20 mm Digital Depth Gauge With 25 mm Stop, 1.5 mm Probe, Preset And Reversible Direction - Metav IndustryLine

Benefit from precise depth checks with the compact design and intuitive digital readout: 0.02 mm accuracy and a Ø1.5 mm measuring pin ensure reproducible results in small bores, while the preset and reversible measuring direction increases inspection speed. Order the M301.053.4 directly via Metav Werkzeuge or consult our specialists for application advice.

Digital depth gauge M301.053.4 — compact digital depth gauge, 20 mm range, Ø1.5 mm probe (Metav IndustryLine)

The Digital depth gauge M301.053.4 is a compact digital instrument for exact depth measurements in small bores and recesses, combining a clear digital display with a robust 25 mm measuring stop.

Digital readout with 0.02 mm accuracy
20 mm depth range, Ø1.5 mm probe
Preset and reversible measuring direction
Robust 25 mm measuring stop

Accurate results where small tolerances matter

This instrument delivers 0.02 mm accuracy on a 20 mm measuring range, making it suitable for fine mechanical and small-component inspection. The digital display with a 0.01 mm resolution provides an immediate numeric result, reducing reading errors compared with analogue dials. The Ø1.5 mm measuring pin is engineered to enter narrow bores reliably; its slim profile minimises contact area and helps maintain repeatable measurements. For quality-controlled production, this combination of compact range and fine accuracy shortens inspection cycles while keeping measurement uncertainty low.

Faster routine checks and fewer handling errors

The preset function and reversible measuring direction simplify repetitive tasks: zero can be set quickly and direction inverted to match workpiece orientation, which accelerates batch testing and reduces handling mistakes. A 25 mm measuring stop provides a positive mechanical reference for consistent placement against shoulders and countersinks. The instrument’s compact form and a net weight of 0.62 kg support comfortable single‑hand operation, lowering operator fatigue during repeated checks and improving throughput on the shop floor.

Designed for small bores and everyday workshop use

Classified in the micro range (max. 10–100 mm), this depth gauge is aimed at precision tasks on small components—ideal for toolmaking, watchmaking, precision assemblies and inspection of mating features. The slender probe and short measuring span make it straightforward to use in confined spaces where full-length depth gauges are impractical. The clear numeric readout and preset capability mean less interpretation and faster decision-making during first-article inspections and routine quality checks.

Practical advantages for production and inspection

The gauge is fitted with a purpose-designed measuring insert (Ø1.5 mm × 20 mm) that is durable and suited to repeated entry into small holes. The device’s digital measurement eliminates parallax and non-linearity typical of analogue instruments, while the reversible measurement direction adapts to different fixturing and measurement approaches. Together, these features support a lean inspection routine that preserves traceability and helps maintain consistent quality across production batches.

Contact Metav Werkzeuge in Emmerich for application guidance or to request the M301.053.4; call +49 2822 7131930 or eMail info@metav-werkzeuge.com to discuss suitability for specific parts and inspection procedures

Technical data

• Article number: M301.053.4
• GTIN: 4054469184609
• Manufacturer: Metav IndustryLine
• Eclass: 21170308
• Net weight: 0.62 kg

Numbers / Core technical data

• Measuring range: 0–20 mm
• Resolution (display): 0.01 mm
• Accuracy: ±0.02 mm
• Measuring pin: Ø 1.5 mm × 20 mm
• Measuring stop: 25 mm

Special features / Versions

• Digital instrument
• Preset function
• Reversible measuring direction
• Compact design for small bores
• Ready for immediate use

FAQ

How precise is the measurement on this depth gauge?
The M301.053.4 achieves an accuracy of ±0.02 mm with a 0.01 mm display resolution, making it suitable for fine depth checks and repeatable quality control.

Can the measuring direction be changed during an inspection?
Yes, the instrument includes a reversible measuring direction so the measuring motion can be inverted to suit different fixturing and workpiece orientations.

Is the probe suitable for very small bores?
The supplied measuring pin is Ø1.5 mm and designed for narrow holes and recesses, enabling reliable depth readings in confined geometries.

Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
