7.5-15mm Radius Gauge Set Concave And Convex Leaves, Werk Standard - Metav IndustryLine

Take advantage of precise profile verification, a practical 7.5–15.0 mm measurement range and robust carbon steel construction to speed up routine inspections. Order the set directly via Metav Werkzeuge or consult the team for application advice.

Metav IndustryLine Radius gauge set M318.006 — 7.5–15.0 mm, concave & convex

The Radius gauge set M318.006 is a compact verification aid for fast comparison of small radii on workpieces, jigs and finished edges in workshop and inspection environments.

• Concave and convex profiles for versatile checks
• Measurement range 7.5–15.0 mm
• Robust carbon steel construction
• Rapid tactile profile verification

Fast, reliable profile checks for small radii

The set supports immediate visual and tactile comparison to control edge radii without lengthy set-ups. By matching a workpiece to the appropriate concave or convex leaf, users achieve repeatable results for small radii from 7.5–15.0 mm, reducing inspection time and limiting rework. This method is particularly efficient where a simple go/no-go decision is required: the calibrated profile either seats cleanly or it does not. The compact design and rigid leaves ensure consistent contact and a dependable reference for quick quality checks.

Built for routine workshop use with solid materials

Manufactured from carbon steel, the leaves withstand frequent handling and contact with machined edges while maintaining profile integrity. The material choice balances durability and cost-effectiveness for everyday use in toolrooms and production inspection stations. Where a robust physical reference is needed for quick checks during set-up or final inspection, the sturdy construction delivers long service life and consistent precision under normal workshop conditions.

Easy to integrate into existing inspection routines

Delivered to a factory standard, the set is intended for straightforward inclusion in quality-control workflows. The collection of shaped leaves covers incrementally spaced radii for systematic sampling across a component’s edges and transitions. Used alongside calipers or optical checks, the gauges offer a fast first-pass assessment that saves time and resources. For specialised applications or integration into a formal inspection plan, Metav Werkzeuge provides further specification support and advice to align the tool with existing procedures.

For ordering, specification queries or application guidance for the Metav IndustryLine radius gauge set, contact Metav Werkzeuge in Emmerich via info@metav-werkzeuge.com or +49 2822 7131930 for prompt expert assistance

Technical data

• SKU: M318.006
• GTIN: 4054469127613
• ECLASS: 21170203
• Standard: factory standard

Facts

• Measurement range: 7.5–15.0 mm
• Range min: 7.5 mm
• Range max: 15.0 mm
• Tariff number: 90173000

Special features

• Profiles: concave and convex gauges
• Material: carbon steel
• Application: quick profile verification in workshop and inspection

FAQ

How is the set used to check radii on a component?
The leaves are placed against the edge or profile; a correct match shows full contact. The radius gauge set M318.006 allows rapid go/no-go checks without complex set-up.

What measurement range does the set cover?
The collection spans a 7.5–15.0 mm range to inspect small radii typically found on machined parts, tool edges and formed components.

What material are the gauges made from and what does that mean for use?
Leaves are fabricated from carbon steel, offering robust contact performance for routine inspection tasks while providing long-term profile stability under normal workshop conditions.

Is the set suitable for precision inspection in a quality department?
The set serves as a fast comparative reference under the factory standard and is ideal for initial verification and process control; for traceable metrological records, complement the set with calibrated measuring equipment.

Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
