150ft-lb Pneumatic Pull Rod 90psi, 3000rpm, AC 110V/220V DC 24V - Vertex

Take advantage of the combination of 150 ft-lb torque, high rotational speed and robust 9.8 kg construction for consistent throughput in assembly operations; order directly via Metav Werkzeuge or consult the Metav team for application advice.

Pneumatic Pull Rod PD-150-R8 — 150 ft-lb torque · 3,000 rpm · Vertex

The Pneumatic Pull Rod PD-150-R8 is a compact pneumatic tensioning and fastening tool designed for industrial assembly tasks that demand controlled torque and rapid cycle rates.

• 150 ft-lb maximum torque
• Up to 3,000 rpm operational speed
• Operates at 90 psi (6.3 kg/cm²)
• Robust 9.8 kg construction

Optimised throughput with measurable performance

The PD-150-R8 delivers a rated 150 ft-lb of torque combined with a peak rotation of 3,000 rpm, which translates into faster cycle times on repetitive fastening or tensioning operations. Torque is the rotational force applied at the drive output; higher torque reduces the number of passes needed on stubborn fastenings and shortens overall process time. The combination of controlled torque and elevated speed makes the unit suitable for workshop lines where consistency and repeatability are required, helping to reduce downtime related to under- or over-tightening.

Designed for reliable pneumatic operation and safety

Built for pneumatic supply at 90 psi / 6.3 kg/cm², this tensioning tool uses compressed air to produce its drive output, avoiding reliance on mains-only power. The model accepts AC 110V or 220V for ancillary electronics and DC 24V where low-voltage control is required, enabling flexible integration with existing control systems. At 9.8 kg, the structure balances heft for stability with manageable handling during fixture changes; mass contributes to smooth torque delivery and reduces vibration transfer to adjacent components.

Practical integration in assembly and maintenance workflows

The PD-150-R8 is suitable for a range of industrial assembly tasks, from production-line fastening to maintenance where a controlled pneumatic drive is preferred. The supply variants and compact footprint facilitate integration into existing rigs and jigs. For users less familiar with pneumatic specifications, psi denotes pounds per square inch of air pressure, and matching compressor capability to the stated 90 psi ensures the tool reaches its rated performance without pressure drop. The solid build and clear performance metrics simplify process planning and spare parts forecasting.

Contact Metav Werkzeuge in Emmerich for tailored procurement and technical guidance on Vertex pneumatic tools; email info@metav-werkzeuge.com or call +49 2822 7131930 for application-oriented advice and delivery options

Technical data

• SKU: PD-150-R8
• GTIN: 4061905084430
• Brand: Vertex
• ECLASS: 23309104

Performance data

• Torque: 150 ft-lb
• Speed: 3,000 rpm
• Air pressure: 90 psi / 6.3 kg/cm²
• Weight: 9.8 kg
• Supply voltage: AC 110V or 220V; DC 24V

Special features

• Pneumatic operation
• High rotational speed for fast cycles
• Robust construction for industrial use
• Product images available in gallery

FAQ

What torque and speed does the tool provide?
The Pneumatic Pull Rod PD-150-R8 delivers 150 ft-lb of torque and operates up to 3,000 rpm, suitable for high-throughput fastening and tensioning tasks.

Which air pressure is required for optimal performance?
Optimal operation of the PD-150-R8 is specified at 90 psi (6.3 kg/cm²); maintaining this supply prevents performance loss due to pressure drop.

Can the unit be integrated with existing voltage systems?
Yes; the PD-150-R8 accepts AC 110V or 220V for auxiliary functions and DC 24V for low-voltage control interfaces.

Is the tool suitable for continuous assembly-line use?
The robust design and rated torque make the PD-150-R8 suitable for continuous industrial assembly cycles where pneumatic drive is preferred.

What is the model identifier for ordering spare parts?
Order and spare parts references use SKU PD-150-R8 and the GTIN 4061905084430 for accurate identification.

Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
