63mm S50U MTENR Drilling Bar for TNMG 1604 Indexable Inserts 60° Cutting Angle, 350mm Length - Teknik Makina

Take advantage of the combination of precise geometry, robust clamping and long reach for stable finishing cuts; the compatibility with TNMG 1604 indexable inserts reduces tooling inventory and improves uptime. Order this boring bar directly via Metav Werkzeuge or consult the technical team for application support.

Boring bar — MTENR for TNMG 1604 indexable inserts, Ø50 mm shank, 350 mm length (Teknik Makina)

A boring bar (S50U MTENR) designed for right-hand turning operations using TNMG 1604 indexable inserts, offering extended reach and stable clamping for metalworking applications

• Compatible with TNMG 1604 indexable inserts
• Ø50 mm shank for secure clamping
• 350 mm overall length for deep reach

Stable geometry for consistent material removal

The tool's geometry, defined by the 60° cutting angle and an optimised insert pocket, delivers predictable chip flow and reduced vibration during turning. As a result, surface finish and dimensional repeatability are improved when machining common metals. The use of standard indexable inserts allows quick index changes, lowering set-up time and ensuring consistent cutting conditions across production runs.

Secure clamping and rigid toolholding

A Ø50 mm shank provides a high clamping surface for standard toolholders, increasing stiffness at the tool-to-holder interface and reducing deflection in interrupted cuts. The S50U MTENR designation indicates a robust shank and holder fit compatible with typical lathe toolposts, which supports stable finishing passes and longer tool life under moderate cutting forces.

Compatibility that simplifies tooling logistics

Designed specifically for TNMG 1604 inserts, the boring system standardises the cutting edge across turning operations. Using widely available indexable inserts simplifies spares management and reduces inventory complexity. The option to run common grades of TNMG inserts enables fine-tuning of wear resistance and surface quality without replacing the boring bar itself.

Reach and balance for industrial turning tasks

With a 350 mm overall length and an outside diameter of 63 mm, the bar is suited for deeper internal and external turning where accessibility is required. The specified cutting height of 70 mm aligns the insert seat for proper rake and clearance, helping to maintain cutting stability over extended overhangs. The component's mass and design balance contribute to reduced chatter and a steadier machining process.

For reliable turning with TNMG 1604 inserts choose Teknik Makina's S50U MTENR boring bar — contact Metav Werkzeuge for delivery details and technical advice at info@metav-werkzeuge.com or call +49 2822 7131930

Technical data

• Article number: K462TM
• SKU: K462TM
• Brand: Teknik Makina
• ISO designation: S50U MTENR
• Designation: MTENR for TNMG 1604 Indexable Inserts
• Compatible inserts: TNMG 1604
• Cutting direction: right

Facts

• Shank diameter: 50 mm
• Cutting height: 70 mm
• Overall length: 350 mm
• Outside diameter: 63 mm
• Weight: 5.125 kg
• Cutting angle: 60°

Special features

• Right-hand cutting configuration
• Indexable-insert system for fast servicing
• Robust shank for improved rigidity
• Suited to industrial turning and finishing tasks
• Tekinik Makina manufacturing

FAQ

What insert type is required for this boring bar?
The boring bar is specified for TNMG 1604 indexable inserts and is compatible with standard grades of that insert type for turning operations.

What are the key dimensions for clamping and reach?
Shank diameter is 50 mm and the overall length is 350 mm, offering a balance of clamp compatibility and extended reach for deeper cuts.

Is the cutting direction defined for this tool?
Yes, the tool is configured for right-hand cutting, as indicated in the technical designation.

How does the 60° cutting angle affect machining?
A 60° cutting angle provides a compromise between shear cutting action and tool strength, supporting reliable chip formation and improved surface finish in common metalworking applications.

What is the ISO designation and why is it important?
The ISO designation S50U MTENR identifies the shank size and tool style, ensuring the correct toolholder match and predictable performance in standard lathe tooling systems.

Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
