Klemmhalter SCLC for CCMT Indexable Inserts — Teknik Cutting Tools SCLCL 1616, left‑hand, 95°

The Klemmhalter SCLC for CCMT Indexable Inserts is a left‑hand clamping toolholder designed for external turning with CC-- 09T3 / CCMT indexable inserts in CNC and manual lathes

• Left‑hand turning orientation
• SCLCL 1616 shank, 16 x 16 mm
• Compatible with CC-- 09T3 CCMT inserts

Consistent seating for repeatable cuts

A reliably engineered clamping seat delivers repeatable results even in batch production. The SCLCL 1616 geometry ensures accurate insert positioning so that each cut starts from the same datum; this reduces set‑up time and minimises rework. With a defined 95° cutting angle, the holder is optimised for standard external turning profiles, supporting predictable chip flow and steady surface finish. Emphasis on rigid contact surfaces helps maintain precision across multiple tool changes.

Rapid replacement and clear compatibility

Designed specifically for CCMT style indexable inserts (designation CC-- 09T3), the holder simplifies insert exchange without compromising clamping integrity. The shank 16 x 16 mm profile (ISO SCLCL 1616) and the declared cutting height 20 mm match common toolpost systems, enabling direct replacement in many setups. The modest total length 100 mm and a weight of 0.215 kg keep centrifugal loads low on rotating assemblies while preserving rigidity during higher feed operations.

Compact design that fits standard toolposts

A compact head width of 20 mm and overall width of 16 mm make this clamping holder suitable where space is limited or multiple stations are required on a turret. The left‑hand orientation is ideal for operations that require reverse‑direction turning or when arranging tool stations for optimal chip evacuation. The combination of compactness and the 95° approach angle supports both light finishing cuts and more robust profiling, depending on insert grade and machine capabilities.

Reliable sourcing and practical service

Manufactured by Teknik Cutting Tools and distributed by Metav Werkzeuge, this toolholder benefits from a European supply chain focused on dependable delivery and technical guidance. The robust ISO‑based design reduces uncertainty at procurement and supports standardisation across a machine park. For enquiries about fitting, insert grades or suitability for a specific turning task, Metav’s consultants can provide targeted recommendations based on workshop requirements and production goals.

For tailored advice or to procure the Teknik Cutting Tools SCLCL 1616 clamping holder, contact Metav Werkzeuge — email info@metav-werkzeuge.com or call +49 2822 7131930 to discuss compatibility and lead times from Emmerich.

Technical data

• Article number: D406TM
• Manufacturer: Teknik Cutting Tools
• Product name: Klemmhalter SCLC for CCMT Indexable Inserts
• ISO designation: SCLCL 1616

Core dimensions

• Height: 16 mm
• Width: 16 mm
• Head width: 20 mm
• Cutting height: 20 mm
• Total length: 100 mm
• Weight: 0.215 kg
• Cutting angle: 95°

Compatibility & features

• For CC-- 09T3 / CCMT inserts
• ISO type SCLCL 1616
• Shank designation H09
• Left‑hand cutting direction

FAQ

Which inserts fit this toolholder?
The toolholder accepts CC-- 09T3 format inserts (CCMT indexable inserts); the SCLCL 1616 interface is matched to that insert family for secure clamping.

Is this a left‑hand or right‑hand holder?
This model is a left‑hand turning toolholder; the SCLCL 1616 geometry and approach angle are configured for left‑hand external turning operations.

What are the main dimensions to check for machine compatibility?
Key dimensions are the shank/profile 16 x 16 mm, head width 20 mm, cutting height 20 mm and total length 100 mm; confirm these against the turret or toolpost envelope.

Can this holder be used for finishing and roughing?
The holder’s rigid design and 95° cutting angle allow both finishing and moderate roughing when paired with the correct CCMT insert grade and appropriate cutting parameters.

Who manufactures and distributes the product?
The clamping holder is manufactured by Teknik Cutting Tools and offered via Metav Werkzeuge; see the manufacturer details below for full contact information.

Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
