25x47x59mm Step Block, Precision Machined Steel - Vertex

Take advantage of the combination of compact dimensions, reliable height support and easy integration into clamping setups for consistent workstation results. Order the part directly via Metav Werkzeuge or consult our specialists for application advice.

Step Block 5134 – Precision clamping step block, 25 x 47 x 59 mm (Vertex)

The Step Block is a compact, stepped support component for height positioning and clamping tasks in workshop fixtures and modular jigs.

• Compact stepped height support 25 x 47 x 59 mm
• Intended for clamping and height positioning
• Compatible with modular fixture setups
• Vertex industrial quality, SKU 5134

Precise height positioning for consistent setups

The Step Block provides a straightforward solution for repeatable height positioning in clamping arrangements. Its 25 x 47 x 59 mm geometry creates defined contact planes that simplify setup and reduce adjustment time. For production and assembly tasks where repeatability matters, the clearly defined steps support uniform clamping heights and predictable part orientation. The compact footprint makes the component suitable for constrained fixturing environments while preserving access to the workpiece.

Integrates cleanly with jigs and fixture systems

With a simple stepped profile, the component is designed to be incorporated into existing fixture and jig systems without complex modification. The uncomplicated form factor aids rapid installation and alignment in modular assemblies, helping to shorten machine downtime during changeovers. Where process efficiency is key, the block’s compatibility with common clamping layouts supports faster set-up cycles and consistent part presentation to tools and inspection devices.

Practical design for everyday workshop reliability

A minimal, functional design emphasises robustness and straightforward handling during routine operations. The stepped arrangement provides multiple discrete support heights, which helps reduce the need for shims or custom spacers and streamlines adjustments on the shop floor. As a Vertex production component, the unit aligns with industrial expectations for durability and consistent manufacture. Traceable identification via SKU 5134 and the included gallery images supports verification and installation planning prior to procurement.

Contact Metav Werkzeuge in Emmerich for technical clarification on the Vertex Step Block 5134 and to request specification support or procurement guidance from our precision team

Technical data

• Article number: 5134
• GTIN: 4061905090776
• ECLASS: 21170107
• Name: Step Block
• Manufacturer: Vertex

Facts

• Dimensions: 25 x 47 x 59 mm
• GTIN: 4061905090776
• SKU: 5134

Special features

• Intended for clamping and height positioning
• Category: Vertex
• Gallery images available

FAQ

What are the exact dimensions of this step block?
The Step Block has dimensions of 25 x 47 x 59 mm, which define its stepped support geometry for clamping applications.

Which type of applications is the block intended for?
The block is intended for height positioning and clamping tasks within jigs, fixtures and modular setups in workshops and production cells.

What is the SKU and GTIN for ordering and verification?
The product is listed as SKU 5134 with GTIN 4061905090776 for order and inspection purposes.

Are there images available to check the design before procurement?
Yes, gallery images are provided to assist with visual inspection and planning prior to purchase.

Who manufactures the component and where is it made?
The component is manufactured by Vertex; the vendor information is provided for traceability and specification checks.

Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
