150mm Precision Parallel Set 8pcs (5×25/31/38/44×150mm), Accuracy 0.01mm - Vertex

Take advantage of precise positioning and a complete set of sizes for dependable setup work. The combination of accuracy 0.01 mm, a compact footprint and a full range of paired parallels ensures smooth fixturing and quicker changeovers. Order the set directly via Metav Werkzeuge or contact our consultants for tailored advice.

Precision Parallel Set VP-163 by Vertex — high-accuracy parallels, 0.01 mm

A Precision Parallel Set VP-163 designed for secure workpiece support and repeatable set-ups in machining, inspection and tool preparation

• High positioning accuracy 0.01 mm
• Includes four paired sizes for versatile use
• Compact dimensions 175 x 85 x 55 mm
• Lightweight 1.7 kg for easy handling

Reliable positioning for repeatable setups

High positioning accuracy is the primary advantage when setting up jigs, vises or inspection fixtures. With a rated accuracy of 0.01 mm, these parallels give a measurable basis for repeatable alignment, reducing set-up time and rework. The precise tolerance allows for consistent reference planes during milling, drilling and measurement tasks, which improves throughput and lowers the risk of scrap. The set supports process stability through predictable fixturing behaviour and better control of part geometry across batches.

Versatile size range for flexible fixturing

A pragmatic selection of paired sizes makes the set suitable for a wide range of component dimensions. The delivery includes 2x 5x25x150 mm, 2x 5x31x150 mm, 2x 5x38x150 mm and 2x 5x44x150 mm, providing 8 pieces arranged as matched pairs that simplify clamping arrangements. These size options enable users to choose the most suitable support height and contact width for diverse workpieces, from small brackets to longer bars, without compromising stability. The result is faster fixturing decisions and fewer tool offsets.

Compact handling and straightforward workshop integration

With overall dimensions of 175 x 85 x 55 mm and a weight of 1.7 kg, the set is compact enough to be stored in standard tool cabinets and carried between workstations. Its modest footprint helps shops streamline workstation layout and maintain an organised tooling system, which contributes to faster setup cycles. The compact design also supports portable inspection tasks at the machine or bench, while the clear size assortment reduces the need for multiple separate purchases.

Contact Metav Werkzeuge for expert guidance on integration of the VP-163 into existing workflows or to request full technical documentation – email info@metav-werkzeuge.com or call +49 2822 7131930

Technical data

• SKU: VP-163
• GTIN: 4061905087240
• ECLASS: 21170610
• Set: yes
• Pieces per set: 8

Facts

• Accuracy: 0.01 mm
• Weight: 1.7 kg
• Dimensions: 175 x 85 x 55 mm

Contents and special features

• Contents: 2x 5x25x150 mm; 2x 5x31x150 mm; 2x 5x38x150 mm; 2x 5x44x150 mm
• Product type: precision parallels set
• Brand: Vertex
• SKU reference: VP-163

FAQ

What applications are the parallels suited for?
The parallels in this set are intended for workpiece support during machining, inspection and tool setup; the Precision Parallel Set VP-163 by Vertex is suitable for parts that require a stable reference plane and repeatable positioning.

How many pieces are included and how are they arranged?
The delivery contains 8 pieces arranged as four matched pairs: 2x 5x25x150 mm, 2x 5x31x150 mm, 2x 5x38x150 mm and 2x 5x44x150 mm, allowing flexible selection of support heights.

What level of accuracy can be expected?
The set is specified with an accuracy of 0.01 mm, providing a reliable tolerance band for repeatable setups and precision fixturing tasks.

Can the parallels be used directly at the machine or for inspection benches?
Yes, the compact dimensions and balanced weight make the set suitable for both bench inspection and direct use at machine tools; the VP-163 supports quick transfers between stations.

Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
