40mm Threaded Rod With Magnet, 30 Kg Load Capacity - Vertex
€54.96
Product information "40mm Threaded Rod With Magnet, 30 Kg Load Capacity - Vertex"
Compact magnetic fixturing is achieved with a 40 mm diameter body and an integrated magnet, delivering a secure 30 kg holding capacity for reliable workshop use; order the part via Metav Werkzeuge or consult the team for application advice.
Vertex Threaded Rod VSJM-50 — magnetic fixturing, 40 mm diameter
The Threaded Rod with Magnet is a compact fixturing element designed for rapid magnetic clamping in workshop and light industrial setups.
- Magnetic fastening for quick securing
- 40 mm diameter for stable support
- Rated max load 30 kg
- Lightweight 0.4 kg for easy handling
Faster setup through secure magnetic holding
The integrated magnet provides magnetic holding that significantly reduces setup time compared with mechanical clamping solutions. With a 40 mm diameter and a rated max load of 30 kg, the component is dimensioned to deliver consistent holding force for jigs, temporary fixtures and small assembly tasks. The magnetic function allows workpieces to be positioned and repositioned swiftly, which improves throughput and reduces non-productive time. Technical terms such as “holding capacity” refer to the force the magnet exerts on a ferrous surface; in practice this means stable support during light machining and inspection operations.
Compact format that supports flexible workflows
A compact height of 47 mm and a low mass of 0.4 kg make the rod easy to handle and integrate into existing setups. The small footprint is advantageous where space on tooling plates or workbenches is limited, and the modest weight simplifies storage and transport between workstations. The form factor suits modular fixturing systems and portable test rigs, enabling faster changeovers without the need for heavy clamping hardware. For users with varied batch sizes, the component’s portability contributes to a more agile production flow while maintaining reliable contact with workpieces.
Consistent performance and clear industrial use cases
Manufactured under the Vertex brand, the VSJM-50 is specified for workshop fixturing, temporary holding during assembly and inspection operations where magnetic attachment is appropriate. The design combines a straightforward mechanical interface with the practical benefits of a magnetised element, making it suitable for applications such as toolroom setups, light milling jigs and gauge fixtures. Material information is not specified in the available data, so compatibility is assumed for ferrous substrates only; the magnetic function will not perform on non-ferrous materials. The clear specification of diameter, height and load rating supports selection decisions and reduces the need for trial-and-error in procurement.
For reliable magnetic fixturing with the Vertex VSJM-50, contact Metav Werkzeuge for purchasing and application guidance via info@metav-werkzeuge.com or by phone on +49 2822 7131930
Technical Data
- Article number: VSJM-50
- GTIN: 4061905084164
- Brand: Vertex
- ECLASS: 23110301
Facts
- Diameter: 40 mm
- Height: 47 mm
- Max. load: 30 kg
- Weight: 0.4 kg
Special features
- Integrated magnet
- Compact design for fixturing
- Suitable for workshop applications
FAQ
What load can the threaded rod carry?
The Vertex threaded rod VSJM-50 is rated for a maximum load of 30 kg.
Is the magnetic function suitable for vertical fixturing?
The integrated magnet provides secure holding on ferrous surfaces for both vertical and horizontal positioning in light-duty applications.
What are the key dimensions to consider for integration?
Diameter 40 mm, height 47 mm and weight 0.4 kg are the primary dimensions to plan for when incorporating the part into fixtures.
Is the material of the rod specified in the product data?
The available product data does not specify the material used for the component.
Which applications are typical for this component?
Common uses include workshop fixturing, temporary clamps for assembly and inspection fixtures where magnetic attachment to ferrous materials is acceptable.
Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
