16mm End Mill For LNMX 0603 Indexable Inserts, M3x7 Clamp Screw T8 - Teknik Makina

Combine reliable compatibility with LNMX 0603 indexable inserts and a 16 mm shank for consistent performance in demanding milling tasks; benefit from secure Torx clamping and two effective cutting edges. Order the cutter directly via Metav Werkzeuge or consult our specialists for application support.

Indexable End Mill S284TM for LNMX 0603 inserts — 16 mm shank, Teknik Makina

The Indexable End Mill S284TM is an indexable insert cutter engineered for robust face and shoulder milling with LNMX 0603 inserts in industrial machining applications.

*Compatible with LNMX 0603 indexable inserts
*16 mm shank for standard toolholders
*Two cutting edges for efficient material removal
*M3x7 Torx screw; T8 key for secure clamping

Consistent cutting performance and proven compatibility

The cutter is built around the proven concept of an indexable insert system, allowing cost-effective edge changes while maintaining high process stability. With a 16 mm shank and an overall length of 110 mm, the tool provides a balanced combination of rigidity and reach for typical milling set-ups. The use of LNMX 0603 inserts supplied by Korloy ensures wide availability of grades and edge geometries, which translates into predictable tool life and controlled cutting forces. This configuration reduces machine downtime because inserts are rotated or replaced quickly, while the solid shank diameter supports repeatable concentricity in standard holders.

Secure clamping and straightforward maintenance

Retention is handled by a M3x7 Torx screw secured with a T8 key, a straightforward system that keeps the insert firmly seated under cutting loads. The simple screw clamping eliminates complex set-up routines and lowers the risk of improper seating, which supports consistent part quality. Because insert handling and screw torque are standardised, maintenance routines are faster and less error-prone, helping to keep production throughput steady when frequent insert changes are required in batch production or multi-shift operations.

Designed for demanding machining with clear process benefits

Featuring two cutting edges, this indexable end mill is configured for stable chip formation and efficient material removal on shoulders and faces. The limited number of active edges reduces cutting force peaks and simplifies chip management, especially in interrupted cuts or when machining tougher materials. The tool’s geometry and insert compatibility make it suitable for a range of tasks where a compromise between aggressiveness and surface finish is required, offering measurable gains in cycle time without sacrificing repeatability.

Integration into the workshop and supply reliability

As a component from Teknik Makina, the cutter fits into established tooling systems and procurement workflows. The S284TM is compatible with common toolholders that accept a 16 mm shank, simplifying inventory and reducing the need for specialised arbors. Sourcing through a trusted distributor provides quick access to replacement inserts and spare screws, ensuring that the machining cell remains productive. For buyers seeking dependable supply and technical guidance, this tool is positioned to minimise supplier-related risks while supporting sustained production.

For tailored application advice or to secure supply of Teknik Makina indexable tooling, contact Metav Werkzeuge in Emmerich: info@metav-werkzeuge.com or +49 2822 7131930 — specialists are available to discuss tooling integration and insert grades for specific materials.

Technical Data

• Article number: S284TM
• Manufacturer: Teknik Makina
• SKU: S284TM
• ECLASS: 21180806
• ETIM: EC011860

Facts

• Diameter: 16 mm
• Shank diameter (nominal): 16 mm
• Overall length: 110 mm
• Cutting edges: 2
• Retention screw: M3x7
• Torx key size: T8

Special features

• Compatible inserts: LNMX 0603
• Compatible insert manufacturer: Korloy
• Product type: Indexable end mill / shank cutter
• Intended use: Demanding machining operations
• Title (shop): Schaftfräser for Korloy LNMX 0603 indexable inserts

FAQ

Which insert type fits this cutter?
The cutter accepts LNMX 0603 indexable inserts; insert compatibility and edge options are specified for the S284TM indexable end mill by Teknik Makina.

What shank size is required for the toolholder?
A 16 mm shank holder is required; the S284TM is manufactured to match standard 16 mm toolholder interfaces.

How many cutting edges does the tool have and what is the advantage?
The tool features two cutting edges, which favour stable cutting and simplified chip control for shoulder and face milling tasks.

Which screw and key are used for insert clamping?
Insert clamping is via a M3x7 Torx screw tightened with a T8 key to ensure secure retention under load.

Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
