surface integrity is required, the robust construction contributes directly to consistent workpiece finish. Seamless integration and practical benefits for the workshop Designed as a live-running support, the centre fits conventional lathe tailstocks and is suitable for a wide range of turning tasks in general metalworking and toolroom environments. The spindle arrangement ensures smooth rotation of the workpiece, reducing chatter and enabling steadier machining at intermittent feed rates. Documentation and identification via the SKU support procurement processes, while the clear technical parameters allow engineers to plan cycles and tool offsets with confidence. As a Vertex product, the unit benefits from established manufacturing practices and traceability, which supports quality control and long-term parts replacement planning. Contact Metav Werkzeuge for tailored specification advice on the Vertex VPC-MT4 universal live centre or to arrange delivery from our Emmerich warehouse and technical consultation Technical data Article number: VPC-MT4 GTIN: 4061905085840 Manufacturer: Vertex Facts Accuracy: 0.005 mm Max speed: 1800 r.p.m. Weight: 1.3 kg Length: 188 mm Materials & special features Material: alloy steel Live-running centre design ECLASS: 21022304 FAQ What level of runout can be expected from this live centre? The specified runout is 0.005 mm for the Vertex VPC-MT4 universal live centre, providing the precise concentricity required for repeatable turning operations. Is the centre suitable for high-speed turning applications? The support is rated to 1800 r.p.m., making the VPC-MT4 appropriate for typical lathe speeds encountered in general workshop and toolroom work. Which material is the body made from and what does that imply? The body is manufactured from alloy steel; this offers a robust balance of wear resistance and toughness for sustained workshop use. Can the live centre be used across different lathes and tailstocks? The live-running design is compatible with conventional tailstock arrangements and is intended for broad use in turning support roles. How does this product support quality assurance in production? By delivering consistent runout and stable rotation, the VPC-MT4 reduces rework and inspection effort, aiding process control and part repeatability. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
200mm Carbide Centre Tip Fixed 60° DIN 806 - Vertex
The combination of a carbide tip, a 60° centre angle and DIN 806 conformity delivers reliable, repeatable centre support for demanding turning operations. Order the part directly via Metav Werkzeuge or consult our advisors for workshop-aligned supply and fast delivery. VLC-115 Fixed Centre Point, Carbide Tip, 60° (Vertex) The centre point is a fixed turning centre with a carbide tip engineered to provide stable workholding and precise axial support in lathe applications. Carbide tip for high wear resistance 60° standard centre angle DIN 806 conformity Fixed design for stable workholding Consistent axial support that keeps production moving The fixed centre offers stable workholding, reducing runout and enabling consistent concentricity across batches. With a 60° angle that follows the DIN 806 specification, centres are positioned reliably during turning and facing operations; this standardisation helps integrate the component into existing tooling setups without additional adjustments. The result is measurable time savings at the lathe through fewer rework cycles and predictable part geometry. Durable carbide tip for extended service intervals The tip is manufactured from carbide, a material chosen for its abrasion resistance and longevity under cyclical loading. Because the cutting and support point is carbide, wear progression is slowed, leading to longer intervals between replacements and lower lifecycle maintenance costs. In practical terms this means fewer interruptions on the shop floor and a higher proportion of productive machining hours. Simple compatibility and workshop integration The fixed design, combined with the product's conformity to DIN 806, simplifies selection and mounting on standard centres and tailstocks. The compact profile and measured length ensure that the centre point sits securely in tooling configurations, providing the stability needed for accurate support. Clear technical specifications streamline procurement and enable the part to be incorporated into jigs and fixtures with minimal modification. Choose the Vertex VLC-115 for robust, standards-based centre support and contact Metav Werkzeuge for tailored delivery from Emmerich—email info@metav-werkzeuge.com or call +49 2822 7131930 for precise order handling and expert advice. Technical data SKU: VLC-115 GTIN: 4061905086663 EClass: 21022304 Core specifications Length: 200 mm Angle: 60° Weight: 2.1 kg Materials & features Carbide tip Fixed design Standard: DIN 806 Brand: Vertex FAQ What is the primary application of this centre point? The VLC-115 fixed centre point is intended for axial support in turning operations, providing a stable reference point for workpieces in lathes and similar machines. Is the carbide tip replaceable? The centre point is supplied with an integrated carbide tip and is designed as a fixed component rather than a modular, tip-replaceable system. Which standard ensures compatibility with existing equipment? Compatibility is supported by conformity to DIN 806, which aligns the centre geometry and mounting expectations with common workshop standards. How should the part be maintained for longest life? Routine cleaning of chips and light lubrication of the seating surfaces will help preserve accuracy; inspect the carbide tip regularly for signs of wear or damage. Can this centre point be used in high-precision setups? Yes, the fixed design and carbide tip deliver the stability and wear resistance expected for precision-support applications in standard turning processes. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
200mm Independent Four-Jaw Lathe Chuck, 1350 rpm, 4-M10 T-Slots - Vertex
Benefit from independent four‑jaw clamping, a 200 mm nominal diameter and a 1,350 r/min rating for reliable turning operations; order the VKC-8 directly via Metav Werkzeuge or consult our advisers if specification support is required. VKC-8 four‑jaw independent chuck (200 mm) by Vertex — 1,350 r/min, 15.9 kg A VKC-8 four‑jaw independent chuck designed for secure, adjustable clamping of irregular and concentric workpieces on lathes and turning centres. Independent four‑jaw clamping for irregular shapes 200 mm nominal diameter Rated up to 1,350 r/min T‑slots 4‑M10 for secure mounting Consistent precision through independent jaw control Independent jaw operation means each jaw can be set separately, allowing secure clamping of non‑cylindrical or off‑centre parts with minimal rework. The independent jaws reduce the need for specialised fixtures when turning irregular shapes, shortening setup times and improving throughput. For shop floors where adaptability matters, the jaw assembly provides repeatable positioning that supports tighter tolerances and fewer scrap parts. The VKC‑8 is engineered to maintain clamping accuracy throughout the machining cycle, contributing directly to consistent part quality. Capacity and dynamic suitability for typical lathe work With a 200 mm diameter capacity and a rated speed of 1,350 r/min, the chuck covers a broad range of medium‑sized turning tasks while matching common spindle speeds on universal and CNC lathes. The specified maximum speed indicates the dynamic operating envelope; within this range the device balances performance and safety. Selecting a chuck with matching diameter and speed rating helps avoid unnecessary spindle loading and supports stable cutting conditions, which in turn improves surface finish and tool life. Practical mounting and workshop integration for faster set‑up Mounting is simplified by T‑slots 4‑M10, which provide defined attachment points for adapter plates or bespoke fixtures, enabling rapid changeovers between jobs. The design reduces fixturing complexity and integrates easily into existing workholding systems. Clear numeric specifications for diameter, speed and fastening standardise procurement and spare‑part planning across the workshop, supporting efficient inventory control and predictable machine availability. For dependable, flexible clamping choose the Vertex VKC‑8—contact Metav Werkzeuge in Emmerich for specification advice and reliable supply Technical data SKU: VKC-8 GTIN: 4061905087295 ECLASS: 21020490 Manufacturer: Vertex Core specifications Diameter: 200 mm Max. speed: 1,350 r/min Weight: 15.9 kg T‑nuts: 4‑M10 Special features Independent four‑jaw design Image available (thumbnail asset) FAQ What is the maximum rotational speed for this chuck? The VKC‑8 four‑jaw independent chuck is rated to 1,350 r/min, which defines its recommended dynamic operating limit. Can the chuck clamp irregularly shaped parts without additional fixtures? Yes. The independent jaw concept allows each jaw to be adjusted individually, making the chuck suitable for irregular and off‑centre workpieces without specialised fixtures. What mounting interface does the chuck use? Mounting is provided via T‑slots 4‑M10, permitting secure attachment to compatible adapter plates or faceplates. What size of workpiece can be accommodated? The chuck has a nominal diameter of 200 mm, specifying the standard clamping envelope for concentric and irregular parts. Who manufactures the VKC‑8 and where is it supplied from? The VKC‑8 is produced by Vertex and is available via Metav Werkzeuge, which supplies and supports precision workholding equipment for European workshops. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
200x250x108mm Four-Jaw Square Self-Centring Machine Vice, 1620 kgf Clamping Force - Vertex
Take advantage of the combination of a self‑centring four‑jaw design, 1,620 kgf clamping force and robust build quality for dependable, repeatable workholding. Order the chuck directly via Metav Werkzeuge or consult the Metav team for specification support. VMJ-8 — 4‑jaw self‑centring square chuck by Vertex with high clamping force The VMJ-8 is a self‑centring, four‑jaw square chuck engineered for secure workholding in precision machining and heavy‑duty turning applications. Self‑centring four‑jaw design High clamping force: 1,620 kgf Accuracy 0.03 Robust construction, 21.5 kg mass Consistent precision for machining accuracy The self‑centring four‑jaw mechanism delivers uniform clamping across the jaw set, which supports consistent part concentricity and reduces rework. With a specified accuracy of 0.03, the chuck provides measurable repeatability that benefits setup reliability and process control. The design minimises radial run‑out during turning and milling operations; for operators less familiar with technical tolerances, this means fewer scrapped parts and more predictable finishing results. Emphasis on stable clamping translates directly into improved surface quality and tighter dimensional control. Heavy clamping capability for larger, demanding workpieces A clamping force of 1,620 kgf ensures secure retention of workpieces under significant cutting loads, enhancing stability during deep cuts or interrupted cuts. The unit's 21.5 kg mass contributes to damping and reduces vibration, supporting longer tool life and higher feed rates where appropriate. The square mounting and robust construction make the chuck suitable for demanding shopfloor environments where mechanical resilience and repeatability are priorities. Performance‑oriented shops benefit from this combination of force and mass when machining tougher materials or larger diameters. Efficient setup and practical integration for workshop use The chuck is designed for straightforward integration with lathes and machining centres that accept square‑mounted chucks, enabling rapid changeovers and reproducible setups. The self‑centring feature reduces alignment steps during workpiece change, saving machine time without sacrificing hold quality. Maintenance requirements are conventional: regular cleaning of the jaw tracks and periodic lubrication preserves long‑term performance. For teams transitioning from simple three‑jaw chucks, the four‑jaw self‑centring design offers a balance between versatility and precision for mixed production runs. For reliable high‑force clamping from Vertex, contact Metav Werkzeuge in Emmerich for availability and tailored advice — Metav's specialists can be reached at info@metav-werkzeuge.com or by phone on +49 2822 7131930 Technical data Article number: VMJ-8 GTIN: 4061905087486 Manufacturer: Vertex Core specifications Dimensions: 200x250x108 mm Weight: 21.5 kg Clamping force: 1,620 kgf Accuracy: 0.03 Features Self‑centring four‑jaw square chuck Square mounting ECLASS: 21020590 FAQ What level of concentricity can be expected from this chuck? The chuck achieves a specified accuracy of 0.03, which in practice supports tight concentricity for precision turning and milling when properly set up and maintained. Is the clamping force sufficient for interrupted cuts and heavy milling? With a clamping force of 1,620 kgf, the chuck provides secure retention for demanding operations; the mass and construction also help to damp vibration during heavy cuts. Which machines is this chuck compatible with? The design suits machines that accept square‑mounted, four‑jaw chucks; compatibility should be confirmed against spindle or adaptor specifications and mounting interfaces. How does the self‑centring four‑jaw design compare to three‑jaw chucks? The self‑centring four‑jaw offers a compromise between the speed of three‑jaw systems and the versatility of independent jaws, delivering improved repeatability with simpler setup than fully independent jaw arrangements. Are replacement jaws or spare parts available for this model? Spare parts and jaw sets are available through Vertex distributors; reference the VMJ-8 article number when enquiring to ensure correct components are supplied. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
218mm Clamping Ring For Soft Jaw Inserts - Vertex
Take advantage of precise clamping, compatibility with soft jaw inserts and a compact design that simplifies handling in daily workshop use. The combination of a 218 mm diameter and stable clamping behaviour supports repeatable setups and steady machining results. Order the VFR-08 clamping ring directly via Metav Werkzeuge or ask our consultants if needed. VFR-08 clamping ring — 218 mm diameter for soft jaw inserts (Vertex) The VFR-08 clamping ring is a dedicated clamping accessory designed for use with soft jaw inserts in chuck systems, providing a reliable interface for repeatable workholding across turning and fixture operations. 218 mm diameter for soft jaw setups Precise clamping for stable machining Compact weight at 2.4 kg Consistent accuracy for repetitive turning and fixturing A robust clamping solution delivers predictable results; the clamping ring acts as a uniform radial support when used with soft jaw inserts, ensuring concentric contact and minimised runout. The design focuses on even force distribution rather than aggressive bite, which benefits delicate or reworked components and reduces the need for repeated adjustment. This stability enables consistent cycle times and contributes to higher first-pass accuracy on series parts. Faster changeovers and straightforward integration with chuck systems Integration into established chuck setups is straightforward: the ring is specified for use with an 8-inch chuck jaw system and interfaces with soft jaw inserts to shorten fixture changeovers. Clear mechanical fitment reduces alignment work during setup, which translates into measurable time savings at the machine. Where quick toolchanger-style swaps are not an option, optimised accessory geometry supports efficient manual handling and repeatable repositioning between batches. Practical workshop performance and handling benefits Weighing 2.4 kg, the component is light enough for manual handling yet substantial enough to remain stable under clamping forces, aiding safe and efficient workshop routines. Constructed as a dedicated clamping component, the ring supports processes where controlled pressure and surface protection are required for softer jaws. Availability through a reliable supplier network helps maintain uninterrupted operations in production and repair environments. For compatibility checks, supply options and technical advice on Vertex clamping rings, contact Metav Werkzeuge in Emmerich for local support and precise product matching. Technical Data Article number: VFR-08 GTIN: 4061905086489 Brand: Vertex Data Diameter: 218 mm Weight: 2.4 kg eCl@ss: 20069202 Special features For soft jaw inserts Suitable for 8-inch chuck jaw Category: Vertex FAQ What applications is this clamping ring suitable for? The VFR-08 clamping ring by Vertex is suitable for turning and fixturing operations where soft jaw inserts are used to protect or shape the workpiece surface. Which chuck systems is the ring compatible with? Compatibility is stated as for 8-inch chuck jaw systems; the VFR-08 is intended to integrate with standard 8‑inch jaw configurations and the corresponding soft jaw inserts. How does the ring affect setup time? By providing a defined interface for soft jaws, the clamping ring reduces alignment effort and supports quicker changeovers compared with ad hoc fixturing methods. Is the VFR-08 heavy to handle during manual setup? At 2.4 kg, the VFR-08 offers a balance between manageable handling and sufficient mass for stable clamping, suitable for routine manual installation and removal. Can the clamping ring be used for delicate or reworked components? Yes, when combined with soft jaw inserts the ring provides controlled pressure distribution, making it appropriate for delicate surfaces and reworked parts. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
220mm Self-Centring Extra-Flat 3-Jaw Lathe Chuck 1800 kgf - Vertex
Take advantage of the combination of robust clamping performance and a low-profile, space-saving design for efficient, repeatable turning. The self-centring mechanism and high clamping force ensure fast set-up and secure workholding — order the 3-jaw chuck directly via Metav Werkzeuge or ask our consultants for installation advice. Vertex VNBK-6 3-jaw lathe chuck — self-centring, extra-flat, 220 mm The Vertex VNBK-6 3-jaw lathe chuck is a self-centring, extra-flat chuck engineered for reliable clamping on turning machines and lathes Self-centring, extra-flat design 220 mm outer diameter 1,800 kgf clamping force Robust construction, 12.4 kg weight Faster set-up through reliable centring The self-centring jaw system reduces set-up time by aligning workpieces automatically when clamped, so changeovers are quicker and repeatability is improved. For batch production and frequent part changes, this mechanism minimises manual adjustment and the associated downtime. The three-jaw arrangement distributes force evenly for consistent positioning, which is particularly advantageous when a precise concentric hold is required for turning operations. High clamping force for stable turning Designed to deliver 1,800 kgf of clamping force, this chuck provides a firm grip that reduces the risk of slippage during heavy cuts or interrupted machining. The 220 mm diameter suits medium-sized components and offers a balance between accessibility and holding capacity. The VNBK-6 is specified to maintain secure contact under operational loads, helping to protect tooling and workpieces while supporting higher material removal rates where process stability is essential. Low-profile design for improved access and safety The extra-flat profile shortens the distance between the workpiece and the spindle, improving tool clearance and accessibility for the cutting tool. As a lathe chuck with a compact form, it reduces overhang and the lever effect on the spindle, which can help to lower dynamic loads and vibration. The robust build, reflected in a 12.4 kg mass, contributes to stable rotation while keeping the footprint minimal for tighter setups on modern turning centres. Contact Metav Werkzeuge for tailored advice and to reserve the Vertex VNBK-6 self-centring 3-jaw chuck for prompt dispatch from Emmerich. Technical Data Article number: VNBK-6 GTIN: 4061905083181 eClass: 21020401 Category: Vertex Dimensions & Performance Diameter: 220 mm Weight: 12.4 kg Clamping force: 1,800 kgf Features & Materials Type: Three-jaw lathe chuck Design: Self-centring, extra-flat Weight indication included in specifications FAQ What is the main advantage of a self-centring chuck? A self-centring chuck like the Vertex VNBK-6 aligns workpieces automatically when the jaws are tightened, reducing set-up time and improving concentricity for repeat operations. Which machines is this chuck suitable for? The VNBK-6 is intended for installation on turning centres and lathes that accept a 220 mm chuck and can accommodate the chuck's mass and mounting requirements. How much clamping force does the chuck provide? The chuck delivers a clamping force of 1,800 kgf, which is designed to hold components securely during demanding turning operations. Does the low-profile design affect accessibility? Yes, the extra-flat design shortens the spindle-to-workpiece distance, improving tool access and reducing overhang compared with taller chuck designs. Is the chuck balanced for high-speed use? The VNBK-6 is built for stable rotation; balancing requirements depend on the specific machine and operating speeds, and final balancing is recommended according to the lathe manufacturer's guidance. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
248mm Universal Centre Punch Self-Centering, Accuracy 0.005mm, 1500r.p.m. - Vertex
Take advantage of a robust alloy steel construction combined with 0.005 mm repeat accuracy and a reliable revolving tip for consistent centring. Order the part directly via Metav Werkzeuge or consult the team for application advice. Universal revolving centre VPC‑MT5 — rotating live centre in alloy steel, 1500 r.p.m. The Universal revolving centre VPC‑MT5 is a rotating live centre designed for general lathe centring, offering precision repeatability and durable alloy‑steel construction for workshop and light industrial use. Alloy steel construction for longevity Repeat accuracy of 0.005 mm Safe operation up to 1500 r.p.m. Length 248 mm, sturdy 3.2 kg Consistent centring for repeatable results The VPC‑MT5 delivers repeatable accuracy of 0.005 mm, which reduces rework and shortens setup cycles on turning operations. This level of precision is achieved through a balanced rotating tip and a rigid body made from alloy steel, ensuring stable contact with the workpiece under normal lathe speeds. By specifying a measured repeatability rather than marketing estimates, the centre provides a verifiable basis for quality control and process planning, supporting predictable outcomes in series production and precision repairs. Built for workshop reliability and safe operation Designed for continuous rotation up to 1500 r.p.m., the revolving tip minimises friction and heat build‑up during turning, which helps protect both the workpiece and the lathe spindle. The solid construction and a length of 248 mm, combined with a mass of 3.2 kg, ensure mechanical stability during centring tasks. These characteristics translate into longer component life, fewer interruptions for maintenance and a lower risk of run‑out; the result is a more economical machining process and less downtime for the workshop. Straightforward integration and practical benefits As a universal live centre, the VPC‑MT5 is suitable for a wide range of standard lathe centring tasks where a revolving centre is required. The robust alloy‑steel body withstands regular handling in busy environments and supports reliable operation over many cycles. Clear technical data such as GTIN 4061905088018, length and measured accuracy enable easier procurement, traceability and inclusion in quality documentation. For teams planning tool inventories or upgrading centre tooling, the combination of precision, durability and known speed limits simplifies specification decisions and aligns with standard workshop requirements. Contact Metav Werkzeuge for purchase or technical guidance on the VPC‑MT5 and receive expert advice from the Emmerich team. Technical Data Article number: VPC-MT5 GTIN: 4061905088018 Material: legierter Stahl Length: 248 mm Weight: 3.2 kg Numbers / Facts Repeat accuracy: 0.005 mm Maximum speed: 1500 r.p.m. eClass: 21022304 SKU: VPC-MT5 Special features / Versions Universal revolving centre (mitlaufend) Alloy steel construction Designed for lathe centring applications FAQ What maximum rotational speed is recommended? The VPC‑MT5 is specified for operation up to 1500 r.p.m., which supports common turning speeds while maintaining designed repeatability. How precise is the centring performance? The universal revolving centre provides a repeat accuracy of 0.005 mm, making it suitable for precision centring tasks requiring consistent results. What are the main dimensions and weight of the unit? The VPC‑MT5 has a length of 248 mm and a mass of 3.2 kg, dimensions that favour stability on standard lathe setups. Which material is the tool made from? The centre body is manufactured from alloy steel, selected for durability and wear resistance in workshop conditions. How is the product identified for ordering and traceability? Order and identify the item by SKU VPC‑MT5 or GTIN 4061905088018 for procurement and inventory purposes. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
250mm Four-Jaw Independent Chuck, 4 T-Slots M12, 1,100 rpm - Vertex
Robust independent clamping with a 250 mm jaw span and a maximum speed of 1,100 r.p.m. delivers stable, precise workholding for varied turning operations; secure the unit from Metav Werkzeuge for reliable supply or speak with our consultants for application advice. VKC-10 Independent Four-Jaw Chuck, Ø250 mm, Vertex The VKC-10 independent four-jaw chuck for lathe applications provides flexible, accurate clamping of irregular and prismatic workpieces in workshop and light industrial use Independent jaw operation for irregular parts Ø250 mm nominal chuck diameter Max speed 1,100 r.p.m. for standard lathes T-slots 4-M12 for secure mounting Faster set-ups through adjustable jaws The independent jaws allow each jaw to be positioned separately, which reduces time spent fitting off-centre or odd-shaped stock and supports quick, incremental alignment. This approach increases process efficiency by removing the need for bespoke fixtures for every non-cylindrical component. The feature improves throughput where repeat clamping accuracy and adaptability are required, while the robust design contributes to consistent repeatability across batches. Stable performance for everyday workshop demands Built to provide a solid interface between machine spindle and workpiece, the chuck’s Ø250 mm diameter and overall mass yield improved stability during machining. The specified 1,100 r.p.m. maximum speed is suitable for a broad range of turning operations on standard lathes, balancing cutting performance and safe rotational limits. Integration with existing setups is simplified by the T-slots 4‑M12, which permit positive, repeatable mounting and reduce vibration for cleaner surface finishes and longer tool life. Versatility that reduces tooling complexity Independent clamping means one device handles a wider variety of geometries, from asymmetric castings to square bar, decreasing the requirement for multiple dedicated fixtures. The design supports stepwise jaw adjustment and controlled clamping pressure, which helps protect delicate faces while ensuring secure holding for more aggressive cuts. As a result, workshops achieve greater flexibility without sacrificing process control. Contact Metav Werkzeuge in Emmerich to discuss specifying the Vertex VKC-10 independent four-jaw chuck for stable, adaptable clamping and dependable delivery from our European warehouse Technical Data Article number: VKC-10 GTIN: 4061905086267 Manufacturer: Vertex Core specifications Diameter: 250 mm Max speed: 1,100 r.p.m. Weight: 21.8 kg Special features Independent four-jaw configuration T-slots 4-M12 SKU: VKC-10 FAQ How does an independent four-jaw chuck differ from a self‑centering chuck? An independent four-jaw chuck allows each jaw to be adjusted separately, while a self‑centering chuck moves all jaws simultaneously; the VKC-10 independent four-jaw chuck by Vertex therefore enables precise off‑centre clamping for irregular workpieces. What maximum spindle speed is recommended for the VKC-10? The VKC-10 is specified for a maximum of 1,100 r.p.m., matching common lathe speeds where stability and safe clamping are priorities. Can the VKC-10 be mounted on standard lathe spindles? Yes, the VKC-10 features mounting provisions and T-slots 4‑M12 to facilitate secure attachment to compatible spindle mounts or backplates. Is the VKC-10 suitable for holding asymmetric or square stock? The independent jaw operation of the VKC-10 is specifically intended for irregular and prismatic stock, offering controlled and repeatable clamping for such geometries. What identifiers should be quoted when ordering this chuck? Please reference the Vertex VKC-10 independent four-jaw chuck and the SKU VKC-10 or GTIN 4061905086267 when enquiring or ordering. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
250x310x122mm Self-Centring Four-Jaw Square Chuck, 1800 kgf Clamping Force - Vertex
Take advantage of the combination of self‑centring four‑jaw clamping, a 1,800 kgf clamping force and dependable repeatability of 0.03 mm for stable machining and consistent results; order the unit directly via Metav Werkzeuge or consult the Metav team for application advice. VMJ-10 Clamping Chuck – 4‑jaw Self‑centring, Square Jaws by Vertex A VMJ-10 clamping chuck designed for heavy‑duty machining, offering precise self‑centring gripping of square and irregular stock for reliable production use Four‑jaw self‑centring design 1,800 kgf clamping force High repeatability: 0.03 mm Robust build, 36.1 kg mass Precise repeatability that stabilises machining results The chuck provides high repeatability, specified at 0.03 mm, which translates into consistent part positioning across repeated setups. This level of precision reduces scrap rates and supports tight tolerance work. The self‑centring mechanism ensures that concentricity is achieved quickly, which shortens setup time compared with manual centring methods. For production environments where cycle‑to‑cycle consistency is required, the combination of mechanical repeatability and a rigid jaw system ensures reproducible clamping without complex adjustments. Secure gripping for square and irregular stock Equipped with square jaws in a four‑jaw arrangement, this workholding solution delivers stable contact on flat‑sided components and improved grip on non‑cylindrical pieces. The specified 1,800 kgf clamping force provides the necessary holding power for demanding cuts and interrupted machining, improving operator confidence in process stability. The square‑jaw format positions the part firmly and resists rotation under load, which benefits milling, drilling and turning operations that impose lateral cutting forces. Compact footprint and robust construction for workshop integration With overall dimensions of 250 x 310 x 122 mm and a mass of 36.1 kg, the chuck offers a compact footprint combined with sufficient inertia to damp vibrations during machining. The robust construction supports heavy‑duty use and contributes to repeatable results across shifts. The physical size and mass also make the unit straightforward to integrate into existing fixtures or lathe spindles where space is constrained. Clear dimensional data enables planners to verify compatibility with machine interfaces before procurement. For machine shops requiring dependable heavy‑duty workholding, contact Metav Werkzeuge in Emmerich to discuss the Vertex VMJ‑10 clamping chuck and receive tailored application advice; Metav’s specialists can provide further technical details and supply options. Technical data Article number: VMJ-10 GTIN: 4061905085376 Brand: Vertex Type: Clamping chuck, 4‑jaw, square, self‑centring Dimensions: 250 x 310 x 122 mm Weight: 36.1 kg Repeatability: 0.03 mm Clamping force: 1,800 kgf Facts Repeatability / accuracy: 0.03 mm Clamping force: 1,800 kgf Mass: 36.1 kg Footprint (L x W x H): 250 x 310 x 122 mm Special features Four‑jaw, self‑centring mechanism Square jaws for flat or square stock SKU: VMJ-10 GTIN: 4061905085376 FAQ What is the declared repeatability of the chuck? The declared repeatability is 0.03 mm for the Vertex VMJ‑10 clamping chuck, which supports consistent positioning for precision machining. Can the chuck handle heavy cutting forces? Yes, the VMJ‑10 offers a clamping force of 1,800 kgf, providing secure grip for operations that generate substantial lateral or axial loads. Is the jaw format suitable for square stock? The square jaws are specifically designed to hold flat or square workpieces securely, improving resistance to rotation during machining. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
