VCT-407 Precision Cross Slide Table by Vertex — 100 x 180 mm table, 35 kg load

The VCT-407 is a precision cross slide table engineered for accurate positioning in machine shops and inspection rigs, designed to support small fixtures and measuring tasks with reliable repeatability.

• Compact 100 x 180 mm working table
• High positioning accuracy 0.02 mm
• 35 kg maximum load capacity
• T-slot 3/8 inch for secure fixturing

Repeatable positioning for precise results

The cross slide is built to deliver consistent positioning: with a specified positioning accuracy of 0.02 mm, the unit reduces setup variability and shortens inspection cycles. The working surface of 100 x 180 mm allows for controlled movement across two axes while maintaining alignment; this is beneficial where sub-millimetre tolerances are required. The mechanism is designed to translate manual adjustments into accurate linear displacement, so measuring and machining tasks proceed with predictable outcomes and fewer reworks.

Sturdy construction that supports demanding setups

A focus on durability ensures that the table copes with everyday workshop stresses. The assembly provides a maximum load of 35 kg while keeping a modest overall weight of 12 kg, balancing portability and stability. This combination allows the unit to be mounted on benches or integrated into small machine stations without excessive support structures. The design minimises deflection under load, which maintains positional accuracy during clamping and operation and supports reliable process control in production and measurement environments.

Secure fixturing and straightforward integration

The integrated T-slot 3/8 inch on the top plate simplifies fixture attachment and repeatable clamping, enabling direct mounting of vices, probes or small tooling plates. The cross slide’s layout supports modular fixturing concepts commonly used in quality control and light machining, making it easier to interchange setups while preserving datum references. The product’s configuration reduces setup time and helps maintain consistent datum points between jobs, which improves throughput and traceability in batch processes.

Practical handling and maintenance for workshop use

Operation and upkeep are uncomplicated: the unit’s dimensions and mechanical design favour quick cleaning and periodic lubrication routines without the need for specialised tools. For workshops upgrading their measuring or positioning capabilities, the table integrates with standard clamping hardware and measuring devices, providing a pragmatic path to finer control. The compact footprint and mechanical simplicity make the table a pragmatic choice where space is limited but precision remains essential.

Contact Metav Werkzeuge in Emmerich for a detailed application consultation on the Vertex VCT-407; email info@metav-werkzeuge.com or call +49 2822 7131930 to discuss fixturing and delivery options

Technical Data

• Article number: VCT-407
• Manufacturer: Vertex
• GTIN: 4061905083327

Facts

• Table size: 100 x 180 mm
• Base size: 100 x 130 mm
• Positioning accuracy: 0.02 mm
• Weight: 12 kg
• Maximum load: 35 kg
• T-slot: 3/8 inch

Special features

• Precision cross slide table design
• T-slot for secure clamping
• Compact footprint for bench or machine integration

FAQ

What level of accuracy can be expected from this cross slide table?
The VCT-407 provides a positioning accuracy of 0.02 mm, suitable for precision measuring and light machining tasks where sub-millimetre repeatability is required.

What is the maximum load the table can support?
The unit is specified for a maximum load of 35 kg, allowing secure mounting of small fixtures and measuring devices without significant loss of positional stability.

Which table and base dimensions are available for mounting space planning?
The working plate measures 100 x 180 mm and the base footprint is 100 x 130 mm, making the table suitable for compact benches and integration into inspection rigs.

How does the T-slot support fixturing?
The T-slot 3/8 inch on the top surface accommodates standard clamping hardware, enabling repeatable and secure attachment of vices, tooling plates or probes.

Is the VCT-407 suitable for integration with measuring equipment?
Yes, the precision cross slide layout and compact dimensions make the VCT-407 compatible with common inspection setups and measuring instruments where controlled two-axis movement is required.

Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
