6–1000mm Internal Dial Bore Gauge Set With Carbide Anvils 0.001mm Resolution, Analog - Microtech Metrology
€1,890.00
Product information "6–1000mm Internal Dial Bore Gauge Set With Carbide Anvils 0.001mm Resolution, Analog - Microtech Metrology"
Take advantage of a broad measuring range and durable carbide contact faces combined with fine analogue resolution for reliable bore inspection. With an accuracy of ±0.012 mm and a reading resolution of 0.001 mm, this set supports reproducible in‑process and inspection measurements; order directly via Metav Werkzeuge or consult our specialists for application advice.
Internal Precision Bore Gauge Set – Carbide Faces, 6–1000 mm (Microtech Metrology)
An Internal Precision Bore Gauge Set engineered for accurate internal measurements across a wide diameter range, suitable for workshop inspection and in‑line quality checks
- Wide measuring range 6–1000 mm
- Carbide measuring faces for durability
- Accuracy ±0.012 mm
- Suitable for deep bores to 2000 mm depth
Broad reach with dependable accuracy for production use
The Internal Precision Bore Gauge Set delivers a continuous measuring span from 6–1000 mm, supplied as a complete set that covers small to very large bores. The specified accuracy of ±0.012 mm provides a clear performance expectation for dimensional control during machining and assembly. For production environments where throughput and traceability matter, the combination of wide range and repeatable accuracy reduces the need for multiple specialised tools and simplifies measurement planning.
Tough carbide faces and long‑reach capability for reproducible contact
Carbide contact surfaces ensure wear resistance and stable contact at the measuring points, which is crucial when inspections are frequent or when measuring harder materials. The set’s effective reach (measuring depths reported as 60–2000 mm) enables measurements in deep bores and long sleeves while maintaining consistent contact geometry. This robustness translates into fewer recalibrations and a longer service life, supporting cost‑efficient quality routines.
Fine analogue resolution and practical workshop integration
An analogue dial arrangement with a 0.001 mm reading resolution provides tactile feedback and quick visual assessment on the shop floor, while the instrument’s analogue design keeps operation straightforward under routine conditions. The device’s characteristics suit both bench inspection and on‑machine checks, helping to catch deviations early in the process and reduce rework. Clear numeric values and proven mechanical simplicity make the tool an effective bridge between manual gauging and more automated metrology systems.
For reliable internal measurement across an extensive diameter range, contact Metav Werkzeuge to discuss delivery and practical use cases for the Microtech Metrology Internal Precision Bore Gauge Set from our Emmerich stock.
Technical Data
- SKU: 132990805
- GTIN: 4061905454080
- Manufacturer: Microtech Metrology
Facts
- Measuring range: 6–1000 mm (set)
- Measuring depth: 60–2000 mm
- Resolution (reading): 0.001 mm
- Accuracy: ±0.012 mm
Special features
- Carbide measuring faces
- Analogue dial indication
- Supplied as a set covering the full range
- Category: Fine measuring instruments
FAQ
What measuring range does the set cover? The set covers a continuous measuring range from 6 to 1000 mm, delivered as a matched set to simplify bore inspection across that diameter span.
How precise is the measurement performance? Measurement precision is specified as ±0.012 mm, with a dial reading resolution of 0.001 mm for fine indication and reproducible checks.
Are the measuring faces wear‑resistant? Yes, the instrument is fitted with carbide measuring faces designed for long service life and stable contact geometry under frequent use.
Can the gauge reach deep bores or long sleeves? The construction supports effective measuring depths in the range indicated (60–2000 mm), making it suitable for relatively deep internal features.
