156x150mm Swivel Heavy-Duty Tilting Rotary Table, 30kg Horizontal/12kg Vertical Capacity, 115mm Height - Vertex

Take advantage of the combination of robust load capacity, a compact precision table, and a swivelling design that improves set-up flexibility for small-series production and inspection tasks; order the clamping table directly via Metav Werkzeuge or consult our specialists for application advice.

VUT-1515 Clamping table by Vertex — heavy‑duty, swivelling precision fixture

A VUT-1515 clamping table engineered for heavy loads and swivelling positioning, ideal for workshop fixtures, inspection benches and precision assembly tasks

• Robust base 180×285 mm for stable mounting
• Swivelling design for versatile positioning
• Precision table 156×150 mm for small workpieces
• Rated 30 kg horizontal, 12 kg vertical load

Stability that keeps measurements and machining consistent

The VUT-1515 delivers a stable platform for demanding workshop tasks thanks to its substantial base footprint of 180×285 mm and a mass of 17.6 kg, which together reduce vibration and movement during clamping or inspection. This stability translates into fewer re‑setups and more reliable results when working with small components on the 156×150 mm measuring surface. The design minimises micro‑motion, aiding repeatable positioning and supporting quality‑control procedures where consistent alignment is required.

Flexible positioning for complex setups

A swivelling top enables faster orientation of the workpiece without the need for repeated reclamping, making the unit suitable for fixtures that require multiple access angles. The swivel function supports efficient workflow in assembly and measuring stations by allowing quick alignment changes while maintaining the clamped part’s datum. The compact height of 115 mm keeps the centre of gravity low, improving handling when rotating loads and preserving secure contact between the workpiece and the measuring table.

Built for heavy‑duty metrology and small production runs

Rated to carry 30 kg horizontally and 12 kg vertically, this clamping table is specified for substantial single‑component loads and fixturing of heavier assemblies on inspection benches. The load ratings permit use with robust measuring instruments and small machine tools where a rigid support is essential. The combination of a precision work surface and high load tolerance reduces the need for auxiliary supports, simplifying setup and shortening cycle times in light production and repair workshops.

Designed for integration and dependable service life

With a compact footprint and standardised mounting dimensions, the clamping fixture fits easily into existing benches or metrology tables, allowing straightforward integration into workshop layouts. The unit’s construction emphasises longevity and consistent performance in repetitive tasks, supporting a predictable maintenance schedule and reducing downtime. Sourcing through Metav Werkzeuge brings additional assurance: supply is coordinated from a European quality filter in Emmerich, ensuring reliable availability and traceable provenance.

Contact Metav Werkzeuge for specification support and to arrange fast delivery of the Vertex VUT-1515 clamping table for the workshop or inspection bench

Technical Data

• Article number: VUT-1515
• GTIN: 4061905084034
• eClass: 21020702
• ETIM: EC001959

Facts

• Weight: 17.6 kg
• Height: 115 mm
• Measuring table: 156×150 mm
• Base footprint: 180×285 mm
• Load capacity horizontal: 30 kg
• Load capacity vertical: 12 kg

Special features

• Swivelling design for versatile positioning
• Suitable for heavy loads
• Compact precision work surface
• Brand: Vertex

FAQ

What maximum load can the clamping table carry horizontally?
The clamping table from Vertex is rated for a 30 kg horizontal load capacity, suitable for substantial single components on inspection or assembly benches.

Is the work surface suitable for small, precision parts?
Yes, the 156×150 mm measuring table provides a compact, accurate platform for small‑part fixturing and measurement tasks.

Can the table be mounted on a standard metrology bench?
The VUT-1515’s base footprint of 180×285 mm and its compact height of 115 mm allow integration onto typical benches and inspection tables with standard mounting arrangements.

Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
