Klemmhalter 93° SVJBL 1616 H16 for VBMT 1604 Wendeplatten Innenkühlung Linksschneidend - Teknik Makina

Benefit from a precise left‑hand clamping holder that pairs a secure fit for VBMT 1604 indexable inserts with a compact 100 mm overall length for reduced overhang and consistent turning performance; order the clamping holder via Metav Werkzeuge or consult our specialists for tailored application advice.

Klemmhalter SVJBL 1616 — Clamping holder for VBMT 1604, left‑hand, 100 mm (Teknik Makina)

Klemmhalter SVJBL 1616 is a left‑hand clamping holder designed for turning operations with VBMT 1604 indexable inserts, offering a compact footprint for confined setups.

• Left‑hand clamping holder for turning
• For VBMT 1604 indexable inserts
• 100 mm overall length for compact setups
• 33 mm cutting height for deep turns

Precise insert seating for repeatable turning results

The design focuses on compatibility and repeatability: the holder accepts VBMT 1604 indexable inserts and carries the ISO designation SVJBL 1616, enabling straightforward replacement and consistent cutting geometry. The left‑hand orientation and a 93° cutting angle stabilise chip flow and support predictable tool path behaviour. With a secure clamping interface and an ISO‑based form factor, the toolholder reduces downtime during insert changes and maintains concentricity across sequential parts — an advantage in batch production and setup‑sensitive tasks where consistency matters.

Compact form that increases rigidity and reduces vibration

A short overall length of 100 mm and a modest mass of 0.192 kg limit overhang and improve stiffness at the cutting zone. The holder’s working dimensions — holder height 16 mm, holder width 16 mm and cutting head width 20 mm — result in a concentrated load path that diminishes chatter and supports cleaner surface finishes. The 33 mm cutting height sets the insert at a stable centre of rotation, which helps to preserve insert life and reduces the need for rework. In practice, this compact configuration suits installations with limited cross‑slide travel and helps to maintain cycle times on small‑ to medium‑sized lathes.

Practical advantages and suitable applications for workshops and production

Built by Teknik Makina to interface with standard boring bars (designation H16) and indexable inserts, the holder is intended for routine external turning where a left‑hand tool is required. The straightforward geometry simplifies programming and fixturing on CNC lathes and supports quick tool changes in mixed production environments. For toolrooms and industrial workshops seeking a dependable, ISO‑compatible clamping solution, the unit delivers predictable seating and mechanical stability — qualities that translate into fewer rejects and more reliable throughput. The construction and form factor favour applications where space is limited but rigidity and repeatability remain priorities.

For application advice or to secure a supply of the Teknik Makina clamping holder through Metav Werkzeuge, contact info@metav-werkzeuge.com or call +49 2822 7131930 to discuss suitability for specific turning tasks.

Technical data

• Article number: D374TM
• Manufacturer: Teknik Makina
• SKU: D374TM
• Designation (ISO): SVJBL 1616
• Suitable for inserts: VBMT 1604
• Direction: left

Facts

• Overall length: 100 mm
• Weight: 0.192 kg
• Cutting height: 33 mm
• Cutting head width: 20 mm
• Holder width: 16 mm
• Holder height: 16 mm
• Cutting angle: 93°

Special features

• Boring bar designation: H16
• Left‑hand orientation
• ISO compatibility: SVJBL 1616
• For VBMT 1604 indexable inserts
• Brand: Teknik Makina

FAQ

Which inserts fit this clamping holder?
The clamping holder accepts VBMT 1604 indexable inserts and is specified as SVJBL 1616, ensuring a precise fit for that insert form.

Is the holder left‑hand or right‑hand?
This toolholder is left‑hand oriented; the specification lists left direction and a 93° cutting angle for turning operations.

What are the key dimensions to consider for setup?
Key dimensions include an overall length of 100 mm, cutting height 33 mm, holder height 16 mm and holder width 16 mm, which together influence overhang and rigidity.

Which boring bar designation is compatible with the holder?
The holder is designed for a boring bar designated H16, enabling direct mounting in compatible tool posts and bar systems.

What is the SKU for ordering and identification?
The SKU for ordering is D374TM, listed under the Teknik Makina clamping holder SVJBL 1616
