80-95mm Three-Point External Measuring Micrometer 0.01mm Readout Carbide Faces, Ratchet, Case - Metav IndustryLine

Combine the 3‑point measuring head, carbide measuring faces and a tactile ratchet stop to secure repeatable external measurements across prism‑shaped workpieces; order the instrument directly via Metav Werkzeuge or consult our specialists for application advice.

3‑point outside micrometer M309.026 — 80–95 mm, 0.01 mm graduation (Metav IndustryLine)

The 3‑point outside micrometer M309.026 is a purpose‑built precision instrument for fast, reliable external measurements of triangular and prism‑shaped components in fine mechanical and toolmaking settings.

• 3‑point measuring head for prism-shaped parts
• Measuring range 80–95 mm
• Graduation 0.01 mm for fine readings
• Carbide measuring faces with ratchet stop

Precision where geometry matters

This micrometer delivers consistent contact with prism‑shaped profiles thanks to its 3‑point measuring head, which seats reliably on three flank surfaces to avoid tilt and eccentricity during measurement. The instrument offers a reading of 0.01 mm and a stated accuracy of 0.008 mm, making it suitable where sub‑0.01 mm stability improves process control. The presence of carbide measuring faces increases wear resistance and keeps contact geometry stable over long production runs, which reduces the need for early rework and supports reproducible quality checks.

Built for reproducible, shop‑floor use

A tactile ratchet stop ensures constant measuring force, reducing operator‑induced variance and improving repeatability across successive checks. The frame is finished in a durable paint and the measuring sleeve is matt‑chrome plated, which limits glare and provides a corrosion‑resistant surface for the engraved scale. A setting gauge of 80 mm is provided for zero verification and straightforward routine checks. Delivered in a protective case, the instrument is ready for safe storage and transport between inspection points without risking damage to the precision faces.

Compact range, versatile application

With its 80–95 mm span the gauge falls into the compact measurement class ideal for fine mechanical work: it combines short, torsion‑resistant anvils with enough reach for many toolroom components. The design is particularly well suited to measuring three‑ or five‑sided workpieces commonly encountered in gear blanks, broached profiles and small fixtures. This balance of geometry, wear‑resistant faces and mechanical reliability makes the instrument a practical choice for small to medium series production, inspection benches and jigs where accurate external dimension control is required.

Contact Metav Werkzeuge today to request the Metav IndustryLine M309.026 and discuss how its carbide faces and ratchet stop can improve measurement repeatability in your production process

Technical Data

• Article number: M309.026
• GTIN: 4054469117614
• Tariff code: 90173000

Facts

• Measuring range: 80–95 mm
• Graduation / reading: 0.01 mm
• Accuracy: 0.008 mm
• Setting gauge: 80 mm
• Type: Analog / mechanical

Special features

• Carbide measuring faces
• Ratchet stop for constant measuring force
• Painted frame; matt‑chrome measuring sleeve
• Delivered in protective case
• Suitable for triangular / prism workpieces

FAQ

How does a 3‑point measuring head improve results?
A 3‑point measuring head centres on three flanks of a prism‑shaped workpiece, reducing tilt and eccentricity; the Metav IndustryLine M309.026 uses this principle to ensure the contact geometry is repeatable for reliable external measurements.

What reading resolution and accuracy can be expected?
The instrument provides a reading of 0.01 mm with a stated accuracy of 0.008 mm, which supports fine inspection tasks and tighter quality tolerances on small components.

Is the micrometer suitable for shop‑floor use?
Yes. The matt‑chrome sleeve, painted frame and carbide measuring faces combine robustness with low maintenance, and the ratchet stop reduces user variability during repeated measurements.

Is the gauge supplied ready for transport and storage?
The micrometer is delivered in a protective case for safe storage and transportation between inspection stations.

Which parts is this micrometer intended for?
The tool is optimised for triangular and prism‑shaped parts such as broached profiles, gear blanks and small fixtures; its compact 80–95 mm range is aimed at fine mechanical and toolroom applications.

Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
