25-50mm Tube Wall Thickness Micrometer Digital Friction Thimble, IP65, ISO 17025 Calibrated - Microtech Metrology
€299.00
Product information "25-50mm Tube Wall Thickness Micrometer Digital Friction Thimble, IP65, ISO 17025 Calibrated - Microtech Metrology"
Benefit from sub‑millimetre accuracy, robust IP65 protection and an ISO 17025 calibration certificate for immediate use in quality assurance; order the tube wall thickness micrometer directly via Metav Werkzeuge or ask our consultants if needed.
Microtech CertiMet TUBE – digital tube wall thickness micrometer (IP65, 25–50 mm)
The Microtech CertiMet TUBE is a purpose‑built digital micrometer for precise measurement of tube wall thickness in production, inspection and laboratory settings.
- IP65 aluminium housing for workshop environments
- 0.001 mm resolution with ±0.003 mm accuracy
- Friction thimble for reproducible measurement force
- Functions: mm/inch, origin and data hold
- Delivered with ISO 17025 calibration certificate
Precise measurement where repeatability matters
Built for traceable quality control, this micrometer offers a resolution of 0.001 mm and an accuracy of ±0.003 mm, delivering consistently measurable differences across production runs. The specified measuring range (25–50 mm) covers typical tube diameters while enabling wall‑thickness checks from 4.7 mm upwards. A rotating measuring spindle combined with a calibrated friction thimble reduces operator‑induced variability, so every reading is comparable and reproducible — a key requirement for inline inspection and final acceptance tests.
Robust construction for the shop floor and laboratory
The instrument combines a protective IP65 aluminium housing with workshop‑grade mechanical features to resist dust and coolant exposure. The friction thimble ensures a constant contact force, improving repeatability when multiple operators perform inspections. The rotating spindle design reduces wear on the anvils and stabilises contact during measurement. For specialised profiles, a custom tube anvil can be supplied on request to adapt the tool to non‑standard tubing without compromising measurement integrity.
Digital functions and calibration for audit‑ready workflows
Equipped with digital readout functions — mm/inch, origin and hold — the micrometer supports quick unit switching and secure capture of critical values. Each unit is supplied with an ISO 17025 calibration certificate (Ilac MRA), providing full traceability and documentation suitable for internal audits and customer reporting. The combination of fine resolution, documented calibration and workshop protection makes this instrument appropriate for fabrication shops, tube manufacturers and metrology laboratories that require audited measurement evidence.
Request tailored guidance from Metav Werkzeuge for integration, calibration evidence and application advice — contact info@metav-werkzeuge.com or call +49 2822 7131930
Technical Data
- Article number: 110350501
- GTIN: 4061905040542
- Manufacturer: Microtech Metrology
Facts
- Measuring range: 25–50 mm
- Resolution: 0.001 mm
- Accuracy: ±0.003 mm
- IP protection: IP65
Special features
- Digital display with mm/inch, origin and hold
- Friction thimble, rotating spindle
- Aluminium housing
- Custom tube anvil on request
- Calibration: ISO 17025 certificate included (Ilac MRA)
FAQ
Is the micrometer delivered calibrated?
Yes. The Microtech CertiMet TUBE is supplied fully calibrated with an ISO 17025 calibration certificate (Ilac MRA) for immediate use in audited quality processes.
What resolution and accuracy can be expected?
The instrument provides a resolution of 0.001 mm and an accuracy of ±0.003 mm, suitable for demanding production and inspection tasks.
Can this device measure tube wall thickness directly?
Yes. The micrometer is configured for tube wall thickness measurement and covers wall thicknesses from 4.7 mm within the 25–50 mm measuring range.
Is the design suitable for workshop conditions?
The aluminium housing with IP65 protection and a friction thimble offers robust resistance to dust and coolant and ensures reproducible contact force in the workshop.
Are customised anvils available for non‑standard tubes?
Custom tube anvils can be supplied on request to adapt the measuring faces to specific profiles or bore geometries.
Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
