150mm Shank Milling Cutter for VCGT 1604 Indexable Inserts, 3 Flutes, 32mm Shank Diameter - Teknik Makina

Benefit from a rigid, indexable-insert solution that combines a 40 mm cutting diameter, a 32 mm shank and three cutting edges for stable metal removal; the tool delivers consistent performance with a 60 mm cutting length and is compatible with VCGT 1604 inserts. Order via Metav Werkzeuge or contact their consultants for application advice.

Shank cutter S714TM — 40 mm diameter, for VCGT 1604 indexable inserts (Teknik Makina)

The Shank cutter S714TM is an indexable-insert milling head engineered for facing and shoulder milling in industrial CNC applications where repeatable results and secure clamping are required.

• 40 mm cutting diameter
• Compatible with VCGT 1604 inserts
• Three cutting edges for stable removal
• 32 mm shank for high rigidity

Consistent metal removal with fewer passes

The design focuses on cycle-time reduction through stable cutting geometry and a three-edge configuration that spreads cutting forces evenly across the insert set. Reduced vibration and a robust body diameter enable higher metal removal rates without compromising surface finish; this is particularly beneficial when machining shoulders and faces where dimensional stability matters. The combination of a 40 mm diameter and a 60 mm cutting length provides an extended effective cutting area while maintaining rigidity for repeatable results.

Secure clamping and easy insert replacement

A practical clamping solution using a torx screw M4x10 and the supplied T15 key ensures secure retention of the VCGT inserts and fast index changes. The shank geometry with a 32 mm diameter minimises runout and increases tool life by improving stability in the holder. For workshops integrating indexable tooling, the concept simplifies maintenance and reduces downtime because inserts can be rotated or replaced quickly without full tool changeover.

Practical integration in CNC setups

The cutter is intended for professional cutting-tool contexts and pairs with standard indexable-insert holders and toolholders compatible with the stated shank size. The relatively low mass of 0.951 kg and an overall length of 150 mm support versatile machine allocation while preserving balance at machining speeds. Clear technical match to VCGT 1604 inserts streamlines procurement and tooling strategies for production lines that favour indexable solutions over solid-carbide alternatives.

Contact Metav Werkzeuge for tailored application guidance on the S714TM shank cutter and secure reliable supply from Emmerich, including compatibility checks and delivery details

Technical data

• Article number: S714TM

• Manufacturer: Teknik Makina

• Compatible inserts: VCGT 1604

• Cutting diameter: 40 mm

• Shank diameter: 32 mm

• Cutting length: 60 mm

• Number of cutting edges: 3

• Overall length: 150 mm

• Weight: 0.951 kg

• Torx screw: M4x10

• Torx key: T15

Facts

• SKU: S714TM
• Suitable insert type: VCGT 1604
• Diameter (D): 40 mm
• Shank (d): 32 mm
• Cutting length (l): 60 mm
• Total length (L): 150 mm
• Weight: 0.951 kg

Design & features

• Indexable-insert milling head
• Three cutting edges for balanced cutting forces
• Torx clamping for fast insert changes
• Robust body for reduced vibration
• Suitable for facing and shoulder milling

FAQ

What inserts fit this cutter?
The cutter is designed for VCGT 1604 indexable inserts; compatibility is specified for this insert size and format.

Which shank size is required in the toolholder?
A toolholder accepting a 32 mm shank is required to ensure correct clamping and minimum runout with this cutter.

How many cutting edges does the tool have and what is the benefit?
The tool has three cutting edges, which balances cutting forces and helps to reduce vibration for smoother machining and longer insert life.

Is the clamping hardware included and what is the screw type?
The cutter uses a torx screw M4x10 and a T15 key for insert clamping, enabling quick and secure insert changes.

For which machining tasks is this cutter best suited?
It is intended for facing and shoulder milling in CNC setups where indexable inserts and repeatable geometry are preferred.

Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
