2200-2400mm Digital Micrometer Caliper With Friction Ratchet, IP65, ISO17025 Calibration Certificate - Microtech Metrology
€3,990.00
Product information "2200-2400mm Digital Micrometer Caliper With Friction Ratchet, IP65, ISO17025 Calibration Certificate - Microtech Metrology"
Take advantage of robust shop-floor protection, traceable ISO 17025 calibration and a wide 2,200–2,400 mm measuring span for reliable large-component control. Order the measuring solution directly via Metav Werkzeuge or request advice from our consultants.
Microtech Metrology Wide‑Range Digital Outside Micrometer 2200–2400 mm, IP65
The Microtech Metrology wide‑range digital outside micrometer is a heavy‑duty measuring instrument for length checks on long shafts, pipes and large assemblies, offering a high‑resolution digital readout and workshop‑grade protection.
- IP65-rated digital head
- ISO 17025 calibration certificate included
- Large-range 2200–2400 mm measuring span
- Ø50 mm hardened measuring faces
Precision and traceability for long‑length control
For production and inspection tasks that demand reproducible results over metres, the micrometer combines a fine resolution of 0.001 mm with an industrial accuracy specification of 0.045 mm, supported by a delivered ISO 17025 calibration certificate. This traceable certification documents measurement uncertainty and ensures results can be relied upon for quality control and audit purposes. The combination of stable mechanical guidance and a calibrated digital head reduces rework and supports process stability in serial manufacturing.
Built to withstand workshop conditions
The instrument is designed for harsh environments: the digital readout is IP65 rated against dust and splash water, while the measuring anvils are large Ø50 mm faces to distribute clamping forces on big workpieces. A friction ratchet ensures consistent contact force, limiting operator‑induced variation during repeat checks. Robust construction and substantial mass make the device suited to heavy‑duty handling and stationary metrology fixtures, so measurements remain reproducible during routine shop use.
Ready for use and easy integration into inspection routines
Delivery includes setting rods and a full calibration certificate, so the micrometer arrives ready for immediate deployment in the workshop or metrology room. The digital head provides a clear numeric display for quick readings and reduces transcription errors commonly associated with analogue instruments. Packs and spare parts are minimised by the straightforward mechanical design, making upkeep manageable and downtimes shorter.
Ideal fit for large component measurement and fixture use
With a measuring span classified as Extra‑Long (2,000–5,000 mm) and a specific range of 2200–2400 mm, this instrument suits tasks such as shaft dimensional checks, flange and pipe inspection, and fixture verification in toolrooms and heavy machining. The large contact area and calibrated status make the device particularly useful where repeatable contact geometry and documented traceability are required for production release or incoming inspection.
For technical advice or to discuss how the Microtech Metrology wide‑range digital outside micrometer fits into existing inspection processes, please contact Metav Werkzeuge for expert consultation and supply coordination
Technical Data
- SKU: 110172401
- GTIN: 4061905039447
- Manufacturer: Microtech Metrology
Core specifications
- Measuring range: 2,200–2,400 mm
- Minimum range: 2,200 mm
- Maximum range: 2,400 mm
- Resolution (display): 0.001 mm
- Accuracy: 0.045 mm
- Measuring faces diameter: Ø50 mm
- Weight: 27 kg
- Protection class: IP 65
Special features
- Digital micrometer head
- Friction ratchet
- Setting rods included
- Calibration certificate ISO 17025 included
- Wide‑range CertiMet digital micrometer (IP65 proof)
FAQ
Is the micrometer delivered calibrated? Yes. The Microtech Metrology wide‑range digital outside micrometer is supplied with a calibration certificate issued to ISO 17025 standards.
What measuring span does this instrument cover? The measuring span is 2,200–2,400 mm, placing it in the Extra‑Long category suitable for large shafts and assemblies.
Can it be used in a wet shop environment? The digital head has an IP65 rating, so it is protected against dust and low‑pressure water jets, making it suitable for typical workshop conditions.
What ensures consistent contact pressure during measurement? A built‑in friction ratchet provides uniform contact force to reduce operator‑induced variation during repeated measurements.
What is included with delivery? Delivery contains the digital micrometer with setting rods and an ISO 17025 calibration certificate; additional accessories are not automatically included.
Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
