20mm S16Q SVUBL Boring Bar For VBMT 1103 Indexable Inserts, Left-Hand 93° Cutting Angle, 180mm Overall Length - Teknik Makina

Take advantage of a compact boring solution that pairs a 16 mm shank with a Ø20 mm head and a 93° cutting angle for stable, left-hand internal turning; secure supply and expert advice through Metav Werkzeuge for seamless shop-floor integration.

S16Q SVUBL Boring Bar – left-hand, for VBMT 1103 indexable inserts (Teknik Cutting Tools)

A S16Q SVUBL boring bar engineered for left-hand internal turning with VBMT 1103 indexable inserts, offering compact dimensions and a stiff shank for reliable clamping and repeatable results.

• S16Q SVUBL boring bar for VBMT 1103 inserts
• Left-hand cutting direction, 93° cutting angle
• Ø20 mm head, 16 mm shank diameter
• Overall length 180 mm, cutting height 30 mm

Stable clamping and predictable machining results

The toolholder is designed around a 16 mm shank, combining rigidity with compact form to reduce deflection in confined bores. Compatibility with VBMT 1103 indexable inserts ensures a familiar insert geometry for many turning operations, while the Ø20 mm head maintains cutting strength without excessive overhang. This configuration reduces vibration and leads to more consistent tolerance retention across batch runs. For workshops that prioritise process reliability, the combination of a stiff shank and standard insert format supports predictable cycle times and fewer part rejections.

Improved chip control and surface quality from geometry

A 93° cutting angle matched to a 30 mm cutting height promotes favourable chip flow and axial stability during left-hand cuts. The insert seat and cutting geometry are optimised for controlled chip engagement, which helps to lower burr formation and improves surface finish in internal turning operations. When machining common materials with moderate cutting data, this geometry can reduce the need for secondary finishing, translating into time savings and lower downstream costs while preserving required surface integrity.

Ready for quick set-up and efficient handling on the shop floor

The bar’s ISO designation S16Q SVUBL simplifies tool selection and documentation; the concise overall length of 180 mm and the modest mass of 0.278 kg make tool handling and balancing straightforward during set-up. The left-hand orientation is clearly specified to avoid mix-ups with right-hand holders, and the standard shank diameter accelerates clamping in common tool posts. This straightforward adoption reduces set-up time and makes the holder suitable for mixed production environments where flexibility and short changeover are priorities.

For dependable left-hand internal turning with VBMT 1103 inserts, contact Metav Werkzeuge in Emmerich to discuss the S16Q SVUBL by Teknik Cutting Tools and secure fast, reliable supply.

Technical data

• SKU: K282TM
• Manufacturer: Teknik Makina
• ISO designation: S16Q SVUBL
• Description: SVUB for VBMT Indexable Inserts

Core data

• Shank diameter: 16 mm
• Head diameter: 20 mm
• Overall length: 180 mm
• Cutting height: 30 mm
• Cutting angle: 93°
• Weight: 0.278 kg

Features

• Left-hand cutting direction
• Compatible with VBMT 1103 indexable inserts
• Compact form for reduced overhang
• ISO-based designation for easy documentation

FAQ

Which insert type fits this holder?
The holder accepts VBMT 1103 indexable inserts; the S16Q SVUBL design provides a standard seat for secure clamping and correct cutting geometry.

Is the tool suitable for internal left-hand turning?
Yes, the S16Q SVUBL is specified for left-hand cutting direction and is intended for internal turning applications where left-hand chip flow is required.

What are the key dimensions to consider for setup?
Key dimensions: 16 mm shank diameter, Ø20 mm head, overall length 180 mm, cutting height 30 mm; weight 0.278 kg (SKU K282TM).

How does the cutting angle affect performance?
The 93° cutting angle stabilises axial engagement and supports consistent chip formation, which helps to improve surface finish and reduce chatter in many internal turning tasks.

Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
