38 Stechklemmhalter S32S 4C, For 4C Wendeplatten, Innenkühlung, Schneidenhöhe 60mm, Schneidenbreite 4mm, Shaft Diameter 32mm - Teknik Makina

Take advantage of the combination of sturdy construction, precise clamping and broad insert compatibility to keep parting and grooving operations stable and productive; order the holder via Metav Werkzeuge or consult their specialists for application advice.

Teknik Makina parting and grooving clamp holder K710TM — 32 mm shank, 4 mm cutting width

The parting and grooving clamp holder from Teknik Makina is engineered for secure clamping of 4C indexable inserts and for use in turning and CNC lathes where rigidity and repeatability matter

• 32 mm shank for rigid toolholding
• 4 mm insert cutting width for precise grooving
• Compatible with ISCAR 4C indexable inserts
• 250 mm overall length for deep reach

Rigidity and repeatability for demanding parting work

The holder is built around a 32 mm shank (ISO designation S32S), which gives a high moment of inertia and reduces deflection during cut-off and grooving operations. This structural stiffness translates into improved precision and consistent part tolerances; less vibration means better surface finish and extended insert life. The relatively substantial mass (approx. 1.655 kg) and the specified body diameter 38 mm contribute to a stable setup, particularly on medium- to heavy-duty turning centres. For production environments where repeatable results are required, the combination of shank size and overall design supports shorter cycle times and fewer rejected parts.

Versatile insert compatibility and cut geometry for controlled chip removal

Designed to accept the 4C family of indexable inserts and specified as compatible with ISCAR, the holder supports a 4 mm cutting width and a cutting height of 60 mm, offering a balance between chip control and tool strength for narrow parting cuts or shallow grooves. The clamping concept provides positive axial and radial support for the insert, which simplifies setup and reduces the need for frequent rework. Where insert geometry or grade is changed to suit different materials, the holder’s acceptance of a standard 4C format allows fast swaps and minimal downtime, aiding continuous production and flexible batch runs.

Reach, handling and application benefits that improve throughput

With an overall length of 250 mm, the tool holder is suited to deeper reaches while keeping the workpiece engagement stable. The measured geometry supports both external and internal grooving styles where access depth is a constraint. The holder designation 4C-R GRP indicates a form factor intended for robust clamping of the 4C insert type, simplifying inventory and tooling selection. In practice, this reduces setup complexity and supports faster changeovers. For machining shops aiming to increase throughput without sacrificing quality, the holder’s combination of reach, clamping security and insert standardisation helps streamline operations and maintain process reliability.

For specification checks, cutting-parameter advice or to source the Teknik Makina parting and grooving clamp holder (K710TM) directly, contact Metav Werkzeuge for tailored guidance and procurement support

Technical Data

• Article number: K710TM
• Manufacturer: Teknik Makina
• Product: Parting and grooving clamp holder
• Compatible insert family: 4C (ISCAR)

Core technical data

• Shank diameter: 32 mm
• Overall length: 250 mm
• Cutting width: 4 mm
• Cutting height: 60 mm
• Diameter: 38 mm
• Weight: 1.655 kg

Design & features

• Shank designation: S32S
• Holder designation: 4C-R GRP
• Fits indexable inserts: 4C
• Compatible insert manufacturer: ISCAR

FAQ

Which insert family fits this clamp holder?
The holder is specified for the 4C insert family and is compatible with ISCAR 4C indexable inserts; use inserts that match the 4 mm cutting width and the holder’s clamping geometry.

What shank and designation are required for mounting?
This tool requires a 32 mm shank and follows the S32S shank designation for secure mounting in the lathe turret or toolpost.

Is the holder suitable for deep parting operations?
With an overall length of 250 mm and a robust shank, the holder supports deeper reach operations while maintaining clamping stability for reliable parting.

How does the 4 mm cutting width affect performance?
A 4 mm cutting width offers a controlled chip thickness that improves surface finish and reduces cutting forces compared with wider parting tools, benefiting both tool life and dimensional stability.
