430x400mm Halogen Lamp Dust-Protected, 55W, IP67/IP20 - Vertex

Take advantage of a robust, dust-protected halogen lamp combined with an adjustable arm and flexible voltage options for reliable workshop illumination; order directly via Metav Werkzeuge or ask the consultants for advice on system integration.

VHL-300L Halogen Lamp by Vertex — dust-protected light with adjustable arm

The VHL-300L is a dust-protected halogen lamp intended for inspection and workshop illumination, offering a compact adjustable arm for targeted lighting and multi-voltage operation.

• Dust-protected lamp head with IP67 rating
• Adjustable arm 430 x 400 mm
• Compatible with 55 W incandescent bulb
• Supplied with 1.8 m power cable

Precise, stable illumination for inspection and measuring work

The combination of a dust-protected light head with an IP67 rating and an articulated arm delivers consistent, glare-free illumination exactly where it is needed. The sealed lamp head keeps dust and contaminants away from the light source, reducing the frequency of cleaning and the risk of inspection errors. Because the lamp accepts a standard 55 W incandescent bulb, replacement is straightforward and cost-effective, while the fixed luminous characteristics of a halogen source ensure accurate visual contrast for fine tasks such as gauging and inspection.

Flexible mounting and targeted reach to increase workflow efficiency

An articulated arm measuring 430 x 400 mm enables precise positioning over benches, measuring stations or machine tables, improving ergonomics and reducing the time spent reorienting workpieces. The unit is lightweight at 2.4 kg, which simplifies handling and mount adjustments without imposing excessive load on fixtures. The included 1.8 m cable supports straightforward installation and versatile placement close to power sources, and the lamp can be configured for 110 / 220 / 380 / 24 V operation to suit diverse industrial power supplies.

Robust design that reduces downtime and maintenance

With the lamp head sealed to IP67 and the arm meeting IP20 protection, the VHL-300L separates the sensitive lighting element from the kinematic components, prolonging service life under workshop conditions. The dust-protected construction minimises ingress-related failures and limits maintenance interruptions. The simple electrical layout and standard bulb compatibility further cut servicing time, meaning the illumination system contributes to steady production flow rather than unexpected stoppages.

Versatile applications and straightforward integration in the workshop

Engineered for focused task lighting, the unit supports inspection benches, measuring stations and general-purpose workshop illumination where reliable, high-contrast light is required. The compact footprint and articulated reach make it suitable for retrofitting to existing fixtures or adding to new workstations. Supplied by Vertex, the lamp aligns with common industrial workflows and can be specified where predictable, high-quality illumination is essential for visual inspection and manual measuring tasks.

Contact Metav Werkzeuge for tailored advice on the Vertex VHL-300L, delivery from Emmerich and assistance with system compatibility — info@metav-werkzeuge.com / +49 2822 7131930

Technical data

• Article number: VHL-300L
• GTIN: 4061905083457
• Product type: Halogen lamp
• Protection: Dust-protected

Facts

• Weight: 2.4 kg
• Arm dimensions: 430 x 400 mm
• Cable length: 1.8 m
• Voltage: 110 / 220 / 380 / 24 V (configurable)
• Compatible bulb: 55 W incandescent bulb

Special features

• Lamp head: IP67
• Arm: IP20
• Supplied accessory: 1.8 m cable
• Intended use: Workshop and inspection lighting
• Manufacturer: Vertex

FAQ

What type of bulb does the VHL-300L use?
The VHL-300L is compatible with a 55 W incandescent (halogen) bulb; the standard fitting provides predictable luminous output for inspection tasks.

Is the lamp suitable for dusty environments?
Yes, the light head of the VHL-300L is dust-protected and rated IP67, making it suitable for environments with particulate exposure while the arm carries IP20 protection.

Can the VHL-300L be used with different power supplies?
The VHL-300L supports 110 / 220 / 380 / 24 V configurations, allowing integration into various industrial power systems; specify the required voltage at purchase.

How large is the reach provided by the lamp arm?
The articulated arm measures 430 x 400 mm, offering targeted positioning for benches, measuring stations and close-up inspection tasks.

Is a power cable included with the lamp?
Yes, the VHL-300L is supplied with a 1.8 m power cable to simplify installation near standard power outlets.

Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
