Durable indexable inserts for efficient metalcutting
Indexable inserts are hardened cutting elements designed to deliver consistent material removal in metalworking, providing cost-effective tool life management and repeatable results for turning, milling and drilling operations. Suited for machining steel, stainless and heat-resistant alloys, these inserts offer rapid edge renewal and reduced downtime through simple indexing, while versions optimised for internal coolant significantly improve chip control and thermal management in demanding applications. By choosing the right insert grade and geometry you gain improved tool life, predictable wear behaviour and better surface finish thanks to enhanced chip control, with key benefits including wear-resistant carbide, internal coolant compatibility and reliable chip breaking.
CCGW 09T302 Indexable Insert for Aluminium - MetavCUT
Areyou not sure whether this tool fulfils your requirements? Or do you need additional technical data?No problem - we will be happy to help you ✔️ WhatsApp: +49 170 2837271, 📧 eMail: info@metav-werkzeuge.com, ☎️ Phone: +49 2822 7131930 Product features indexable inserts CCGW 09T302 from MetavCUT Brand: MetavCUT Manufacturer Order Number: CCGW09T302-Aluminium Dataand Figures: ISO-Code: CCGW09T302 Clearance Angle: 7° Angle: 80° Thickness: 3,97mm Radius: 0.2 Special features Material: cemented carbide Usage for: Aluminium with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Form: rhombic Chip Breaker: without Manufacturer: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; www.metav-shop.de; info@metav-werkzeuge.com 40START indexable-inserts-CCGW-09T302-Aluminium-MetavCUT 40END
CCGW 09T302 Indexable Insert for Stahl - MetavCUT
Are you unsure whether the tool is suitable for your application? Or are you still missing technical data?No problem, just contact us!!! 📧 eMail: info@metav-werkzeuge.com ☎️ Phone: +49 2822 7131930 ✔️ WhatsApp: +49 170 2837271 Product characteristics indexable inserts CCGW 09T302 from MetavCUT Brand: MetavCUT Manufacturer Order Number: CCGW09T302-Steel Dataand Figures: ISO-Code: CCGW09T302 Clearance Angle: 7° Angle: 80° Thickness: 3,97mm Radius: 0.2 Features Material: cemented carbide Usage for: Steel with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Form: rhombic Chip Breaker: without Manufacturer: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; www.metav-shop.de; info@metav-werkzeuge.com 40START indexable-inserts-CCGW-09T302-Stahl-MetavCUT 40END
CCGW 09T302 Indexable Insert for Stainless Steel - MetavCUT
Unsure whether the tool is the right one? Or are you missing technical data?Just get in touch with us! ✔️ WhatsApp: +49 170 2837271, 📧 eMail: info@metav-werkzeuge.com, ☎️ Phone: +49 2822 7131930 Information on technical features for indexable inserts CCGW 09T302 from MetavCUT Brand: MetavCUT Manufacturer Order Number: CCGW09T302-Stainless Facts / Figures: ISO-Code: CCGW09T302 Clearance Angle: 7° Angle: 80° Thickness: 3,97mm Radius: 0.2 Features Material: cemented carbide Usage for: Stainless steel with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Form: rhombic Chip Breaker: without Manufacturer: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; www.metav-shop.de; info@metav-werkzeuge.com 40START indexable-inserts-CCGW-09T302-Stainless Steel-MetavCUT 40END
CCGW 09T302 KBH10 Indexable Insert - Kennametal
Not sure whether this tool is suitable for your application? Or are you still missing important technical details? No problem!Contact us - we will be happy to advise you. 📧 eMail: info@metav-werkzeuge.com, ☎️ Phone: +49 2822 7131930, ✔️ WhatsApp: +49 170 2837271 Product specifications CCGW 09T302 indexable inserts from Kennametal Brand: Kennametal Manufacturer Order Number: CCGW09T302S01015MT-KBH10-KENNAMETAL ISO-Code: CCGW09T302 Grade: KBH10 Material: cemented carbide Form: rhombic Clearance Angle: 7° with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Thickness: 3,97mm Radius: 0.2 Chip Breaker: without Angle: 80° Manufacturer: Kennametal; 600 Grant Street, Suite 5100, Pittsburgh, PA 15219, USA; www.kennametal.com; ftmill.service@kennametal.com Brand names and registered trademarks are the property of their rightful owners. The mention of protected trademarks and trade names is for illustrative purposes only. There is no connection whatsoever between our company and the brands mentioned. This is a brand new original product of the leading brand Kennametal. 40START indexable-inserts-CCGW-09T302-KBH10-Kennametal 40END
CCGW 09T302 KBH20 Indexable Insert - Kennametal
Unsure whether the tool is the right one? Or are you missing technical data?Just get in touch with us! 📧 eMail: info@metav-werkzeuge.com, ☎️ Phone: +49 2822 7131930, ✔️ WhatsApp: +49 170 2837271 Design details CCGW 09T302 indexable inserts from Kennametal Brand: Kennametal Manufacturer Order Number: CCGW09T302S01225MT-KBH20-KENNAMETAL Figures for the tool: ISO-Code: CCGW09T302 Clearance Angle: 7° Angle: 80° Thickness: 3,97mm Radius: 0.2 Features Material: cemented carbide Grade: KBH20 with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Form: rhombic Chip Breaker: without Manufacturer: Kennametal; 600 Grant Street, Suite 5100, Pittsburgh, PA 15219, USA; www.kennametal.com; ftmill.service@kennametal.com Brand names and registered trademarks are the property of their rightful owners. The mention of brands and registered trademarks is for descriptive purposes only. There is no connection whatsoever between our company and the brands mentioned. The items offered are original, brand-new goods of the Kennametal brand. 40START indexable-inserts-CCGW-09T302-KBH20-Kennametal 40END
CCGW 09T304 7015 Indexable Insert - Sandvik
Unsure whether the tool is the right one? Or are you missing technical data?Just get in touch with us! 📧 eMail: info@metav-werkzeuge.com, ✔️ WhatsApp: +49 170 2837271, ☎️ Phone: +49 2822 7131930 Information on technical features CCGW 09T304 indexable inserts from Sandvik Brand: Sandvik Manufacturer Order Number: CCGW09T304S01020F7015-SANDVIK Dataand Figures: ISO-Code: CCGW09T304 Clearance Angle: 7° Thickness: 3,97mm Radius: 0.4 Special features Material: cemented carbide Grade: 7015 with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Form: rhombic Chip Breaker: without Manufacturer: Brand names and protected trademarks are the property of their respective owners. The inclusion of registered trademarks and trade names is for illustrative purposes only. Our company has no commercial, legal or other connection with the brands concerned. This is a brand new original product of the leading brand Sandvik. 40START indexable-inserts-CCGW-09T304-7015-Sandvik 40END
CCGW 09T304 7015 Indexable Insert - Sandvik
Areyou not sure whether this tool fulfils your requirements? Or do you need additional technical data?No problem - we will be happy to help you 📧 eMail: info@metav-werkzeuge.com, ☎️ Phone: +49 2822 7131930, ✔️ WhatsApp: +49 170 2837271 Information on technical features for insert CCGW 09T304 from Sandvik Brand: Sandvik Manufacturer Order Number: CCGW09T304S01530F7015-SANDVIK Facts and Figures: ISO-Code: CCGW09T304 Clearance Angle: 7° Thickness: 3,97mm Radius: 0.4 Special features Material: cemented carbide Grade: 7015 with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Form: rhombic Chip Breaker: without Manufacturer: Brand names and registered trademarks are the property of their respective owners. The indication of brand names and trademarks is for information purposes only. Named brands are in no way associated or co-operate with our company. This is a brand new original product of the leading brand Sandvik. 40START indexable-inserts-CCGW-09T304-7015-Sandvik 40END
CCGW 09T304 7015 Indexable Insert - Sandvik
Areyou not sure whether this tool fulfils your requirements? Or do you need additional technical data?No problem - we will be happy to help you 📧 eMail: info@metav-werkzeuge.com, ☎️ Phone: +49 2822 7131930, ✔️ WhatsApp: +49 170 2837271 Information on technical features for indexable inserts CCGW 09T304 from Sandvik Brand: Sandvik Manufacturer Order Number: CCGW09T304T01020FWH7015-SANDVIK Figures for the tool: ISO-Code: CCGW09T304 Clearance Angle: 7° Thickness: 3,97mm Radius: 0.4 Special features Material: cemented carbide Grade: 7015 with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Form: rhombic Chip Breaker: without Manufacturer: Registered trademarks and trade names are the property of their respective owners. The mention of brands and registered trademarks is for descriptive purposes only. The brands mentioned are not in any contractual relationship with our company. The article presented is a brand-new original product of the Sandvik brand. 40START indexable-inserts-CCGW-09T304-7015-Sandvik 40END
CCGW 09T304 7105 Indexable Insert - Sandvik
Unsure whether the tool is the right one? Or are you missing technical data?Just get in touch with us! ☎️ Phone: +49 2822 7131930 📧 eMail: info@metav-werkzeuge.com ✔️ WhatsApp: +49 170 2837271 Product specifications indexable inserts CCGW 09T304 from Sandvik Brand: Sandvik Manufacturer Order Number: CCGW09T304S01020F7105-SANDVIK Data/ Figures: ISO-Code: CCGW09T304 Clearance Angle: 7° Thickness: 3,97mm Radius: 0.4 Special features Material: cemented carbide Grade: 7105 with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Form: rhombic Chip Breaker: without Manufacturer: The rights to brand names and registered trademarks are held by their rightful owners. The mention of brands and registered trademarks is for descriptive purposes only. The brands mentioned are not in any contractual relationship with our company. The items offered are original, brand-new goods of the Sandvik brand. 40START indexable-inserts-CCGW-09T304-7105-Sandvik 40END
CCGW 09T304 7105 Indexable Insert - Sandvik
Are you unsure whether the tool is suitable for your application? Or do you need further technical information?No problem - feel free to contact us! 📧 eMail: info@metav-werkzeuge.com, ☎️ Phone: +49 2822 7131930, ✔️ WhatsApp: +49 170 2837271 Product specifications CCGW 09T304 indexable inserts from Sandvik Brand: Sandvik Manufacturer Order Number: CCGW09T304S01520FWG7105-SANDVIK Facts for the tool: ISO-Code: CCGW09T304 Clearance Angle: 7° Thickness: 3,97mm Radius: 0.4 Features Material: cemented carbide Grade: 7105 with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Form: rhombic Chip Breaker: without Manufacturer: Registered trademarks and trade names are the property of their respective owners. The designation of brand names and trademarks is for explanatory purposes only. Our company has no commercial, legal or other connection with the brands concerned. The article presented is a brand-new original product of the Sandvik brand. 40START indexable-inserts-CCGW-09T304-7105-Sandvik 40END
CCGW 09T304 7105 Indexable Insert - Sandvik
Didn't find the right insert in our selection? No problem, we are at your side!► Send us a photo of your insert directly by email► Send us your drawing by e-mail.► Send us your sample insert or drawing by post. Performance features CCGW 09T304 indexable inserts from Sandvik Brand: Sandvik Manufacturer Order Number: CCGW09T304S01520FWH7105-SANDVIK Figures for the tool: ISO-Code: CCGW09T304 Clearance Angle: 7° Thickness: 3,97mm Radius: 0.4 Special features Material: cemented carbide Grade: 7105 with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Form: rhombic Chip Breaker: without Manufacturer: Brand names and registered trademarks are the property of their rightful owners. Brand names and protected trademarks are mentioned solely for explanatory purposes. There is no connection whatsoever between our company and the brands mentioned. The items offered are original, brand-new goods of the Sandvik brand. 40START indexable-inserts-CCGW-09T304-7105-Sandvik 40END
CCGW 09T304 7115 Indexable Insert - Sandvik
Not sure whether this tool is suitable for your application? Or are you still missing important technical details? No problem!Contact us - we will be happy to advise you. 📧 eMail: info@metav-werkzeuge.com, ☎️ Phone: +49 2822 7131930, ✔️ WhatsApp: +49 170 2837271 Information on technical features for indexable inserts CCGW 09T304 from Sandvik Brand: Sandvik Manufacturer Order Number: CCGW09T304S01020F7115-SANDVIK ISO-Code: CCGW09T304 Grade: 7115 Material: cemented carbide Form: rhombic Clearance Angle: 7° with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Thickness: 3,97mm Radius: 0.4 Chip Breaker: without Manufacturer: Brand names and registered trademarks are the property of their respective owners. The indication of brand names and trademarks is for information purposes only. There is no connection whatsoever between our company and the brands mentioned. The items offered are original, brand-new goods of the Sandvik brand. 40START indexable-inserts-CCGW-09T304-7115-Sandvik 40END
CCGW 09T304 7115 Indexable Insert - Sandvik
Unsure whether the tool is the right one? Or are you missing technical data?Just get in touch with us! 📧 eMail: info@metav-werkzeuge.com ☎️ Phone: +49 2822 7131930 ✔️ WhatsApp: +49 170 2837271 Features for insert CCGW 09T304 from Sandvik Brand: Sandvik Manufacturer Order Number: CCGW09T304S01520FWG7115-SANDVIK Figures for the tool: ISO-Code: CCGW09T304 Clearance Angle: 7° Thickness: 3,97mm Radius: 0.4 Features Material: cemented carbide Grade: 7115 with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Form: rhombic Chip Breaker: without Manufacturer: Registered trademarks and trade names are the property of their respective owners. The naming of brand names and protected trademarks is for descriptive purposes only. Our company has no commercial, legal or other connection with the brands concerned. The article presented is a brand-new original product of the Sandvik brand. 40START indexable-inserts-CCGW-09T304-7115-Sandvik 40END
CCGW 09T304 7115 Indexable Insert - Sandvik
Unsure whether the tool is the right one? Or are you missing technical data?Just get in touch with us! ☎️ Phone: +49 2822 7131930 📧 eMail: info@metav-werkzeuge.com ✔️ WhatsApp: +49 170 2837271 Technical data for indexable inserts CCGW 09T304 from Sandvik Brand: Sandvik Manufacturer Order Number: CCGW09T304S01520FWH7115-SANDVIK Facts / Figures: ISO-Code: CCGW09T304 Clearance Angle: 7° Thickness: 3,97mm Radius: 0.4 Features Material: cemented carbide Grade: 7115 with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Form: rhombic Chip Breaker: without Manufacturer: Brand names and registered trademarks are the property of their respective owners. The designation of brand names and trademarks is for explanatory purposes only. Named brands are in no way associated or co-operate with our company. The sales offer includes high-quality, new branded articles from the manufacturer Sandvik. 40START indexable-inserts-CCGW-09T304-7115-Sandvik 40END
CCGW 09T304 7115 Indexable Insert - Sandvik
Not sure whether this tool is suitable for your application? Or are you still missing important technical details? No problem!Contact us - we will be happy to advise you. 📧 eMail: info@metav-werkzeuge.com, ☎️ Phone: +49 2822 7131930, ✔️ WhatsApp: +49 170 2837271 Product details for indexable inserts CCGW 09T304 from Sandvik Brand: Sandvik Manufacturer Order Number: CCGW09T304S02030F7115-SANDVIK Facts / Figures: ISO-Code: CCGW09T304 Clearance Angle: 7° Thickness: 3,97mm Radius: 0.4 Special features Material: cemented carbide Grade: 7115 with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Form: rhombic Chip Breaker: without Manufacturer: Brand names and protected trademarks are the property of their respective owners. The indication of brand names and trademarks is for information purposes only. There is no connection whatsoever between our company and the brands mentioned. The sales offer includes high-quality, new branded articles from the manufacturer Sandvik. 40START indexable-inserts-CCGW-09T304-7115-Sandvik 40END
CCGW 09T304 7125 Indexable Insert - Sandvik
Not sure whether this tool is suitable for your application? Or are you still missing important technical details? No problem!Contact us - we will be happy to advise you. ✔️ WhatsApp: +49 170 2837271 📧 eMail: info@metav-werkzeuge.com ☎️ Phone: +49 2822 7131930 Information on technical features for CCGW 09T304 insert from Sandvik Brand: Sandvik Manufacturer Order Number: CCGW09T304S01020F7125-SANDVIK Facts and Figures: ISO-Code: CCGW09T304 Clearance Angle: 7° Thickness: 3,97mm Radius: 0.4 Features Material: cemented carbide Grade: 7125 with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Form: rhombic Chip Breaker: without Manufacturer: Ownership of brand names and protected trademarks remains with their owners. Brand names and protected trademarks are mentioned solely for explanatory purposes. Mention of the brands does not imply any relationship to our company. The article presented is a brand-new original product of the Sandvik brand. 40START indexable-inserts-CCGW-09T304-7125-Sandvik 40END
CCGW 09T304 7125 Indexable Insert - Sandvik
Not sure whether this tool is suitable for your application? Or are you still missing important technical details? No problem!Contact us - we will be happy to advise you. 📧 eMail: info@metav-werkzeuge.com, ☎️ Phone: +49 2822 7131930, ✔️ WhatsApp: +49 170 2837271 Product details CCGW 09T304 indexable inserts from Sandvik Brand: Sandvik Manufacturer Order Number: CCGW09T304S01520FWG7125-SANDVIK Figures for the tool: ISO-Code: CCGW09T304 Clearance Angle: 7° Thickness: 3,97mm Radius: 0.4 Features Material: cemented carbide Grade: 7125 with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Form: rhombic Chip Breaker: without Manufacturer: Registered brand names and trademarks are the property of their respective owners. The indication of brand names and trademarks is for information purposes only. The brands mentioned are not in any contractual relationship with our company. The items offered are original, brand-new goods of the Sandvik brand. 40START indexable-inserts-CCGW-09T304-7125-Sandvik 40END
CCGW 09T304 7125 Indexable Insert - Sandvik
Unsure whether the tool is the right one? Or are you missing technical data?Just get in touch with us! 📧 eMail: info@metav-werkzeuge.com, ☎️ Phone: +49 2822 7131930, ✔️ WhatsApp: +49 170 2837271 Technical data for CCGW 09T304 indexable inserts from Sandvik Brand: Sandvik Manufacturer Order Number: CCGW09T304S01520FWH7125-SANDVIK Facts for the tool: ISO-Code: CCGW09T304 Clearance Angle: 7° Thickness: 3,97mm Radius: 0.4 Special features Material: cemented carbide Grade: 7125 with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Form: rhombic Chip Breaker: without Manufacturer: Brand names and registered trademarks are the property of their respective owners. The mention of protected trademarks and trade names is for illustrative purposes only. Mention of the brands does not imply any relationship to our company. This is a brand new original product of the leading brand Sandvik. 40START indexable-inserts-CCGW-09T304-7125-Sandvik 40END
CCGW 09T304 7135 Indexable Insert - Sandvik
Are you unsure whether the tool is suitable for your application? Or are you still missing technical data?No problem, just contact us!!! ☎️ Phone: +49 2822 7131930, ✔️ WhatsApp: +49 170 2837271, 📧 eMail: info@metav-werkzeuge.com Specifications for insert CCGW 09T304 from Sandvik Brand: Sandvik Manufacturer Order Number: CCGW09T304S01530F7135-SANDVIK ISO-Code: CCGW09T304 Grade: 7135 Material: cemented carbide Form: rhombic Clearance Angle: 7° with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Thickness: 3,97mm Radius: 0.4 Chip Breaker: without Manufacturer: Ownership of brand names and protected trademarks remains with their owners. The designation of brand names and trademarks is for explanatory purposes only. Our company has no commercial, legal or other connection with the brands concerned. The article presented is a brand-new original product of the Sandvik brand. 40START indexable-inserts-CCGW-09T304-7135-Sandvik 40END
CCGW 09T304 CBN Indexable Insert for Cast Iron - MetavCUT
Areyou not sure whether this tool fulfils your requirements? Or do you need additional technical data?No problem - we will be happy to help you 📧 eMail: info@metav-werkzeuge.com ☎️ Phone: +49 2822 7131930 ✔️ WhatsApp: +49 170 2837271 Technical data for CCGW 09T304 indexable inserts from MetavCUT Brand: MetavCUT Manufacturer Order Number: CCGW09T304-CBN-CastIron Facts / Figures: ISO-Code: CCGW09T304 Clearance Angle: 7° Angle: 80° Thickness: 3,97mm Radius: 0.4 Features Material: CBN Usage for: Cast steel with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Form: rhombic Chip Breaker: without Manufacturer: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; www.metav-shop.de; info@metav-werkzeuge.com 40START indexable-inserts-CCGW-09T304-Cast Iron-MetavCUT 40END
CCGW 09T304 CBN Indexable Insert for Stainless Steel - MetavCUT
Are you unsure whether the tool is suitable for your application? Or are you still missing technical data?No problem, just contact us!!! 📧 eMail: info@metav-werkzeuge.com ☎️ Phone: +49 2822 7131930 ✔️ WhatsApp: +49 170 2837271 Technical data indexable inserts CCGW 09T304 from MetavCUT Brand: MetavCUT Manufacturer Order Number: CCGW09T304-CBN-Stainless Figures for the tool: ISO-Code: CCGW09T304 Clearance Angle: 7° Angle: 80° Thickness: 3,97mm Radius: 0.4 Features Material: CBN Usage for: Stainless steel with hole Hole Style: cylindrical hole + single-sided countersink (40°–60°) Form: rhombic Chip Breaker: without Manufacturer: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; www.metav-shop.de; info@metav-werkzeuge.com 40START indexable-inserts-CCGW-09T304-Stainless Steel-MetavCUT 40END
CCGW 09T304 DX140 Wendeplatten - Tungaloy
Take advantage of the combination of a DX140 PCD cutting material for high cutting speeds, a 0.4 mm corner radius for robust edge strength, and ISO compatibility for rapid tool changeovers; order the CCGW09T304 DX140 insert directly via Metav Werkzeuge or consult our technical advisors for holder matching. CCGW09T304 DX140 CCGW — Indexable Turning Insert, PCD for Turning | Tungaloy A CCGW09T304 DX140 indexable insert engineered for high-speed turning of aluminium and other non-ferrous and abrasive non-metal workpieces. PCD grade DX140 for high cutting speeds Very long tool life in abrasive materials ISO rhombic CCGW 09 form, 80° included angle 7° clearance and 0.4 mm corner radius Faster cycles with a PCD grade designed for non-ferrous alloys The insert is built around polycrystalline diamond (PCD) technology, represented here by the DX140 grade. That construction enables high cutting speeds and exceptional wear resistance when machining aluminium and other non-ferrous materials, which translates into shorter cycle times and fewer tool changes. The diamond cutting layer on a carbide substrate provides a very hard cutting edge that resists abrasive wear, resulting in a long tool life and predictable performance in production runs. ISO conformity for reliable fit and straightforward system integration Being an ISO-designated rhombic insert in the CCGW family ensures dimensional and positional conformity with standard external holders and boring bars. Compatibility is determined by shape, clearance angle, tolerance class, fastening method, size and thickness; this insert’s standardised geometry simplifies selection and reduces setup time. A complete system typically comprises the insert, a matched outer holder or boring bar, support shim/clamping kit and replacement screws, ensuring secure fastening and repeatable positioning during turning operations. Edge geometry tuned for strength and surface quality The insert features an 80° included angle, a 0.4 mm corner radius and a 7° clearance angle, which together affect cut stability and finish. The modest corner radius increases edge robustness for interrupted cuts while still supporting fine surface results on continuous passes. The 7° clearance reduces flank rubbing and heat generation. Note that this grade is supplied without a chipbreaker, so chip control must be planned via cutting parameters or external chip-control measures; selecting an appropriate chipformer and machining strategy is recommended based on workpiece material and machine stability. Robust backing and application scope for productive turning The substrate material is Hartmetall, giving the insert a stable base that supports the PCD cutting layer; the plate thickness of 3.97 mm and the size designation 09 provide rigidity for stable cutting. The insert is intended for turning applications—both external and internal—and is especially suited to abrasive non-metals in addition to aluminium and other non-ferrous metals. The cylindrical hole with single-sided countersink (40°–60°) ensures secure clamping in compatible holders, contributing to consistent finish quality and reduced rework rates. For expert advice on integrating the Tungaloy CCGW09T304 DX140 insert into existing tool systems and to confirm holder compatibility, contact Metav Werkzeuge at info@metav-werkzeuge.com or call +49 2822 7131930 — our consultants will assist with technical matching and ordering. Technical Data Article number: 6801365 Manufacturer SKU: TUN6801365 Brand: Tungaloy Model series: ISO-Drehwendeschneidplatten Name: CCGW09T304 DX140 Tungaloy-Wendeplatte Core specifications Size: 09 Plate form: rhombic Included angle: 80° Clearance (relief) angle: 7° Corner radius: 0.4 mm Plate thickness: 3.97 mm Materials & features Substrate: Hartmetall Cutting material: Polycrystalline diamond (PCD) Grade: DX140 Chipbreaker: without Hole: cylindrical hole + single-sided countersink (40°–60°) Application: Turning (external and internal) FAQ Is this insert suitable for aluminium machining? Yes. The CCGW09T304 DX140 insert uses a PCD cutting material specifically intended for aluminium and other non-ferrous materials, offering high cutting speeds and extended tool life. Can the insert be used for internal turning as well as external turning? Yes. The design and ISO form factor make the insert suitable for both external and internal turning operations when paired with the appropriate holder or boring bar. How does the absence of a chipbreaker affect machining? The DX140 insert is supplied without a chipbreaker, so chip control should be achieved through cutting parameters, tool path strategy or external chip-control devices, especially in unstable set-ups or with long continuous cuts. What does the 0.4 mm corner radius mean for finish and strength? A 0.4 mm corner radius increases edge strength for interrupted cuts and helps maintain a consistent surface finish on continuous cuts; it is a compromise between robustness and fine surface quality. Which holders are compatible with this insert? Compatibility follows ISO form and is determined by shape, relief angle, tolerance class, fastening method, size and thickness; matching holders designed for CCGW 09 inserts with a cylindrical hole and countersink are required. Manufacturer/Responsible: Tungaloy-NTK Germany GmbH, Katzbergstraße 3a, 40764 Langenfeld - Protected trademarks and product names are the property of their respective owners. Brand names and protected trademarks are mentioned solely for explanatory purposes. There is no affiliation between our company and the mentioned brands. The item offered is an original, brand-new product from the manufacturer.
CCGW 09T304 DX160 Wendeplatten - Tungaloy
Take advantage of PCD cutting performance and the DX160 grade for sustained high-speed machining and extended tool life; the rhombic ISO geometry ensures reliable compatibility with standard turning holders. Order the insert directly via Metav Werkzeuge or consult our technical advisors for application-specific setup and holder selection. CCGW 09T304 DX160 Tungaloy indexable turning insert — PCD grade for high-speed aluminium turning CCGW 09T304 DX160 Tungaloy indexable turning insert designed for high-speed external and internal turning of aluminium and non-ferrous materials. PCD grade DX160 for long tool life Optimised for aluminium and non-ferrous alloys ISO rhombic form 09 for versatile turning Central hole and countersink for secure clamping Precision for fast, repeatable aluminium machining The PCD cutting layer in the DX160 grade delivers consistently low wear when machining non-ferrous materials, translating into long tool life and fewer insert changes during batch production. On a carbide substrate, the diamond cutting edge maintains a sharp profile across long runs, which reduces downtime and improves process stability. For shops aiming to increase throughput on aluminium parts, this insert provides the high cutting speeds and abrasion resistance that support predictable cycle times without compromising surface finish. Compatibility and secure clamping for industrial setups As an ISO-series, rhombic insert in size 09, the geometry is compatible with standard turning holders when matching form, relief angle, tolerance class, fixing and thickness are observed. The central hole with a cylindrical bore and a one-sided countersink (40°–60°) ensures secure clamping and repeatable positioning in compatible toolholders. Attention to the specified 7° relief angle and the 3.97 mm thickness helps avoid improper seating; correct holder choice preserves edge life and machining accuracy, especially in interrupted cuts or less rigid setups. Practical benefits for production and tool selection Using a PCD grade tailored for aluminium and abrasive non-metals minimises built-up edge and improves surface integrity on cast and wrought non-ferrous components. The insert’s lack of a chipbreaker suits stable, continuous feeds where chip control is managed by tool geometry and process parameters. The 0.4 mm corner radius delivers a balance between edge strength and surface finish; selecting a larger radius increases robustness, whereas a smaller radius favours finer finishes. For general turning needs, this grade reduces overall tooling costs by extending service intervals and lowering scrap rates. Setup guidance and process reliability To achieve the advertised benefits, configure the turning system with a holder that matches the ISO rhombic form and the insert thickness; set cutting speeds appropriate for PCD on aluminium and ensure rigid workholding. The combination of a carbide substrate and the PCD cutting layer makes the insert particularly suitable for high-speed, high-volume applications where consistency is critical. For ambiguous cases—such as machining abrasive composites or mixed-material batches—consult machining data sheets or Metav Werkzeuge’s technical advisors to adapt feeds and speeds for optimal edge life. Contact Metav Werkzeuge for tailored recommendations on the Tungaloy CCGW 09T304 DX160 insert and holder compatibility; technical advisors are available to assist with process parameter selection and application validation. Technical Data Article number: 6801366 Manufacturer SKU: TUN6801366 SKU: 6801366-Tungaloy Model series: ISO-Drehwendeschneidplatten Label: CCGW09T304 DX160 Tungaloy-Wendeplatte Key measurements Included angle: 80° Relief angle: 7° Plate thickness: 3.97 mm Corner radius: 0.4 mm Plate size: 09 Materials & special features Substrate material: Hartmetall (carbide substrate) Cutting material: Polycrystalline diamond (PCD), grade DX160 Shape: rhombic (CCGW) Hole: with hole (central bore) Hole style: cylindrical hole + single-sided countersink (40°–60°) Chipbreaker: without Typical application: external and internal turning Suitable for: aluminium, non-ferrous metals and abrasive non-metals System requirements: ISO insert, matching holder and clamping set required FAQ What materials is this insert intended for? The CCGW 09T304 DX160 insert from Tungaloy is designed primarily for aluminium, other non-ferrous metals and abrasive non-metals, leveraging the PCD cutting edge for long life. How does the DX160 grade improve production? DX160 provides a hard, wear-resistant PCD edge that sustains high cutting speeds and extends in-service time, reducing insert changes and improving throughput for turning operations. Which holder features are required for safe use? A holder matching the rhombic ISO form, correct tolerance class, fixing method and the 3.97 mm thickness is required; the central hole and countersink ensure secure clamping when the holder is compatible. Is there a chipbreaker on this insert? This variant is supplied without a chipbreaker, making it suitable for continuous-feed turning where chip control is managed by geometry and process parameters. Can the insert be used for internal turning? Yes, the insert is suitable for both external and internal turning, provided the holder and rigidity of the setup match the application demands. Manufacturer/Responsible: Tungaloy-NTK Germany GmbH, Katzbergstraße 3a, 40764 Langenfeld - Protected trademarks and product names are the property of their respective owners. Brand names and protected trademarks are mentioned solely for explanatory purposes. There is no affiliation between our company and the mentioned brands. The item offered is an original, brand-new product from the manufacturer.
CCGW 09T304 GH110 Wendeplatten - Tungaloy
Take advantage of the combination of long tool life, ISO compatibility and stable cutting-edge performance for efficient turning operations; order or request application advice via Metav Werkzeuge. CCGW 09T304 GH110 twist insert for turning — Tungaloy The CCGW09T304 GH110 is an ISO-format indexable turning insert designed for external and internal turning, offering a balance of wear resistance and edge stability for productive metalcutting. ISO rhombic insert CCGW 09T304 GH110 0.4 mm corner radius for precise contouring 7° relief angle with 80° cutting geometry Carbide grade GH110 for wear resistance Robust carbide grade for sustained productivity The insert is manufactured from carbide and specified in the GH110 grade, which combines wear resistance with adequate toughness to maintain a stable cutting edge under continuous operation. This composition reduces edge degradation and extends service intervals, contributing to predictable cycle times and less downtime. The result is improved productivity for machining tasks where consistent surface quality and tool life are priorities. ISO-format design for straightforward tool-system integration As an ISO-format component, the insert is compatible with holders that match its form, relief angle, tolerance class, fastening method, size and thickness. This standardisation simplifies inventory management and enables rapid changeovers on the shop floor. Where exact fit is essential, matching the insert to the correct holder geometry avoids positioning errors and supports repeatable set-ups in production environments. Geometry engineered for versatile turning performance The rhombic insert form with an 80° cutting angle and 0.4 mm corner radius offers a good compromise between strength and contour fidelity, suitable for a range of finishing and semi-finishing tasks. A 7° relief helps to reduce rubbing at the flank and improves chip flow. The article is supplied without a chipbreaker, permitting selection of cutting parameters and downstream chip-control measures to suit the specific material and process stability requirements. Practical selection and application guidance Intended for turning operations, the insert supports external and internal machining when paired with the appropriate holder and clamping set. Toolset planners should consider cutting speed, feed and depth of cut together with the GH110 characteristics to exploit the grade’s balance of wear resistance and edge stability. For specific machining recommendations or to confirm compatibility with an existing holder arrangement, the Metav Werkzeuge team can provide tailored advice and technical data. For application-oriented ordering and further technical consultation on the Tungaloy GH110 insert, contact Metav Werkzeuge — info@metav-werkzeuge.com or +49 2822 7131930 — to ensure the component fits the intended turning system and process conditions Technical data Article number: 6801363 Manufacturer SKU: TUN6801363 SKU: 6801363-Tungaloy Designation: CCGW09T304 GH110 Tungaloy insert Key dimensions Size: 09 Thickness: 3.97 mm Corner radius: 0.4 mm Relief angle: 7° Cutting geometry: 80° Materials / Special features Material: carbide Grade: GH110 (Tungaloy) Shape: rhombic Chipbreaker: without chipbreaker Hole style: cylindrical hole + single-sided countersink (40°–60°) Series: ISO indexable turning inserts Application: turning FAQ What is the insert made from and which grade is used? The insert is made from carbide and specified in the GH110 grade; the GH110 formulation provides a compromise of wear resistance and edge stability suitable for productive turning. Which toolholders are compatible with this insert? Compatibility depends on holder form, relief angle, tolerance class, fastening, size and thickness; the ISO-format CCGW09T304 GH110 is intended for holders designed for CCGW 09 inserts. Does the insert include a chipbreaker? The supplied insert is without a chipbreaker, allowing process engineers to select chip-control strategies and cutting parameters that match the workpiece and machining conditions. For which turning tasks is this insert suitable? The insert is intended for external and internal turning operations where a balance of contour accuracy and tool life is required; pairing with an appropriate holder and cutting data is critical for best results. Manufacturer/Responsible: Tungaloy-NTK Germany GmbH, Katzbergstraße 3a, 40764 Langenfeld - Protected trademarks and product names are the property of their respective owners. Brand names and protected trademarks are mentioned solely for explanatory purposes. There is no affiliation between our company and the mentioned brands. The item offered is an original, brand-new product from the manufacturer.
Why indexable inserts are indispensable in modern machining
Indexable inserts, also known as cutting inserts or indexable cutting inserts, are standardised, replaceable cutting elements that mount on tool holders such as turning bits, milling cutters or drills. Made from wear-resistant materials like carbide, cermet, ceramic or other superhard grades, they carry the actual cutting edge and allow a worn corner to be rotated or flipped instead of replacing or regrinding the entire tool body.
How these inserts work and when to choose them
In everyday workshop and production settings, indexable inserts perform the direct material removal on the workpiece. Standard inserts for tool systems without internal coolant typically feature closed faces or a single central fixing hole, with heat evacuation handled by external machine nozzles. Inserts designed for systems with internal coolant are engineered to support coolant flow: they include calculated chipbreaker geometries that guide an internal coolant jet under the chip or, in specialised designs, contain sintered microchannels to direct coolant right to the cutting edge. Such coolant-compatible inserts are essential for machining heat-resistant alloys, heavy cutting operations and deep internal machining, where thermal load and chip control are critical.
Tangible benefits for production and workshop efficiency
Choosing the right indexable inserts delivers measurable operational advantages:
- Reduced downtime: faster changeover because a worn insert is simply indexed rather than the whole tool being replaced.
- Extended cutting-edge life: targeted coolant application and optimised chipbreaker design lower thermal stress and improve tool life.
- Consistent part quality: predictable cutting-edge geometry from standardised inserts maintains tolerances across batches.
- Versatility: availability in carbide, cermet, ceramic and superhard grades permits selection according to workpiece material and cutting conditions.
- Lower tooling costs over time: fewer full-tool replacements and less regrinding required.
Metav as a dependable source for inserts and tooling systems
Metav combines decades of precision expertise with a wide-ranging supply chain, positioning itself as a practical partner for industry, craft and trade. From Emmerich on the Rhine, Metav operates as a quality filter for the European market, offering more than 250,000 products and serving over 48,000 customers. For procurement teams aiming to reduce supplier count while retaining technical reliability, Metav’s assortment of indexable inserts and compatible tool holders provides a central, trustworthy solution.
Quick summary
Indexable inserts (cutting inserts or indexable cutting inserts) enable economical, repeatable material removal by allowing worn cutting edges to be indexed or replaced quickly; coolant-adapted designs further reduce thermal load and enhance chip control for demanding applications.
FAQ
What materials are indexable inserts available in?
Indexable inserts are available in wear-resistant grades such as carbide, cermet, ceramic and other superhard materials, selected according to the workpiece material and cutting conditions.
When should I choose inserts with internal coolant support?
Choose inserts designed for internal coolant when machining heat-resistant alloys, performing heavy cuts or working in deep internal features, because the coolant reduces thermal load at the cutting edge and actively improves chip breakage.
How do chipbreaker geometries affect performance?
Chipbreaker geometries on indexable inserts guide the chip flow and, when matched to an internal coolant jet, direct the coolant under the chip to control temperature and facilitate reliable chip formation, which extends edge life and stabilises machining.
Can standard inserts be used with external coolant only?
Yes; standard inserts for tool systems without internal coolant typically have closed faces or a central fixing hole and rely on external machine nozzles for heat evacuation, which is sufficient for many routine, accessible cuts.
Why source inserts through Metav?
Metav supplies a broad range of indexable inserts and tooling, backed by decades of expertise and a comprehensive European stock, making it a practical choice for consistent quality and dependable delivery.
