Take advantage of precise clamping and proven insert compatibility to keep turning operations consistent and predictable; the combination of a compact 100 mm overall length and firm insert support reduces setup time and tool chatter. Order the SVJC for VCMT Indexable Inserts directly via Metav Werkzeuge or ask our consultants if needed.

Klemmhalter — SVJC for VCMT Indexable Inserts (right-hand, SVJCR 1616) by Teknik Makina

The SVJC for VCMT Indexable Inserts is a right-hand turning toolholder engineered for secure clamping of VCMT 1103 inserts in general workshop and industrial turning operations.

Fits VCMT 1103 indexable inserts Right-hand turning orientation ISO designation SVJCR 1616 Compact 100 mm overall length

Consistent clamping for repeatable turning results

The SVJC holder is built to deliver stable clamping and repeatable performance in batch production and single-part turning alike. Its geometry secures VCMT-style inserts so that chip formation and surface finish remain predictable; this reduces rework and increases process yield. The SVJCR 1616 designation denotes compatibility with common toolpost layouts and helps ensure correct tool selection during planning. Where operators need predictable tolerances, the holder's design reduces vibration and improves the life of the cutting edge.

Compact design that supports efficient workflows

A short overall length makes tool changes quicker and reduces overhang on the turret. With an overall length of 100 mm and a focused cutting head width, the toolholder minimises cantilever effects while preserving accessibility to tight features. The H11 shank reference matches common boring bar and toolpost interfaces, enabling straightforward replacement in existing setups. Reduced changeover time and fewer adjustments translate into measurable gains in machine uptime and throughput.

Clear compatibility and straightforward set-up

Compatibility is simple: the toolholder is intended for VCMT 1103 indexable inserts and provides a cutting height of 25 mm for nominal insert seating. The right-hand orientation and a 93° cutting angle are matched to standard turning tasks where a controlled rake and clearance are required. Clamping is achieved with a mechanical fastener that secures the insert reliably; this arrangement is easy to verify and maintain, so set-up times are predictable and quality controls are simplified.

Designed for reliable everyday use in production

At just 0.204 kg, the holder offers a balance of rigidity and low mass that helps maintain tool performance without imposing excessive load on mounting hardware. The compact construction supports long-term repeatability and is suitable for workshop environments where tool handling and change frequency are high. Supplied under the Teknik Makina range and available through Metav Werkzeuge, the component benefits from a distribution network that emphasises consistent stock and traceable quality, helping procurement and production teams avoid unexpected supply gaps.

For robust right-hand turning with reliable VCMT insert support, contact Metav Werkzeuge in Emmerich for order placement or technical guidance at +49 2822 7131930 or info@metav-werkzeuge.com

Technical data

• Article number: D241TM
• Manufacturer: Teknik Makina
• SKU: D241TM
• ISO designation: SVJCR 1616

Facts

• Overall length: 100 mm
• Cutting height: 25 mm
• Holder height: 16 mm
• Cutting head width: 20 mm
• Holder width: 16 mm
• Weight: 0.204 kg
• Cutting angle: 93°

Special features

• For inserts: VCMT 1103
• Shank designation: H11
• Right-hand orientation
• Indexable insert turning holder

FAQ

Which inserts are compatible with this toolholder?
The SVJC for VCMT Indexable Inserts is specified for VCMT 1103 geometry and secures that type of indexable insert for turning operations.

Is the holder right- or left-hand?
This toolholder is right-hand oriented; the geometry and cutting angle (93°) are arranged for right-hand turning.

What are the key dimensions to check before purchase?
Key dimensions include an overall length of 100 mm, a cutting height of 25 mm, holder height 16 mm, and cutting head width 20 mm; weight is 0.204 kg.

What is the ISO designation and shank reference?
The holder carries the SVJCR 1616 ISO designation and uses the H11 shank reference for mounting compatibility.

Can this holder be used in existing toolposts?
The holder is designed to fit installations that accept an H11-style shank and SVJCR-style tooling; verify turret or toolpost compatibility with these references before installation.
