1000-1500mm Micrometer With Modular Electronics, Colour Touchscreen, IP65, ISO17025 Calibrated - Microtech Metrology
€3,990.00
Product information "1000-1500mm Micrometer With Modular Electronics, Colour Touchscreen, IP65, ISO17025 Calibrated - Microtech Metrology"
Take advantage of the combination of modular construction, a 1,000–1,500 mm measuring range and ISO 17025 calibration for precise, reproducible inspections of large components; order the micrometer directly via Metav Werkzeuge or consult our specialists for integration advice.
Wide‑Range Modular Outside Micrometer (Microtech Metrology) — modular digital micrometer with wireless and USB data transfer
The Wide‑Range Modular Outside Micrometer is a modular measuring instrument designed for large‑format dimensional inspection in toolrooms, jig and fixture workshops and quality laboratories.
- Modular aluminium housing for easy transport
- Measuring range 1,000–1,500 mm
- IP65 protection for workshop use
- ISO 17025 calibration certificate included
High precision over long measuring spans
The modular design delivers consistent repeatability across a long measuring span, combining a measuring range of 1,000–1,500 mm with a verified accuracy of 0.028 mm and a fine readout step of 0.0001 mm. This places the instrument in the long category for calipers and micrometers, where stiffness and stability are crucial; the robust construction and large Ø50 mm measuring faces reduce bending and ensure reproducible results on shafts, housings and large assemblies. Included ISO 17025 calibration and the accompanying calibration certificate substantiate traceability and shorten internal validation procedures, helping to maintain audit‑ready measurement records.
Efficient data handling and Industry 4.0 compatibility
Measurement workflows are accelerated by integrated digital functions: wireless and USB data transfer, HID modes and a built‑in memory manager that stores 2000 values in a folder structure for rapid retrieval. The instrument supports synchronized connections to Microtech instruments and offers graphical output, statistics and time‑stamped records for trend analysis. Optional MODBUS RTU output enables direct integration into PLCs and industrial data networks, while the modular electronics and MICS system facilitate Industry 4.0 scenarios where continuous data flow and automated logging reduce manual transcription errors and inspection cycle times.
Rugged build for the workshop and mobile inspection teams
Machined from solid aluminium, the housing combines protective robustness with manageable weight and modular portability; the micrometer arrives as a two‑module assembly that simplifies transport and on‑site configuration. An IP65 rating protects internal electronics from dust and spray, making the instrument suitable for demanding shopfloor environments. The large measuring anvils (Ø50 mm) and sturdy frame are designed to withstand routine handling while maintaining the alignment required for long‑range measurements. Together, these features cut downtime and lower the risk of measurement variation during production checks.
For tailored advice on adapting this Microtech long‑range modular micrometer to existing inspection systems, or to secure delivery from Metav Werkzeuge in Emmerich, contact our technicians at Metav Werkzeuge for precise consultation and fast processing.
Technical data
- Article number: 110160155
- GTIN: 4061905040061
- Manufacturer: Microtech Metrology
- Measuring range: 1,000–1,500 mm
- Display: digital colour touchscreen
- Data output: Wireless + USB
- Protection class: IP 65
- Measuring faces: Ø50 mm
- Modules: 2
- Memory capacity: 2000 values
- Calibration: ISO 17025 certificate included
Facts
- Accuracy: 0.028 mm
- Resolution / Readout: 0.0001 mm
- Weight: 18 kg
- ECLASS: 21170328
- ETIM: EC003590
Special features
- Modular construction for transport and assembly
- CNC machined aluminium housing
- Industry 4.0 MICS microcomputer functions
- Wireless Microtech instrument synchronization
- USB HID data modes
- Optional MODBUS RTU for industrial integration
- IP65 workshop protection
FAQ
Is the instrument delivered calibrated? Yes. The Wide‑Range Modular Outside Micrometer from Microtech Metrology is supplied with an ISO 17025 calibration certificate included.
What data interfaces are available for automated logging? The unit supports wireless transfer and USB HID modes, plus optional MODBUS RTU for direct PLC integration, enabling automated capture of measurement data.
What measuring range and accuracy can be expected? The micrometer covers 1,000–1,500 mm with an accuracy of 0.028 mm and a readout step of 0.0001 mm, suitable for large assemblies and production checks.
Is the micrometer robust enough for shopfloor use? Yes. The machined aluminium housing and IP65 protection make it suitable for workshop conditions while preserving measurement stability.
Can stored measurement sets be reviewed or transferred? Stored values (up to 2000 values) are organised in folders and can be exported via the supported data interfaces for further analysis.
Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
