50mm Digital Inclinometer 0.1° Resolution, Aluminium Housing With Permanent Magnet, IP54 - Metav IndustryLine

Benefit from precise angle measurements, a compact 50 mm contact face and a robust IP54 aluminium housing with a permanent magnet — ideal for repeatable alignment tasks. Order the Metav IndustryLine inclinometer directly via Metav Werkzeuge or consult our specialists for application advice.

Digital inclinometer M215.207 — 50 mm contact face, 0.1° resolution, IP54 aluminium housing (Metav IndustryLine)

A compact Digital inclinometer M215.207 for fast angle checks and machine set‑up across four 90° ranges, designed for workshop and maintenance use.

• High‑resolution 0.1° digital display
• Robust IP54 aluminium housing
• Integrated permanent magnet mounting
• Quick ABS/ZERO and HOLD functions

Faster, traceable angle checks with industrial accuracy

The compact inclinometer delivers a 0.1° resolution and defined accuracy bands — ±0.2° up to 15° and ±0.5° from 15° to 90° — enabling reliable decisions during alignment and inspection. The four 90° segments (4 × 90°) give effective coverage for most fixturing and machine‑tool positions without complicated reorientation. These measurable parameters reduce setup time and increase the reproducibility of correction steps, making the tool suitable for routine quality checks and maintenance cycles.

Workshop‑proof mounting and protection for everyday use

Built around an aluminium housing with an integrated permanent magnet, the instrument fastens securely to steel surfaces for hands‑free operation, improving safety and consistency in measurements. Rated IP54, the construction resists dust ingress and splash water, so occasional exposure in a busy shop does not compromise function. The lightweight design (approx. 0.2 kg) and compact footprint support use on portable jigs as well as fixed machinery, offering a practical balance between durability and manoeuvrability.

Clear controls and efficient inspection workflow

The digital display is operated via straightforward keys (ON/OFF, HOLD, ABS/ZERO), simplifying zeroing on angled references and freezing readouts for transfer to check sheets. The readable numeric output expedites handover between setup and production, while the short‑cycle operation lowers downtime during repetitive adjustments. Supplied as a Metav IndustryLine product, the gauge complements modular tool sets for workshops aiming to standardise measurement routines and maintain consistent process quality.

Contact Metav Werkzeuge to obtain the Metav IndustryLine M215.207 for robust workshop alignment or to request tailored application advice from our consultants in Emmerich

Technical data

• SKU: M215.207
• GTIN: 4054469109961
• Tariff number: 90318080
• Category: Angle measuring instruments

Core data

• Measurement range: 4 x 90°
• Resolution: 0.1°
• Accuracy: ±0.2° (≤15°); ±0.5° (15°–90°)
• Dimensions: 50 x 51 x 33 mm
• Weight: 0.2 kg
• Protection class: IP54
• eCl@ss: 21170321

Features

• Frame material: aluminium
• Special feature: permanent magnet
• Display: digital with ON/OFF, HOLD and ABS/ZERO keys
• Digital device: yes
• Story trigger / application hint: angle

FAQ

What level of precision can be expected from this inclinometer?
The inclinometer achieves a resolution of 0.1° with specified accuracies of ±0.2° up to 15° and ±0.5° from 15°–90°, making it suitable for workshop alignment and routine inspection tasks using the Metav IndustryLine M215.207.

Can the device be mounted on machine surfaces?
Yes, the instrument includes an integrated permanent magnet that secures the unit to ferrous machine parts and fixtures for hands‑free measurements.

Is the inclinometer suitable for use in a production environment with occasional splashes?
The device has an IP54 rating, providing protection against dust and splashing water, so it is appropriate for standard shopfloor conditions but not for immersion.

What is the effective measurement coverage of the gauge?
The measurement range is organised in four 90° segments (4 × 90°), providing practical coverage for most alignment and tilt checks without complex reorientation.

Which controls are available for zeroing and holding readings?
The digital display offers ON/OFF, HOLD and ABS/ZERO functions to freeze measurements and set reference zero points quickly during setup.

Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
