Internal Dial Bore Gauge M208.023 – Analogue 0.01 mm graduation, 50–100 mm range (Metav IndustryLine)

The Internal Dial Bore Gauge M208.023 is an analogue instrument for precise internal diameter checks in workshop and production settings

• Analogue dial with 0.01 mm graduation
• Repeatability 0.005 mm for consistent checks
• Measuring range 50–100 mm with extensions
• Supplied in protective case for transport

Reliable measurement accuracy for production control

The instrument delivers 0.01 mm resolution and a measured repeatability of 0.005 mm, which makes it appropriate for routine inspection and process control where small deviations affect part fit and function. The 50–100 mm nominal range covers common bore sizes, while the included measuring positions extend the usable span to 105 mm. With a measuring depth of 150 mm, the gauge reaches recessed bores without compromising stability. These technical characteristics translate into fewer rejected parts and more consistent batch quality during serial production.

Built for robust handling and straightforward operation

A clear analogue dial and a matt chrome-plated holder provide durability and intuitive readings on the shop floor. The set includes six measuring pins and a series of twelve measuring positions (50–105 mm ±0.7 as supplied) to adapt quickly to varying diameters; the complete kit is delivered in a protective case for safe transport and storage. For operators new to metrology: graduation (0.01 mm) describes the smallest step visible on the dial, while repeatability (0.005 mm) indicates the instrument’s ability to produce the same result under unchanged conditions, which together ensure reproducible checks.

Integrating the gauge into workshop quality routines

The instrument’s analogue design demands minimal maintenance and is compatible with existing manual inspection workflows, making it a pragmatic choice where digital networking is not required. Its modest weight (approx. 1.3 kg) and balanced construction simplify handling over repetitive checks. For procurement and stocking, sourcing from a dedicated supplier in Emmerich ensures reliable supply and consistent quality control across deliveries. The configuration supports fast setup for incoming inspection and in-process control, helping to keep assembly lines running within tolerance.

Contact Metav Werkzeuge in Emmerich to discuss the Internal Dial Bore Gauge M208.023, arrange delivery from our stock and confirm the exact set of measuring pins and extensions required for specific applications — eMail: info@metav-werkzeuge.com | Tel: +49 2822 7131930

Technical Data

• SKU: M208.023
• GTIN: 4061905042294
• Manufacturer: Metav IndustryLine
• Category: Dial gauges
• Weight: 1.3 kg

Core technical data

• Measuring range: 50–100 mm
• Graduation: 0.01 mm
• Repeatability: 0.005 mm
• Measuring depth: 150 mm
• Measuring pins: 6
• Measuring positions included: 12 (50–105 mm ±0.7)

Materials and features

• Holder: matt chrome-plated
• Analogue dial display
• Supplied in protective case
• Extensions/messtaster included
• Designed for internal diameter measurement

FAQ

What measuring range does this instrument cover?
The Internal Dial Bore Gauge M208.023 covers a nominal range of 50–100 mm, with supplied measuring positions extending the set up to 105 mm.

What resolution and repeatability are provided?
The instrument features a graduation of 0.01 mm and a repeatability of 0.005 mm, suitable for precise internal checks and consistent comparative measurements.

Is the gauge suitable for workshop and production use?
Yes; the analogue design, robust holder and protective case make the gauge appropriate for regular use on the shop floor and in production inspection stations.

Which accessories are included with the set?
The delivery contains the base instrument with a matt chrome-plated holder, six measuring pins, a set of twelve measuring positions for diameters from 50 to 105 mm, and a protective case for transport.

Can the gauge reach deep bores?
With a measuring depth of 150 mm, the set is intended for deeper internal checks within the specified measuring range.
