50-180mm Internal Precision Bore Gauge With 5mm Dial, 0.01mm Resolution, Repeatability 0.005mm, Supplied In Case - Metav IndustryLine

Take advantage of a compact instrument that combines a wide 50–180 mm measuring range with a fine 0.01 mm dial resolution to ensure reliable internal dimension checks; the robust matt chrome-plated holder and 0.005 mm repeatability support consistent quality control. Order the internal precision gauge directly via Metav Werkzeuge or consult our specialists for application advice.

Internal precision gauge M208.054 — 50–180 mm range, 0.01 mm dial resolution (Metav IndustryLine)

An Internal precision gauge M208.054 designed for precise measurement of bores, recesses and internal diameters in workshop and quality‑control environments.

• 50–180 mm measuring range
• 0.01 mm dial resolution
• Repeatability 0.005 mm
• Measuring depth 150 mm

Accurate internal measurement for routine inspection

The instrument delivers a clear advantage where internal dimensions must be tracked regularly: the 50–180 mm range covers the typical span for component bores encountered in general machining, while the 0.01 mm analogue dial resolution provides readable increments for controlled adjustments. The compact design combines reach and handling so that measurement tasks remain efficient without sacrificing precision. Built for repeatable checks, this tool supports process stability in production and inspection routines.

Engineered for workshop durability and access

Classified as a Standard range instrument (suitable for everyday machine‑shop and metal‑working tasks), the device features a matt chrome‑plated holder that resists surface wear and eases handling. The measuring depth 150 mm allows access into deeper bores and stepped features, reducing the need for multiple tools. Where space is restricted, the construction minimises bending of the gauge beam so measurements remain reliable across the stated span.

Repeatable results through controlled indicator travel

A 5 mm dial travel on the analogue dial indicator smooths out small variations during adjustment, while the documented repeatability of 0.005 mm reflects the instrument’s ability to reproduce the same reading under repeated conditions. In practical terms, this consistency reduces the influence of operator technique on results and shortens the time spent validating parts during serial inspection. The mechanical readout also offers immediate visual feedback for set‑up and adjustment tasks.

Practical kit and application scope

The instrument is supplied with a comprehensive set of interchangeable measuring pins to match common internal diameters, covering typical increments from 50 to 125 mm, together with pass gauges for reference (0.5 / 1 / 2 / 3 mm). At a net weight of 1.15 kg the tool is substantial enough for stable handling yet light enough for regular bench or bench‑mounted use. Its configuration makes it suitable for workshop quality control, fixture checks and component acceptance tests where precise internal measurement is required.

For dependable internal dimension control choose the Metav IndustryLine M208.054 — contact Metav Werkzeuge in Emmerich for procurement and technical guidance at info@metav-werkzeuge.com or by phone on +49 2822 7131930

Technical data

• Article number: M208.054
• GTIN: 4061905042515
• Manufacturer: Metav IndustryLine

Facts

• Measuring range: 50–180 mm
• Minimum range: 50 mm
• Maximum range: 180 mm
• Resolution: 0.01 mm
• Repeatability: 0.005 mm
• Dial travel: 5 mm
• Measuring depth: 150 mm
• Weight: 1.15 kg
• Analogue indicator

Special features

• Matt chrome-plated device holder
• 16 interchangeable measuring pins covering common increments
• Pass gauges included: 0.5 / 1 / 2 / 3 mm
• Standard range instrument for workshop quality control

FAQ

What measuring range does the instrument cover?
The internal precision gauge covers a measuring range of 50–180 mm, suitable for many internal diameter checks in general machine work.

How fine is the reading and how repeatable are the measurements?
The dial indicator reads 0.01 mm increments and the instrument demonstrates a repeatability of 0.005 mm, supporting reliable repeated checks.

Which feature helps when measuring deeper bores?
A measuring depth of 150 mm provides access to deeper internal features; the matt chrome‑plated holder maintains rigidity during extended reach measurements.

What accessories are supplied for different diameters?
The instrument includes a set of interchangeable measuring pins covering common increments from 50 to 125 mm and pass gauges of 0.5 / 1 / 2 / 3 mm for reference.

Is this instrument suitable for standard workshop quality control?
Yes; designed as a standard‑range internal measuring instrument, the M208.054 is intended for everyday use in machine shops and quality inspection benches.
