Turning Holder (SVJCL 1616) by Teknik Makina

The Turning Holder (SVJCL 1616) secures VCMT 1103 indexable inserts for precise left-hand turning operations on lathes.

• Turning Holder SVJCL 1616 for VCMT 1103 inserts
• 100 mm overall length for stable tool engagement
• 16 mm shank width and height for secure clamping
• 20 mm cutting head width for robust chip control
• Left-hand cutting geometry with 93° cutting angle

Precision and Stability for Consistent Turning

The Turning Holder delivers reliable Stability through its 100 mm Overall Length and a precise ISO designation SVJCL 1616, ensuring consistent seat and support for the Insert during cutting. Operators benefit from reduced vibration and predictable tool behaviour, which translates into improved Surface Finish and longer Insert Life. This Holder is engineered to keep the Insert firmly in position so that single-pass operations remain accurate and repeatable.

Secure Clamping Designed for VCMT 1103 Inserts

This tool is optimised for VCMT 1103 Indexable Inserts, offering a straightforward clamping method that simplifies Insert changes and maintenance. For users unfamiliar with indexable tooling: an Indexable Insert is a replaceable cutting tip; when one edge wears, the Insert can be rotated or replaced without regrinding the entire tool, reducing downtime and tooling costs. The Holder’s geometry and clamping interface enable fast, repeatable insert seating for efficient shop-floor workflows.

Geometry That Improves Chip Control and Surface Quality

With a 20 mm Cutting Head Width and a 93° Cutting Angle, the Holder promotes reliable Chip Control and consistent cutting forces during left-hand operations. The combination of these dimensions helps channel chips away from the cutting zone and supports stable cut engagement, which benefits both roughing and finishing passes. Users will notice improved surface appearance and fewer interruptions for chip clearing when the tool is matched to the correct Insert and cutting parameters.

Who Benefits and Where to Use It

Manufacturing shops, maintenance departments and precision workshops that run lathes with left-hand operations will find this Holder particularly suitable. Its 16 mm Shank Width and Height make it compatible with common turret and toolpost setups, while the robust Cutting Head supports heavier cuts when required. For teams aiming to streamline Insert swaps and minimise setup variability, this Holder offers practical advantages and straightforward interoperability with standard tooling systems.

We recommend the Teknik Makina Turning Holder as a dependable choice for precision turning — for personalised advice or technical clarification contact METAV Werkzeuge at info@metav-werkzeuge.com or call +49 2822 7131930 / WhatsApp +49 170 2837271

Technical Specifications

• Bezeichnung: Turning Holder (SVJCL 1616)
• Marke: Teknik Makina
• SKU: D385TM
• Suitable Inserts: VCMT 1103
• Gesamtlänge / Overall Length: 100 mm
• ISO Bezeichnung / ISO designation: SVJCL 1616
• Bezeichnung 2 / Secondary designation: H11
• Shank Width / Breite: 16 mm
• Shank Height / Höhe: 16 mm
• Cutting Head Width / Schneidkopf Breite: 20 mm
• Cutting Direction / Schnittrichtung: Left
• Cutting Angle / Schnittwinkel: 93°
• Weight / Gewicht: 0.204 kg
• GTIN: 4061905153945
• Availability: in Stock
• Condition: new
• Manufacturer: Teknik Makina, Nolu Sokak, No 9, Selcuklu, Türkei, eMail: info@teknik-makina.com
• Responsible Person: Metav Werkzeuge GmbH, Parkring 45, 46446 Emmerich, eMail: info@metav-werkzeuge.com

FAQ

What Inserts fit the Turning Holder and how do I mount them?
The Turning Holder (SVJCL 1616) by Teknik Makina is designed for VCMT 1103 indexable inserts; mounting is achieved via the clamping seat and screw interface, ensuring the Insert sits flush for correct Cutting Angle and stable performance.

Is the Turning Holder suitable for heavy-duty turning operations?
The Teknik Makina Turning Holder features a 20 mm Cutting Head Width and robust shank dimensions, making the Holder appropriate for many heavy-duty and general turning tasks when paired with the correct VCMT 1103 grade and cutting parameters.

Can METAV Werkzeuge help with selection and technical support?
Yes, METAV Werkzeuge provides expert advice for the Turning Holder (SVJCL 1616) by Teknik Makina; contact info@metav-werkzeuge.com or call +49 2822 7131930 for assistance in choosing the right Insert and setup.

What is the cutting direction for this Holder and how does it affect setup?
The Holder is configured for left-hand cutting (left), which determines the orientation in the lathe turret or toolpost; ensure the Holder is mounted accordingly to maintain the specified 93° Cutting Angle and intended chip flow.
