25mm Digital Thickness Gauge With Interchangeable Tips Spring-Opening, 0.01mm Readout, Plastic Case - Metav IndustryLine

Take advantage of precise, workshop-ready measurement: the small footprint and 0.01 mm resolution deliver repeatable thickness checks, while interchangeable measuring tips expand applicability across components. Order the gauge via Metav Werkzeuge or consult our specialists for application advice.

Digital thickness gauge M209.274 – 0–25 mm, 0.01 mm resolution (Metav IndustryLine)

The Digital thickness gauge M209.274 is a compact digital probe designed for precise thickness and wall‑thickness measurement in workshop and inspection environments

• 0.01 mm resolution for fine thickness checks
• Interchangeable measuring tips for varied tasks
• mm/inch display with On/Zero, Off and Hold keys
• Spring‑opening probe suited to pipe wall inspections

Reliable precision for routine quality checks

The instrument offers 0.01 mm resolution combined with a stated accuracy of ±0.05 mm, which makes it suitable for routine quality control and maintenance tasks where repeatable results are required. The fine display increment reduces reading ambiguity and supports fast pass/fail decisions on the workshop floor. Built around a compact digital probe, the device balances sensitivity with robustness so that small components and thin sheets can be assessed without complex setup. This level of precision is frequently sufficient for general engineering tolerances and for incoming inspection where clear, comparable readings are needed.

Adaptability through interchangeable tips and probe geometry

Interchangeable measuring tips extend the gauge’s usefulness across a range of surfaces and geometries: flat faces, recessed areas and edges can be accommodated simply by changing the tip. The probe tip length of 36 mm allows access into tighter bores, and the instrument is specifically suitable for pipe wall thickness measurement from an inner diameter of 10 mm. The spring‑opening action ensures consistent contact pressure during repeated measurements, which reduces operator‑induced scatter and increases reproducibility when inspecting series parts or assemblies.

Practical display functions and ergonomic handling

The digital readout includes mm/inch conversion, an On/Zero function for relative measurements, a power Off control and a Hold key for frozen readings — features that speed up documentation and bench work. At about 0.7 kg, the tool feels substantial without compromising mobility, making it straightforward to handle during spot checks or when transferring between workstations. The combination of a clear display, simple controls and a compact form factor supports efficient measurement routines and reduces time spent on manual transcription.

For reliable thickness and wall‑thickness inspection, choose the Metav IndustryLine digital thickness gauge M209.274 from Metav Werkzeuge; for product selection and application guidance contact Metav Werkzeuge directly via info@metav-werkzeuge.com or by phone on +49 2822 7131930

Technical data

• Article number: M209.274
• GTIN: 4054469184487
• Brand: Metav IndustryLine
• Digital display: yes

Facts

• Measuring range: 0–25 mm
• Resolution/readout: 0.01 mm
• Accuracy: ±0.05 mm
• Probe tip length: 36 mm
• Weight: 0.7 kg

Special features

• Interchangeable measuring tips
• Spring‑opening probe mechanism
• mm/inch display with On/Zero, Off and Hold functions
• Suitable for pipe wall thickness measurement from inner Ø 10 mm

FAQ

What measuring range does the gauge cover?
The M209.274 covers a measuring range of 0–25 mm, suitable for small components and thin walls.

What resolution and accuracy can be expected?
Resolution is 0.01 mm with an accuracy specified as ±0.05 mm, providing clear incremental readings for workshop control.

Can pipe wall thickness be measured with this probe?
Yes, the gauge is suitable for pipe wall thickness measurement from an inner diameter of 10 mm when used with the appropriate measuring tip.

Are the measuring tips interchangeable for different tasks?
Interchangeable measuring tips are supported, enabling adaptation to varied surface geometries and recessed areas.

Which display functions are available for documentation?
The device offers mm/inch conversion, On/Zero for relative measures, Off and Hold for frozen readings, which simplify recording and inspection workflows.
