Teknik Makina Shank milling cutter S472TM — 17 mm diameter, 2 flutes, for 4NKT 0603 indexable inserts

The Shank milling cutter S472TM is a solid shank cutter designed for use with 4NKT 0603 indexable inserts, optimised for stable slotting and profile milling in CNC and machining-centre applications.

• Compatible with Taegutec 4NKT06 inserts
• 17 mm cutting diameter for mid-range routing
• 16 mm shank for high rigidity
• Secure Torx M3x6,5 clamping with T8 key

Reliable clamping and insert compatibility for fast changeovers

The Teknik Makina tool is engineered around fast, reproducible insert clamping. The combination of a Torx M3x6,5 clamping screw and a T8 key ensures secure seat retention and simple replacement of the indexable inserts. As the cutter accepts Taegutec type 4NKT06 inserts, shops benefit from broad insert availability and flexible grade choice, reducing downtime and simplifying inventory management for repetitive series production.

Precision geometry that improves chip control and surface finish

With a 17 mm cutting diameter and 2 flutes, this milling tool delivers a balance between material removal rate and surface quality. The geometry is optimised to promote consistent chip evacuation and reduced cutting forces, which helps to maintain cycle-time stability. A 22 mm cutting length provides sufficient engagement for common slotting and shoulder operations while avoiding excessive overhang that would compromise accuracy.

Built for rigidity and repeatable accuracy in CNC set-ups

A 16 mm shank diameter and a total length of 150 mm overall length provide a compact, stiff toolholder interface that reduces runout and deflection during heavier passes. The assembly’s modest mass — approximately 0.241 kg — makes it easier to handle during tool changes and minimises inertial loading on high-speed spindles. This mechanical stability translates into predictable tool life and repeatable dimensional results across batches.

Supply reliability and expert backing from Metav

Delivered via Metav’s European distribution network, the cutter benefits from a stocked and quality-filtered supply chain centred in Emmerich. Metav’s long-standing presence and broad product range support workshop consolidation and make it straightforward to source matching inserts, spares and complementary tooling. Confidence in supply helps maintain planned production schedules and reduces the risk of unplanned machine downtime.

Contact Metav Werkzeuge to discuss suitability for specific materials and machining strategies, or to arrange supply of Teknik Makina cutting tools — call +49 2822 7131930 or email info@metav-werkzeuge.com

Technical Data

• Article number: S472TM
• Manufacturer: Teknik Makina
• Product: Shank milling cutter for 4NKT 0603 indexable inserts
• ECLASS: 21180806
• ETIM: EC011860

Facts

• Cutting diameter: 17 mm
• Shank diameter: 16 mm
• Cutting length: 22 mm
• Overall length: 150 mm
• Number of flutes: 2
• Weight: 0.241 kg
• Torx screw: M3x6,5
• Torx key: T8

Special features

• Compatible with Taegutec 4NKT06 inserts
• Suitable for indexable insert machining
• Files available: 62de7e510f56dbb4de4dbf07, 62de7ee6bd24461b3d5f7a72
• SKU: S472TM

FAQ

What inserts fit this shank milling cutter?
The cutter accepts 4NKT06 indexable inserts and is listed as compatible with Taegutec inserts for that size.

Is the clamping screw type industry standard?
Yes, the tool uses a Torx M3x6,5 clamping screw operated with a T8 key for standardised, secure insert retention.

What are the key dimensions to check for holder compatibility?
Confirm a 16 mm shank holder and a toolholder able to accommodate a 150 mm overall length; these dimensions match the cutter’s design.

Can this tool be used for slotting and profile milling?
The 17 mm diameter and 22 mm cutting length make the cutter suitable for typical slotting and shoulder milling operations in CNC environments.
