Prism Jaw Attachment VWS - Vertex
€67.45
Product information "Prism Jaw Attachment VWS - Vertex"
High-precision prism geometry and a compact, lightweight construction (0.26 kg) deliver stable, repeatable clamping and simplify fixture handling; order the Prism attachment jaw VWS directly via Metav Werkzeuge or consult our specialists for application advice.
Prism attachment jaw VWS – Precision prism jaw, compact 0.26 kg (Vertex)
The Prism attachment jaw VWS is a precision prism jaw designed for secure, repeatable clamping of cylindrical components in inspection and measuring fixtures.
- Precision prism geometry for secure clamping
- Compact design at 0.26 kg for easy handling
- Exact alignment for repeatable measurement results
Higher measurement reliability through precise prism geometry
The prism-shaped contact surface provides defined line contact with round workpieces, reducing lateral movement and enabling repeatable seating during successive checks. With a focus on precision, this prism jaw converts geometric fit into measurable benefits: consistent contact points mean fewer repositioning errors and more reliable dimension data in routine inspection tasks. The result is improved measurement accuracy with minimal additional effort.
Compact build that simplifies fixture integration
Weighing just 0.26 kg, the compact construction supports straightforward integration into existing inspection jigs and small vises without adding significant mass. The lightweight design eases handling during set-up and reduces fixture inertia, which is particularly useful where quick changeovers are required. Supplied as SKU VWS-VK-4, the component suits bench-top metrology environments where space and agility matter.
Practical applications and straightforward handling for shop use
Designed for the metrology sector, the prism jaw supports dimensional checks on shafts, pins and similar cylindrical parts, making it a practical choice for quality control and workshop measurement routines. As a prism jaw from Vertex, it offers clear functional advantages when used as a fixture insert or as an accessory to measuring stands: secure seating, consistent alignment and compatibility with common inspection workflows. Specification-led handling reduces set-up time and helps maintain throughput in small-batch inspection.
For tailored guidance on integrating the Vertex prism jaw into inspection workflows, contact Metav Werkzeuge in Emmerich for expert advice and prompt supply via info@metav-werkzeuge.com or by phone at +49 2822 7131930
Technical data
- Article number: VWS-VK-4
- GTIN: 4061905084690
- Brand: Vertex
Facts
- ECLASS: 21029205
- Weight: 0.26 kg
Special features
- Prism-shaped clamping surface
- Compact, lightweight design for fixtures
- Suitable for cylindrical workpieces
FAQ
What is the primary function of this prism jaw? The Prism attachment jaw VWS provides stable line contact for cylindrical workpieces, improving seating consistency and repeatability in dimensional inspections.
Which types of parts benefit most from this accessory? Round shafts, pins and similar cylindrical components benefit from the defined prism contact offered by the VWS-VK-4, aiding accurate measurement and reduced part movement.
How heavy is the item and why does that matter? The unit weighs 0.26 kg; this lightweight characteristic simplifies handling and integration into bench-top fixtures without significantly increasing fixture mass.
Is the prism jaw suitable for integration into existing measuring fixtures? Yes, the prism jaw is intended as an insert or accessory for inspection and measuring setups and can be fitted where a prism seating is required for cylindrical parts.
What identifiers should be used when ordering or specifying this part? Use SKU VWS-VK-4 and GTIN 4061905084690 when specifying the prism jaw for procurement or documentation.
Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
