1-7/8" Collet Chuck V-Clamp Style 120x84mm, 47.63mm Jaw Depth - Vertex
€11.28
Product information "1-7/8" Collet Chuck V-Clamp Style 120x84mm, 47.63mm Jaw Depth - Vertex"
Efficient precision clamping and a compact footprint combine to improve setup speed and machining consistency; order the collet directly via Metav Werkzeuge or consult our specialists for application advice.
VCL-2C collet — Vertex precision clamping, 1-7/8" opening, compact 120×84 mm
The VCL-2C is a precision collet intended for secure workpiece retention in machining and light workholding applications, offering a defined opening for standardised clamping.
- Precision clamping for consistent concentricity
- 1-7/8" bore for oversized toolholders
- Compact 120×84 mm footprint
- Lightweight design 0.22 kg
Reliable concentricity for repeatable results
The collet is engineered to provide precision clamping that helps maintain concentricity across repeated setups. By centring the workpiece accurately within the holder, the clamping sleeve reduces runout and contributes to consistent machining tolerances, which translates into fewer rejects and less rework. A focused design for axial alignment ensures stable cutting conditions and predictable outcomes in serial production.
Space-saving format that eases workshop workflows
With a compact 120×84 mm footprint and lightweight construction of 0.22 kg, this clamping component minimises the space required in storage and on the workbench. The modest dimensions support efficient tool changes and simpler handling during fixture preparation. As a result, throughput can be improved where bench or turret space is at a premium, while still retaining robust clamping performance suitable for routine shopfloor tasks.
Faster setups through consistent clamping behaviour
Consistent mechanical behaviour is the foundation for reduced setup times. The collet's geometry delivers reliable grip and repeatability, helping to shorten alignment and verification steps between jobs. Reduced variation in clamping force supports quicker measurement cycles and easier interchangeability of parts, enabling operators to maintain machining momentum and keep production schedules on track.
Transparent identification and industrial compatibility
Manufactured by Vertex, the component is documented for straightforward procurement and inventory control, with clear identifiers for ordering and classification. The plain specification of the opening and dimensions enables straightforward matching to compatible toolholders and machine spindles. Where exact machine compatibility or integration questions arise, the technical data provides a concise reference for selection and planning.
Contact Metav Werkzeuge for procurement and application guidance on Vertex collets such as the VCL-2C — email info@metav-werkzeuge.com or call +49 2822 7131930 for tailored advice and fast supply from Emmerich
Technical specifications
- SKU: VCL-2C
- GTIN: 4061905083921
- ECLASS: 21041712
- Designation: Collet
Core dimensions
- Opening: 1-7/8"
- Overall dimensions: 120×84 mm
- Clamping depth: 47.63 mm
- Weight: 0.22 kg
Features & references
- Brand: Vertex
- Image assets available
- Category: Clamping technology / collets
FAQ
What clamping diameter does this component provide?
The VCL-2C collet offers an opening of 1-7/8", sized for workpieces and toolholders that match this nominal bore.
What are the overall dimensions and weight for storage planning?
Overall dimensions are 120×84 mm and the unit weight is 0.22 kg, simplifying storage and handling calculations.
How does the clamping geometry affect machining accuracy?
The clamping geometry of this collet promotes consistent concentricity and repeatability, which supports tight machining tolerances and reduced rework.
Which toolholders or spindles is this compatible with?
Compatibility is determined by the 1-7/8" opening and standard collet interfaces; verify the receiving toolholder or spindle specification against these nominal values for correct pairing.
What identifiers should be used when ordering or specifying this part?
Use the SKU VCL-2C and GTIN 4061905083921 for unambiguous ordering and classification.
Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
