100mm SVJB For VBMT Indexable Inserts, 93° Cut Angle, 16mm - Teknik Makina

Turning Holder (Klemmhalter) by Teknik Makina

The Turning Holder is engineered for left-hand machining with VBMT 1103 indexable inserts, offering a rigid 16×16 mm cross-section and a 100 mm overall length for reliable workshop performance.

• Fits VBMT 1103 indexable inserts
• Overall length 100 mm for stable setup
• ISO designation SVJBL 1616 for precise fit
• Left-hand cutting with 93° cutting angle
• Compact 16×16 mm cross-section for high Rigidity

Reliable Rigidity that Reduces Vibration and Improves Surface Finish

Robust construction and a compact Cross-Section deliver tangible benefits in daily turning operations. The Rigidity of the 16×16 mm Body minimises Deflection and Vibration, so single-pass cuts remain consistent and Surface Finish improves. Shops that prioritise repeatability value the shorter Overhang and controlled tool geometry because it reduces rework and tool wear, enhancing productivity and component quality.

Secure Clamping and Clear Compatibility with VBMT Inserts

Compatibility with VBMT 1103 indexable inserts and the ISO designation SVJBL 1616 ensures predictable mounting and alignment. The holder’s geometry, combined with a 93° Cutting Angle and Left-hand orientation, supports favourable Chip Flow and stable cutting forces. For operators this means easier setup and fewer indexing corrections between cycles, which saves time and reduces scrap rates.

Practical Dimensions and What They Mean in Use

The Cutting Head width of 16 mm and a Cutting Height of 25 mm define the machined envelope and help determine suitable insert grades and insert clamping methods. When assessing fitment, remember that ISO codes like SVJBL 1616 describe shank and clamping form; this makes selection straightforward even for those with limited tooling experience. If uncertain, matching the Holder geometry to the Insert specification avoids clearance issues and improves tool life.

Designed for Shop Efficiency and Reliable Supply

Manufactured by Teknik Makina, this holder supports standardised tooling setups for repeated production runs. Availability in stock reduces lead times and helps maintain uninterrupted operation, while the compact design simplifies fixturing on small and medium Lathes. For workshops seeking a dependable left-hand turning solution, the combination of standard ISO designation and robust construction offers both predictability and a low learning curve.

For expert advice on whether this Turning Holder from Teknik Makina matches your application, or for personalised technical support, contact METAV Werkzeuge at info@metav-werkzeuge.com, call +49 2822 7131930 or message via WhatsApp +49 170 2837271 — METAV offers competent consultation for complex tooling decisions

• Turning Holder
• Brand: Teknik Makina
• SKU: D397TM
• Compatible Indexable Inserts: VBMT 1103
• Overall Length: 100 mm
• Weight: 0.204 kg
• ISO Designation: SVJBL 1616
• Alternative Designation: H11-F
• Width: 16 mm
• Height: 16 mm
• Cutting Head Width: 16 mm
• Cutting Height: 25 mm
• Cutting Direction: left
• Cutting Angle: 93°
• GTIN: 4061905153839
• Availability: in Stock
• Condition: new
• Manufacturer: Teknik Makina, Nolu Sokak, No 9, Selcuklu, Turkey, eMail: info@teknik-makina.com
• Responsible Person: Metav Werkzeuge GmbH, Parkring 45, 46446 Emmerich, eMail: info@metav-werkzeuge.com

FAQ

What inserts does the Turning Holder by Teknik Makina accept?
The Teknik Makina Turning Holder is designed to accept VBMT 1103 indexable inserts; the SVJBL 1616 ISO designation ensures correct shank and clamping compatibility so inserts seat precisely and clamp securely during left-hand operations.

What is the overall length and how does it affect setup?
The overall length of the Teknik Makina Turning Holder is 100 mm, which reduces overhang and increases Support; shorter length improves Stability and makes the Holder suitable for setups where minimizing Deflection is important.

Can the Turning Holder be used for right-hand turning?
This particular Turning Holder from Teknik Makina is configured for left-hand cutting; it is not suitable for right-hand turning without a corresponding right-hand holder variant, so confirm Cutting Direction before tooling selection.

Who can I contact for technical advice or special requirements?
For tailored technical advice, METAV Werkzeuge provides competent consultation on the Teknik Makina Turning Holder; contact via info@metav-werkzeuge.com, phone +49 2822 7131930 or WhatsApp +49 170 2837271 for assistance with application-specific questions.
