40mm S32T SVQCL Boring Bar For VCMT 1604 Indexable Inserts 50mm Cutting Height, Left Hand - Teknik Makina

Take advantage of a rigid left‑hand boring bar with a 32 mm shank and 300 mm overall length for stable internal turning operations; the tool supports VCMT 1604 indexable inserts and combines precise geometry with robust clamping for consistent bore quality — available via Metav Werkzeuge or consult Metav’s specialists for technical guidance.

K324TM S32T SVQCL Boring Bar (left‑hand) — for VCMT 1604 inserts, Ø32 mm shank

K324TM S32T SVQCL is a left‑hand turning/boring bar designed for internal and facing operations with indexable inserts, optimised for workshop use and industrial turning centres

• Left‑hand cutting orientation
• Shank Ø 32 mm for high rigidity
• Compatible with VCMT 1604 inserts
• 300 mm overall length for deep reach

Consistent bore quality through optimised rigidity

The bar’s 32 mm shank and 300 mm overall length deliver a balance between reach and stiffness that reduces vibration during internal turning. Reduced chatter improves surface finish and extends insert life, which translates into lower tooling costs per part. The specified cutting angle of 107.5° helps control cutting forces in left‑hand operations, so the tool maintains concentricity in demanding bore and shoulder cuts. This mechanical stability is particularly beneficial in serial production, where repeatability and minimal rework are priorities.

Insert compatibility and geometry that boost productivity

Designed for VCMT 1604 indexable inserts, the holder accepts widely used carbide grades and geometries, enabling flexible process optimisation. The S32T SVQCL ISO designation indicates the shank and head configuration suitable for standard clamping systems; this simplifies toolholder selection at the machine and reduces setup time. With a cutting height of 50 mm and a head diameter of 40 mm, the geometry supports effective chip control and predictable cutting behaviour, helping to maintain cycle times and throughput.

Workshop integration and safe handling for reliable use

The tool’s weight of 1.786 kg and a clear left‑hand orientation make it straightforward to fit and check during tool changes. The explicit ISO designation and compatibility notes facilitate inventory management and spare‑part planning. For retrofit and replacement workflows, the bar’s conventional dimensions mean minimal adaptation of existing clamping systems; the listed clamp size (16) aligns with common holder fixtures. Practical handling and robust construction contribute to safer operation and steady machine performance across shifts.

Contact Metav Werkzeuge today for tailored advice on Teknik Makina’s K324TM boring bar and to arrange reliable supply from our Emmerich warehouse

Technical Data

• Article number: K324TM
• Product name: S32T SVQCL boring bar
• Brand: Teknik Makina
• Type designation: SVQC for VCMT indexable inserts
• ISO code: S32T SVQCL

Core data

• Shank diameter: 32 mm
• Overall length: 300 mm
• Head diameter: 40 mm
• Cutting height: 50 mm
• Weight: 1.786 kg
• Cutting angle: 107.5°

Special features

• Left‑hand cutting direction
• Suitable for VCMT 1604 inserts
• Clamp size: 16
• Designed for internal turning and facing
• SKU: K324TM

FAQ

What insert type fits this boring bar?
The boring bar is suited for VCMT 1604 indexable inserts; the S32T SVQCL configuration supports standard carbide VCMT geometries for general turning.

Is the bar suitable for deep‑hole boring operations?
With an overall length of 300 mm and a 32 mm shank, the K324TM offers reach for many internal machining tasks while maintaining sufficient rigidity for repeatable results.

Which cutting direction does the tool support?
The holder is configured for left‑hand cutting; the left‑hand orientation is specified in the S32T SVQCL code and in the product data.

How does the cutting angle affect machining performance?
The 107.5° cutting angle helps control cutting forces and chip flow in internal turning, improving tool life and surface finish when using the recommended inserts.

What information is needed to replace an existing boring bar?
Provide the SKU K324TM, the ISO code S32T SVQCL, and the clamp size (16) to ensure correct selection and compatibility with existing fixtures.

Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
