Compact, precise and simple to set up: the combination of the SVJCR 1616 ISO designation, compatibility with VCMT 1103 inserts and a compact 100 mm overall length supports stable turning cycles and efficient changeovers. Order the Klemmhalter directly via Metav Werkzeuge or ask our consultants if needed.

Klemmhalter SVJC for VCMT Indexable Inserts by Teknik Makina — right-hand, compact 16 mm head

The Klemmhalter is a right-hand clamping toolholder designed for turning operations with VCMT 1103 indexable inserts, offering a compact profile for use in workshop and production lathe set-ups.

• Toolholder SVJCR 1616 for VCMT 1103 inserts
• Right-hand orientation for standard turning
• 16 mm head width and 16 mm height
• 100 mm overall length, compact design

Greater process stability through rigid clamping and proven geometry

The SVJCR 1616 designation signals a standardised clamping geometry that secures VCMT 1103 indexable inserts with repeatable positioning; this results in reliable cutting behaviour and consistent component tolerances. The holder’s 90° cutting angle aligns insert forces to the toolpost, reducing chatter and helping to maintain surface finish over long runs. For production-oriented turning, the rigid interface between insert and body reduces rework and supports predictable tool life, which translates into lower overall machining costs.

Fast integration into existing lathe setups for reduced downtime

With a 100 mm overall length and compact 16 mm head dimensions, the toolholder slides into customary turret and toolpost layouts without excessive overhang, shortening set-up times and minimising interference. The right-hand orientation and shank reference H11-F make it compatible with common boring-bar fixtures and modular systems. At 0.202 kg, the component is light enough to avoid adding undue inertia yet robust enough to keep insert seating stable during turning operations, helping workshops and small production cells increase throughput.

Low-maintenance design that supports reliable daily use

Designed as a dedicated holder for indexable inserts, the unit keeps service requirements minimal: simple clamp access and standard screw interfaces permit rapid insert changes and orientation checks. The compact clamping head reduces the need for frequent repositioning, while standard ISO form ensures replacement and spare parts are straightforward to source. For industrial and craft environments requiring repeatable results, the holder offers a balance of durability, accessibility and cost-efficient operation, making it well suited to both single-shift workshops and continuous production lines.

For supply, technical advice or a tailored quotation for the Teknik Makina SVJC clamping holder (SKU D462TM), contact Metav Werkzeuge at info@metav-werkzeuge.com or call +49 2822 7131930 — support and reliable delivery from Emmerich are available on request.

Technical Data

• Article number: D462TM
• Manufacturer: Teknik Makina
• Designation: SVJC for VCMT Indexable Inserts

Dimensions and weight

• Head height: 16 mm
• Head width: 16 mm
• Body width: 16 mm
• Overall length: 100 mm
• Weight: 0.202 kg
• Cutting angle: 90°

Compatibility and features

• Compatible with VCMT 1103 inserts
• ISO designation SVJCR 1616
• Right-hand cutting orientation
• Boring bar designation H11-F
• Suitable for indexable inserts

FAQ

Which inserts fit this holder best?
The Klemmhalter is designed for VCMT 1103 indexable inserts; the SVJCR 1616 form secures the insert reliably for turning applications.

Is the holder for right-hand or left-hand machining?
The toolholder is configured for right-hand cutting, indicated by the right-hand orientation in the product specification.

What are the key dimensions and weight?
The holder has a 16 mm head height and width, 100 mm overall length and a weight of 0.202 kg (SKU D462TM by Teknik Makina).

What ISO designation does the holder use?
The holder carries the ISO reference SVJCR 1616, which relates to the clamping geometry and insert seating form.

Is the holder suitable for small workshop lathes?
Yes. Its compact 100 mm length and modest mass make it suitable for workshop lathes and production turrets where space and stability are important.
