Clamping holder SVJB for VBMT Indexable Inserts — right‑hand toolholder with SVJBR 1616 profile

The Clamping holder SVJB for VBMT Indexable Inserts is a right‑hand turning holder engineered for secure clamping of VBMT 1103 inserts in restricted‑space operations.

• SVJBR 1616 profile for stable seating
• Compatible with VBMT 1103 inserts
• Compact 100 mm overall length
• 16 mm shank and head dimensions

Reliable clamping for precision turning

The holder is designed as a toolholder for turning operations where stability and repeatability matter. Its SVJBR 1616 ISO profile gives a defined pocket geometry that secures the insert and reduces micro‑movement under load, which translates into consistent surface finish and extended insert life. The right‑hand cut orientation and a 93° approach angle reduce chatter in interrupted cuts; this makes the holder suitable for short overhangs and subcontracting environments where predictable results are essential. The technical design focuses on functional rigidity rather than decorative detail, so shops can expect dependable performance during routine production.

Space‑saving design that supports productivity

With a 100 mm overall length and matched 16 mm shank and head widths, this holder is made for tight set‑ups and compact toolposts. The reduced projection lowers leverage on the toolpost and allows faster spindle acceleration during cycle changes, improving throughput in small‑batch turning. The 25 mm cutting height positions the insert accurately at centre height for many standard lathes, meaning less adjustment time at setup and more time cutting. For operations that require quick changeovers, the short, lightweight construction — 0.204 kg — eases handling and minimises fixture stress without compromising clamping force.

Clear compatibility and simple specification

Compatibility with VBMT 1103 indexable inserts is a core feature; the pocket geometry and clamp alignment are produced to match that insert style so insert fitment and seat are repeatable. The holder’s ISO designation SVJBR 1616 identifies its shank profile and size, aiding rapid selection from tooling lists or CAD libraries. The H11‑F bar reference indicates the suitable bore or bar connection where required. For engineers unfamiliar with insert codes: VBMT 1103 denotes a triangular‑shaped, negative‑geometry insert with a specific corner radius and chipbreaker style, chosen here for general turning and facing tasks.

Robust choice for production environments

Manufactured for industrial use, the holder prioritises mechanical simplicity and manufacturing tolerances that matter on the shopfloor. The pronounced 93° cutting angle supports better chip evacuation and allows a stable cutting edge engagement for facing and light profiling. Where repeatability contributes directly to cost‑efficiency, this clamping solution supports predictable tool life and reduces scrap rates. It is particularly well suited to contract workshops and job shops that need a reliable, easy‑specified holder for common negative inserts.

For selection guidance or to confirm suitability for a specific turning task, contact Metav Werkzeuge for expert advice on the Teknik Cutting Tools SVJB clamping holder (SKU D130TM) and benefit from rapid supply from Emmerich — eMail info@metav-werkzeuge.com or call +49 2822 7131930

Technical data

• Article number: D130TM

• Manufacturer: Teknik Makina

• Product: SVJB for VBMT Indexable Inserts

• ISO designation: SVJBR 1616

• Weight: 0.204 kg

• Overall length: 100 mm

• Shank height: 16 mm

• Head width: 16 mm

• Cutting height: 25 mm

• Approach angle: 93°

• Suitable for inserts: VBMT 1103

• Cutting direction: right‑hand

• Bar reference: H11‑F

• SKU: D130TM
