28x17mm Flange With M12x1.75mm Thread, 43g - Vertex

The compact design and standard metric thread make this flange a practical choice for reliable mechanical mounting; its small footprint and low weight support streamlined assemblies and reduced component load. Order the flange directly via Metav Werkzeuge or ask our consultants for tailored advice.

Flange 4514 — M12 x 1.75 mm, 28 x 17 mm, Vertex

Flange 4514 is a compact mounting component intended for secure fastening in mechanical assemblies, offering a standard M12 x 1.75 mm thread and a small 28 x 17 mm footprint.

• Compact 28 x 17 mm flange
• Thread M12 x 1.75 for secure mounting
• Lightweight 0.043 kg reduces component load

Reliable mounting with a standard metric thread

The design focuses on dependable clamping where space and repeatability matter. With a M12 x 1.75 mm metric thread and a compact 28 x 17 mm form, the component delivers consistent engagement with standard fasteners, simplifying assembly procedures. The small footprint supports denser configurations without sacrificing stability, while the precise thread pitch ensures predictable preload and reduced risk of loosening under vibration. These characteristics translate into fewer rework cycles and improved process efficiency for production and maintenance tasks.

Practical benefits for assembly and machine uptime

A lightweight flange contributes to overall system performance by reducing moving mass and load on bearings or mounts. At 0.043 kg, this component helps lower inertia in dynamic applications and minimises added stress on adjacent parts. The standardised thread format streamlines procurement and compatibility across equipment that accepts metric fastenings, enabling fast replacement and easier inventory management. The combination of a compact form and common thread standard supports quicker assembly times and reliable clamping force retention.

Procurement and quality assurance for workshop environments

Supplied under the Vertex name and identified by SKU 4514 and GTIN 4061905090912, the component fits into organised parts logistics and traceability systems. Its concise specification aids selection in parts lists and CAD libraries, reducing time spent on part matching. Sourcing through a precision-focused partner provides an additional quality filter: consistent part dimensions and identifiable SKU information help minimise errors during procurement and support predictable production planning.

Contact Metav Werkzeuge to discuss suitability of this Vertex flange (SKU 4514) for specific assemblies or to request delivery details — eMail info@metav-werkzeuge.com or call +49 2822 7131930

Technical data

• Article number: 4514
• GTIN: 4061905090912
• Manufacturer: Vertex

Facts

• Dimensions: 28 x 17 mm
• Thread: M12 x 1.75 mm
• Weight: 0.043 kg

Special features

• Brand: Vertex
• Compact flange for mechanical mounting
• Standard metric thread for broad compatibility

FAQ

What is the thread specification of this flange?
The flange is specified with a M12 x 1.75 mm thread, allowing use with standard M12 metric fasteners.

What are the flange dimensions and how do they affect installation?
Dimensions are 28 x 17 mm; the compact size reduces required mounting space and facilitates installation in confined assemblies.

How much does the component weigh?
The flange weighs 0.043 kg, which helps to lower added mass in rotating or moving constructions.

Is the material specified for this flange?
Material is not specified in the provided product data for the flange (SKU 4514).
