50mm Dial Indicator, Tolerance Marks, ISO 17025 Calibrated, 0.01mm Resolution - Microtech Metrology

Take advantage of the combination of precise readout, factory calibration and easy limit checks to keep inspection routines efficient and reproducible — the gauge is factory‑calibrated to ISO 17025, offers 0.01 mm resolution across a 0–50 mm span and features clear tolerance marks for rapid go/no‑go assessment. Order the instrument directly via Metav Werkzeuge or ask our consultants for application advice.

Microtech dial indicator 0–50 mm, Ø60 mm dial, ISO 17025 calibrated

The dial indicator for comparative, runout and setup measurements in workshop and inspection environments

• 0.01 mm resolution for fine readings
• 0–50 mm measuring range, Ø60 mm dial
• Delivered with ISO 17025 calibration certificate
• Tolerance marks for fast limit checks

Precision where visual clarity speeds decisions

This analogue measuring instrument delivers a fine 0.01 mm graduation and a stated accuracy of ±0.035 mm, permitting reliable comparative and runout measurements on small to medium components. The 60 mm dial combines legibility with a compact footprint so readings are quick and less error‑prone during repetitive tasks. The measurement span of 0–50 mm covers routine inspection work and many assembly checks; the robust mechanical movement gives a tactile feel that experienced technicians trust for repeatable results.

Faster inspection with integrated tolerance marks and proven calibration

Clear tolerance marks on the dial enable immediate go/no‑go evaluation without additional templates, reducing inspection time on the shop floor. The instrument is supplied fully calibrated to ISO 17025, and a traceable calibration certificate is included, which supports quality documentation and audit trails. This combination of marked limits and accredited calibration helps to integrate the gauge smoothly into formal quality systems and keeps measurement uncertainty transparent.

Designed for everyday workshop and metrology tasks

The analogue mechanism is suited to comparative checks, height bench work and spindle runout inspection in toolrooms and maintenance departments. Readings are taken visually from the large dial and transferred to process documentation or spot checks; the scale and movement are engineered for stable performance during frequent use. For tasks that require quick alignment or verification, the gauge provides a reliable, low‑complexity solution compared with more complex digital systems.

Durable construction for continuous use in inspection environments

Manufactured by Microtech Metrology, the indicator combines a sturdy case with a precise movement to withstand normal workshop handling. The mechanical design minimises drift and provides consistent index behaviour over repeated cycles. Where reproducibility and documented accuracy are required, this instrument fits into a practical measuring set‑up and supports both routine QC and sporadic troubleshooting without special training.

Contact Metav Werkzeuge for purchasing advice and delivery from our Emmerich stock — technical consultants can confirm fit‑for‑purpose use and arrange supply with the included ISO 17025 calibration certificate

Technical Data

• Article number: 120121500
• GTIN: 4061905451805
• Manufacturer: Microtech Metrology

Facts

• Measuring range: 0–50 mm
• Resolution: 0.01 mm
• Accuracy: ±0.035 mm
• Dial diameter: 60 mm

Special features

• Analogue dial indicator
• Tolerance marks on dial
• Delivered calibrated to ISO 17025 with certificate
• Suitable for runout, comparative and height measurements

FAQ

Is the indicator delivered calibrated?
Yes. The Microtech dial indicator is supplied fully calibrated to ISO 17025 and includes a calibration certificate with the delivery.

What is the smallest readable increment on the dial?
The instrument provides a reading increment of 0.01 mm, allowing fine comparative and adjustment work.

Can this gauge be used for spindle runout and bearing checks?
Yes. The design and accuracy of this dial indicator make it suitable for runout, bearing and alignment checks in maintenance and inspection tasks.

How is the dial marked for limit checks?
The dial includes tolerance marks for quick visual go/no‑go assessment, speeding up repetitive inspection routines.

Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
