160mm Indexing Head With Three- Or Four-Jaw Chuck 1° Division, 139mm Height - Vertex

Take advantage of the combination of compact design, reliable 1° indexing and flexible chuck options for predictable machining results. Order the unit directly via Metav Werkzeuge or consult the team for specification support.

VSR-6 Simple Dividing Head (Vertex) — 1° indexing, 160 mm diameter

A practical simple dividing head, VSR-6, designed for angular indexing and rotational positioning in milling and preparatory fixture work.

• 1° indexing resolution for accurate division
• 160 mm diameter for stable workpiece support
• Three- or four-jaw chuck option for versatile clamping
• Compact 139 mm height for space-efficient mounting

Precision indexing for consistent series production

The Vertex VSR-6 delivers reliable 1° indexing, enabling straightforward division steps and consistent angular set-ups for repetitive tasks. The precise indexing mechanism reduces time spent on re-centring and adjustment, supporting predictable cycle times and less scrap. Built to assist common workshop operations, the indexing capability is particularly beneficial in small-batch milling, peripheral engraving and other tasks that demand repeatable angular positioning. The robust mechanism prioritises repeatability and stable performance under routine use.

Compact footprint that aids machine-table organisation

With a working diameter of 160 mm and an overall height of 139 mm, the device fits neatly on standard machine tables and rotary fixtures while keeping the centre of gravity low. The mass of 17.8 kg contributes to inherent vibration damping, which helps to produce cleaner cuts and steadier rotation without adding complex support structures. The compact dimensions make the unit straightforward to integrate into existing setups, reducing the need for extensive fixture redesign and preserving usable table space for auxiliary tooling.

Versatile chucking for adaptable clamping tasks

Supplied with a three- or four-jaw chuck option, the indexing device accommodates both round and irregular workpieces, enhancing workshop flexibility without the immediate need for bespoke adaptors. The chuck options support a range of common clamping scenarios, from concentric turning to eccentric workholding, and simplify transitions between different part families. As a simple dividing head, the design focuses on essential functionality — sturdy clamping, accurate division and straightforward mounting — to keep set-up times low and throughput high.

Backing and service from an experienced precision partner

Metav Werkzeuge acts as a committed distribution and quality filter for the European market, offering practical purchasing and logistics from Emmerich. With a long-standing product range and a wide customer base, Metav provides access to technical advice and a controlled supply chain that supports installation and selection decisions. The combination of an established dealer network and a broad product portfolio helps maintain continuity in supply and simplifies material planning for workshops and small production facilities.

For tailored advice on chuck options and mounting configurations, contact Metav Werkzeuge in Emmerich to discuss the Vertex VSR-6 and confirm the specification that best suits the application.

Technical data

• SKU: VSR-6
• GTIN: 4061905083648
• ECLASS: 21020590

Facts

• Diameter: 160 mm
• Height: 139 mm
• Weight: 17.8 kg
• Indexing resolution: 1°

Special features

• Three- or four-jaw chuck option
• Simple dividing head for angular indexing
• Manufacturer: Vertex
• Images: vsr-6-main.jpg, vsr-6-detail.jpg

FAQ

What indexing accuracy does the device offer?
The unit provides a 1° indexing resolution, allowing straightforward and repeatable angular divisions for common workshop tasks.

Which chuck options are available for clamping?
The device is supplied with a three- or four-jaw chuck option to support a variety of round and irregular workpieces without immediate need for special adapters.

Is the dividing head suitable for standard milling machines?
Yes, the simple dividing head is intended for integration on typical milling tables and rotary fixtures where accurate angular indexing is required.

What are the key dimensions and mass of the unit?
Key dimensions are a diameter of 160 mm, height 139 mm and a mass of 17.8 kg, which supports stability and vibration damping during operation.

Who manufactures the product and what is the SKU?
The product is manufactured by Vertex; the SKU is VSR-6 and the GTIN is 4061905083648.

Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
