11 mm Step Clamp M8/M10 Bolts 25x64x12mm, 0.11kg - Vertex
€7.87
Product information "11 mm Step Clamp M8/M10 Bolts 25x64x12mm, 0.11kg - Vertex"
Take advantage of the combination of compact design, compatibility with standard clamping pins and fast fixture set-up for reliable machining results. Benefit from Vertex quality and secure your components through Metav Werkzeuge or consult our specialists for application advice.
Step Clamp Vertex – Compact clamp for t-slot 11 mm, M8/M10 compatible
Step Clamp designed for modular fixturing in milling and drilling applications, compatible with 11 mm t-slots and standard M8 or M10 clamping pins.
- Compact step clamp for t-slot 11 mm
- Compatible with M8 or M10 clamping pins
- Lightweight construction, approx 0.11 kg
- Precision-made by Vertex for repeatability
Faster set-ups thanks to compact, standard-compatible design
The Step Clamp delivers a practical balance between size and functionality. With a t-slot 11 mm compatibility and support for M8 or M10 pins, the component integrates directly into common clamping rails and fixture plates, reducing the need for bespoke adaptors. The compact footprint (25 x 64 x 12 mm) and low mass (0.11 kg) allow quicker repositioning and minimise inertia during manual handling. This translates into shorter set-up times and fewer interruptions on the shop floor, supporting a smoother production flow.
Reliable clamping and repeatable results for serial work
Manufactured by Vertex, the clamp is engineered to provide secure step-style positioning that helps maintain consistent workpiece height across batches. The step profile enables defined vertical adjustment without incremental shimming, which improves repeatability and reduces the potential for setup error. For workshop environments where small tolerances and steady throughput are required, the clamp’s straightforward mechanical function contributes directly to process reliability and reduced rework.
Practical inventory and integration benefits for busy workshops
The compact dimensions and compatibility with standard clamping bolts simplify stock management and fixture planning. Keeping a set of these clamps reduces the variety of specialised clamps required, enabling flexible fixture builds with fewer individual parts. Supplied as a single, ready-to-install element (SKU 6113), the component fits into modular fixturing systems and is particularly suited to small to medium-sized milling and drilling operations that favour rapid changeovers and lean inventory.
Contact Metav Werkzeuge to secure Vertex clamping components for precise fixturing and request tailored application advice from our consultants in Emmerich
Technical data
-
Article number: 6113
-
GTIN: 4061905084027
-
Brand: Vertex
-
Dimensions: 25 x 64 x 12 mm
-
Weight: 0.11 kg
-
T-slot compatibility: 11 mm
-
Compatible with M8 or M10 clamping pins
-
Compact step profile for vertical adjustment
-
Suitable for modular fixture systems
FAQ
What t-slot size does the clamp fit? The clamp is designed for an 11 mm t-slot and integrates with standard 11 mm rails.
Which clamping bolts are compatible with this clamp? Compatible clamping bolts are M8 or M10; the clamp accepts both sizes for flexible fixture design.
What are the dimensions and its impact on fixture layout? Dimensions are 25 x 64 x 12 mm, allowing compact placement and close packing on fixture plates where space is limited.
Is the clamp supplied ready to install? The component (SKU 6113) is supplied as a ready-to-install clamp for immediate integration into modular systems.
How does the clamp support repeatability in serial production? The step profile provides defined vertical positioning that reduces the need for shims, which helps maintain consistent workpiece heights across multiple set-ups.
Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
