100mm Dial Indicator, Tip Bearing, 0.01mm Resolution, Tolerance Marks, ISO 17025 Calibrated - Microtech Metrology

Take advantage of ISO 17025 calibration, a 60 mm high‑visibility dial and 0.01 mm resolution for consistent, reproducible inspection results — ideal for laboratory and shop‑floor quality control. Order the dial indicator directly via Metav Werkzeuge or contact our consultants for tailored advice.

Dial indicator 120121990 — Analogue gauge with ISO 17025 calibration and 60 mm dial

The Dial indicator 120121990 is an analogue measurement instrument designed for precise linear displacement checks across workshop and inspection environments, with a measurement range suited to typical sub‑assemblies and components.

ISO 17025 calibrated gauge 60 mm high‑visibility dial 0.01 mm resolution Tolerance marks for quick checks

Accuracy that supports faster decisions on the production line

With a stated accuracy of ±0.04 mm and a display resolution of 0.01 mm, this analogue instrument provides a reliable balance between sensitivity and robustness. The combination of fine resolution and proven accuracy enables operators to detect small deviations during setup or final inspection, reducing rework and avoiding costly overnight production delays. The clear dial face accelerates read‑out times, which supports throughput improvements without compromising traceability.

Certified calibration for traceable quality assurance

Delivered with an ISO 17025 calibration certificate, the instrument meets rigorous laboratory standards for measurement reliability. This calibration provides documented traceability to national standards, simplifying audit preparation and process qualification. For procurement and quality engineers, the certificate removes ambiguity about measurement uncertainty and supports the creation of reproducible inspection routines across shifts and sites.

Designed for routine use and quick go/no‑go checks

The 60 mm dial and the inclusion of tolerance marks enable fast visual assessment during series inspection and setup tasks. The analogue mechanism is robust against workshop contamination and does not depend on batteries, making it suitable for repetitive checks in machining, assembly and fixture alignment. The solid feel of the gauge and straightforward mounting options help maintain stable contact pressure, enhancing measurement repeatability in everyday use.

Clear technical data explained for practical application

Rated for a measurement range of 0–100 mm, the instrument covers common inspection tasks from small components through to larger subassemblies. The analogue display provides continuous indication, which is especially useful when watching dimensional changes during adjustment or while performing manual run‑out checks. The tolerance marks act as a rapid visual aid, allowing operators to assess conformity at a glance before committing parts to subsequent processes.

Typical uses and integration into quality workflows

This analogue indicator is appropriate for incoming inspection, in‑process spot checks and tool setting where a calibrated, rugged instrument is required. It integrates easily with magnetic bases, dial stands and bespoke fixtures, forming part of a cost‑effective metrology toolkit. For teams standardising inspection across several workstations, the certified calibration and uniform performance simplify training and harmonise measurement practice across shifts.

Choose the ISO 17025‑calibrated Microtech Metrology dial indicator for reliable, documented measurements — contact Metav Werkzeuge for delivery from Emmerich and specialist application advice.

Technical data

• Article number: 120121990
• GTIN: 4061905451812
• Manufacturer: Microtech Metrology
• Type: analogue dial indicator
• Calibrated: ISO 17025 certificate included

Facts

• Measurement range: 0–100 mm
• Dial diameter: 60 mm
• Resolution: 0.01 mm
• Accuracy: ±0.04 mm
• SKU: 120121990

Special features

• With tolerance marks
• Analogue dial display
• Supplied with calibration certificate
• Suitable for shop‑floor and laboratory inspection

FAQ

What is the measurement range of this indicator?
The instrument covers a 0–100 mm measurement range, making it suitable for a wide variety of component and sub‑assembly checks.

Is the gauge delivered calibrated?
Yes, the dial indicator is supplied fully calibrated with an ISO 17025 certificate for traceable measurement results.

What resolution and accuracy can be expected?
The display resolution is 0.01 mm and the stated accuracy is ±0.04 mm, supporting reliable go/no‑go decisions and fine adjustment monitoring.

Are there visual aids for quick acceptance checks?
The dial includes tolerance marks, allowing fast visual assessment during repetitive inspections and setup operations.

Can this analogue instrument be used on the shop floor?
Yes, the robust analogue design is well suited to workshop conditions and integrates with standard stands and magnetic bases for practical use.
