50mm Digital Twist Drill Caliper 118° Cut Angle, 3V Power, Data Output RB5, Stainless Hardened Body, Supplied in Case - Metav IndustryLine

Benefit from a combination of precise digital measurement, a compact 50 mm measuring range and a hardened stainless-steel build for dependable workshop performance; order directly via Metav Werkzeuge or ask our consultants if needed.

Digital Twist‑Drill Caliper M240.145 — 50 mm range, 118° twist‑drill measurement (Metav IndustryLine)

The Digital Twist‑Drill Caliper M240.145 is a dedicated digital caliper for measuring the cutting length and geometry of twist drills with 118° (and compatible 130°) point angles, designed for toolrooms and routine quality checks

• Compact 50 mm measuring range for fine tool measurement
• Hardened stainless‑steel construction with metal housing
• Digital display with ON/OFF, ZERO, UNIT and HOLD keys
• RB 5 data output for process integration

Precise, compact measurement that speeds up quality checks

Built for tasks where repeatable small‑length measurements matter, this instrument combines a 50 mm measuring range with a robust hardened stainless‑steel frame to deliver steady results on short cutting edges. The compact design reduces lever‑action and twist on the jaws, improving reproducibility during repeated checks. The result is faster inspection cycles and fewer rejects in batch tool production, while the moderate weight (approx. 0.4 kg) eases handling in a busy metrology bench.

Accurate digital readout and simple operation for reliable data

The integrated digital display provides direct numerical readout and the usual control keys (ON/OFF, ZERO, UNIT, HOLD) for straightforward operation and rapid transfer of results into documentation. The measuring electronics run from a 3 V supply and the instrument features an RB 5 data output to connect to data loggers or a PC, reducing transcription errors and enabling faster reporting in quality assurance workflows. This combination supports measurable process improvements and traceable records.

Designed specifically for twist‑drill inspection and workshop use

Engineered to assess the cutting length of twist drills, the gauge is suited to toolshops, maintenance departments and production quality control where angle and edge length must be checked quickly. The metal housing protects the electronics in daily use, while hardened measuring faces resist wear, maintaining performance over time. Delivery includes a protective case for transport and storage to keep the instrument ready for on‑bench use.

Practical partner for routine inspection and integration

The caliper is classified in the micro range of workshop calipers, offering the ideal balance of reach and rigidity for small‑part metrology. Integration via the RB 5 interface streamlines data capture and supports digital traceability in production documentation. As part of Metav IndustryLine, the instrument benefits from a supplier network that emphasises consistent availability and a transparent supply chain, supporting uninterrupted inspection routines in industrial and craft environments.

For RB 5 connectivity and compact precision from Metav IndustryLine, contact Metav Werkzeuge for ordering and application advice — eMail: info@metav-werkzeuge.com or Tel: +49 2822 7131930

Technical data

• Article number: M240.145
• GTIN: 4054469168951
• Brand: Metav IndustryLine
• Category: Twist‑drill caliper / digital caliper

Facts

• Measuring range: 0–50 mm
• Weight: 0.4 kg
• Power supply: 3 V
• Customs tariff number: 90173000

Special features

• Material: hardened stainless steel, metal housing
• Digital display with ON/OFF, ZERO, UNIT, HOLD
• Data output: RB 5
• Suitable for twist drills with 118° (compatible with 130°) point angles
• Delivered in a protective plastic/wooden case

FAQ

How does the interface transfer measurement data?
The caliper uses an RB 5 data output for wired transfer to data loggers or PC systems, allowing direct capture of results from the device M240.145 into inspection software.

What resolution and readout behaviour can be expected?
The instrument features a standard digital readout suitable for workshop control; typical digital caliper resolution is 0.01 mm, and the display functions (ZERO, UNIT, HOLD) assist repeatable documentation.

Is the caliper suitable for measuring drill cutting length only?
No, the tool is intended primarily for twist‑drill cutting‑length and point geometry checks but can also be used for other small internal, external and step measurements within the 0–50 mm range.

What protects the electronics and measuring faces during daily use?
A metal housing shields the electronics and hardened measuring faces resist wear; the protective case supplied supports safe transport and storage between uses.

Which environments and users benefit most from this instrument?
The device is ideal for toolrooms, production quality control and maintenance workshops where compact, repeatable drill‑bit measurements and digital data output improve inspection efficiency.

Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
