4x90° Digital Inclinometer 36x36mm Plastic Housing, Rechargeable Battery, Hold/Abs-Rel Display - Metav IndustryLine

Take advantage of precise, repeatable angle checks thanks to the combination of a 0.05° display resolution and a compact magnetic base for hands‑free alignment. Order the instrument directly via Metav Werkzeuge or consult our product advisors for application guidance.

Digital Inclinometer M215.215 — compact 4 x 90° inclinometer with magnetic base

The Digital Inclinometer M215.215 is a compact digital tilt gauge designed for quick, repeatable angle checks and alignment tasks across workshop, maintenance and assembly applications.

• Compact 36 x 36 mm magnetic housing
• Rechargeable lithium battery included
• 0.05° resolution, 0.2° accuracy
• HOLD and ABS/REL display functions

Fast, reliable angle checks on the shop floor

The instrument offers a display resolution of 0.05° combined with a stated accuracy of 0.2°, which supports precise alignment tasks during machine set‑up and routine maintenance. The digital readout includes HOLD and ABS/REL modes, enabling fixed readings and relative angle comparisons without additional calculation. For production environments where repeatability matters, the clear numerical feedback reduces interpretation errors and shortens inspection cycles, improving overall process efficiency.

Compact magnetic housing for hands‑free alignment

Housed in a 36 x 36 x 20 mm plastic casing and equipped with a permanent magnetic base, the device secures to ferrous surfaces for stable, hands‑free measurements. At just 0.2 kg it is easy to position in confined spaces and on machine beds, while the robust design maintains consistent contact during setup work. This makes the instrument particularly suitable for alignment of chucks, fixtures and small assemblies where access is limited and reliable support is essential.

Low running costs and practical features for daily use

Power is provided by a rechargeable lithium battery (3.7 V) supplied with a charging cable, eliminating frequent battery replacements and reducing consumables. An automatic shut‑off after approximately 3 minutes helps conserve charge between intermittent checks. The compact instrument supports four 90° measurement ranges for practical orientation checks across multiple planes. For further technical details or application advice, Metav Werkzeuge provides specialist support and documentation to ensure the instrument meets specific workshop requirements.

Contact Metav Werkzeuge for tailored advice or to request a supply proposal for the Metav IndustryLine Digital Inclinometer M215.215 — reach our specialists in Emmerich by phone or email

Technical data

• Article number: M215.215
• GTIN: 4054469182483
• Manufacturer: Metav IndustryLine
• Material: Plastic
• Housing dimensions: 36 x 36 x 20 mm
• Weight: 0.2 kg
• Measuring range: 4 x 90°

Numbers / Core technical data

• Resolution: 0.05°
• Accuracy: 0.2°
• Battery: Rechargeable lithium 3.7 V
• Charge accessory: Charging cable included
• Auto shut‑off: ~3 minutes

Special features / Versions

• Digital display with HOLD and ABS/REL functions
• Permanent magnetic base for hands‑free use
• Plastic housing for compactness and light weight
• Shows orientation correctly in any mounting position
• Compact design for confined spaces

FAQ

What is the measurement range of the inclinometer?
The instrument measures across a 4 x 90° range, enabling orientation checks in four quadrant positions for comprehensive angle assessment.

How precise is the readout on the display?
The device provides a 0.05° display resolution with a declared accuracy of 0.2°, suitable for routine alignment and workshop checks.

Is the unit ready to use out of the box?
The inclinometer is supplied with a rechargeable lithium battery (3.7 V) and a charging cable, allowing immediate use after charging.

Can the instrument be fixed to a machine for hands‑free operation?
Yes, a permanent magnetic base secures the unit to ferrous surfaces for stable, hands‑free alignment tasks.

Which display functions assist with comparative measurements?
Integrated ABS/REL and HOLD modes permit relative angle comparisons and the capture of readings for repeatable checks.

Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
